Communication machinery corporation Emulationengine 11a/b/g User manual

v2.3

Communication Machinery Corporation | 402 E. Gutierrez Street | Santa Barbara, CA. 93101

Phone: 1.805.879.1521| Fax: 1.805.564.7188 | Web: www.cmc.com

Communication Machinery Corporation (CMC)

ii 080104

rights reserved. This document may not be reproduced in whole or in part

by any means without the written consent of CMC.

EmulationEngine and vSTA are registered trademarks of Communication

Machinery Corporation.

The web-based user interface uses the GoAhead WebServer: Copyright (c)

Radio Frequency Interference Requirements

802.11a devices transmit in the 5 GHz band. 802.11b and 802.11g

devices transmit in the 2.4 GHz band. FCC regulations require this product

to be used indoors to reduce the potential for interference with (to or

from) other devices that operate in the same frequency range.

FCC Warning

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC rules. These limits

are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses,

and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio

communications. There is no guarantee that interference will not occur in

a particular installation. If this equipment does cause harmful interference

to radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

!" Reorient or relocate the radio /TV receiving antenna.

!" Increase the separation between the equipment and the radio/TV receiver.

!" Connect the equipment to an outlet that is on a different circuit from

where the radio/TV receiver is connected.

!" Consult the dealer or an experienced radio/TV technician for help.

Unless expressly approved by CMC, modifications to this product could

void the user's authority to operate the equipment.

RF Exposure Requirements

To ensure compliance with FCC RF exposure requirements, the antenna

used for this device must be installed to provide a separation distance of

at least 20 cm from all persons and must not be co-located or operating in

conjunction with any other antenna or radio transmitter. Installers and

end-users must follow the installation instructions provided in this guide.

EmulationEngine 11a/b/g User's Guide

080104 iii

TABLE OF CONTENTS

CHAPTER 1:

CHAPTER 1:CHAPTER 1:

CHAPTER 1: Overview

OverviewOverview

Overview ................................

................................................................

..................................

....

..1

---1

Packaging Checklist ................................................................................... 1-1

Feature List .............................................................................................. 1-2

Files......................................................................................................... 1-3

System Requirements................................................................................ 1-3

Hardware Characteristics............................................................................ 1-4

General Usage Notes ................................................................................. 1-4

CHAPTER 2:

CHAPTER 2:CHAPTER 2:

CHAPTER 2: Connectors, LEDs & Antennas

Connectors, LEDs & AntennasConnectors, LEDs & Antennas

Connectors, LEDs & Antennas................................

................................................................

.............................................................

..........................................................

.............................2

---1

Front Panel/LEDs....................................................................................... 2-1

Back Panel................................................................................................ 2-2

Connectors............................................................................................ 2-2

Antennas............................................................................................... 2-2

Reset Button.......................................................................................... 2-2

CHAPTER 3:

CHAPTER 3:CHAPTER 3:

CHAPTER 3: Installation

InstallationInstallation

Installation................................

................................................................

.................................

...3

---1

Connecting Directly to a Command PC ......................................................... 3-1

Connecting Through an Ethernet Hub/Switch ................................................ 3-1

Connecting to the Serial Port (Optional) ....................................................... 3-1

CHAPTER 4:

CHAPTER 4:CHAPTER 4:

CHAPTER 4: Initial Setup

Initial SetupInitial Setup

Initial Setup................................

................................................................

...............................................................

..............................................................

...............................4

---1

For an Ethernet Port Connection.................................................................. 4-1

For a Serial Port Connection........................................................................ 4-3

CHAPTER 5:

CHAPTER 5:CHAPTER 5:

CHAPTER 5: The Web

The WebThe Web

The Web-

---Based User Interface

Based User InterfaceBased User Interface

Based User Interface................................

................................................................

............................................................

........................................................

............................5

---1

System Requirements................................................................................ 5-1

Start-Up/Login.......................................................................................... 5-1

Choosing a Scenario/Test ........................................................................... 5-1

Create New Scenario .............................................................................. 5-3

Open Existing Scenario ........................................................................... 5-4

The Main Page ....................................................................................... 5-4

Creating an Internal Mode/Ping Test......................................................... 5-5

Creating an External Mode Test................................................................ 5-8

Running a Test.......................................................................................... 5-9

About/Using the Main Page........................................................................5-11

Group Control Grid ................................................................................5-14

Load Profile ..........................................................................................5-18

Target Systems.....................................................................................5-18

Load Profile/Monitor Graphs....................................................................5-19

Range Checking/Error Messages..............................................................5-20

Using Load Profiles ................................................................................5-20

vSTA Side Bar..........................................................................................5-22

vSTA->New Group ................................................................................5-22

vSTA->New Group->vSTA...................................................................5-22

vSTA->New Group->Traffic .................................................................5-24

vSTA->New Group->Runtime ..............................................................5-26

vSTA->New Group->On Error..............................................................5-27

vSTA->New Group->Encryption...........................................................5-29

vSTA->Edit Group .................................................................................5-30

vSTA->Delete Group .............................................................................5-31

vSTA->Add New vSTA to Group ..............................................................5-31

EE (EmulationEngine) Side Bar...................................................................5-32

EE->Select SUT ....................................................................................5-33

EE->Join SUT .......................................................................................5-34

EE->Configure EE..................................................................................5-34

EE->Configure EE->UI........................................................................5-34

EE->Configure EE->EE/Basic...............................................................5-36

EE->Configure EE->EE/Radio...............................................................5-38

EE->Configure EE->EE/Power..............................................................5-39

Communication Machinery Corporation (CMC)

iv 080104

EE->Reconnect EE.................................................................................5-41

EE->Reset EE .......................................................................................5-42

EE->Reboot EE .....................................................................................5-42

Monitors Side Bar .....................................................................................5-43

Monitors->New Monitor..........................................................................5-43

Monitors->New Monitor->Predefined ....................................................5-43

Monitors->New Monitor->Summary .....................................................5-44

Monitors->New Monitor->vSTA............................................................5-45

Monitors->Delete Monitor.......................................................................5-47

Monitors->Clear Monitor ........................................................................5-47

Monitors->Export Monitor.......................................................................5-48

Monitors->Config Monitors .....................................................................5-49

Event Log Side Bar ...................................................................................5-50

Event Log->Event Log ...........................................................................5-50

Event Log->Clear Log ............................................................................5-51

Event Log->Export Log ..........................................................................5-52

Event Log->Configure Log......................................................................5-52

Reports Side Bar ......................................................................................5-53

Reports->EE Configuration .....................................................................5-54

Reports->Scenario Summary..................................................................5-54

Reports->Group Summary .....................................................................5-55

Reports->vSTA Master...........................................................................5-56

Reports->vSTA Detail ............................................................................5-57

Reports->Export Reports........................................................................5-57

Configuration Side Bar ..............................................................................5-58

Configuration->Encryption .....................................................................5-58

Configuration->Ping Defaults..................................................................5-59

Configuration->Preferences....................................................................5-60

Menus & Toolbars.....................................................................................5-60

File Toolbar ..........................................................................................5-61

Edit Toolbar..........................................................................................5-61

Scenario Toolbar ...................................................................................5-61

vSTA Toolbar........................................................................................5-61

Reports Toolbar ....................................................................................5-62

Monitor Toolbar.....................................................................................5-62

File Menu .............................................................................................5-64

Edit Menu.............................................................................................5-66

Scenario Menu ......................................................................................5-66

Group Menu..........................................................................................5-67

vSTA Menu...........................................................................................5-68

Reports Menu .......................................................................................5-68

Options Menu .......................................................................................5-69

CHAPTER 6:

CHAPTER 6:CHAPTER 6:

CHAPTER 6: The Command Line Interface (CLI)

The Command Line Interface (CLI)The Command Line Interface (CLI)

The Command Line Interface (CLI)................................

................................................................

....................................................

........................................

....................6

---1

CLI Usage Notes........................................................................................ 6-1

User Log-In .............................................................................................. 6-1

User Log-Off ............................................................................................. 6-2

CLI Commands.......................................................................................... 6-2

System Under Test Commands.................................................................... 6-4

bssid (get/set/clear) ............................................................................... 6-5

get bssid............................................................................................ 6-5

set bssid ............................................................................................ 6-5

clear bssid.......................................................................................... 6-5

bsslist (get)........................................................................................... 6-5

join ...................................................................................................... 6-6

scan ..................................................................................................... 6-6

wirelessmode (get/set) ........................................................................... 6-7

EmulationEngine 11a/b/g User's Guide

080104 v

get wirelessmode ................................................................................ 6-7

set wirelessmode ................................................................................ 6-8

Virtual Station Set-Up & Control Commands ................................................. 6-8

acquireip..............................................................................................6-10

assoc...................................................................................................6-10

auth ....................................................................................................6-10

autoconf...............................................................................................6-11

autorun................................................................................................6-14

conf.....................................................................................................6-15

deauth.................................................................................................6-16

disassoc...............................................................................................6-16

group (clear/del/get/reset/save/set)........................................................6-17

clear group stats................................................................................6-17

del group ..........................................................................................6-17

get group..........................................................................................6-17

reset group .......................................................................................6-19

save group stats ................................................................................6-19

save group summary..........................................................................6-19

set group ..........................................................................................6-19

halt .....................................................................................................6-21

init ......................................................................................................6-22

releaseip ..............................................................................................6-22

run......................................................................................................6-22

vsta (clear/del/get/reset/save/set)..........................................................6-23

clear vsta stats ..................................................................................6-23

del vsta.............................................................................................6-23

get vsta ............................................................................................6-23

reset vsta..........................................................................................6-27

save vsta stats...................................................................................6-28

save vsta all summary........................................................................6-28

set vsta.............................................................................................6-28

Statistics File Commands...........................................................................6-31

Delete Statistics File ..............................................................................6-31

del statfile group................................................................................6-31

del statfile vsta ..................................................................................6-31

del summfile group.............................................................................6-31

del summfile vsta all...........................................................................6-31

Get/Display Statistics File.......................................................................6-31

get statfile group................................................................................6-31

get statfile vsta..................................................................................6-32

get summfile group ............................................................................6-32

get summfile vsta all ..........................................................................6-32

Event Log Commands ...............................................................................6-32

Clear Event Log.....................................................................................6-32

clear evlog buffer ...............................................................................6-32

clear evlog file ...................................................................................6-32

Get/Display Event Log ...........................................................................6-33

get evlog buffer .................................................................................6-33

get evlog file......................................................................................6-33

get evlog settings...............................................................................6-34

Save Event Log (save evlog)...................................................................6-34

Set Event Log Controls...........................................................................6-34

set evlog...........................................................................................6-34

set evlog console................................................................................6-34

set evlog file......................................................................................6-34

set evlog level ...................................................................................6-35

Communication Machinery Corporation (CMC)

vi 080104

set evlog module................................................................................6-35

EmulationEngine Commands......................................................................6-35

association (get) ...................................................................................6-37

channel (get)........................................................................................6-37

config (get) ..........................................................................................6-37

countrycode (get/set) ............................................................................6-38

get countrycode .................................................................................6-38

set countrycode .................................................................................6-38

date (set).............................................................................................6-38

eemac (get/reset/set)............................................................................6-38

get eemac.........................................................................................6-39

reset eemac ......................................................................................6-39

set eemac .........................................................................................6-39

eemask (get/set) ..................................................................................6-39

get eemask .......................................................................................6-39

set eemask........................................................................................6-40

eestatus (get).......................................................................................6-40

exec ....................................................................................................6-40

factorydefault (set)................................................................................6-40

features (get/set)..................................................................................6-41

get features.......................................................................................6-41

set features.......................................................................................6-41

frequency (get).....................................................................................6-41

ftp.......................................................................................................6-42

gateway (get/set) .................................................................................6-42

get gateway ......................................................................................6-42

set gateway.......................................................................................6-43

hardware (get) .....................................................................................6-43

help.....................................................................................................6-43

history.................................................................................................6-43

hwtxretries (get/set) .............................................................................6-43

get hwtxretries ..................................................................................6-43

set hwtxretries...................................................................................6-44

ipaddr (get/set) ....................................................................................6-44

get ipaddr .........................................................................................6-44

set ipaddr..........................................................................................6-44

ipmask (get/set) ...................................................................................6-44

get ipmask ........................................................................................6-44

set ipmask ........................................................................................6-44

key (del/get/set)...................................................................................6-44

del key..............................................................................................6-44

get key .............................................................................................6-45

set key .............................................................................................6-45

keyentrymethod (get/set) ......................................................................6-45

get keyentrymethod ...........................................................................6-45

set keyentrymethod............................................................................6-45

get login ...........................................................................................6-45

set login............................................................................................6-46

password (set)......................................................................................6-46

ping.....................................................................................................6-46

pmmode (get/set).................................................................................6-46

get pmmode......................................................................................6-46

set pmmode ......................................................................................6-47

power (get/set).....................................................................................6-47

get power..........................................................................................6-47

EmulationEngine 11a/b/g User's Guide

080104 vii

set power..........................................................................................6-47

psinterval (get/set) ...............................................................................6-48

get psinterval ....................................................................................6-48

set psinterval.....................................................................................6-48

quit .....................................................................................................6-48

rate (get/set)........................................................................................6-48

get rate.............................................................................................6-48

set rate.............................................................................................6-49

reboot..................................................................................................6-49

sntpserver (get/set/clear) ......................................................................6-49

clear sntpserver .................................................................................6-49

get sntpserver ...................................................................................6-49

set sntpserver....................................................................................6-50

station (get) .........................................................................................6-50

systemname (clear/get/set) ...................................................................6-50

clear systemname ..............................................................................6-50

get systemname ................................................................................6-50

set systemname.................................................................................6-50

telnet (get/set) .....................................................................................6-50

get telnet ..........................................................................................6-50

set telnet ..........................................................................................6-50

time (set).............................................................................................6-51

timeofday.............................................................................................6-51

tzone (get/set) .....................................................................................6-51

get tzone ..........................................................................................6-51

set tzone...........................................................................................6-51

uptime (get).........................................................................................6-51

version (get) ........................................................................................6-51

802.11b/g Commands...............................................................................6-52

basic11b (get/set).................................................................................6-52

get basic11b (11b only) ......................................................................6-52

set basic11b (11b only).......................................................................6-52

ctsmode (get/set) .................................................................................6-53

get ctsmode (11g only).......................................................................6-53

set ctsmode (11g only).......................................................................6-53

ctsrate (get/set)....................................................................................6-53

get ctsrate (11g only).........................................................................6-53

set ctsrate (11g only) .........................................................................6-53

ctstype (get/set)...................................................................................6-53

get ctstype (11g only) ........................................................................6-53

set ctstype (11g only).........................................................................6-54

shortpreamble (get/set).........................................................................6-54

get shortpreamble (11b/11g)...............................................................6-54

set shortpreamble (11b/11g)...............................................................6-54

shortslottime (get/set)...........................................................................6-54

get shortslottime (11g only) ................................................................6-54

set shortslottime (11g only) ................................................................6-54

Administrative Mode Commands.................................................................6-55

admin (clear)........................................................................................6-55

basic11g (get/set).................................................................................6-56

get basic11g (11g only) ......................................................................6-56

set basic11g (11g only).......................................................................6-56

boot ....................................................................................................6-56

bootrom...............................................................................................6-57

calibration (get/set)...............................................................................6-57

get calibration....................................................................................6-57

Communication Machinery Corporation (CMC)

viii 080104

set calibration....................................................................................6-57

cp .......................................................................................................6-57

format .................................................................................................6-57

hostipaddr (get/set) ..............................................................................6-57

get hostipaddr ...................................................................................6-57

set hostipaddr....................................................................................6-57

ls ........................................................................................................6-58

mv ......................................................................................................6-58

regulatorydomain (set) ..........................................................................6-58

rm.......................................................................................................6-58

trace....................................................................................................6-58

watchdog (get/set)................................................................................6-59

get watchdog.....................................................................................6-59

set watchdog.....................................................................................6-59

Example Configurations.............................................................................6-59

Example First Time Configuration............................................................6-59

Example Security Configuration...............................................................6-60

Changing the EmulationEngine IP Address................................................6-61

CLI Editor................................................................................................6-64

Movement & Search Commands..............................................................6-65

Insert Commands..................................................................................6-65

Editing Commands ................................................................................6-66

Special Commands................................................................................6-66

CHAPTER 7:

CHAPTER 7:CHAPTER 7:

CHAPTER 7: The Programming Interface (Perl)

The Programming Interface (Perl)The Programming Interface (Perl)

The Programming Interface (Perl)................................

................................................................

.......................................................

..............................................

.......................7

---1

CHAPTER 8:

CHAPTER 8:CHAPTER 8:

CHAPTER 8: Event Logging

Event LoggingEvent Logging

Event Logging ................................

................................................................

..........................................................

....................................................

..........................8

---1

Overview.................................................................................................. 8-1

Event Record Format ................................................................................. 8-1

CLI Commands.......................................................................................... 8-2

The Web-Based User Interface.................................................................... 8-2

CHAPTER 9:

CHAPTER 9:CHAPTER 9:

CHAPTER 9: Statistics Counters

Statistics CountersStatistics Counters

Statistics Counters ................................

................................................................

..................................................

....................................

..................9

---1

Individual Virtual Station Counters .............................................................. 9-1

Individual Virtual Station 802.11 Management Counters ............................. 9-1

Individual Virtual Station Signal Quality Indication...................................... 9-1

Individual Virtual Station Frame Counts .................................................... 9-1

Individual Virtual Station Ping Statistics .................................................... 9-2

Individual Virtual Station Error Statistics ................................................... 9-2

Summary Statistics.................................................................................... 9-3

Summary Signal Counters....................................................................... 9-3

Summary Transmit Statistics................................................................... 9-3

Summary Receive Statistics..................................................................... 9-4

Summary Error Statistics ........................................................................ 9-5

CHAPTER 10:

CHAPTER 10:CHAPTER 10:

CHAPTER 10: Troubleshooting

TroubleshootingTroubleshooting

Troubleshooting ................................

................................................................

...............................................

..............................

...............10

1010

10-

---1

Using a Third-Party Load Generator ............................................................10-1

Web-Based User Interface Start-Up Error ....................................................10-1

Web-Based User Interface Login Error.........................................................10-2

Hardware Installation/LEDs........................................................................10-2

EmulationEngine Busy or Not Responding....................................................10-3

Loading Files from the Command PC...........................................................10-4

Missing Key File........................................................................................10-4

Configuration Records...............................................................................10-6

APPENDIX A:

APPENDIX A:APPENDIX A:

APPENDIX A: Specifications

SpecificationsSpecifications

Specifications................................

................................................................

...........................................................

......................................................

...........................A

A-

---1

Hardware ................................................................................................. A-1

Software .................................................................................................. A-2

Performance ............................................................................................. A-3

EmulationEngine 11a/b/g User's Guide

080104 ix

APPENDIX B:

APPENDIX B:APPENDIX B:

APPENDIX B: Software Upgrades

Software UpgradesSoftware Upgrades

Software Upgrades................................

................................................................

.................................................

..................................

.................B

B-

---1

APPENDIX C:

APPENDIX C:APPENDIX C:

APPENDIX C: C

Cable Pin Assignments

able Pin Assignmentsable Pin Assignments

able Pin Assignments................................

................................................................

..........................................

....................

..........C

C-

---1

Standard Ethernet Cable ............................................................................ C-1

Ethernet Cross-Over Cable ......................................................................... C-1

RJ-45 Connector........................................................................................ C-1

Serial Cable .............................................................................................. C-1

APPENDIX D:

APPENDIX D:APPENDIX D:

APPENDIX D: Error and Status Messages

Error and Status MessagesError and Status Messages

Error and Status Messages................................

................................................................

...................................

......

... D

D-

---1

EmulationEngine or Virtual Station Control Messages .....................................D-1

MAC Layer Management Messages...............................................................D-1

Standard 802.11 WLAN Reason Codes .........................................................D-2

Standard 802.11 WLAN Status Codes...........................................................D-2

Communication Machinery Corporation (CMC)

x 080104

EmulationEngine 11a/b/g User's Guide

080104 1-1

CHAPTER 1: Overview

The EmulationEngine is a test and measurement device that emulates up

to 64 wireless stations in an IEEE 802.11 wireless LAN environment. The

EmulationEngine operates in accordance with the IEEE 802.11a, 802.11b,

and 802.11g specifications. The EmulationEngine is offered in three

configurations:

!" EmulationEngine 11a: Supports IEEE 802.11a only.

!" EmulationEngine 11b: Supports IEEE 802.11b only.

!" EmulationEngine 11a/b/g: Supports IEEE 802.11a, 802.11b, and 802.11g.

Each configuration is shipped with a unique feature key that is stored in

the EmulationEngine’s flash file system. The EmulationEngine software is

locked to its specific hardware platform and feature set through the use of

this feature key. Feature keys can be upgraded at any time to provide

access to additional features.

The objective of the EmulationEngine is to reduce the number of PC and

station NIC cards that are needed to test and stage 802.11 products and

wireless LANs in terms of packet performance and number-of-stations

capacity. In addition, it allows a user to fine-tune system parameters in

order to maximize performance during testing. The primary difference

between the EmulationEngine and other IP Load Generators is:

!" IP-based Load Generators are per-station devices that do not reduce the

number of PCs and station NIC cards. You can only configure an IP per

station and then send traffic.

!" The EmulationEngine allows all stations to be emulated on a single

platform and radio chipset thus reducing the cost and complexity of

multiple PCs.

CMC's EmulationEngine creates Virtual Stations (vSTAs) and generates or

passes traffic that will load and stress test a Wireless LAN and 802.11

products in terms of:

!" Frame performance

!" Number-of-stations capacity

!" Scalability

!" WLAN optimization

Because a single physical 802.11a/b/g emulator emulates multiple STAs,

it reduces the number of PC and station NIC cards that are needed to test

and stage 802.11 products and wireless LANs.

Packaging Checklist

Your shipping container should include the following items:

!" EmulationEngine

!" Power Adapter

!" Crossover cable

!" Serial Cable

!" Quick Start Guide

!" Specifications

Communication Machinery Corporation (CMC)

1-2 080104

!" Release Notes

!" Warranty Card

!" End User License Agreement

!" Installation CD-ROM which includes this User's Guide, the

EmulationEngine Test Setup & Configuration Guide, and the Perl SDK.

If any of these items are not included in your shipping container, contact

CMC.

Feature List

!" Supports IEEE 802.11a, 802.11b, and 802.11g

!" Emulates up to 64 concurrent virtual stations (vSTAs)

!" Interaction with virtual stations in real time

!" Configuration and monitoring of virtual stations

!" Internally inject load into a System Under Test (SUT)

!" Externally forward load from third-party traffic generator into a System

Under Test

!" For external mode, frames can be captured based on the source 802.3

MAC address (Layer 2) or the source IP address (Layer 3).

!" Log and performance statistics data

!" vSTA support: 802.11 Authentication, Association, De-authentication,

Disassociation

!" ICMP Echo Request/Reply (Ping)

!" WEP Encryption (Shared static key for authentication and data) per vSTA

!" Persistent connection to the System Under Test

!" DHCP Client: vSTAs can have IP addresses dynamically assigned from a

DHCP server on the network rather than a fixed, configured IP address.

!" Command Line Interface (CLI) and Web-Based User Interface.

!" Telnet and Serial Port access to the CLI

!" Automatically configure and run multiple virtual stations via the CLI

!" The Web-Based User Interface supports:

#Different types of graphs per time and virtual station

#Export of event log and statistics data

#Scenario scheduling to bring vSTAs online in a time appointed manner

#User defined virtual station groups based on end-user requirements

#Multiple types of reports

#The ability to save test scenario files in order to repeat a test

#Configuration and monitoring of virtual stations include: copy and

paste, printing, and add and delete virtual stations

#The ability to select a System Under Test

#The ability to set up groups and select individual virtual stations to run

through the 802.11 state machine

EmulationEngine 11a/b/g User's Guide

080104 1-3

Files

The following files are maintained in the EmulationEngine’s flash file

system:

1) EmulationEngine Configuration (eecfg)

2) Scenario definitions

3) Logs

4) Statistics

5) EE22.SYS

6) keyfile

1) The EmulationEngine configuration file (eecfg) stores information

settings that can be defined via the CLI or the web-based user interface. A

backup version (.bak) of this file is also maintained in the unlikely event

that the original might become corrupted. The EmulationEngine will load

from this file at power-up/initialization time. It contains basic

configuration information.

2) After the EmulationEngine is configured, you may create test scenarios

that contain virtual station definitions that are organized into groups. This

information is stored in scenario files. The scenario files are created and

used by the web-based user interface. The CLI does not create or use

scenario files.

3) Log files store records of all EmulationEngine activities with a time

stamp indicating when the activity occurred. Logging to the CLI console,

the web-based user interface, or a file can be enabled/disabled.

4) Statistics files contain statistics of a test (scenario) run. When a test is

complete, a statistics file can be written in the flash file system for each

virtual station involved in the test. The Reports section of the web-based

user interface can be used to show the contents of these files.

5) The EE22.SYS file is the EmulationEngine software image file.

6) The keyfile is a reserved file that contains the EmulationEngine

authorization code. It is a hidden file and will only be shown in the

directory list in the CLI’s administrative mode. Do not delete this file or

attempt to access or modify it. It is required by the system.

System Requirements

!" An A/C power outlet (100~240 V, 50~60 Hz) that will supply power to the

EmulationEngine

!" A PC with an available serial port or 10/100 Ethernet port that can be

used to send commands to the EmulationEngine

!" If the web-based user interface is used, the command PC must be

equipped with the following:

#Microsoft Windows 2000/XP

#Microsoft Internet Explorer Version 6.0 or higher

#Recommended Memory: 256 MB

#Recommended Virtual Memory: 300 MB

#Recommended Processor Speed: PIII 700 MHz.

Communication Machinery Corporation (CMC)

1-4 080104

Hardware Characteristics

Ethernet Compatibility: The EmulationEngine can attach directly to

10BASE-T/100BASE-TX (twisted-pair) Ethernet LAN Hubs, segments or a

PC. All of these must conform to the IEEE 802.3 specification.

Radio Characteristics: The EmulationEngine conforms to the IEEE

802.11a, 802.11b, and 802.11g specifications. In 802.11a mode, it

operates at the 5GHz Unlicensed National Information Infrastructure

(UNII) band. Data is transmitted over a half-duplex radio channel

operating at up to 54 Megabits per second (Mbps) using OFDM

(Orthogonal Frequency Division Multiplexing). In 802.11b mode, the

EmulationEngine operates in the 2.4 GHz band and sends data at up to 11

Mbps. In 802.11g mode, the EmulationEngine operates within the 2.4 GHz

band using OFDM at rates up to 54 Mbps.

General Usage Notes

1) The EmulationEngine's default IP address is 192.168.0.50. In order to

establish initial communications between the command PC and the

EmulationEngine using an Ethernet connection, you must set your PC's IP

address and network mask to match this default address (e.g., IP

address: 192.168.0.2, Netmask: 255.255.255.0). After you establish

communications using the default IP address, you can change the

EmulationEngine's and your command PC's address to match the

addressing scheme used in your network.

2) Depending on your feature key, the EmulationEngine can operate in

802.11a, 802.11b, or 802.11g wireless mode. The EmulationEngine's

wireless mode affects the devices that you can select as a System Under

Test. For example, an EmulationEngine that is operating in 802.11a

wireless mode will not discover an 802.11b or 802.11g device. Make sure

the wireless mode you select for the EmulationEngine is compatible with

the device you wish to test. See EE->Configure EE in Chapter 5 and “set

wirelessmode” in Chapter 6.

3) The EmulationEngine's Wireless LAN MAC address defaults to a specific

address (typically in the 00:0b:cd:xx:xx:xx range). It is a globally unique

MAC address that is programmed in to the EmulationEngine hardware.

The WLAN base MAC address and mask (ff:ff:ff:ff:00:00) define the range

of MAC addresses that can be assigned to virtual stations. When you

specify a starting MAC address for virtual stations, make sure that address

is within the range defined by the WLAN base MAC address and mask. See

vSTA->New Emulation Group->vSTA and EE->Configure EE in Chapter 5

and “set eemac” and “set eemask” in Chapter 6.

4) The default WLAN base MAC address can be overridden to prevent

conflict with other wireless devices. If you use multiple EmulationEngines

at your facility, each should have a WLAN MAC whose prefix is unique. For

example, on the first EmulationEngine, use WLAN MAC Address:

04:0d:e0:62:23:57 and on the second EmulationEngine, use WLAN MAC

Address: 06:0f:14:62:32:a0.

5) The IP Mask of the EmulationEngine must match the IP subnet

addressing scheme for internal mode testing (it is not used for external

mode). For example, if the EmulationEngine's IP address is 10.1.40.18

and the System Under Test is 10.1.35.17, then the subnet mask must be

16 bits or 255.255.0.0 for an internal mode test.

EmulationEngine 11a/b/g User's Guide

080104 2-1

CHAPTER 2: Connectors, LEDs & Antennas

Front Panel/LEDs

LED Status Description

Off Power is not supplied to the EmulationEngine

On Power is supplied to the EmulationEngine

Power

Flashing Running a self test, loading software, or system errors

10/100: Off No Ethernet activity

100: On Green Indicates 100 Mbps Ethernet cable link

10: On Green Indicates 10 Mbps Ethernet cable link

100: Flashing

Green The EmulationEngine is transmitting or receiving data on

the 100 Mbps Ethernet LAN. Blink rate is proportional to

network activity.

Ethernet Link

10/100

(See Note

below)

10: Flashing Green The EmulationEngine is transmitting or receiving data on

the 10 Mbps Ethernet LAN. Blink rate is proportional to

network activity.

Off Wireless link disabled

On Valid wireless link but the EmulationEngine is not joined

with a System Under Test or the EmulationEngine has lost

communication with a System Under Test and has not

joined with any other System Under Test.

Wireless Link

Flashing EmulationEngine has joined with a System Under Test.

NOTE: The Ethernet LED is normally ON while a link is detected. It turns

OFF when a packet is received or transmitted. The OFF period is 50

milliseconds. If packets are being transmitted or received every 50

milliseconds or faster (e.g., 20 packets per seconds evenly spaced) for a

sustained period, the LED will stay off. This is done by the hardware and

the timing/proportionality is not adjustable.

Communication Machinery Corporation (CMC)

2-2 080104

Back Panel

Connectors

10/100 Ethernet Connector: This connector provides 10/100 Mbps

connectivity to a wired Ethernet LAN. It is used to connect a command PC

to the EmulationEngine.

Serial Port: This connector can also be used to connect a command PC to

the EmulationEngine. The configuration of the serial port is: 9600 bps, 8

data bits, no parity, 1 stop bit, and no flow control

AC Power Connector: This connector is used to connect the

EmulationEngine to the provided power supply.

Antennas

There are two antennas on the back of the device. The system chooses

the best antenna for transmit and receive. The antennas can be swiveled

180 degrees and angled up or down to optimize signal gain.

Reset Button

A recessed reset button is located between the Ethernet Connector and

Power Supply Connector on the back of the unit. It can be used to perform

a hard reset of the EmulationEngine. To perform a hard reset, use a paper

clip to press the reset button.

EmulationEngine 11a/b/g User's Guide

080104 3-1

CHAPTER 3: Installation

Use the provided Power Adapter to supply power to the EmulationEngine.

Connecting Directly to a Command PC

!" Connect one end of the supplied Ethernet crossover cable to the Ethernet

port on the command PC.

!" Connect the other end of the crossover cable to the RJ-45 Ethernet

Connector on the EmulationEngine.

Connecting Through an Ethernet Hub/Switch

!" Connect one end of a standard Ethernet cable (not provided) to the

Ethernet port on the command PC. Connect the other end of the cable to

the Ethernet Connector on the Ethernet hub/switch.

!" Connect one end of a standard Ethernet cable to a port on the hub/switch.

Connect the other end of the cable to the Ethernet Connector on the

EmulationEngine.

Connecting to the Serial Port (Optional)

!" A standard straight serial cable is provided with the EmulationEngine.

!" Connect the female connector end of the cable to a serial port on the

command PC.

!" Connect the male connector end of the cable to the serial port on the

EmulationEngine.

Communication Machinery Corporation (CMC)

3-2 080104

EmulationEngine 11a/b/g User's Guide

080104 4-1

CHAPTER 4: Initial Setup

For an Ethernet Port Connection

If the Command PC is attached to the Ethernet Port on the

EmulationEngine, complete the following steps to configure the Command

PC and access the EmulationEngine web-based user interface or

Command Line Interface (CLI):

1) Select Control Panel from the Start menu on the PC.

2) Double click on the Network Connections icon.

3) Right-click on the Local Area Connection icon for the Ethernet

controller that is connected to the EmulationEngine. Select Properties from

the right-click menu to display the Local Area Connection Properties

dialog.

4) Select/highlight Internet Protocol (TCP/IP).

5) Click the Properties button to display the Internet Protocol (TCP/IP)

Properties dialog.

Communication Machinery Corporation (CMC)

4-2 080104

6) Select the “Use the following IP address” radio button and enter the IP

address for the Ethernet connection. Use an IP Address that resides on the

same IP subnet as the EmulationEngine. For example, use 192.168.0.2 if

you are using the EmulationEngine's default IP address 192.168.0.50.

7) Click “OK” to close the Internet Protocol (TCP/IP) Properties dialog.

8) Click the Close button in the Local Area Connection Properties dialog.

You can access the EmulationEngine using one of the following methods.

Web-Based User Interface: You can use a PC with Microsoft Windows

2000/XP and Internet Explorer (Version 6.0 or higher) to access the web-

based user interface.

!" Launch Internet Explorer on the command PC.

!" Select Internet Options from the Tools menu. Select the Settings button

and make sure the "Every Visit to Page" radio button is selected in the

Settings dialog. This step is only required the first time you use the web-

based user interface.

!" For initial setup, use the EmulationEngine's default IP address

192.168.0.50. Example:
