Community MVP38 User manual

MVP38
TWO-WAY MONITOR LOUDSPEAKER WITH 90° X 40° HF HORN
COMMUNITY PROFESSIONAL LOUDSPEAKERS
333 East 5th Street, Chester, PA USA 19013-4511 TEL [phone] FAX [phone]
www.loudspeakers.net
MVP38 [04-17-02]
Specifications subject to change without notice.
MVP38 Page 1 of 2
DESCRIPTION
Loudspeaker Type: Two-way, full-range
Operating Range: 70 Hz - 16 kHz
80 Hz - 14 kHz (+/-5dB)
Max Input Ratings: 200W continuous, 500W Program
40 volts RMS, 89 volts momentary peak
Recommended Power Amplifier:
For maximum SPL: 400W to 600W @ 8 Ohms
Sensitivity 1W/1m: 94 dB SPL (63 Hz - 12.5 kHz 1/3 octave bands)
93 dB SPL (250 Hz - 4 kHz speech range)
Maximum Output: 117 dB SPL / 124 dB SPL (peak)
Nominal Impedance: 8 Ohms
Min Impedance: 3.9 Ohms @ 10720 Hz
Nominal -6dB Beamwidth:
90° H (-4° / -47°, 1 kHz - 12.5 kHz)
40° V (+34° / -19°, 1 kHz - 12.5 kHz)
Axial Q / DI: 14.9 / 11.7, 1 kHz - 12.5 kHz
Crossover Frequency: 2 kHz
Recommended Signal Processing: 70Hz high pass filter
Drivers: LF (1) 15"
HF (1) LM20™ compression driver
non-metallic diaphragm, Ferrofluid-cooled
Driver Protection: Thermal Link™
Input Connection: (2) 1/4” jacks, (2) Locking Connectors
Controls: None
Enclosure: MDF
Enclosure Hardware: (2) Recessed handles
(6) Interlocking corner protectors
(4) Rubber feet
Mounting / Rigging Provisions: None
Grille: 16 gauge perforated steel
Required Accessories: None
Supplied Accessories: None
Optional Accessories: None
Dimensions: Height: 23.4” / 594 mm
Width: 17.5” / 445 mm
Depth: 15” / 380 mm
Front slope: 35º from horizontal
Weight: 41 lb. / 18.5 kg
Shipping Weight: 45 lb. / 20.4 kg
1. Sensitivity: Free field pink noise measurement at 40 ft / 12.2 m at 50%
power; extrapolated to 1 meter and an input of 2.83 volts RMS.
2. Watts: All wattage figures are calculated using the rated
nominal impedance.
The MVP38 is a high output, super-compact, two-way stage monitor
system. The system utilizes one LM20™ proprietary high-frequency
compression driver coupled to an exponential horn and one 15" woofer
for high sensitivity and excellent power handling capability. These
components are matched to an extremely low-profile enclosure of an
optimally tuned, direct radiating, bass reflex design. The recessed han-
dles, black carpet exterior, perforated steel grille, and injection molded
corners make this system attractive, rugged and easily transportable.
The MVP38 offers a robust internal crossover with Thermal Link™
Dynamic HF Driver Protection. The crossover is built to last with high
quality inductors, precision wound coils and military grade circuit
boards.The proprietary Thermal Link Dynamic HF Driver Protection
circuit provides both over-current and thermal protection for added per-
formance and reliability. Designed as a high performance stage moni-
tor, the MVP38 offers the clarity and detail necessary forcritical live
performance use. In addition, its smooth, peak-free response provides
maximum gain before feedback ensuring capability for high on-stage
sound pressure levels. The compact, low-profile design makes the
MVP38 ideal for TV broadcast, house of worship and other applica-
tions where stage equipment must be as unobtrusive as possible, yet
provide fully professional performance.
SPECIFICATIONS (See notes 1 and 2)
APPLICATIONS:
·SOUND REINFORCEMENT/PORTABLE PA
·CLUBS/DJ
·BANDS
·HOUSES OF WORSHIP
·PERMANENT INSTALLATION
·SPORT FACILITIES & HEALTH CLUBS
·RENTAL SYSTEMS
·KARAOKE
FEATURES:
·SIGNAL PRESENT LED
·THERMAL LINK™ HF DRIVER PROTECTION
·LM20™ LOW MASS FERROFLUID-COOLED NON-METALLIC DIAPHRAGM
·HEAVILY BRACED MDF CONSTRUCTION
·TWO ¼" INPUT CONNECTORS, AND TWO LOCKING CONNECTORS
·RECESSED HANDLES
·16 GAUGE STEEL GRILLES

COMMUNITY PROFESSIONAL LOUDSPEAKERS
333 East 5th Street, Chester, PA USA 19013-4511 TEL [phone] FAX [phone]
www.loudspeakers.net
MVP38 [04-17-02]
Specifications subject to change without notice.
MVP38 Page 2 of 2
The loudspeaker system shall be a two-way, full-range stage monitor design with one 15” woofer and one 3/4” exit HF
driver with a non-metallic diaphragm mounted to a 90° H x 40° V molded horn. Drivers shall be connected to an inte-
gral crossover with a crossover frequency of 2 kHz and a HF driver over-current and thermal protection circuitry. There
shall be two 1/4" phone jacks and two locking connectors. The loudspeaker enclosure shall be black carpeted MDF con-
struction with a 16 gauge perforated steel grille. The system shall have an amplitude response of 80 Hz to 14 kHz (+/-
5 dB), input capability of 40V RMS, 94 dB sensitivity at one meter and 2.83 V/8 ohms nominal impedance. The nomi-
nal dispersion shall be 90° H x 40° V from 1 kHz to 12.5 kHz. The loudspeaker shall be 23.4” (594 mm) H x 17.5” (445
mm) W x 15” (380 mm) D and weigh 41 lbs (18.6 kg).
LIMITED WARRANTY
Community MVP loudspeakers are guaranteed to be free from defects in materials and workmanship from the original
date of sale for a period of five years in the U.S.A and worldwide. This warranty is automatically transferable to any and
all owners during the specified period. For complete warranty information, consult the product owners manual or call
[phone] for a copy.
DIMENSIONS
Frequency Response Impedance
Beamwidth Axial Q
Frequency in Hertz
Degrees
Frequency in Hertz
Q
Frequency in Hertz
Frequency in Hertz
dB SPL
Ohms
MVP38
TWO-WAY MONITOR LOUDSPEAKER WITH 90° X 40° HF HORN
20,000
20,000
20,000
20,000
RIGHT
SIDE
FRONT
VIEW
LEFT
SIDE
TOP
VIEW
BOTTOM
VIEW
ARCHITECTS AND ENGINEERS SPECIFICATIONS
