COMPAC INDUSTRIES LIMITED C4000 SERVICE MANUAL
31 May, 2004 Page i
C4000
MASTER
MANUAL
Last Update:
Friday, 03 May 2004
Compac Industries Ltd.
P O Box 12-417
Penrose
Auckland
New Zealand
Ph 64 9 5792 094
Fax [phone]
www.compac.co.nz

CONTENTS C4000 SERVICE MANUAL COMPAC INDUSTRIES LIMITED
Page ii 31 May, 2004

COMPAC INDUSTRIES LIMITED C4000 SERVICE MANUAL
31 May, 2004 Page iii
1. Description1
1.1. General.............................................................................................................................................. 1
1.2. Safety Precautions............................................................................................................................ 2
1.3. Static Electricity Precautions .......................................................................................................... 3
2. MAIN FEATURES ............................................................................................. 4
2.1. Components ...................................................................................................................................... 4
2.2. Configurations.................................................................................................................................. 4
2.2.1. Single Commercial Fuel Dispenser ............................................................................................... 4
2.2.2. Single Suction Dual Commercial (Duo)........................................................................................ 4
2.2.3. Dual Commercial (Dual or Double) .............................................................................................. 4
2.2.4. Single Retail .................................................................................................................................. 5
2.2.5. Single Suction Dual Retail (Duo).................................................................................................. 5
2.2.6. Dual Retail (Dual or Double) ........................................................................................................ 5
2.2.7. Multi Product (4 hose) Retail ........................................................................................................ 5
2.2.8. Multi Product (4 hose) Retail, Type 'A' all hoses in use................................................................ 5
2.2.9. Multi Product (6 hose) Retail ........................................................................................................ 6
2.2.10. Multi Product (6 hose) Retail, Type 'A' all hoses in use................................................................ 6
2.2.11. Futra (Uses 'Futra' Software)......................................................................................................... 6
3. SET-UP MODES ............................................................................................... 7
3.1. 'K' Factor Switch ............................................................................................................................. 8
3.1.1. Using the ‘K’ Factor Switch.......................................................................................................... 8
3.1.2. Calibration ('K') Factor.................................................................................................................. 8
3.1.3. No Flow Cut-Off Timer ................................................................................................................ 9
3.1.4. Display (Litres) Resolution ......................................................................................................... 10
3.1.5. Solenoid Delay ............................................................................................................................ 10
3.1.6. Pre-Set Cut-Off ........................................................................................................................... 11
3.1.7. ‘b’ Settings. ................................................................................................................................. 11
3.1.8. Configuration Code ..................................................................................................................... 14
3.2. Further Settings Available on the ‘K’ factor Switch................................................................... 16
3.2.1. Product Density Factor................................................................................................................ 16
3.2.2. Specific Density (With a densometer)......................................................................................... 16
3.2.3. Temperature Calibration.............................................................................................................. 17
3.2.4. ACV Valve Flowrate................................................................................................................... 18
3.2.5. L-Cut ........................................................................................................................................... 18
3.2.6. H-Cut........................................................................................................................................... 18
3.2.7. F-Cut ........................................................................................................................................... 18
3.3. Parameter Switch........................................................................................................................... 18
3.3.1. Program Version Number ........................................................................................................... 19
3.3.2. Setting the Price per Litre............................................................................................................ 19
3.3.3. Setting the Product Density......................................................................................................... 21
3.3.4. Setting the Dispenser/Pump Number .......................................................................................... 22
3.3.5. Displaying the End of Sale Indications ....................................................................................... 22
3.3.6. Setting the Sequencing Rate........................................................................................................ 22
3.3.7. Validating/Invalidating Cards, Pins, or Keys .............................................................................. 23
3.3.8. Setting the Access Code .............................................................................................................. 23

CONTENTS C4000 SERVICE MANUAL COMPAC INDUSTRIES LIMITED
Page iv 31 May, 2004
4. PRINTER SETUP.............................................................................................24
4.1. Comcard, Compin, and CWIDKey Basic Systems. .....................................................................24
4.2. Printer Self Test ..............................................................................................................................24
5. DISPLAYING AND PRINTING TOTALS .........................................................25
5.1. General ............................................................................................................................................25
5.2. Scrolling Tote Option .....................................................................................................................25
5.3. Using a Totals Only - Report Printer............................................................................................25
5.4. Receipt Printer................................................................................................................................25
5.4.1. Printer Housed at the Pump/Dispenser (Card King) ....................................................................26
5.4.2. Receipt Printer Connected to the Central Controller ...................................................................26
6. BASIC SYSTEMS (COMCARD, COMPIN, & CWIDKEY).......................................28
6.1. Comcard Basic ................................................................................................................................28
6.2. Compin Basic ..................................................................................................................................28
6.3. CWIDKey Basic..............................................................................................................................28
6.3.1. CWIDKey Number Identification................................................................................................28
7. ERROR CODES...............................................................................................30
7.1. Other Error Messages ....................................................................................................................30
8. INDICATOR LED’S..........................................................................................32
8.1. Power LED ......................................................................................................................................32
8.2. WatchDog LED...............................................................................................................................32
8.3. TXD and RXD LEDs......................................................................................................................33
8.4. Output LEDs...................................................................................................................................33
8.5. Diagnostic LED...............................................................................................................................34
9. SOLID STATE RELAYS (TRIACS) .................................................................35
9.1. General ............................................................................................................................................35
9.2. High Current Triac Option............................................................................................................37
10. ELECTRICAL WIRING ....................................................................................39

COMPAC INDUSTRIES LIMITED C4000 SERVICE MANUAL
31 May, 2004 Page v
10.1. 230 Volt Wiring .............................................................................................................................. 39
10.2. Communications (Comms) Wiring............................................................................................... 39
10.2.1. Comms DIP Switch settings........................................................................................................ 39
10.2.2. C4000 Gilbarco Protocol Converter............................................................................................ 40
10.3. Intrinsically Safe Wiring ............................................................................................................... 40
10.3.1. Air Detector Cut-out Switch........................................................................................................ 40
10.3.2. Nozzle switch(es) ........................................................................................................................ 41
10.3.3. Sump Switch ............................................................................................................................... 41
10.3.4. Temperature Pressure Compensation PCB (CI075) .................................................................... 41
10.3.5. Display Backlighting................................................................................................................... 42
10.3.6. Card-readers ................................................................................................................................ 42
10.3.7. Compac Wireless Transceiver.....................................................................................................42
10.3.8. Displays: Litres only, Retail, Multi-price & Preset ..................................................................... 43
10.3.9. Modem ........................................................................................................................................ 45
10.3.10. Standard PIN Pad Unit ................................................................................................................ 45
10.3.11. Secure PIN Pad Unit ................................................................................................................... 46
10.3.12. Encoder ....................................................................................................................................... 46
10.3.13. High/Low Flow Switch ............................................................................................................... 47
10.3.14. High/Low Flow Operation Methods ........................................................................................... 48
10.3.15. CNG Dispenser Shut-Off Switch ................................................................................................ 48
10.3.16. Electromechanical Totalisers ...................................................................................................... 49
10.3.17. Electronic Totals ......................................................................................................................... 49
10.4. Software Upgrade Procedure........................................................................................................ 49
11. FAULT FINDING ............................................................................................. 51
11.1. End of Sale Indications .................................................................................................................. 52
12. GLOSSARY OF TERMS ................................................................................. 54
APPENDIX A (IS CABLE MICROPROCESSOR - IS POWER SUPPLY) ............. 55

COMPAC INDUSTRIES LIMITED C4000 SERVICE MANUAL DESCRIPTION
31 May, 2004 Page 1
1. DESCRIPTION
1.1. General
The Compac C4000 is a microprocessor-based circuit board designed for use in liquid and
gaseous fuel metering systems. It is suitable for commercial, retail, and bulk-metering
applications and can be used for Tank Gauging, card reader access, and many other control
functions.
'K' Factor SwitchParameter Switch
Connectors:
J1: Comms Test J7: Displays J13: CWIT/Secure
J2: To I.S. Power J8: Temperature Comp. PINPad
J3: Encoder 1 J9: PINPads J14: Printers
J4: Encoder 2 J10: Totes J15: Cardreader 1
J5: Encoder 3 J11: ParSw & Buzzer J16: Cardreader 2
J6: Encoder 4 J12: Nozzle Switches J17: Backlighting
Figure 1. Layout of C4000 Microprocessor Board
The C4000 microprocessor, commonly referred to as the 'head', is powered by an
intrinsically safe power supply, and is designed to operate in a class 1 zone 1 area. The
power supply and the 220-240V output circuitry is housed in a flameproof box.
The C4000 ('head') performs the following functions (depending upon which accessories are
connected):
•Converts the rotation of a meter into pulses via the Compac Encoder.

DESCRIPTION C4000 SERVICE MANUAL COMPAC INDUSTRIES LIMITED
Page 2 31 May, 2004
•Converts these input pulses into litres.
•Controls the operation of an electric motor or a submersible pump.
•Controls the Preset Valves.
•Provides Temperature Compensation to the litres value.
•Provides an electronic 'K-Factor' for calibration. This means that the unit can be used on
any type of meter, regardless of turns per litre.
•Can be fitted with a card-reader directly on the dispenser/pump to give unattended 'fleet'
type access.
•Can be fitted with a PIN / Odometer pad, with or without card reader, on the
dispenser/pump.
•Can be plugged into the Compac Modem Package (Futra only).
•Has a real time clock for memory and card-reader reporting functions (Futra only).
•The Display options available are (no. of digits in parenthesis):
°6 digit Commercial Display (Litres only) *
°Standard Retail Display (Price, Litres and $/L) (5 x 5 x 4)
°6 digit Retail Display (Price, Litres, and $/L) (6 x 6 x 4) *
°Bulkmeter Display (Litres, Preset, and Rate of Flow) (6x6x4)
°MPD Display (Price, Litres, and up to three $/L) (5 x 5 x 4)
°Preset (Litres or Dollars) (5)
°Last Sale, kilograms, dollars and price (CNG only)
* Set Display resolution to Hiflow when using 6 digit displays. (refer section 3.1.4)
•Can report by any of the following options:
°Card/Pin/Key Totals printout (Comcard, Compin, & CWIDKey only)
°Card/Pin/Key Transaction Audit Trail printout - Small Docket Printer (Comcard,
Compin, & CWIDKey only)
°Receipt Printout - Small Docket Printer (Central Controller & Futra systems)
°Audit Trail/Report Printout of transactions - 11" Report Printer (Central Controller &
Futra only)
1.2. Safety Precautions
The C4000 head, and its associated circuits and wiring, is a certified piece of electrical
equipment approved for use in a hazardous area (Class 1 Zone 1, Group IIA T3). Only parts
identical to those covered by the certification may be used where the integrity of the intrinsic
safety may be affected. All circuit boards are to be repaired only by Compac Industries Ltd.

COMPAC INDUSTRIES LIMITED C4000 SERVICE MANUAL DESCRIPTION
31 May, 2004 Page 3
1.3. Static Electricity Precautions
Electronic components used are sensitive to static. Please take anti-static precautions.
All circuit boards must be carried and transported in static-shielded bags. An anti-static wrist
strap should be worn and connected correctly when working on any electronic equipment. If
an anti-static wrist strap is unavailable, or in an emergency, hold onto an earthed part of the
pump/dispenser frame whilst working on the equipment. This is not a recommended
alternative to wearing an anti-static wrist strap.
Note: Compac Industries Limited reserves the right to refuse to accept any circuit boards returned, if proper
anti-static precautions have not been taken.

MAIN FEATURES C4000 SERVICE MANUAL COMPAC INDUSTRIES LIMITED
Page 4 31 May, 2004
2. MAIN FEATURES
2.1. Components
The main components associated with the C4000 head are:
•Encoder
•Displays
°Litres
°Dollars, litres and price
°Litres, rate of flow and preset
°Preset
°Last Sale, kilograms, litres and price
(CNG only)
•Temperature compensation
•Card-reader
•PIN/Odometer Pad
•Printer
•Modem
•Mechanical Totaliser (Tote)
•Nozzle Switch
2.2. Configurations
The C4000 'head' can be used with the equipment listed below in the following standard
configurations:
2.2.1. Single Commercial Fuel Dispenser
Standard Options: Extras:
•Litres only display, two - one per side
•Motor circuit, one only
•One Encoder
•One Nozzle Switch
•C4000 Head
•Card-reader
•High/Low Flow Operation
•Temperature Compensation
•PIN-Pad
* Also see 'FUTRA' configuration.
2.2.2. Single Suction Dual Commercial (Duo)
Standard Options: Extras:
•Litres only display, four - two per side
•Two motor circuit.
•Two Encoders
•Two Nozzle Switches
•C4000 Head
•Temperature Compensation
•Preset
2.2.3. Dual Commercial (Dual or Double)
Standard Options: Extras:
•Litres only display, four - two per side
•Two Motor circuits
•Two Encoders
•Two Nozzle Switches
•C4000 Head
•Temperature Compensation
•Preset

COMPAC INDUSTRIES LIMITED C4000 SERVICE MANUAL MAIN FEATURES
31 May, 2004 Page 5
2.2.4. Single Retail
Standard Options: Extras:
•Dollars, litres and price display, two - one per
side
•Presets, two - one per side
•One Encoder
•One Nozzle Switch
•One Motor Output
•C4000 Head
•Card-reader
•Temperature Compensation
•PIN-Pad
•Receipt Printer
* Also see 'FUTRA' configuration
2.2.5. Single Suction Dual Retail (Duo)
Standard Options: Extras:
•Dollars, litres and price display, two - one per
side
•Presets, two - one per side
•Two Encoders
•Two Nozzle Switches
•Two Motor Outputs
•C4000 Head
•Temperature Compensation
2.2.6. Dual Retail (Dual or Double)
Standard Options: Extras:
•Dollars, litres and price display, four - two
per side
•Presets, four - two per side
•Two Encoders
•Two Nozzle Switches
•Two Motor Outputs
•C4000 Head
•Temperature Compensation
2.2.7. Multi Product (4 hose) Retail
Standard Options: Extras:
•Dollars, litres and price display, two - one
per side
•Presets, two - one per side
•Four Encoders
•Four Nozzle Switches
•Two Motor Outputs
•One C4000 Head
•Multi-price Displays, four – one per product
per side
•Card-reader
•PIN Pad
•Receipt Printer
2.2.8. Multi Product (4 hose) Retail, Type 'A' all hoses in use
Standard Options: Extras:
•Dollars, litres and price display, four - one
per product per side
•Presets, four - one per product per side
•Four Encoders
•Four Nozzle Switches
•Two Motor Outputs
•One C4000 Head
•Temperature Compensation

MAIN FEATURES C4000 SERVICE MANUAL COMPAC INDUSTRIES LIMITED
Page 6 31 May, 2004
2.2.9. Multi Product (6 hose) Retail
Standard Options: Extras:
•Dollars, litres and price display, two - one
per side
•Presets, two - one per side
•Six Encoders
•Six Nozzle Switches
•Three Motor Outputs - shared by C4000
Heads
•Two C4000 Heads
•Multi-price Displays, six - one per product
per side
•Card-reader
•PIN Pad
•Receipt Printer
2.2.10. Multi Product (6 hose) Retail, Type 'A' all hoses in use
Standard Options: Extras:
•Dollars, litres and price display, six - three
per side
•Presets, six - three per side
•Six Encoders
•Six Nozzle Switches
•Three Motor Outputs - shared by C4000
Heads
•Two C4000 Heads
•Temperature Compensation
2.2.11. Futra (Uses 'Futra' Software)
This type of system is a stand-alone system that cannot be set up to communicate to any type
of controller.
Standard Options: Extras:
•Litres Only Display
•Motor Circuit (One only)
•One Encoder
•One Nozzle Switch
•C4000 Head
•PIN-Pad
•CardReader
•Retail Displays
•Preset
•Modem
•Temperature Compensation
•High/Low Flow Operation
•Tank Gauging, for one tank only
•Receipt Printer

COMPAC INDUSTRIES LIMITED C4000 SERVICE MANUAL SET-UP MODES
31 May, 2004 Page 7
3. SET-UP MODES
To enable the C4000 to operate as desired, two things must be set:
1. Configuration (K Factor) Switch Settings
°This switch accesses different options that must be set appropriately for the particular
type of dispenser.
2. Parameter Switch Settings
°This switch is used to conduct the Display Segment Test, set price (product density -
if a bulkmeter or LPG), and set pump number. Also, when the C4000 is configured for
'Comcard', 'Compin', or 'CWIDKey' the parameter switch is used for card/pin/key
validation and for setting the card/key system number (access code - refer section
3.3.8).
°With CNG dispensers, the sequencing rate between 'banks' is also set using the
parameter switch (reference section 3.3.6).
The positions of the above switches are shown on Figure 1, page 1. Set up of the C4000 must
be done in the following sequence:
1. ‘K’ Factor Switch Settings - starting with configuration setting and moving back
through the options to the K Factor setting:
‘K’ Factor Switch Settings
Setting Price Display Litres Display Reference
Configuration Code ‘C’‘XXXXX’ Refer section 3.1.8.
Display Resolution ‘Sr’ ‘Sr X.XX’ Refer section 3.1.4.
Temperature ‘E’ ‘EXXX.X’ Refer section 3.2.3. LPG and
Bulk-metering only
ACV Flowrate ‘FLO’ ‘rXXXX’ Refer section 3.2.4. Bulk-
metering only
Density Calibration ‘LP6’ ‘00000’Refer section Error!
Reference source not found..
LPG only.
No-flow cut-off ‘n’ ‘nXXX’ Refer section 3.1.3
Solenoid delay ‘Sd’ ‘dXXX’ Refer section 3.1.5
Preset Cut-Off ‘PCut’ ‘PC X.XX’ Refer section 3.1.6
‘b’ settings ‘b’ ‘bXXXX’ Refer section 3.1.7
‘K’ Factor ‘F’, ‘Fb’,
‘F1’, ‘F2’, or
‘F3’
‘X.XXXX’ Refer section 3.1.2
H-Cut ‘HCut’ ‘HXXXX’ Refer section 3.2.6. Bulk-
metering only
L-Cut ‘LCut’ ‘LXXXX’ Refer section 3.2.5. Bulk-
metering only
F-Cut ‘FCut’ ‘FXXXX’ Refer section 3.2.7. Bulk-
metering only
Density Factor ‘dSF’‘X.XXXX’ Refer section 3.2.1. CNG only
SP: Set decimal place. Appears only when the unit is set-up for CNG.

SET-UP MODES C4000 SERVICE MANUAL COMPAC INDUSTRIES LIMITED
Page 8 31 May, 2004
NOTE: The K Factor setting should be done last of all (i.e. until parameter switch settings are
made, the pump/dispenser may not be operational, and so a calibration fill may not be possible).
2. Parameter Switch Settings - all must be set, but the order of the set-up is not critical.
3.1. 'K' Factor Switch
The 'K' Factor switch is located on the C4000 PCB as shown in Figure 1 on page 1. The 'K'
Factor switch is used to access and change various set-up options of the C4000 head. The
following flow charts detail the operation of setting up the C4000 head:
Any change of set-up effected by the 'K' Factor switch takes effect as soon as the C4000
resets. The power supply does not have to be interrupted.
NOTE: The C4000 will reset at any stage during the 'K' Factor switch operation if the switch is not pressed for
a period exceeding ten (10) seconds. If the C4000 resets out of any field before the numbers have been set
correctly, then that field must be entered again to ensure the details are correct.
3.1.1. Using the ‘K’ Factor Switch
Using the ‘K’ Factor Switch to Change a Setting
Step ACTION RESULT
1Ensure that the nozzles are hung up Dispenser in idle state
2Press and release the ‘K’ Factor switch,
in quick succession, until the desired
setting is displayed.
The price display and volume display
indicates the desired setting. See
following paragraphs.
3Press and hold the ‘K’ factor switch. A digit, of the displayed setting, will
begin to increment.
4When the digit is correct, release the
‘K’ Factor switch.
5Repeat steps 3 and 4 for each digit of
the setting
NOTE: the C4000 will reset itself if the ‘K’
factor switch is left for more than 10 seconds.
Continue for multiple hose units, if appropriate.
6Press and release the ‘K’ factor switch
8 or more times in quick succession
The setting for side “B” (or hose 2, 3,
or 4) is displayed.
7Repeat steps 3 to 5 above.
IMPORTANT NOTE:
The K-Factor switch must be sealed with a lead or paper seal after commissioning.
3.1.2. Calibration ('K') Factor
(See also section 0 for more information on the encoder/pulser)
The 'K' Factor is a ratio of litres dispensed per revolution of the meter.
To follow is the method of calibration, including how to calculate the new 'K' Factor and
how to enter it in the C4000 memory.
Calibration
To calibrate the dispenser/pump, dispense fuel into a certified measuring container, and
compare the display value with the amount dispensed.

COMPAC INDUSTRIES LIMITED C4000 SERVICE MANUAL SET-UP MODES
31 May, 2004 Page 9
Example:
Display shows 10.00
True volume 20.00
To calculate the correct 'K' Factor from the information above; firstly record the
existing 'K' Factor.
2FactorK''Existing
10.00
20.00
FactorK''Existing
AmountDisplayed
AmountDispensed
FactorK''ExistingFactorK''New
×=
×=
×=
Change the existing 'K' Factor to this new value.
Setting the ‘K’ Factor
Refer to section 3.1.1 page 8. The displays will indicate as below
Type Price Display
indication
Volume Display
Indication
Single Hose ‘F’‘X.XXXX’
Dual Hose Side “A”
Side “B”
‘F’
‘Fb’
‘X.XXXX’
Quad or Multi-product Hose 1
Hose 2
Hose 3
Hose 4
‘F1’
‘F2’
‘F3’
‘F4’
‘X.XXXX’
Note: Once the dispenser/pump resets with the correct 'K' factor entered, the display will show the new
volume unless the 'head' is in Compensation mode, in which case the display volume will not change (see
section 3.2.5).
Caution: Be careful when calibrating dual or multi-hose pumps & dispensers to ensure that the correct 'K'
factor is being changed.
3.1.3. No Flow Cut-Off Timer
Under normal conditions to end a transaction on a C4000 controlled pump/dispenser, there
are three possibilities:
•Returning the nozzle to its holder.
•Reaching the preset amount entered.
•Cut out on the 'No flow cut-off timer'.
The No Flow Cut-off Timer sets the amount of time the dispenser/pump will allow a sale to
continue after the flow has stopped. The No Flow Cut-off Timer is terminated if the nozzle is
returned to its holster.
The range available is between 1 & 256 seconds. The default setting is 'n0000'(256
seconds).

SET-UP MODES C4000 SERVICE MANUAL COMPAC INDUSTRIES LIMITED
Page 10 31 May, 2004
Setting the No Flow Cut-Off Timer
Refer to section 3.1.1 page 8. While setting this value the price display will indicate ‘n’ and
the volume display will indicate ‘nXXXX’.
3.1.4. Display (Litres) Resolution
For standard dispenser/pumps, high flow dispenser/pumps & bulk metering, different
resolutions are often required:
Display Resolution Sr setting on k
factor switch
Litres Display
resolution
Max presetable or
fill amount
Standard (default) 0.000 0.00 970 L
Hi-Flow 0.00 0.00 9700 L
Bulk-metering 0.0 00000.0
0000000
000000[0]
[0] is not displayed
NOTES:
1. As well as displaying the decimal point, a full colon will show on the display after 'power on', until the
first transaction is started (i.e. the display shows ‘:
0.0 ’until the first new transaction begins).
The display resolution does not affect the price display, which will always display to a
resolution of 0.01 dollars.
Setting the Display Resolution
Step ACTION RESULT
1Ensure that the nozzles are hung up Dispenser in idle state
2Press and release the ‘K’ Factor switch
continuously until the Litres resolution
is displayed
The price display indicates ‘Sr’ and
the Litres Resolution is displayed as
“0.00” (standard resolution on 5-digit
display)
3Press and hold the ‘K’ factor switch. The decimal point will begin to move.
4When the resolution (decimal point) is
correct, release the ‘K’ Factor switch.
NOTE: the C4000 will reset itself if the ‘K’
factor switch is left for more than 10 seconds.
3.1.5. Solenoid Delay
The Solenoid Delay was installed in the program to enable the "delay" between the
submersible pump operating and the dispenser solenoids operating to be controlled on initial
start-up. This setting should only be set on dispensers.
This setting should never be set more than 4-6 seconds. Its main purpose is to allow the leak
detector on the submersible pump to carry out its leak test.
The default setting is 'd0000’(i.e., no delay). All dispensers with a self-contained pump
should be left at the default setting.

COMPAC INDUSTRIES LIMITED C4000 SERVICE MANUAL SET-UP MODES
31 May, 2004 Page 11
Setting the Solenoid Delay
Refer to section 3.1.1 page 8. While setting this value, the price display will indicate ‘Sd’
and the volume display will indicate ‘dXXXX’
3.1.6. Pre-Set Cut-Off
Prior to the dispenser reaching its preset amount, the solenoids are switched to give a low
flowrate. The “preset cut-off” sets the amount (in litres), prior to the preset amount being
attained, at which the solenoids will switch to a low flowrate.
With the value set to 0.00, the default values are used. These are:
°LPG 0.75
°Oil 0.05
°Other products 0.32
The Preset Cutoff is calculated as follows:
[Price per Litre] X [over-run (displayed as a dollar value)] + default value as above
Example:
Price per Litre = $0.96
Dollar amount of fuel required = $20.00
After delivery price display shows: $20.01 ($0.01 is the over-run dollar value)
New preset = (0.96 x 0.01) + 0.32 (Other Products) = 0.3296
0.3296 rounded up = 0.33
New preset cutoff to be entered is 0.33.
Setting the Pre-Set Cut-Off
Refer to section 3.1.1 page 8. The Price display shows 'PCut' and the volume display
shows 'PCX.XX'. The range is from 0.01 to 9.99 litres.
3.1.7. ‘b’ Settings.

SET-UP MODES C4000 SERVICE MANUAL COMPAC INDUSTRIES LIMITED
Page 12 31 May, 2004
Figure 2. ‘b’ settings
Auto-authorise (Digit 4)
0: If digit 4 is set to zero, then the pump/dispenser software defaults to conventional
operation, (i.e. The nozzle switch controls the pump start after initial authorisation).
1: If digit 4 is set to one, then the dispenser/pump software will run in AUTO
AUTHORISE mode of operation (used for wharf & aviation sites, or any other sites where
the hose reel is remote from the pump unit):
•The pump/dispenser will start automatically after it has been initialised by the card-
reader or remotely by a Compac controller.
•The dispenser/pump will switch off after four minutes if flow does not commence.
•The pump/dispenser will switch off XXX seconds after flow rate stops.
°This can be adjusted to clients' requirements, between 1 and 256 seconds (refer
section 3.1.3 above)
•The nozzle switch becomes a shut-off switch (i.e., The nozzle switch can be replaced
with a stop pushbutton or normally closed toggle switch).
NOTE: In AUTO AUTHORISE mode the nozzle input must be shorted out.
CNG Only: If digit 4 is set to zero, the solenoids stay on at the end of sequencing until the refuelling assembly
is returned to its holder, at which point all outputs turn off. With digit 4 is set to one, all the solenoids turn off
at the end of sequencing.
Transaction Data (Digit 3)
0: If digit 3 is set to zero, the system will function as a conventional dispenser/pump and
the sale data goes through to Point of Sale as soon as the preset is reached. This is the default
setting.
1: If digit 3 is set to one, the system will function as a convention dispenser/pump but the
sale data will go through to the Point of Sale only after the nozzle has been hung up.
2: With digit 3 set to two,the head is set up for Comcard Basic, Compin Basic, or
CWIDKey Basic, which are self-contained systems operating independently of any
controller.
b X X X X
0 = Standard
1 = Auto-authorise mode. (If CNG then auto end)
0 = Sale goes through to Point of Sale as soon as the
preset is reached (Default)
1 = Nozzle has to be hung up before the sale goes
through to the Point of Sale.
2 = Comcard, Compin, and CWID/Key Basic Systems
0 = Price/litre is displayed as dollars/litre (Default NZ)
1 = Price/litre is displayed as cents/litre (Default AUS)
If CNG then this will display pressure in the
'Dollars' display during delivery.
0 = Stand alone operation
1 = Inhibit stand alone operation.

COMPAC INDUSTRIES LIMITED C4000 SERVICE MANUAL SET-UP MODES
31 May, 2004 Page 13
To operate, a card-reader/CWIDKey reader must be plugged into the 'head' and the correct
access code and card/key number validations must be set by the Parameter switch.
NOTE: For the Bulk Meter Register, digit 3 must be zero or one. Comcard, Compin, and
CWIDKey Basic systems are not available in this mode.
Price per litre (Digit 2)
0: If digit 2 is set to zero, the price per litre is displayed as dollars per litre ($0.000)
1: If digit 2 is set to one, the price per litre is displayed as cents per litre (000.0 cents).
For CNG: If digit 2 is set to one then the display that normally shows the dollar value of the
transaction, will display the CNG pressure during the fill. At the end of the fill the display will
revert to displaying the value.
Controller option (Digit 1)
The function of this digit (1) depends on whether the head has been set up as one of the
Basic Systems (Comcard, Compin, or CWIDKey) or a conventional pump/dispenser, using
digit 3.
•Basic Systems: (digit 3 set to two)
With all Compac pumps/dispensers, the 'head' will display the dollars and litres grand
totals when the nozzle switch is pressed quickly five or more times.
NOTE: On a commercial pump/dispenser with litres-only display, only the total litres can be
read.
If the 'head' is set-up as a Comcard, Compin, or CWIDKey Basic system then, after
displaying the grand totals as above, the head will also printout the totals for each
card/pin/key, irrespective of the digit 1 setting.
By setting digit 1 to one, the 'Scrolling Totes' option is selected (See section 5.2 page
25). In this mode of operation, after printing the totals as above, the 'head' will flash
card totals on the pump's main display. All non zero card totals are displayed
consecutively, for 10 seconds each.
NOTE: The totals can only be zeroed by replacing the memory chip.
•Conventional Pump/Dispenser (digit 3 set to zero or one)
If digit 1 is zero, the pump/dispenser can be operated in 'stand-alone' mode
irrespective of the pump/dispenser number loaded.
If digit 1 set to one, the pump/dispenser will not work in 'stand-alone' mode, (i.e., it
requires initialisation from a controller).
NOTE: The pump/dispenser ceases to work in 'stand-alone' mode if digit 1 is set to zero and it is
connected to a controller. Generally on retail forecourts, this switch should be left off. Hence, if
the forecourt controller breaks down, the dispensers/pumps can be set to work in the 'stand-alone'
mode simply by turning them OFF for 1 minute minimum, then back ON.
However, for unattended situations (e.g. truckstops), the pumps must not be left able to work in
the 'stand-alone' mode in case of a controller failure. Therefore, digit 1 should always be set to
one for unattended operation. For the Bulk Meter Register configuration, when digit 1 is zero,
the unit will work in the 'stand-alone' mode. When digit 1 is one, the unit must be connected to a
Compac Central Controller.
Setting the ‘b’ settings
Refer to section 3.1.1 page 8. While setting the ‘b’ settings, the price display shows 'b' and
the volume display shows 'bXXXX'.

SET-UP MODES C4000 SERVICE MANUAL COMPAC INDUSTRIES LIMITED
Page 14 31 May, 2004
3.1.8. Configuration Code
The C4000 pump/dispenser software, the configuration code (used to set the pump/dispenser
to single, dual or multi mode) has been extended to 5 digits. When configuring the
pumps/dispensers, the litre display will display each digit, as shown in Figure 3 on page 15.
NOTES:
1. For FUTRA software configuration options, see the FUTRA service supplement.
2. Multi-hosed Pump/Dispenser with LPG
An MPD with LPG is configured by setting digits 5=3 and 4=5.
With COM125 magnetic or Bennett meters, to set LPG compensation and motor spirit without
correction, set digit 1=4.
For COM125 optical meters when motor spirit correction is required as well, set digit 1=6.
Setting the Configuration Code
Refer to section 3.1.1 page 8. While setting the configuration code, the price display shows
'C' and the volume display shows 'XXXXX'.
