Compaq 207590-B21 - Power Distribution Unit Strip User manual

NOTICE
The information in this publication is subject to change without notice.
COMPAQ COMPUTER CORPORATION SHALL NOT BE LIABLE FOR
TECHNICAL OR EDITORIAL ERRORS OR OMISSIONS CONTAINED HEREIN,
NOR FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM
THE FURNISHING, PERFORMANCE, OR USE OF THIS MATERIAL. THIS
INFORMATION IS PROVIDED “AS IS” AND COMPAQ COMPUTER
CORPORATION DISCLAIMS ANY WARRANTIES, EXPRESS, IMPLIED OR
STATUTORY AND EXPRESSLY DISCLAIMS THE IMPLIED WARRANTIES OF
MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE, GOOD TITLE
AND AGAINST INFRINGEMENT.
This publication contains information protected by copyright. No part of
this publication may be photocopied or reproduced in any form without
prior written consent from Compaq Computer Corporation.
©2000 Compaq Computer Corporation
Compaq, Registered U.S. Patent and Trademark Office.
COMPAQ 0U / 1U INSTALLATION KIT
QUICK INSTALLATION GUIDE FOR RACK-MOUNTED 0U / 1U DEVICES
Second Edition (November 2000)
Part Number 216252-022
Compaq Computer Corporation
0U / 1U
INSTALLATION KIT
Printed on recycled paper
Open Guide Completely Before
Beginning Installation Procedures
Quick Installation Guide for
Rack-Mounted 0U / 1U Devices
Kit Contents
!Assembly, 0U mounting hardware
"Mounting brackets - 0U (2)
"Screws 3mounting unit (0U) to rack (6) [2 extra]
!Assembly, 1U mounting hardware
"Mounting brackets - 1U (2)
"Rail assembly for rack-mounting (assembly required) - 1U
- Rail, front 1U (2)
- Rail, rear 1U (2)
- Nut, wing (4)
- Nut, metric hex (4) [recommended when shipping in a rack]
- Cage nuts - (4) [2 extra]
"Screws 1mounting brackets to unit (6) [2 extra]
"Screws 2mounting rails to rack (10) [2 extra]
!1U installation rack template tool
2
R
F
2
2
Align bracket with screw holes in unit. Use screws 1to attach brackets to sides
of unit. Slide unit into rails and secure by using screws 2to attach unit.
2
21
1
1
3
3
1
1
3
Align bracket with screw holes in unit. Use screws 1to attach brackets to the
sides of unit. Secure the unit to the side of rack by using screws 3(two on each
side) to attach unit.
Rack installation is complete.
To complete installation of the unit, refer to the installation guide which is
included with the device.
Installing the Unit - 0U Configuration
1
2
Installing the Unit - 1U Configuration
Use 1U installation template (included) to select and align rack mounting holes.
Place rear rail over the studs in the front rail . Tighten the nuts finger tight.
The mounting tab will be facing out, so the holes will align with the rack sides.
Adjust the length of rail assembly to fit inside rack. Tighten the nuts.
Insert the cage nuts (one on each side) in rack. Set hooks at rear of rail over
holes in rack. Use screws 2(one on each side) to attach the rails to the rear of
the rack, through the cage nut. Use screws 2(two on each side) to attach the
rails to the front of the rack.
R F
