WHITEPAPER
14A4-0201A-USEN 1
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
March 2001
Prepared By
Commercial Desktop
Product Marketing
Communications
Compaq Computer
Corporation
CONTENTS
Scope and
Assumptions...................3
Process Overview,
Conventions, Other
Documentation................3
Distribution Share
Setup – Windows
2000 Professional
Operating System............5
Service Pack 1.................5
Machine-Specific
Information......................6
Installing Plug and
Play Drivers.....................6
Integrating Video
Drivers ............................6
Integrating Network
Interface Card
(NIC) Drivers ...................7
Integrating Audio
Drivers ............................7
Integrating Chipset
Drivers ............................7
Appendix A......................9
Appendix B....................11
Tips for Hardware
Preinstallation...............11
Appendix C....................13
Appendix C....................15
Appendix D....................16
Appendix E....................17
Appendix F....................18
Compaq Guide to PC Deployment
Network Installation of Microsoft Windows 2000 Professional
on All Compaq Deskpro EN and Deskpro EX Series of Personal
Computers Using Microsoft Tools
This paper provides a solution to the ongoing challenge of creating and deploying a
corporate software image, including the operating system, hardware-specific device
drivers and value-added software applications. It describes the procedure for setting up
and initiating an unattended network installation of Windows 2000 Professional on
Compaq Deskpro EN and Deskpro EX Series of Personal Computers.

WHITE PAPER (cont.)
14A4-0201A-USEN
2
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
NOTICE
© 2001 Compaq Computer Corporation.
Compaq, the Compaq logo, Armada, Deskpro Registered in U. S. Patent and Trademark Office. iPAQ is
a trademark of Compaq Information Technologies Group, L.P. in the United States and other countries.
Microsoft, MS-DOS, Windows, Windows NT are trademarks of Microsoft Corporation in the United
States and other countries.
Intel, Pentium, Intel Inside, and Celeron are trademarks of Intel Corporation in the United States and
other countries.
All other product names mentioned herein may be trademarks of their respective companies.
Compaq shall not be liable for technical or editorial errors or omissions contained herein. The
information in this document is provided “as is” without warranty of any kind and is subject to change
without notice. The warranties for Compaq products are set forth in the express limited warranty
statements accompanying such products. Nothing herein should be construed as constituting an
additional warranty.
Compaq service tool software, including associated documentation, is the property of and contains
confidential technology of Compaq Computer Corporation. Service customer is hereby licensed to
use the software only for activities directly relating to the delivery of, and only during the term of,
the applicable services delivered by Compaq or its authorized service provider. Customer may not
modify or reverse engineer, remove, or transfer the software or make the software or any resultant
diagnosis or system management data available to other parties without Compaq’s or its
authorized service provider’s consent. Upon termination of the services, customer will, at
Compaq’s or its service provider’s option, destroy or return the software and associated
documentation in its possession.
Compaq Guide to PC Deployment
Network Installation of Microsoft Windows 2000 Professional on All
Compaq Deskpro EN and Deskpro EX Series of Personal Computers
Using Microsoft Tools
North America First Edition (March 2001)

WHITE PAPER (cont.)
14A4-0201A-USEN
3
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
SCOPE AND ASSUMPTIONS
This Guide provides the following information:
• PC Deployment Process overview
• Distribution Share setup for Windows 2000 Professional, including:
-Operating system-specific configuration
-Hardware-specific configuration
-Value-add software configuration
• Overview of the unattended installation environment for Windows 2000 Professional
• Sample UNATTEND.TXT document
• Sample CMDLINES.TXT document
• Sample TXTSETUP.OEM document
The following assumptions are made in this paper:
• You understand how to create a network boot diskette used to access the Microsoft Windows
2000 Professional distribution share. (Refer to “Network Installation of Microsoft Windows
on Compaq Deskpro EP and Deskpro EN Series of Personal Computers Using the Multi-NIC
Boot Utility,” Document NA141A/1098, located on the Compaq Web site at
http://207.18.199.3/support/techpubs/whitepapers/na141a1098.html.)
• You know what hardware must be supported.
• You can access the Web and download the appropriate SoftPAQs containing the device driver
software from www.compaq.com/support. Instructions for downloading and extracting
SoftPAQs are provided at www.compaq.com/support.
• The deployment team has access to the Microsoft Windows 2000 Professional Resource Kit.
• Each client computer has a licensed copy of Windows 2000 Professional.
PROCESS OVERVIEW,CONVENTIONS,OTHER
DOCUMENTATION
High level overview of the process
The following steps outline the network installation process:
1. Copy the Windows 2000 Professional operating system (and associated Service Packs if
applicable) to a designated location on the server.
2. Create the unattended setup directory structure as shown in Appendix A of this White Paper.
3. Download the appropriate SoftPAQs and run them to extract device drivers into the correct
folders (see hardware component sections of this white paper for more detailed information).
4. Modify the UNATTEND.TXT file as required.
5. Set up a network share for the operating system, device drivers, and other software to be
installed.
6. Boot client computer to the shared network directory.
7. Perform a Remote ROM Flash (optional). Refer to Appendix E for more details.

WHITE PAPER (cont.)
14A4-0201A-USEN
4
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
8. Install the operating system, device drivers and other software from the network.
Conventions
Distribution share refers to the combination of the operating system, 3rd party device drivers and
any value-add software in a centralized location.
servername refers to the name of the server containing the distribution share.
sharename refers to the name of the share established for accessing the distribution share on the
server.
References to Microsoft Documentation
Use the following resources to help you deploy Microsoft Windows 2000 Professional on Compaq
Deskpro Series client systems:
• The Microsoft Windows 2000 Professional Resource Kit. This is very useful for understanding
the deployment strategies described in this paper. It gives specific information on the options
used to automate the installation of Windows 2000 Professional.
• Microsoft’s Knowledge Base, located on the Web at http://support.microsoft.com/support,
contains articles describing known installation issues and solutions.
• Microsoft Windows 2000 Professional Deployment Resource documents, located at
http://www.microsoft.com/windows2000/library/resources/reskit/default.asp.
• Hardware and Software Compatibility List, located on the Web at
http://www.microsoft.com/windows2000/upgrade/compat.
Hard Drive and Hardware Preparation
You should make file system decisions before installing the operating system. Microsoft Windows
2000 Professional supports FAT16, FAT32 and NTFS.
Ensure that all factory-installed Compaq hardware is properly connected in each target computer.
Refer to the hardware documentation included with all Compaq Deskpro Series computers if you
have any questions regarding how the hardware is installed in the system.

WHITE PAPER (cont.)
14A4-0201A-USEN
5
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
DISTRIBUTION SHARE SETUP –WINDOWS 2000
PROFESSIONAL OPERATING SYSTEM
Copy the entire \I386 directory and its subdirectories from the Windows 2000 Professional CD to
the hard disk of the server from which Windows 2000 Professional will be installed. Some
modifications may need to be made to the distribution directory because not all target systems will
require every directory of a distribution directory structure (Refer to Appendix A for layout of the
directory structure). From the target PC, establish a connection to the distribution share and from
within the \I386 directory, use the following command to invoke the installation process:
WINNT /U:\\servername\sharename\I386\$oem$\UNATTEND.TXT
/S:\\servername\sharename\I386
Where
/U[:] refers to an unattended installation using an optional script file (requires /s)
/S[:] refers to the source location of the Windows 2000 Professional files. For example:
WINNT.EXE /u:n:\w2k\I386\$oem$\UNATTEND.TXT /s:n:\w2k\I386
NOTE: For a complete listing of WINNT.EXE and WINNT32.EXE commands, see
Windows 2000 Help. Or, at a command prompt, switch to the \i386 folder on the Windows 2000
product CD, and then type: winnt /? or winnt32 /?
SERVICE PACK 1
To add the files from the Service Pack 1 release to the unattended installation, complete the
following steps:
1. Copy the entire \I386 directory from the Windows 2000 Professional Service Pack 1 CD onto
the distribution share.
NOTE: Since an \I386 folder already exists on the distribution share, you may want to create a
new folder for these files (e.g., \W2KSP1).
2. Move the \W2KSP1 directory into the \\servername\sharename\I386\$oem$\$1 directory. This
will copy this folder down to the local hard drive during the installation process and it will
remain there following setup.
3. Insert the following line in the [GUIRunOnce] section of the UNATTEND.TXT file:
[GUIRunOnce]
SP1=" C:\W2ksp1\i386\update\UPDATE.EXE -u -z -n -o"
Optional: Instead of using the UNATTEND.TXT file, the CMDLINES.TXT file can be used with
the following syntax:
[Commands]
" C:\W2ksp1\i386\update\UPDATE.EXE -u -z -n -o"

WHITE PAPER (cont.)
14A4-0201A-USEN
6
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
MACHINE-SPECIFIC INFORMATION
There are no machine-specific items to configure for Windows 2000 Professional.
INSTALLING PLUG AND PLAY DRIVERS
Since Windows 2000 supports Plug and Play detection, it is relatively easy to install third party
drivers for non-boot devices (Audio, Video, NIC, Chipset, etc.) Refer to the Driver Signing Policy
in Appendix B for more information on how the Windows 2000 operating system selects the
optimal driver for any Plug and Play device.
Steps for integrating Plug and Play Devices
1. In the \$OEM$ subfolder of the distribution share, create a folder (and/or subfolders) for any
Plug and Play drivers and their associated files (catalog, INF and drivers), for example:
\\servername\sharename\I386\$oem$\$1\PnPDrvrs
NOTE: The PnPDrvrs folder can be renamed to reference the specific devices being installed. For
example, you could create a \Drivers\NIC folder for network card drivers and a \Drivers\AUDIO
for sound card drivers.
2. Modify the UNATTEND.TXT file by adding an OEMPNPDRIVERSPATH parameter to
point to the driver files. Using the example from above the following entry would need to be
created:
[Unattended]
OemPreinstall = Yes
OemPnPDriversPath = “PnPDrvrs\Nic;PnPDrvrs\Audio"
NOTE: Setup will add the following in the registry:
%systemdrive% to each of the folder names
path for each subfolder to the Plug and Play device search path
3. Set the OemPreinstall=YES parameter in the [Unattended] section of the UNATTEND.TXT.
INTEGRATING VIDEO DRIVERS
General Process
1. Download each required SoftPAQ to its own directory. For SoftPAQs containing Plug and
Play drivers, execute the SoftPAQ with the –flat switch as a command line option. This will
extract the SoftPAQ out into a flat (single) directory.
2. Copy all of the driver files (INF, CAT and SYS files) from the flat directory into the
distribution share directory (i.e. \\servername\sharename\I386\$oem$\$1\PnPDrvrs).
3. Refer to the Installing Plug and Play Drivers section above to complete the setup for the
driver.

WHITE PAPER (cont.)
14A4-0201A-USEN
7
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
INTEGRATING NETWORK INTERFACE CARD (NIC) DRIVERS
General Process
1. Download each required SoftPAQ to its own directory. For SoftPAQs containing Plug and
Play drivers, execute the SoftPAQ with the –flat switch as a command line option. This will
extract the SoftPAQ out into a flat (single) directory.
2. Copy all of the driver files (INF, CAT and SYS files) from the flat directory into the
distribution share directory (i.e. \\servername\sharename\I386\$oem$\$1\PnPDrvrs).
3. Refer to the Installing Plug and Play Drivers section above to complete the setup for the
driver.
INTEGRATING AUDIO DRIVERS
General Process
1. Download each required SoftPAQ to its own directory. For SoftPAQs containing Plug and
Play drivers, execute the SoftPAQ with the –flat switch as a command line option. This will
extract the SoftPAQ out into a flat (single) directory.
2. Copy all of the driver files (INF, CAT and SYS files) from the flat directory into the
distribution share directory (i.e. \\servername\sharename\I386\$oem$\$1\PnPDrvrs).
3. Refer to the Installing Plug and Play Drivers section above to complete the setup for the
driver.
INTEGRATING CHIPSET DRIVERS
General Process
1. Download each required SoftPAQ to its own directory. For SoftPAQs containing Plug and
Play drivers, execute the SoftPAQ with the –flat switch as a command line option. This will
extract the SoftPAQ out into a flat (single) directory.
2. Copy all of the driver files (INF, CAT and SYS files) from the flat directory into the
distribution share directory (i.e. \\servername\sharename\I386\$oem$\$1\PnPDrvrs).
3. Refer to the Installing Plug and Play Drivers section above to complete the setup for the
driver.
Specific Errata
Intel 8xx Chipset Support
1. Download each required SoftPAQ to its own directory. For SoftPAQs containing Plug and
Play drivers, execute the SoftPAQ with the –flat switch as a command line option. This will
extract the SoftPAQ out into a flat (single) directory.
2. If in Windows, exit to a DOS box and run the setup file with the –a –a switches (example:
“C:\chipset\SETUP.EXE –a –a”. These switches will layout all the chipset INF files in the
“C:\Program Files\Intel\InfInst” directory. All the INF’s will be broken down by chipset
architecture and OS type.
3. Copy all of the required driver files (INF, CAT and SYS files) from the flat directory into the
distribution share directory (i.e. \\servername\sharename\I386\$oem$\$1\PnPDrvrs).

WHITE PAPER (cont.)
14A4-0201A-USEN
8
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
4. Refer to the Installing Plug and Play Drivers section above to complete the setup for the
driver.
Integrating Mass Storage Drivers
Use the following information to install mass storage controllers not included with the Windows
2000 operating system.
1. Create a \TEXTMODE subfolder in the distribution share: \I386\$oem$\Textmode
2. Copy the files supplied by the device vendor to the \I386\$oem$\Textmode folder
3. Copy or create a TXTSETUP.OEM file in the \I386\$oem$\Textmode directory. This file
contains descriptions of all the OEM-supplied drivers listed in this section and includes
instructions on how to install them. This file must exist if the [OEMBootFiles] section exists
in the UNATTEND.TXT file.
4. Add the following lines to the UNATTEND.TXT file:
[Unattended]
ComputerType = “HALDescription", OEM
[OEMBootFiles]
OEMHal.sys
Txtsetup.oem
NOTE: TXTSETUP.OEM and all files listed in it (drivers and/or .INF files) must also be listed in
the [OEMBootFiles] section of the UNATTEND.TXT file.

WHITE PAPER (cont.)
14A4-0201A-USEN
9
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
APPENDIX A
Unattended Setup Environment
To install Windows 2000 Professional on multiple computers across a network, a Distribution
Share directory needs to be created. Distribution directories are the central location of all files
needed for a network install, including all Original Equipment Manufacturer (OEM) additions.
Following is an example of the directory structure of a Distribution Share:
\I386 \$oem$ \Textmode
\$$
\$1
\$1\Pnpdvrs
\drive_letter
Distribution Directory Structure
$oem$
This directory contains the subdirectories needed to support an unattended installation of
applications, drivers, etc. not included on the Windows 2000 Professional retail CD. This directory
can also include the optional file CMDLINES.TXT, which contains a list of commands to be run
during GUI Mode Setup. (Refer to the Windows 2000 Professional Resource Kit for detailed
information).
$oem$\Textmode
This directory contains the hardware-dependent files that Setup Loader and text-mode Setup install
on the destination computer during the Text Mode portion of the Windows 2000 Professional
install. The files for SCSI, Keyboard, Video or Pointing Device Drivers or HALs that are not
included with Windows 2000 Professional retail version must appear in this directory. This
directory should also contain a standard TXTSETUP.OEM file. This file contains pointers to all
the files required to install these components. Only one TXTSETUP.OEM file can exist in this
directory.
NOTE: TXTSETUP.OEM and all files listed in it (HALs and drivers) must also be listed in the
[OEMBootFiles] section of the UNATTEND.TXT file.
$oem$\$$
This directory contains the system files, either new or replacements for retail files, that are copied
to the various subdirectories when Windows 2000 Professional is installed. The structure of this
directory must match the structure of a standard Windows 2000 Professional installation, where
\$oem$\$$ matches \%Windir%, \$oem$\$$\System32 matches \%Windir%\System32, and so on.
For example:
\I386\$oem$\$$\system32\drivers\myscsi.sys
would be copied to:
Winnt\system32\drivers\myscsi.sys

WHITE PAPER (cont.)
14A4-0201A-USEN
10
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
$oem$\$1
This folder is equivalent to the %systemdrive% environment variable. For example, if the
operating system is installed on drive C, \$oem$\$1 would refer back to drive C. The use of this
variable makes it possible to rearrange drive letters without creating errors in applications that
point to a hard-coded drive letter.
$oem$\$1\PnPdrvrs
This folder contains additional Plug and Play drivers not included with the Windows 2000
Professional retail CD. The PnPdrvrs name can be replaced by any eight-character or less name.
NOTE: The $oem$\$1\PnPdrvrs folder replaces the \DISPLAY and \NET folders used in the
Microsoft Windows NT 4.0 distribution share installation.
$oem$\drive_letter
This directory contains a subdirectory structure that is copied during Text Mode Setup to the root
of the corresponding drive in the target computer. Any subdirectory of this directory will be copied
to the local (destination) hard drive and will remain there following the setup process.
Using an Answer File (UNATTEND.TXT)
Answer files are text files that automate user responses to questions during the installation process.
The answer file is specified with the /U:<answer file> option with the winnt or winnt32
command. Any legal file name can be used for an answer file in place of UNATTEND.TXT. An
answer file can be created by editing a copy of the UNATTEND.TXT included on both the
Windows 2000 Professional CD and the Windows 2000 Professional Resource Kit. Refer to the
Resource Kit for more information on creating an answer file.
Using CMDLINES.TXT
This file resides in the $OEM$ directory and is used for installing files included in the $OEM$
subdirectories, including those directories copied down to the local hard drive. By listing the
installation command within the CMDLINES.TXT file, the files will get installed automatically at
the end of the Setup process. IMPORTANT: The installation command must be surrounded by
double quotation marks. ALL machines using the distribution share will execute any command
entered in this file, even if the command doesn’t apply for a particular system (i.e., installing a
video driver).

WHITE PAPER (cont.)
14A4-0201A-USEN
11
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
APPENDIX B
DRIVER SIGNING POLICY AND PLUG AND PLAY DEVICE DRIVERS
If you intend to use any updated drivers, you must first verify that they have a valid signature. If
they do not, the driver being installed will depend on:
§ The driver signing policy you indicate in your answer file.
§ The availability of a compatible signed driver that ships with the operating system.
DriverSigningPolicy
Specifies how non-signed drivers are processed during unattended Setup. Signed drivers have gone
through the Microsoft driver testing and signing process to ensure they are Windows 2000
compatible.
§ Block Setup does not install the non-signed device driver.
§ Warn Setup stops the installation and prompts the user for input before accepting the non-
signed device driver.
§ Ignore Setup continues even if the driver is not signed.
NOTE: Refer to Appendix C for examples of how to set these options in the UNATTEND.TXT.
IMPORTANT: Microsoft strongly advises against using DriverSigningPolicy = Ignore unless
you have fully tested the device driver in your environment and are sure that it works properly.
Using non-signed drivers increases the risk of device driver problems that can affect the
performance or stability of your computer.
If you are using DriverSigningPolicy = Ignore and you attempt to install a newer, unsigned copy of
a driver that is protected by Windows 2000, the policy level is automatically updated to Warn.
For the most up-to-date list of supported hardware, see the Hardware Compatibility List by visiting
the Microsoft Web site at: http://www.microsoft.com/
Your Windows 2000 CD includes a copy of this list (drive:\Support\HCL.TXT) that was accurate
as of the date Windows 2000 was released.
TIPS FOR HARDWARE PREINSTALLATION
The following information is provided to help ensure that the correct Plug and Play device driver
support is selected properly for the devices in your computers.
PnP Devices
If you are installing an updated Windows 2000 driver for a device, but find that the new driver is
not used when Windows 2000 installation is complete, you should:
§ Verify that the driver has a valid signature.
§ Check the ranking of the new driver. For more information on driver ranking, see “How Does
Windows 2000 Select the Correct Driver” below.

WHITE PAPER (cont.)
14A4-0201A-USEN
12
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
§ Check the SETUPAPI.LOG for information on how Windows 2000 processed the driver.
§ To view the SETUPAPI.LOG file, go to %windir%\SETUPAPI.LOG. To expand the
SETUPAPI.LOG file to provide the most information, see “Increasing the Verbosity of the
SETUPAPI.LOG” in Appendix F.
For additional information about SETUPAPI.LOG, see the Microsoft Windows 2000 Device Driver
Kit or visit the Windows Driver and Hardware Development Web site at:
http://www.microsoft.com/hwdev/
How Does Windows 2000 Select the Correct Driver?
To determine which driver is the best one for a device, Windows 2000 ranks the drivers and takes
the driver with the lowest rank. The lower the rank, the better the match to the device. If multiple
drivers have the same rank, the driver with the newest date is chosen.
To determine the rank, Windows 2000 compares the device’s Hardware IDs and Compatible IDs
with the IDs listed in the Models section of the .INF file. The best match for a device is one that
has a Hardware ID match for the first choice Hardware ID specified in the device.
If there is no Hardware ID match:
1. The device’s Hardware ID is compared with Compatible IDs listed in the .INF file.
2. The device’s Compatible IDs are compared with the Hardware IDs in the .INF file.
3. The device’s Compatible IDs are compared with the Compatible IDs listed in the .INF file.
The match in step 3 has the highest rank for the device and, thus, is the worst match.
Generally speaking, it is not important to know the exact rank number of your device because this
may change in future releases. However, it is important to know that the lower the rank, the better
the match of the driver to the device. A driver with the rank of 0 is the best match.
If the ranks for device drivers are equal, Windows 2000 compares the drivers’ dates, which are
located in the DriverVer entry of the .INF file. If an .INF file is not digitally signed, then its
DriverVer entry is ignored and the date is considered 00/00/0000, or worse than any other date.
For more information about how Windows 2000 ranks drivers, see the Microsoft Windows 2000
Device Driver Kit or visit the Windows Driver and Hardware Development Web site at:
http://www.microsoft.com/hwdev/

WHITE PAPER (cont.)
14A4-0201A-USEN
13
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
APPENDIX C
UNATTEND.TXT (Sample file)
; Microsoft Windows 2000 Professional, Server, Advanced Server and Datacenter
; (c) 1994 - 1999 Microsoft Corporation. All rights reserved.
;
; Sample Unattended Setup Answer File
;
; This file contains information about how to automate the installation
; or upgrade of Windows 2000 Professional and Windows 2000 Server so the
; Setup program runs without requiring user input.
[Unattended]
Unattendmode = FullUnattended
OemPreinstall = YES
ComputerType = “Adaptec AIC-78xx PCI SCSI Controller", OEM
DriverSigningPolicy= Warn
ExtendOEMPartition = 0
FileSystem = LeaveAlone
OemFilesPath = “\\servername\sharename\I386”
OemPnPDriversPath = “drivers\audio;drivers\nic”
NtUpgrade = NO
Win9xUpgrade = NO
TargetPath = WINNT
OverwriteOemFilesOnUpgrade = NO
OemSkipEula = YES
[GuiUnattended]
AdminPassword = *
Autologon = Yes
OemSkipWelcome = 1
OEMSkipRegional = 1
TimeZone = "(GMT-06:00) Central Time (US & Canada)"
[UserData]
FullName = "Your User Name"
OrgName = "Your Organization Name"
ComputerName = *
ProductID = "xxxxx-xxxxx-xxxxx-xxxxx-xxxxx"
[Display]
BitsPerPel = 16
XResolution = 800
YResolution = 600
Refresh = 60
[OEMBootFiles]
Txtsetup.oem
Aic78xx.sys
[Networking]
InstallDefaultComponents = YES

WHITE PAPER (cont.)
14A4-0201A-USEN
14
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
[Identification]
JoinWorkgroup=WORKGROUP
JoinDomain=
CreateComputerAccountDomain=
DomainAdmin=
DomainAdminPassword=
[OEM_Ads]
[Data]
UseBIOSToBoot=1
[GUIRunOnce]
WELCOFF="c:\winnt\regedit /s c:\WELC_OFF.REG"
SP1="C:\W2ksp1\i386\update\UPDATE.EXE -u -z -n -o "

WHITE PAPER (cont.)
14A4-0201A-USEN
15
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
APPENDIX C
CMDLINES.TXT (Sample File)
[Commands]
" C:\W2ksp1\i386\update\UPDATE.EXE -u -z -n -o"
"C:\scg\SETUP.EXE -s"
".\regedit /s POWER.REG"

WHITE PAPER (cont.)
14A4-0201A-USEN
16
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
APPENDIX D
TXTSETUP.OEM (Sample File)
[COMPAQ]
[Disks]
d1= "Adaptec 7800 Family Manager Set", \disk1, \
[Defaults]
scsi= OEMSCSI
[scsi]
a78NT40= "Adaptec AIC-78xx PCI SCSI Controller"
[Files.scsi.a78NT40]
driver= d1, aic78xx.sys, AIC78XX
inf= d1, aic78xx.inf

WHITE PAPER (cont.)
14A4-0201A-USEN
17
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
APPENDIX E
Remote ROM Flash
The Remote ROM Flash Utilities SoftPAQ contains utilities to update the system ROM and set the
administrator password for setup without interaction. These can be used either by integrating them into
the boot diskette used to set up new machines or in conjunction with remote setup utilities such as
LCM. For instructions on using these utilities refer to the README.TXT file contained in the SoftPAQ.
The Remote ROM Flash Utilities SoftPAQ can be found on both the Software Support CD and on the
Web at http://www.compaq.com/support/files/desktops/us/index.html located with software for the
machine under the “ROMPaqs and System Software” heading.

WHITE PAPER (cont.)
14A4-0201A-USEN
18
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
APPENDIX F
Additional Enhancements for Distributed Share Installations
NOTE: For additional information on any of these features, reference the Microsoft Windows
2000 Professional Deployment Resource documents located at
http://www.microsoft.com/windows2000/library/resources/reskit/default.asp
Automatically Logging on After an Unattended Installation
AutoLogon
Value: Yes | No
Sets up the computer to automatically log on once with the Administrator account if set to Yes.
The default behavior is No. The key is not valid on upgrades.
Example:
[GUIUnattended]
AutoLogon = YES
NOTE: If you specify a password by using AdminPassword, that password is used when you
automatically log on. After the installation is complete, the password is deleted from the copy of
the answer file left on the computer.
If AdminPassword = * (is blank) and AutoLogon = Yes, the computer logs on only one time.
However, if AdminPassword = <password>, the computer logs on repeatedly and the non-blank
password is saved in the registry.
Suppressing the Welcome Screen When Logging into Windows 2000 Professional
This feature provides the capability to automatically suppress the Welcome screen when logging
into Windows 2000 Professional.
1. Using any text editor, create a file named WELC_OFF.REG and place the file in the
\\servername\sharename\I386\$oem$\C directory of the distribution share
2. Enter the following information in the file:
Windows Registry Editor Version 5.00
[HKEY_CURRENT_USER\Software\Microsoft\Windows\CurrentVersion\Explorer\Tips]
"DisplayInitialTipWindow"=dword:00000000
"Show"=hex:00,00,00,00
"Next"=hex:03,00
3. To insert the information into the registry, add the following lines to the UNATTEND.TXT
file:
[GUIRunOnce]
WELCOFF="c:\winnt\regedit /s c:\WELC_OFF.REG"

WHITE PAPER (cont.)
14A4-0201A-USEN
19
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Using [GUIRunOnce] to Execute Commands After Logging into Windows 2000
Professional
This feature allows Windows 2000 Professional to automatically execute additional commands
(i.e. batch files, Setup installs, etc.) upon logging into the operating system.
[GuiRunOnce]
This section contains a list of commands to be executed the first time a user logs on to the
computer after GUI-mode Setup has completed. Each line specifies a command to be executed by
the GuiRunOnce registry entry. For example:
To install Add this line to [GuiRunOnce]
Domain Controller "dcpromo/answer:<answer file>"
Cluster Service "%windir%\cluster\cluscfg.exe -unattend"
Important Each command line must be in quotes.
Example:
[GUIRunOnce]
WELCOFF="c:\winnt\regedit /s c:\WELC_OFF.REG"
SP1="C:\W2ksp1\i386\update\UPDATE.EXE -u -z -n -o "
Commands run using the GuiRunOnce key run in the context of the currently logged in user. If the
user does not have the permissions necessary to run the command completely, then the application
fails. Because this is run in the context of a logged-in user rather than as a service, the registry
entries that the application creates are written for the current user rather than the default user.
(Default user registry settings are propagated to new users.) If you want any settings and updates to
show only for the specifically logged in user, then this may be appropriate. Otherwise,
Cmdlines.txt is a better approach to running commands and installing applications because it runs
as a system service.
Increasing the Verbosity of the SETUPAPI.LOG
If you need more information than the SETUPAPI.LOG currently provides in its default setting to
help with diagnosing driver selection issues, you can increase verbosity of the logging by using the
following procedures.
To increase the verbosity of SETUPAPI.LOG during GUI-mode Setup
NOTE: This procedure assumes that you are installing Windows 2000 to D:\Winnt and have an
existing “safe build” of Windows 2000 on another partition.
1. Stop the Setup process during the first boot (after Text-mode Setup, before GUI-mode Setup).
If the system is already in GUI-mode Setup, quit and reboot.
2. Boot into the safe mode.
3. Go to the registry hives (files) in D:\Winnt\System32\config and find SOFTWARE.SAV.
4. Run Regedt32. In the Registry Editor, in the HKEY_LOCAL_MACHINE on Local Machine
dialog box, click HKEY_LOCAL_MACHINE.

WHITE PAPER (cont.)
14A4-0201A-USEN
20
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
5. On the Registry menu, click Load Hive.
6. In the Load Hive dialog box, go to D:\Winnt\System32\config\ and click SOFTWARE.SAV.
When prompted for a key name, type _SW.SAV.
7. In the Registry Editor, in the HKEY_LOCAL_MACHINE on Local Machine dialog box,
under HKEY_LOCAL_MACHINE, click _SW.SAV. Find the following key:
HKEY_LOCAL_MACHINE\_SW.SAV\Microsoft\Windows\CurrentVersion\Setup
8. On the Edit menu, click Add Value and provide the following:
Value Name: LogLevel
Data Type: REG_DWORD
9. Then click OK.
10. For this value, set the Data as 0xFF00 or 0xFFFF to enable full verbose logging.
11. In the HKEY_LOCAL_MACHINE on Local Machine dialog box, under
HKEY_LOCAL_MACHINE, click _SW.SAVIN. Then, on the Registry menu, click
Unload Hive. The file _SW.SAV should disappear from the HKEY_LOCAL_MACHINE
data.
12. Copy D:\Winnt\System32\config\SOFTWARE.SAV to D:\Winnt\System32\config\software.
13. Reboot and continue Setup.
