White Paper
Document number PRT009A1098
Publication date: November 1998
PRT009A1098
Prepared by Software Product
Marketing
Compaq Computer Corporation
Introduction .................................3
Installation Requirements
and Dependencies.......................3
Installation Scripts ......................5
Installation of Compaq
Drivers and Enhancements......12
Appendix 1: Downloading
Software from the Compaq
Website.......................................22
Appendix 2: Using the
SoftPaq Utility............................23
Appendix 3: Installing
Diagnostics and Setup..............24
Appendix 4: Determining
your ROM Version and
Upgrading if Needed .................25
Appendix 5: Docking for the
first time.....................................27
Installing Microsoft Windows NT
Workstation 4.0 on Compaq
Armada Products
Abstract: This white paper focuses on the steps necessary for the
successful installation of Microsoft Windows NT Workstation (NTW)
4.0 with Service Pack 3 on Compaq Armada Portable Products. The
steps outlined provide you with complete installation procedures and
work regardless of the currently installed operating system.
For details on Compaq’s overall operating system strategy,
operating system features, and the installation of additional Service
Packs, please refer to the white paper titled “Operating System
Support for Compaq Portable Platforms.”
This document is intended for Compaq personnel and customers
needing information on installing Microsoft NT Workstation 4.0 on
selected Compaq Armada portable products.

Installing Microsoft Windows NT Workstation 4.0 on Compaq Armada Products 2
Document number PRT009A1098
Notice
The information in this publication is subject to change without notice and is provided “AS IS” WITHOUT
WARRANTY OF ANY KIND. THE ENTIRE RISK ARISING OUT OF THE USE OF THIS
INFORMATION REMAINS WITH RECIPIENT. IN NO EVENT SHALL COMPAQ BE LIABLE FOR
ANY DIRECT, CONSEQUENTIAL, INCIDENTAL, SPECIAL, PUNITIVE OR OTHER DAMAGES
WHATSOEVER (INCLUDING WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS
PROFITS, BUSINESS INTERRUPTION OR LOSS OF BUSINESS INFORMATION), EVEN IF
COMPAQ HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
The limited warranties for Compaq products are exclusively set forth in the documentation accompanying
such products. Nothing herein should be construed as constituting a further or additional warranty.
This publication does not constitute an endorsement of the product or products that were tested. The
configuration or configurations tested or described may or may not be the only available solution. This test
is not a determination or product quality or correctness, nor does it ensure compliance with any federal
state or local requirements.
Product names mentioned herein may be trademarks and/or registered trademarks of their respective
companies.
Compaq, Fastart, Compaq Insight Manager, LTE, ROMPaq, LicensePaq, SmartStart, NetFlex, RemotePaq,
BackPaq, TechPaq, SpeedPaq, QuickBack, PaqFax, SmartStation, MiniStation, and PaqRap, registered
United States Patent and Trademark Office.
Netelligent, Armada, Cruiser, Concerto, Net1, LTE Elite, SoftPaq, FirstPaq, SolutionPaq, EasyPoint, are
trademarks and/or service marks of Compaq Computer Corporation.
Microsoft, Windows, Windows NT, Windows NT Server and Workstation, Microsoft SQL Server for
Windows NT are trademarks and/or registered trademarks of Microsoft Corporation.
NetWare and Novell are registered trademarks and intraNetWare, NDS, and Novell Directory Services are
trademarks of Novell, Inc.
Pentium is a registered trademark of Intel Corporation.
Copyright ©1998 Compaq Computer Corporation. All rights reserved. Printed in the U.S.A.
Installing Microsoft Windows NT Workstation 4.0 on Compaq Armada Products
White Paper prepared by Software Product Marketing
First Edition (November 1998)
Document Number PRT009A1098

Installing Microsoft Windows NT Workstation 4.0 on Compaq Armada Products 3
Document number PRT009A1098
Introduction
This white paper discusses installing Microsoft Windows NT Workstation (NTW) 4.0 with
Service Pack 3 (SP 3) on Compaq Armada portable products. This white paper provides step by
step instructions for the installation process. When you have completed all of the procedures
outlined for your specific platform, you will have successfully installed Windows NTW and all
Compaq provided software deliverables to extend functionality and enhance the overall user
experience.
Installation Requirements and
Dependencies
Before beginning the installation scripts for any of the platforms, obtain the items listed below.
The following items can be obtained directly from Microsoft:
•Microsoft Windows NTW 4.0 CD and the three setup diskettes
•Microsoft Windows NTW Service Pack 3 CD
•Microsoft MS-DOS v6.22 Boot Disk with FDISK utility
The following items can be obtained from Compaq:
•The latest Compaq Support Software CD containing all updated drivers and deliverables needed in the
section, “Installation of Compaq Drivers and Enhancements.” The Compaq Support Software CD is
updated monthly and is available either via an annual subscription or as a one-time purchase. The user
interface mirrors the Compaq Website.
Alternatively, all files may be obtained from the Compaq Website at
http://www.compaq.com/support/files/portables/us/index.html.See Appendix 1, “Downloading Software
from the Compaq Website” for instructions on using the Compaq Website if you are unfamiliar with
obtaining SoftPaqs.
•You must obtain the latest version of the drivers and enhancements that are compatible with Windows
NTW. Previous versions may not work or may produce anomalies.
Alternatively, you may use the Compaq Software CD. However, many of these drivers and
enhancements have been updated. Therefore, Compaq strongly suggests you obtain the latest versions
from the current Compaq Support Software CD or the Compaq Website before you begin these
installation procedures.
•The most current available ROM for your platform. See Appendix 4, “Determining your ROM Version
and Upgrading if Needed” for information on determining your current ROM version and how to
update if necessary.
•A blank, high-density floppy diskette if you choose to make the recommended Emergency Rescue
Diskette.
NOTE: You must back up all data and applications prior to installing Microsoft NTW.

Installing Microsoft Windows NT Workstation 4.0 on Compaq Armada Products 4
Document number PRT009A1098
Terms and Assumptions
•Secondary-click - The term secondary-click is used throughout the scripts. For right-handed mouse
users, this is the right mouse button. For left-handed mouse users, this is the left mouse button.
•Drive Letters – All drive letters used for hard drives and CD-ROM drives are examples only. Your
individual configuration may make the examples incorrect. For example, you are told to click CD-
ROM drive D: when actually your CD-ROM drive letter is E:.
•Drivers and Enhancement File Locations – Most drivers and enhancements are assumed to be in the
directory C:\~COMPAQ\XXXXXXXX where XXXXXXXX is the subdirectory name created by the
SoftPaq utility for these scripts. See Appendix 2, “Using the SoftPaq Utility” if you are not familiar
with the SoftPaq utility and how to extract files from them. One possible exception is the Real Mode
CD-ROM drivers that may be on diskette, normally the A: drive.
•Restarting the Computer – During the Windows NTW installation, and the installation of several
drivers and enhancements, you are prompted to restart the computer. Please ensure that you have
removed any floppy diskettes from the diskette drive and the Windows NTW disc from the CD-ROM
drive as applicable before restarting the computer.
•Real Mode CD-ROM Drivers – Depending upon your platform, these can be found on the Web, either
under Windows 3.1, Windows 95 or Windows 98. They will be listed as either “IDE CD-ROM
Drivers” under the Storage section or as “Real Mode Support” under the Utilities section.
•When the term Web is used, it is synonymous with the
www.compaq.com/support/files/portables/us/index.html, the Support Software CD, the Compaq BBS,
or the Compaq FTP site. It is important that you obtain the latest Windows NTW compatible drivers
and enhancements from one of these sites.
•Instructions for using the Compaq Website and Compaq SoftPaqs are located in the appendices at the
end of this document.
NOTE: Attempt the installation of Windows NTW only while on AC Power. This prevents the unit from
abruptly shutting down if it runs out of battery power, which could corrupt the installation.

Installing Microsoft Windows NT Workstation 4.0 on Compaq Armada Products 5
Document number PRT009A1098
Installation Scripts
NTW Installation – Armada 1500, 4100, & 4200 Families
1. Prior to installing Windows NTW, the original operating system should be removed from the system.
To remove the original operating system, boot the system with an MS-DOS v6.22 Boot Disk. Next,
delete the all DOS partitions using the FDISK utility. If you are unsure how to use the FDISK
program, refer to the Microsoft KB article Q76802 for instructions. This article may be found online at
http://support.microsoft.com/support/kb/articles/q76/8/02.asp.
CAUTION: Do not delete the Non-DOS partition that contains Compaq Diagnostics and Setup/P.
2. Restart the system with the first NTW Setup Disk inserted into the diskette drive and the NTW CD
inserted into the CD-ROM drive. Windows NTW reads the entire contents of the first disk into
memory and prompts you for the second NTW setup disk.
3. Insert Setup Disk Two per the instructions and press Enter. The ‘Welcome to Setup’ screen is
displayed.
4. Press Enter. The next screen describes how Setup automatically detects the computer’s standard
controllers.
5. Press Enter. You are prompted for NTW Setup Disk Three.
6. Insert disk three into the drive and press Enter to continue. You are informed that an IDE CD-ROM
(ATAPI 1.2)/PCI IDE Controller has been found.
7. Press Enter. The Windows NTW Licensing Agreement displays.
8. Read through the agreement by pressing PgDn, then press F8 to agree to accept the terms of the
Licensing Agreement. Setup displays any hardware that is detected.
9. Press Enter to display a list of hard drive partitions upon which to install the operating system.
If you are not familiar with hard drive partitioning schemes, see the File Systems and their use on
Compaq Armada Portable Products white paper. For additional information, see Chapter 5 of your
Windows NT Workstation manual, “Beginning Installation.”
10. Select the 2nd option, Unpartitioned space, and press Enter.
1See Appendix 5, “Docking for the First Time” for information on docking your Armada Portable for the first time.
NOTE: Make sure that the system is undocked (Standalone) and there are no PC Cards in the
PCMCIA slots when installing the operating system.1

Installing Microsoft Windows NT Workstation 4.0 on Compaq Armada Products 6
Document number PRT009A1098
11. Select the best file system for your applications, then press Enter. If you are unsure which file system
to select, contact your IT department or choose the FAT file system2.
12. If you choose FAT and the partition is larger than 2-GB, you are prompted that the size exceeds the
amount supported by MS-DOS. You can return to the previous menu and create a 2-GB or smaller
partition upon which to install the operating system. To do so:
a. Press Esc to return to the disk partitioning menu.
b. Highlight ‘Unpartitioned space’ and press C.
c. Enter the number of the partition you wish to create, then press Enter.
d. Highlight ‘C: New (Unformatted)’ and press Enter. The hard drive is formatted4.
13. Select the directory where the operating system will be installed by typing the appropriate directory
name, then pressing Enter. It is recommended that the default directory of \WINNT be selected.
14. Press Enter to examine the hard disk for corruption, or Esc to skip the examination. It is recommended
that you allow Setup to perform this step.
15. The system copies files from the NTW CD to the hard drive. This takes several minutes.
16. Remove the floppy disk from the diskette drive and press Enter to restart the computer.
15. After the computer restarts, the graphical portion of Setup loads and additional files are copied to the
hard drive.
16. The Setup Wizard gathers information about the hardware. Click Next.
17. Select the type of installation is to be performed. If you are unsure which type of installation to select,
contact your IT department or choose PORTABLE, then click Next.
18. Enter your name and, if desired, tab to the organization field and enter your company name. Click
Next.
18. Enter the Product Key that came with your Windows NTW documentation, Certificate of Authenticity.
Click Next.
19. Enter the computer name:
a. This name must be unique on the network.
b. The name can be up to 15 characters but should not include spaces.
c. If you are unsure what to name your computer, contact your IT department.
d. Enter the name and click Next to continue.
2FAT partitions are limited to 4-GB under Windows NT Workstation and 2-GB for MS-DOS compatibility. You may need to redo
step 11 and create a smaller partition. For more information on file systems, you may refer to the White Paper “File Systems and Their
Use on Compaq Armada Portable Products.” For additional information also refer to Chapter 5 – Beginning Installation in your
Windows NT Workstation manual.
3If you choose to use NTFS, ensure that you use version 2.0F or later of F10 Setup/P.
4If you choose NTFS, the hard drive is formatted with FAT and converted on the next restart.
NOTE: The FAT file system can be converted to NTFS3at a later time. If you select NTFS as your file
system, it can only be changed to a FAT file system on the drive by reformating the hard drive and
reinstalling the operating system

Installing Microsoft Windows NT Workstation 4.0 on Compaq Armada Products 7
Document number PRT009A1098
20. Select an Administrator password:
a. Enter, then reenter the password.
CAUTION: If you forget this password before setting up additional user accounts, the operating
system will have to be reinstalled.
b. Click Next.
21. You are asked if you want to create an Emergency Repair Disk. It is highly recommended that you
make an Emergency Repair Disk.
22. Select the operating system components you want to install, then press Next.
The Installing Windows NTW Network screen is displayed.
23. Click Next. You are asked if you are on a network and if so, how you will be accessing the network.
Since no two network setups are the same, it is highly recommended that you do not set up any
networking components. You should contact your Network Administrators and have them properly set
up the networking portions of NTW.
24. Choose ‘Do not connect this computer to a network at this time’ and click Next.
25. This phase is complete. Click Finish to continue the setup procedure.
26. Verify that the Date and Time are correct and choose the proper Time Zone, then click Close.
27. Verify that your video adapter was properly detected, then click OK.
28. Click Test and OK to test the defaults. A multicolor graphic is displayed for several seconds.
29. You are asked if the graph appeared correctly. Answer Yes, then click OK twice to continue setup.
30. Various files are copied from the CD to the hard drive.
31. If you chose to make an Emergency Repair Disk, the configuration is saved and you are prompted to
insert a floppy disk. Choose OK to make the Emergency Repair Disk.
32. You are prompted to restart the system. Be sure you have removed any diskettes from the diskette
drive.
NOTE: If passwords do not match, you will be prompted to reenter them until they do.
NOTE: You can create additional Emergency Repair Disks after the installation is complete by
running the RDISK program.
NOTE: If you are unsure, install the most common components.
NOTE: You will update the video drivers in the “Installation of Compaq Drivers and
Enhancements” section so no changes are necessary at this time.

Installing Microsoft Windows NT Workstation 4.0 on Compaq Armada Products 8
Document number PRT009A1098
The Windows NTW installation is complete. Proceed to “Installing Service Pack 3 from CD.”
After installing Service Pack 3, see “Installing Compaq Drivers and Enhancements” to install the
additional drivers and support.
NTW Installation – Armada 1700, 3500, 6500, and 7000
Families
Prior to installing Windows NTW, the original operating system should be removed from the
system. To remove the original operating system:
1. Boot the system with an MS-DOS v6.22 Boot Disk.
2. Delete all DOS partitions using the FDISK utility. If you are unsure how to use the FDISK program,
refer to Microsoft’s KB article Q76802 for instructions. This article may be found online at
http://support.microsoft.com/support/kb/articles/q76/8/02.asp.
CAUTION: Do not delete the Non-DOS partition that contains Compaq Diagnostics and Setup/P.
Armada 6500 and 7000 Family users should now power off the system, swap the diskette drive
for the CD-ROM drive and then restart the computer.6
To install Windows NTW:
1. Restart the system with the NTW CD inserted into the CD-ROM drive. The computer boots from the
NTW CD and the system reads several files into memory.
2. Press Enter when the ‘Welcome to Setup’ screen displays.
3. You are informed that an IDE CD-ROM (ATAPI 1.2)/PCI IDE Controller has been found. Press Enter.
4. If you receive an informational screen that Setup has determined that your hard drive has more than
1024 cylinders, press Enter. The Windows NTW Licensing Agreement displays.
5. Read through the agreement by pressing PgDn.
6. Press F8 to accept the Licensing Agreement. Setup displays the hardware that is detected.
7. Press Enter. A list of hard drive partitions upon which to install the operating system is displayed.
For customers not familiar with hard drive partitioning schemes, please refer to the White Paper titled
“File Systems and Their Use on Compaq Armada Portable Products.” For additional information also
refer to Chapter 5 - Beginning Installation in your Windows NT Workstation manual.
8. Select the 2nd option, ‘Unpartitioned space’ then press Enter.
5See Appendix 5, “Docking for the First Time” for information on docking your Armada Portable for the first time.
6See your documentation if unsure how to swap the diskette drive for the CD-ROM drive.
NOTE: You must install all drivers for your system to have complete functionality.
NOTE: Make sure that the system is undocked (Standalone) and there are no PC Cards in the
PCMCIA slots when installing the drivers.5

Installing Microsoft Windows NT Workstation 4.0 on Compaq Armada Products 9
Document number PRT009A1098
9. Select the best file system for your applications, then press Enter. If you are unsure which file system
to select, contact your IT department or choose the FAT file system7.
10. If you choose FAT and the partition is larger than 2-GB, you are prompted that the size exceeds the
amount supported by MS-DOS. You can return to the previous menu and create a 2-GB or smaller
partition upon which to install the operating system. To do so:
a. Press Esc to return to disk partitioning menu.
b. Highlight ‘Unpartitioned space’ and press C.
c. You will then be asked to enter the size of the partition you wish to create. Enter that number and
then press Enter.
d. Highlight ‘C: New (Unformatted)’ and press Enter.
The hard drive is formatted9.
11. Select the directory where the operating system will be installed, then press Enter. It is recommended
that the default directory of \WINNT be selected.
12. Press Enter to examine the hard disk for corruption (recommended) or Esc to skip the examination.
13. Allow the system to copy files from the NTW CD to the hard drive. This takes several minutes.
14. Remove any floppies and CDs from the drives when prompted.
15. Press Enter to restart the computer.
16. Re-insert the NTW CD at the boot menu. The graphical portion of Setup loads, and additional files are
copied to the hard drive.
17. Allow the Setup Wizard to gather information about the hardware, then click Next.
18. Select the type of installation to perform, then click Next.
If you are unsure which type of installation to select, contact your IT department or choose
PORTABLE.
19. Enter your name and, if desired, tab to the organization field and enter your company name, then click
Next.
20. Enter the Product Key that came with your Windows NTW documentation, Certificate of Authenticity,
then click Next.
21. Enter the computer name, then click Next.
a. This name must be unique on the network.
b. The name can be up to 15 characters but should not include spaces.
c. If you are unsure what to name your computer, contact your IT department.
7FAT partitions are limited to 4-GB under Windows NT Workstation and 2-GB for MS-DOS compatibility. You may need to redo
step 11 and create a smaller partition. For more information on file systems, you may refer to the White Paper “File Systems and Their
Use on Compaq Armada Portable Products.” For additional information also refer to Chapter 5 – Beginning Installation in your
Windows NT Workstation manual.
8If you choose to use NTFS, ensure that you use version 2.0F or later of F10 Setup/P.
9If you choose NTFS, the hard drive is formatted with FAT and converted on the next restart.
NOTE: The FAT file system can be converted to NTFS8at a later time if you choose to do so. If you
select NTFS as your file system, the only way to again have a FAT file system on the drive would be
to reformat the hard drive and reinstall the operating system.

Installing Microsoft Windows NT Workstation 4.0 on Compaq Armada Products 10
Document number PRT009A1098
22. Select an Administrator password:
a. Enter, then reenter the password.
CAUTION: If you forget this password before setting up additional user accounts, the operating
system will have to be reinstalled.
23. You are asked if you want to create an Emergency Repair Disk. It is highly recommended that you
make an Emergency Repair Disk. Armada 6500 and 7000 Family users will not be able to accomplish
this step during Setup as there is no floppy drive in the system. You can create additional Emergency
Repair Disks after the installation is complete by running the RDISK program.
24. Select the operating system components to be installed, then click Next.
The Installing Windows NTW Network screen displays.
25. Click Next. You are asked if you are on a network and if so, how you will be accessing the network.
Since no two network setups are the same, it is recommended that you not set up any networking
components. You should contact your Network Administrators and have them properly setup the
networking portions of NTW.
26. Choose ‘Do not connect this computer to a network at this time’ and click Next.
27. This phase is complete. Click Finish to continue the setup procedure.
28. Verify that the Date and Time are correct and choose the proper Time Zone, then click Close.
29. Click OK when the screen displays ‘VGA compatible display adapter’ has been detected.
30. Click OK on the ‘Display Properties’ tab.
31. Various files are copied from the CD to the hard drive.
32. If you chose to make an Emergency Repair Disk, the configuration is saved and you are prompted to
insert a floppy disk. Choose OK to make the Emergency Repair Disk.
33. You will be prompted to restart the system. Be sure to remove the NTW disc from the CD-ROM
drive before restarting the computer.
The Windows NTW installation is complete. Proceed to “Installing Service Pack 3 from CD.”
After installing Service Pack 3, see “Installation of Compaq Drivers and Enhancements” to install
the additional drivers and support software.
NOTE: If you are unsure, install the most common components.
NOTE: You will update the video drivers in the “Installation of Compaq Drivers and Enhancements”
section, so no changes are necessary at this time.
NOTE: You must install all drivers for your system to have complete functionality.

Installing Microsoft Windows NT Workstation 4.0 on Compaq Armada Products 11
Document number PRT009A1098
Installing Service Pack 3 from CD
1. Log on to the system as Administrator.
2. Click OK to close the Tip window.
3. Insert the Windows NTW Service Pack 3 CD into the CD-ROM drive. Internet Explorer starts
automatically and displays the initial installation screen.
4. Click ‘Install Service Pack 3 for Windows NT 4.0’ to start the installation. A Confirm File Open dialog
box appears.
5. Choose OPEN to continue.
6. Click Next from the Welcome screen.
7. Read the Software License Agreement and click Yes to accept the terms.
8. Click Next to install the Service Pack from the Service Pack Setup screen.
9. It is highly recommended that you choose to create an Uninstall Directory. Make the appropriate
choice and click Next to continue.
10. Click Finish to install Service Pack 3 and wait while the files are copied from the CD to the hard drive.
11. Read the ‘Windows NT Service Pack Setup’ screen then click OK.
12. The system reboots.
NOTE: If at anytime, you change the configuration of your system including adding or
removing any NTW components, you must reapply the Service Pack and the Windows NTW 4.0
Support Diskette (installed in the Installation of Compaq Drivers and Enhancements section).
You should also update the Emergency Repair disk after ensuring the configuration is correct.

Installing Microsoft Windows NT Workstation 4.0 on Compaq Armada Products 12
Document number PRT009A1098
Installation of Compaq Drivers and
Enhancements
Table 1 lists the necessary drivers and enhancements, available as of the publication of this white
paper. You should always check the Compaq Website for the complete, up-to date list of
available drivers and enhancements. The most current SoftPaq file name, as of the publication of
this white paper, is also listed. Instructions for obtaining these SoftPaqs may be found in
Appendix 1, “Downloading Software from the Compaq Website.” After obtaining the necessary
files for your Armada portable, proceed to the installation instructions for each deliverable.
Important Notes
•Make sure that the system is undocked (Standalone) and there are no PC Cards in the PCMCIA slots
when installing the drivers.10
•Any first step which begins with ‘Double-click SETUP’ assumes that you have used ‘My Computer’
or Explorer to navigate to the directory where the files are located after having been extracted from the
SoftPaq.
•These SoftPaq numbers are the minimum required for Windows NT Workstation. They may be
superceded as noted on the Compaq Website.
•Since no two network setups are the same, it is highly recommended that you do not set up any
networking components. You should contact your Network Administrators and have them properly set
up the networking portions of Windows NT Workstation.
•It is strongly recommended that after all of the additional software programs and drivers have been
installed, you update the Emergency Repair Disk by running the RDISK program.
Table 1. Compaq Driver and Enhancement SoftPaqs for Windows NT Workstation
Family Driver/Enhancement SoftPaq #
Armada 1500 C&T 68554 Video Drivers SP5487
CardWare SP5443
Compaq 336 Series Modem INF File SP3655
Compaq 560CL Telephony Modem Driver SP6469
Diagnostics SP5644
Display Support SP3168
ESS Audio Drivers SP5655
Insight Management Agents SP5167
Intel Ethernet Drivers SP7129
Netflex-3 Ethernet Drivers SP2978
Power Management SP5490
Programmable Keys SP5414
Security32 SP5628
Support Software SP4768
continued
10 See Appendix 5, “Docking for the First Time” for information on docking your Armada Portable for the first time.

Installing Microsoft Windows NT Workstation 4.0 on Compaq Armada Products 13
Document number PRT009A1098
Table 1. Compaq Driver and Enhancement SoftPaqs for Windows NT Workstation
(continued)
Family Driver/Enhancement SoftPaq #
Armada 1700 C&T 65555 Video Drivers SP7222
CardWare SP7223
Compaq 560VL Telephony Modem Driver SP7447
Diagnostics SP7237
ESS 1869 Audio Drivers SP7248
Insight Management Agents SP6573
Intel Ethernet Drivers SP7129
Netflex-3 Ethernet Drivers SP6599
Power Management SP7266
Programmable Keys SP7176
Security32 SP7191
System Enhancements SP7281
Armada 3500 C&T Video Drivers SP8327
CardWare SP8328
Diagnostics SP8342
ESS1869 Audio Drivers SP7248
Insight Management Agents SP7393
Intel Ethernet Drivers SP7129
Netflex-3 Ethernet Drivers SP6599
Power Management SP8355
Programmable Keys SP7176
Security32 SP8086
System Enhancements SP7281
Armada 4100 CardWare SP5443
Cirrus Logic 7543/7548 Video Driver SP2057
ESS 688/1688/1788 Audio Drivers SP2354
Ethernet Drivers SP2761
Insight Management Agents SP3695
Programmable Keys SP2787
Supplemental Programs SP2759
Armada 4200 C&T 68554 Video Driver SP5487
CardWare SP5443
ESS 187x Audio Drivers SP6423
Ethernet Drivers SP5387
Diagnostics SP4911
Insight Management Agents SP5399
MultiBay Support SP5504
continued

Installing Microsoft Windows NT Workstation 4.0 on Compaq Armada Products 14
Document number PRT009A1098
Table 1. Compaq Driver and Enhancement SoftPaqs for Windows NT Workstation
(continued)
Family Driver/Enhancement SoftPaq #
Armada 4200
(continued) Power Management SP5490
Programmable Keys SP5414
Security 32 Support SP5429
Armada 6500 ATI Video Driver SP8208
ESS Audio Driver SP8201
ESS Audio Rack 32 Driver SP8203
IDE CD-ROM Driver SP8200
CardWare SP8204
Plug and Play Management Driver SP8206
Power Management SP8205
Armada 7300/7700 CardWare SP5443
Diagnostics SP4911
External Display Configuration Utility SP4840
ESS 1878 Audio Drivers SP4767
Insight Management Agents SP5167
Modem Information File SP3716
MultiBay Support SP5834
Netflex-3 Ethernet Drivers SP2978
Power Management SP5490
Programmable Keys SP5414
S3 Display Drivers SP6301
Security 32 Support SP6284
Support Software SP4768
Armada 7400/7800 CardWare SP6656
Compaq Series II Modem Driver SP6471
Diagnostics SP6700
External Display Configuration Utility SP6586
ESS 1879 Audio Drivers SP6671
Insight Management Agents SP6573
MultiBay Support SP6685
Netflex-3 Ethernet Drivers SP6599
Power Management SP6686
Programmable Keys SP5414
S3 M5 Video Drivers SP6672
Security 32 Support SP6284
System Enhancements SP6670

Installing Microsoft Windows NT Workstation 4.0 on Compaq Armada Products 15
Document number PRT009A1098
Installing the C & T 68554 Video Driver (1540, 1560, 1570, 1571, 1573,
1590, 1592, 1598, 4210, & 4220)
1. Secondary-click on an open area of the desktop and select ‘Properties’.
2. Click on the ‘Settings’ tab.
3. Click on ‘Display Type’.
4. Click Change.
5. Click on ‘Have Disk’.
6. Enter the path to the video driver extracted from the SoftPaq, then click OK.
7. Click OK to select the highlighted ‘Chips Video Accelerator (64300/10 65535/40/45/48/50/54/55)’.
You are told that you are installing a third-party driver.
8. Click YES. The necessary drivers are installed.
9. Click OK on the successful installation dialog.
10. Click Close to close the ‘Change Display type’ and ‘Display Properties’ windows.
11. Click YES to restart the system.
12. After the system reboots and you log on, you are shown that you have installed a new graphics driver.
Click OK to close this dialog and OK again to close the ‘Display Properties’ window.
Installing the C & T NT 4.0 Video Driver
1. Secondary-click on an open area of the desktop and select ‘Properties’.
2. Click the ‘Settings’ tab.
3. Click ‘Display Type’.
4. Click CHANGE.
5. Click ‘Have Disk’.
6. Enter the location of the video driver ‘C:\~COMPAQ\VIDEO’ and click OK.
7. Click on OK to select the highlighted ‘Chips Video Accelerator (64300/10 65535/40/45/48/50/54/55)’.
You are told that you are installing a third-party driver.
8. Click YES. The necessary drivers are installed.
9. Click OK on the successful installation dialog.
10. Click Close to close the ‘Change Display type’ and ‘Display Properties’ windows.
11. Click YES to restart the system.
12. After the system reboots and you log on, you are shown that you have installed a new graphics driver.
Click OK to close this dialog and OK again to close the ‘Display Properties’ window.
Installing Display Support or Cirrus Logic 7543/7548
Video Driver (1510, 1520, 1530, 1535, 1550, 1580, 1585, & 4100 Family)
1. Secondary-click on an open area of the desktop and select ‘Properties’.
2. Click the ‘Settings’ tab.
3. Click ‘Display Type’.
4. Click Change.

Installing Microsoft Windows NT Workstation 4.0 on Compaq Armada Products 16
Document number PRT009A1098
5. Click ‘Have Disk’.
6. Enter the location where the video driver was extracted to from the SoftPaq and then click OK.
7. Click OK to select the highlighted ‘Cirrus Logic CL-GD 754x 1.40E Graphics Adapter’. You are told
that you are installing a third-party driver.
8. Click YES. The necessary drivers are installed.
9. Click OK on the successful installation dialog.
10. Click Close to close the ‘Change Display type’ and ‘Display Properties’ windows.
11. Click YES to restart the system.
12. After the system reboots and you log on, you are shown that you have installed a new graphics driver.
Click OK to close this dialog and OK again to close the ‘Display Properties’ window.
Installing the ATI Video Driver
1. Secondary-click on an open area of the desktop and select ‘Properties’.
2. Click the ‘Settings’ tab.
3. Click ‘Display Type’.
4. Click CHANGE.
5. Click ‘Have Disk’.
6. Enter the location of the video driver ‘C:\~COMPAQ\VIDEO’ and click OK.
7. A list of ATI graphics accelerators is displays. Select the one you are using, then click OK.
8. Click YES. The necessary drivers are installed.
9. Click OK on the successful installation dialog.
10. Click Close to close the ‘Change Display type’ and ‘Display Properties’ windows.
11. Click YES to restart the system.
12. After the system reboots and you log on, you are shown that you have installed a new graphics driver.
Click OK to close this dialog and OK again to close the ‘Display Properties’ window.
Installing the Display Driver Support
1. Secondary-click on an open area of the Windows desktop and select ‘Properties’.
2. Click the ‘Settings’ tab.
3. Click ‘Display Type’.
4. Click CHANGE.
5. Click ‘Have Disk’.
6. Enter the location of the video driver ‘C:\~COMPAQ\VIDEO_NT4’ and click OK.
7. Highlight ‘7548’ then click OK.
8. Highlight ‘Cirrus Logic CL-GD 754x 1.40 Graphics Adapter’ and click OK. You are told that you are
installing a third-party driver.
9. Click YES. The necessary drivers are installed.
10. Click OK on the successful installation dialog.
11. Click Close to close the ‘Change Display type’ and ‘Display Properties’ windows.

Installing Microsoft Windows NT Workstation 4.0 on Compaq Armada Products 17
Document number PRT009A1098
12. Click YES to restart the system.
13. After the system reboots and you log on, you are shown that you have installed a new graphics driver.
Click OK to close this dialog and OK again to close the ‘Display Properties’ window.
Installing the S3 Display Driver
1. Secondary-click on an open area of the Windows desktop and select ‘Properties’.
2. Click the ‘Settings’ tab.
3. Click ‘Display Type.’
4. Click CHANGE.
5. Click ‘Have Disk’.
6. Enter the location of the video driver ‘C:\~ COMPAQ\VIDEO’ and click OK.
7. Click OK to select the highlighted ‘S3 Incorporated Display Driver v1.02.21.’ You are then told that
you are installing a third-party driver.
8. Click YES to proceed. The necessary drivers are installed.
9. Click OK on the successful installation dialog.
10. Click Close to close the ‘Change Display type’ and ‘Display Properties’ windows.
11. Click YES to restart the system.
12. After the system reboots and you log on, you are shown that you have installed a new graphics driver.
Click OK close this dialog and OK again to close the ‘Display Properties’ window.
Installing the Windows NT Display Refresh Utility
1. Open an Explorer window and highlight the C:\~COMPAQ\REFRESH directory.
2. Locate the file S3_M1.INF and secondary-click it.
3. Highlight and click INSTALL to add a Compaq tab in the ‘Display Properties’ to control the refresh
rates.
Installing the NonDDC Monitor Configuration
1. Double-click SETUP in the C:\~COMPAQ\CRTCFG directory.
2. Click Next from the Welcome screen.
3. Click OK to restart the computer.

Installing Microsoft Windows NT Workstation 4.0 on Compaq Armada Products 18
Document number PRT009A1098
Installing CardWare11
1. Double-click SETUP in the directory where CardWare was extracted from the SoftPaq.
2. Click Next from the ‘Welcome to CardWare’ setup screen.
3. Ensure that there are no PC Cards currently in the system, then click Next.
4. Confirm the directory choice, then click Next.
5. Ensure the correct Compaq family is highlighted and the ‘Express’ option is selected. Click Next.
6. Click Finish and allow the computer to restart.
Installing the Compaq 336 Series Modem INF (1510, 1520,1530,
1535, 1540, 1550,1580, 1585, 1590)
1. Select Start →Settings →Control Panel.
2. Double-click the Modem icon.
3. Highlight ‘Don’t detect my modem’ and click Next.
4. Click ‘Have Disk’.
5. Enter the location where the modem INF file was extracted to from the SoftPaq and click OK.
6. Choose Next to select ‘Compaq Armada 1500 Series 336 Telephony Modem’.
7. Highlight COM2 and click Next.
8. Check the country and correct it if necessary.
9. Enter your area code and, if needed, what number to dial to get an outside line.
10. Verify that the phone system is tone or pulse dial and click Next.
11. Click Finish, then Close to complete the installation.
Installing the Compaq Armada 1500 Series 560CL
Telephony Modem (1560, 1570, 1571,1573, 1592, 1598)
1. Double-click SETUP in the directory where the SoftPaq was extracted.
2. Click Next.
3. Click Next to ‘Install new modem driver and components.’
4. Select the appropriate county and click YES.
5. Click Finish to restart the computer.
Installing the Armada 7000 Family 336 Modem INF
1. Select Start →Settings →Control Panel.
2. Double-click the Modem icon.
11 Prior to installing CardWare, install Power Management or the Supplemental Programs as applicable for your system.
NOTE: Only user accounts with Administrator rights have access to PCTray functions of
CardWare. Once installed, PC Cards are useable by all users regardless of the user rights.

Installing Microsoft Windows NT Workstation 4.0 on Compaq Armada Products 19
Document number PRT009A1098
3. Highlight ‘Don’t detect my modem’ and click Next.
4. Click ‘Have Disk’.
5. Enter the location of the modem INF file ‘C:\~COMPAQ\MODEM’ and click OK.
6. Choose Next to select ‘Compaq Armada 7000 Series Global SpeedPaq Telephony Modem’.
7. Highlight COM2 and click Next.
8. Check the country and correct it if necessary.
9. Enter your area code and, if needed, which number to dial to get an outside line.
10. Verify that the phone system is tone or pulse dial and click Next.
11. Click Finish and then Close to complete the installation.
Installing Diagnostics
1. Double-click SETUP in the directory where Diagnostics was extracted to from the SoftPaq.
2. Click ‘Yes, I want to restart my computer now.’
3. Click OK to restart the computer.
Installing the ESS Audio Drivers
1. Select Start →Settings →Control Panel.
2. Double-click the Multimedia icon.
3. Click the ‘Devices’ tab and click Add.
4. Click OK to select ‘Unlisted or Updated Driver’.
5. Enter the location where the audio driver was extracted to from the SoftPaq and click OK.
6. Choose OK again to select (for example) ‘ES1878 AudioDrive 2.00.85’.
7. Click Restart Now to restart the system so the new driver can take effect.
Installing the ESS1788 Audio Driver
1. Select Start →Settings →Control Panel.
2. Double-click the Multimedia icon.
3. Click the ‘Devices’ tab and click Add.
4. Click OK to select ‘Unlisted or Updated Driver’.
5. Enter the location of the audio driver ‘C:\~COMPAQ\1788__NT4’ and click OK.
6. Choose OK again to select ‘ES688/ES1688/ES1788 AudioDrive 2.00.04’.
7. Click Continue to confirm the I/O Address.
8. Change the Interrupt from 7 to 5 and click OK to confirm the additional configuration settings.
9. Restart the system for the new drivers to take effect.

Installing Microsoft Windows NT Workstation 4.0 on Compaq Armada Products 20
Document number PRT009A1098
Installing the ESS Audio Rack 32 Driver
1. Double-click SETUP in the directory where Audiorac.32 was extracted to from the SoftPaq.
2. Click Next on the ‘Welcome’ screen.
3. The ‘Choose Destination Location’ dialog box appears.
a. Click Next to install the AudioRack32 in the default directory or Browse to choose a different
directory.
b. When you are done click OK, or Cancel to return to the Choose Destination Location dialog box.
c. If the directory you designate doesn't exist, you are asked to confirm your selection. Click YES to
proceed or NO to go back and enter a new destination directory.
4. Once you have chosen the default directory or entered a directory of your own choosing, the Setup
program installs the AudioRack32. Click OK.
5. Click OK again to restart the computer.
Installing the Insight Management Agents
1. Double-click SETUP in the directory where the Insight Management Agents where extracted to from
the SoftPaq.
2. Click Next.
3. Click OK when prompted for Disk 2.
4. Click Next from the DMI dialog box.
5. Click Next to confirm the destination directory.
6. When the program finishes, highlight YES and click Finish to restart the computer. You are shown the
IM Agents Help File the next time the unit is rebooted and you log on. The file may be closed by
clicking on the ‘X’ in the upper right-hand corner of the window.
Installing Power Management12
1. Double-click SETUP in the directory where Power Management was extracted from the SoftPaq.
2. Click Finish to restart the computer.
Installing the Programmable Keys
1. Double-click SETUP in the directory where the Programmable Keys were extracted to from the
SoftPaq.
2. Click Next from the ‘Welcome’ screen.
3. Click OK.
4. Click ‘Yes, I want to restart my computer now.’
5. Click OK to restart the computer.
12 WinNT Powercon must be installed prior to installing PCMCIA CardWare.
