Hardware Guide
Compaq Evo Notebook N410c Series
Document Part Number: 274039-001
July 2002
This guide provides comprehensive information on setting up the
notebook’s hardware and software, identifying notebook
components, using the battery pack, connecting external devices,
and adding upgrades and accessories.
274039-001.book!!Page!i!!Thursday,!April!25,!2002!!11:26!AM

© 2002 Compaq Information Technologies Group, L.P.
Compaq, the Compaq logo, and Evo are trademarks of Compaq Information
Technologies Group, L.P. in the U.S. and/or other countries. Microsoft and
Windows are trademarks of Microsoft Corporation in the U.S. and/or other
countries. All other product names mentioned herein may be trademarks of their
respective companies.
Compaq shall not be liable for technical or editorial errors or omissions
contained herein. The information is provided “as is” without warranty of any
kind and is subject to change without notice. The warranties for Compaq
products are set forth in the express limited warranty statements accompanying
such products. Nothing herein should be construed as constituting an additional
warranty.
Hardware Guide
Compaq Evo Notebook N410c Series
First Edition July 2002
Document Part Number: 274039-001
274039-001.book!!Page!ii!!Thursday,!April!25,!2002!!11:26!AM

Hardware Guide iii
Contents
1 Hardware and Software Setup
Setting Up the Hardware . . . . . . . . . . . . . . . . . . . . . . . . . 1–1
Setting Up the Software . . . . . . . . . . . . . . . . . . . . . . . . . . 1–6
After Software Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–7
2 A Look at the Notebook
Front Panel Components . . . . . . . . . . . . . . . . . . . . . . . . . 2–1
Top Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–2
Right Side Components . . . . . . . . . . . . . . . . . . . . . . . . . . 2–5
Left Side Components . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–7
Bottom Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–8
Rear Panel Components . . . . . . . . . . . . . . . . . . . . . . . . . 2–10
Additional Standard Components . . . . . . . . . . . . . . . . . 2–11
3 Pointing Devices and Keyboard
Using the TouchPad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–1
Using Hotkeys and Shortcut Keys . . . . . . . . . . . . . . . . . . 3–2
Fn Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–2
Hotkeys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–3
Shortcut Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–4
Hotkey and Shortcut Key Procedures . . . . . . . . . . . . 3–4
Using the Embedded Numeric Keypad . . . . . . . . . . . . . . 3–7
Enabling the Numeric Keypad . . . . . . . . . . . . . . . . . 3–7
Disabling the Numeric Keypad . . . . . . . . . . . . . . . . . 3–7
Converting the Numeric Keypad Keys to
Standard Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–8
Enabling the Numeric Keypad at Startup . . . . . . . . . 3–8
274039-001.book!!Page!iii!!Thursday,!April!25,!2002!!11:26!AM

iv Hardware Guide
Contents
Using the Easy Access Buttons . . . . . . . . . . . . . . . . . . . . 3–9
Using Default Settings. . . . . . . . . . . . . . . . . . . . . . . . 3–9
4 Battery Packs
Charging Battery Packs . . . . . . . . . . . . . . . . . . . . . . . . . . 4–1
Using a New Battery Pack . . . . . . . . . . . . . . . . . . . . . . . . 4–3
Replacing a Battery Pack . . . . . . . . . . . . . . . . . . . . . . . . . 4–3
Replacing the Primary Battery Pack . . . . . . . . . . . . . 4–4
Replacing an Optional External Battery Pack . . . . . . 4–6
Storing a Battery Pack . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–9
5Drives
Caring for Drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–1
Removing a Hard Drive . . . . . . . . . . . . . . . . . . . . . . . . . . 5–1
Inserting a Hard Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–6
6 Audio and Video
Using Audio Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–1
Connecting a Stereo Speaker or Headphone . . . . . . . 6–3
Connecting a Microphone . . . . . . . . . . . . . . . . . . . . . 6–3
Adjusting Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–3
Using Video Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–4
Connecting a Device to the Composite Video-Out Jack . .
6–5
Changing the Video Mode. . . . . . . . . . . . . . . . . . . . . 6–5
7 External Device Connections
Connecting an External Monitor . . . . . . . . . . . . . . . . . . . 7–2
Connecting a Video Device . . . . . . . . . . . . . . . . . . . . . . . 7–2
Connecting Infrared Equipment. . . . . . . . . . . . . . . . . . . . 7–3
Infrared Connection Guidelines. . . . . . . . . . . . . . . . . 7–3
Infrared Configuration Guidelines. . . . . . . . . . . . . . . 7–4
Enabling the Infrared Port . . . . . . . . . . . . . . . . . . . . . 7–4
Connecting USB Equipment . . . . . . . . . . . . . . . . . . . . . . 7–5
Connecting an Optional Mobile Expansion Unit . . . . . . . 7–5
274039-001.book!!Page!iv!!Thursday,!April!25,!2002!!11:26!AM

Contents
Hardware Guide v
Connecting a Modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7–6
Using the RJ-11 Cable. . . . . . . . . . . . . . . . . . . . . . . . 7–6
Using a Country-Specific Modem Cable Adapter. . . 7–7
Connecting a Network Cable. . . . . . . . . . . . . . . . . . . 7–8
Connecting an Optional External MultiBay. . . . . . . . . . . 7–9
Connecting to Wireless Devices . . . . . . . . . . . . . . . . . . 7–10
Connecting an Optional Cable Lock . . . . . . . . . . . . . . . 7–10
8 Notebook Upgrades and Add-ons
Before Removing or Installing Components . . . . . . . . . . 8–1
Upgrading Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8–2
Inserting and Removing a Memory Expansion Board 8–3
Upgrading or Adding a Modem or NIC. . . . . . . . . . . . . . 8–9
Adding and Using PC Cards . . . . . . . . . . . . . . . . . . . . . 8–13
Configuring a PC Card . . . . . . . . . . . . . . . . . . . . . . 8–13
Inserting a PC Card . . . . . . . . . . . . . . . . . . . . . . . . . 8–14
Removing a PC Card . . . . . . . . . . . . . . . . . . . . . . . . 8–15
Conserving Energy . . . . . . . . . . . . . . . . . . . . . . . . . 8–16
Installing Additional Device Drivers . . . . . . . . . . . . . . . 8–16
Upgrading the Hard Drive . . . . . . . . . . . . . . . . . . . . . . . 8–17
Adding a Second Battery Pack. . . . . . . . . . . . . . . . . . . . 8–17
9 Specifications
Index
274039-001.book!!Page!v!!Thursday,!April!25,!2002!!11:26!AM

Hardware Guide 1–1
1
Hardware and Software Setup
Setting Up the Hardware
1. Record the operating system Product Key printed on the
Certificate of Authenticity label on the bottom of the
notebook. The Product Key is essential when you:
❏Set up the software.
❏Start the notebook for the first time.
❏Update or troubleshoot your operating system.
274039-001.book!!Page!1!!Thursday,!April!25,!2002!!11:26!AM

1–2 Hardware Guide
Hardware and Software Setup
ÅWARNING: This is a Class B digital device, pursuant to Part 15 of the
FCC Rules. For more Class B information, refer to the
Regulatory and
Safety Notices Guide on the Documentation Library CD, included with
the notebook.
To reduce the risk of personal injury, electric shock, fire, or damage to the
equipment:
■Do not disable the power cord grounding plug. The plug is an
important safety feature.
■Plug the equipment into a grounded (earthed) electrical outlet
that is easily accessible at all times.
■Disconnect power from the equipment by unplugging the power
cord from the electrical outlet.
■Do not set up the notebook while it is docked in an optional
Mobile Expansion Unit.
2. Place the notebook on a flat surface near an electrical outlet.
274039-001.book!!Page!2!!Thursday,!April!25,!2002!!11:26!AM

Hardware and Software Setup
Hardware Guide 1–3
3. Connect the notebook to an external outlet.
Plug the AC adapter cable into the power connector 1. Plug
the power cord into the AC adapter 2and into an electrical
outlet 3.
✎Power cords and electrical outlets vary by country.
When power is turned on, the battery light:
❏Remains on while the battery pack is charging.
❏Turns off when the battery pack is fully charged.
274039-001.book!!Page!3!!Thursday,!April!25,!2002!!11:26!AM

1–4 Hardware Guide
Hardware and Software Setup
4. Open the notebook by sliding the display latch to the right 1
and raising the display 2.
274039-001.book!!Page!4!!Thursday,!April!25,!2002!!11:26!AM

Hardware and Software Setup
Hardware Guide 1–5
5. Turn on the notebook by sliding and momentarily holding,
then releasing, the power switch 1.
When power is turned on:
❏The power/standby light 2turns on.
❏The battery pack in the primary battery bay and the
external battery pack (if attached) begin to charge and the
battery light 3turns on. You are prompted to begin
software setup.
274039-001.book!!Page!5!!Thursday,!April!25,!2002!!11:26!AM

1–6 Hardware Guide
Hardware and Software Setup
Setting Up the Software
Read the following guidelines, then set up the software.
ÄCAUTION: To prevent file corruption and ensure that the correct drivers
install during initial setup:
■Do not unplug the notebook from the electrical outlet.
■Do not shut down the notebook.
■Do not remove or insert a drive.
■When you begin software setup, online instructions guide
you through the setup process.
■After you have begun software setup, you must complete the
entire process. Setup time varies by notebook configuration.
■If you are prompted to select a language or operating system,
choose carefully.
ÄCAUTION: The languages and operating systems that you do
not
choose will be deleted from the system and cannot be restored
during initial setup. An operating system available during initial
setup is enhanced by Compaq. When an operating system is
deleted, the enhancements are also deleted.
274039-001.book!!Page!6!!Thursday,!April!25,!2002!!11:26!AM

Hardware and Software Setup
Hardware Guide 1–7
After Software Setup
After the initial setup is complete, you may want to Install any
optional applications.
You can install third-party applications or preloaded Compaq
utilities at any time after initial setup is complete.
■To install a third-party application, refer to the documentation
included with the application.
■To install a preloaded Compaq utility, select the Start > All
Programs > Setup Compaq Software > Next. Select the check
box for components you want to install; clear the components
you do not want to install. Follow the instructions on the
screen.
After initial setup is complete, select Start > Run. On the
command line, type:
C:\cpqapps\setup.exe preload /s
✎To view the descriptions and space requirements of preloaded
Compaq utilities without installing the utilities, Start > All
Programs > Setup Compaq Software >then select Next. After
viewing the utility information, select Cancel.
Compaq Help and Support provides links to the Compaq Web site
where you can:
■Download the latest software and drivers for your notebook.
■Open an online service event with a Compaq support
specialist.
■Get information about your notebook, including reference
guides, specifications, white papers, part numbers, and
customer advisories.
274039-001.book!!Page!7!!Thursday,!April!25,!2002!!11:26!AM

1–8 Hardware Guide
Hardware and Software Setup
To access Compaq Help and Support, select Start > Compaq Info
Center > Compaq Help and Support.
For information about choosing a workspace and creating a safe
and comfortable work environment, refer to the Safety & Comfort
Guide on the Documentation Library CD included with the
notebook.
274039-001.book!!Page!8!!Thursday,!April!25,!2002!!11:26!AM

Hardware Guide 2–1
2
A Look at the Notebook
Front Panel Components
Front Panel Components
Component Function
1Vents Allow airflow to cool internal components.
2Display release latch Releases the display to open the
notebook.
3Volume buttons (2) Adjust or mute the system volume.
4MultiPort Supports an optional USB-enabled
wireless device such as a Bluetooth
MultiPort, 802.11b Wireless LAN
Multiport, and future wireless
technologies.
274039-001.book!!Page!1!!Thursday,!April!25,!2002!!11:26!AM

2–2 Hardware Guide
A Look at the Notebook
Top Components
Top Components
Light, Button, or Component Function
1Standby button ■Turns on the notebook if it
is off.
■Initiates and exits Standby.
■When pressed with the Fn key,
initiates Hibernation.
2Easy Access buttons (4) Four buttons that provide quick
access to the Internet. See
Chapter 3, “Pointing Devices and
Keyboard,” for information about
these buttons.
274039-001.book!!Page!2!!Thursday,!April!25,!2002!!11:26!AM

A Look at the Notebook
Hardware Guide 2–3
3Microphone Inputs single-channel sound to the
notebook; can be used whether the
notebook is open or closed.
4Display switch Can be set to turn off the notebook
display if the notebook is closed
while on.
5IDE drive light On: The main hard drive or any IDE
(Integrated Drive Electronics) or
optical device is being accessed.
6Floppy light On: A floppy drive in the optional
Mobile Expansion Unit is being
accessed.
7Num lock light On: Num lock is on and the
embedded numeric keypad is
enabled.
8Caps lock light On: Caps lock is on.
9Scroll lock light On: Scroll lock is on.
-Battery light On: A battery pack is charging.
Blinking: A battery pack that is the
only available power source has
reached a low-battery condition.
qPower/standby light On: power is turned on.
Blinking: notebook is in Standby.
✎The power/standby light
also blinks if a battery pack
that is the only available
power source reaches a
critical low-battery condition
while Hibernation is
disabled.
Top Components
(Continued)
Light, Button, or Component Function
274039-001.book!!Page!3!!Thursday,!April!25,!2002!!11:26!AM

2–4 Hardware Guide
A Look at the Notebook
wRight TouchPad button Functions like the right mouse
button on an external mouse.
eTouchPad Moves the mouse cursor, selects,
and activates.
rLeft TouchPad button Functions like the left mouse button
on an external mouse.
Top Components
(Continued)
Light, Button, or Component Function
274039-001.book!!Page!4!!Thursday,!April!25,!2002!!11:26!AM

A Look at the Notebook
Hardware Guide 2–5
Right Side Components
Right Side Components
Component Function
1Power switch Initiates and resumes from
Hibernation.
2Stereo
speaker/headphone jack
Connects stereo speakers,
headphones, headset, or television
audio.
3Microphone jack Connects a single-sound channel
microphone.
4PC Card eject button Ejects a PC Card from the
PC Card slot.
5PC Card slot Supports 32-bit (CardBus) and
16-bit PC Cards.
274039-001.book!!Page!5!!Thursday,!April!25,!2002!!11:26!AM

2–6 Hardware Guide
A Look at the Notebook
6Universal serial bus (USB)
connector
Connects USB 2.0 and 1.1 compliant
devices to the notebook using a
standard USB cable.
67External MultiBay connector Connects an optional External
MultiBay to the notebook using the
External MultiBay-Powered USB
Cable.
8Infrared port Links another IrDA-compliant device
for wireless communication.
9RJ-45 jack (network
models only)
Connects the network cable.
✎A network cable is included
with network models.
-RJ-11 jack (internal modem
models only)
Connects the modem cable to an
internal modem.
✎A modem cable is included
with internal modem models.
Right Side Components
(Continued)
Component Function
274039-001.book!!Page!6!!Thursday,!April!25,!2002!!11:26!AM

A Look at the Notebook
Hardware Guide 2–7
Left Side Components
Left Side Components
Component Function
1External monitor connector Connects an external monitor or
overhead projector.
2AC power connector Connects any one of the following:
■AC Adapter
■Optional Automobile Power
Adapter/Charger
■Optional Aircraft Power Adapter
3Universal serial bus (USB)
connector
Connects USB 2.0 and 1.1
compliant devices.
4Vent Allows airflow to cool internal
components.
5Security cable slot Allows an optional security cable to
be attached to the notebook.
274039-001.book!!Page!7!!Thursday,!April!25,!2002!!11:26!AM
