Compaq.com Compaq Presario Maintenance and Service Guide - 305
United States June 27, 2004
COMPAQ
STORE | PRODUCTS | SERVICES | SUPPORT | CONTACT US |
SEARCH
Maintenance & Service Guide
Presario 305 Model
MSG Index | Home Page | Notice | Preface | Product Description |
Troubleshooting
Illustrated Parts Catalog | Removal & Replacement Procedures |Specifications
Pin Assignments |Battery Pack Operations
Product
Description
Troubleshooting
Illustrated
Parts Catalog
Removal &
Replacement
Procedures
Specifications
Connector Pin
Assignments
Battery Pack
Operations
See the Notice for copyright and trademark information, and see the Preface for
symbol conventions, Technician Notes and Serial Number locations on the unit.
Download a ZIP file of the complete MSG onto local hard drive.
This MSG will be periodically maintained and updated as needed. To report a
technical problem, contact your Regional Support Center or IM Help Center. For
content comments or questions, contact the Editor.
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20checked%20ok/NOTEBOOKS/PRESARIO%20305/index.html (1 of 2)6/27/2004 2:16:02 AM

Compaq.com Compaq Presario Maintenance and Service Guide - 305
1.800.AT.COMPAQ
privacy and legal statement
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20checked%20ok/NOTEBOOKS/PRESARIO%20305/index.html (2 of 2)6/27/2004 2:16:02 AM

Compaq.com Compaq Presario Maintenance and Service Guide - 305
United States June 27, 2004
COMPAQ
STORE | PRODUCTS | SERVICES | SUPPORT | CONTACT US |
SEARCH
Maintenance & Service Guide
Presario 305 Model
MSG Index | Home Page | Notice | Preface | Product Description |
Troubleshooting
Illustrated Parts Catalog | Removal & Replacement Procedures |Specifications
Pin Assignments |Battery Pack Operations
Notice
The information in this guide is subject to change without notice.
COMPAQ COMPUTER CORPORATION SHALL NOT BE LIABLE FOR TECHNICAL OR EDITORIAL
ERRORS OR OMISSIONS CONTAINED HEREIN, NOR FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES RESULTING FROM THE FURNISHING, PERFORMANCE, OR USE OF THIS MATERIAL.
This guide contains information protected by copyright. No part of this guide may be photocopied or
reproduced in any form without prior written consent from Compaq Computer Corporation.
© 1999 Compaq Computer Corporation.
All rights reserved. Printed in the U.S.A.
Compaq and Presario are registered in the U. S. Patent and Trademark Office.
Microsoft, MS-DOS, Windows and Windows NT are registered trademarks of Microsoft Corporation.
Windows 98 is a trademark of Microsoft Corporation.
The software described in this guide is furnished under a license agreement or nondisclosure agreement.
The software may be used or copied only in accordance with the terms of the agreement.
Product names mentioned herein may be trademarks and/or registered trademarks of their respective
companies.
Maintenance and Service Guide
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20checked%20ok/NOTEBOOKS/PRESARIO%20305/notice.html (1 of 2)6/27/2004 2:16:12 AM

Compaq.com Compaq Presario Maintenance and Service Guide - 305
Compaq Presario 305 Model Portable Computers
First Edition (July 1999)
Compaq Computer Corporation
1.800.AT.COMPAQ
privacy and legal statement
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20checked%20ok/NOTEBOOKS/PRESARIO%20305/notice.html (2 of 2)6/27/2004 2:16:12 AM

Compaq.com Compaq Presario Maintenance and Service Guide - 305
United States June 27, 2004
COMPAQ
STORE | PRODUCTS | SERVICES | SUPPORT | CONTACT US |
SEARCH
Maintenance & Service Guide
Presario 305 Model
MSG Index | Home Page | Notice | Preface | Product Description |
Troubleshooting
Illustrated Parts Catalog | Removal & Replacement Procedures |Specifications
Pin Assignments |Battery Pack Operations
Preface
This Maintenance and Service Guide is a troubleshooting reference that can be
used when servicing the Compaq Presario 305 Model Portable Computers. Compaq
Computer Corporation reserves the right to make changes to the Compaq Presario
305 Model Portable Computers without notice.
Symbols
The following words and symbols mark special messages throughout this guide.
WARNING: Text set off in this manner indicates that
failure to follow directions in the warning could result in
bodily harm or loss of life.
CAUTION: Text set off in this manner indicates that
failure to follow directions could result in damage to
equipment or loss of data.
IMPORTANT: Text set off in this manner presents clarifying
information or specific instructions.
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20checked%20ok/NOTEBOOKS/PRESARIO%20305/preface.html (1 of 3)6/27/2004 2:16:13 AM

Compaq.com Compaq Presario Maintenance and Service Guide - 305
NOTE: Text set off in this manner presents commentary,
sidelights, or interesting points of information.
Technician Notes
WARNING: Only authorized technicians trained by Compaq should
repair this equipment. All troubleshooting and repair procedures are
detailed to allow only subassembly/module level repair. Because of
the complexity of the individual boards and subassemblies, the user
should not attempt to make repairs at the component level or to
make modifications to any printed circuit board. Improper repairs can
create a safety hazard. Any indications of component replacement or
printed circuit board modifications may void any warranty.
WARNING: The computer is designed to be
electrically grounded. To ensure proper operation,
plug the AC power cord into a properly grounded
electrical outlet only.
CAUTION: To properly ventilate the system, you
must provide at least 3 inches (7.62 cm) of clearance
on the left and right sides of the computer.
Serial Number
When requesting information or ordering spare parts, the computer serial number
should be provided to Compaq. The serial number is located on the bottom of the
computer.
Locating Additional Information
The following documentation is available to support this product:
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20checked%20ok/NOTEBOOKS/PRESARIO%20305/preface.html (2 of 3)6/27/2004 2:16:13 AM

Compaq.com Compaq Presario Maintenance and Service Guide - 305
●Compaq Presario 305 Model Portable Computer documentation set
●Introducing Windows 98 Guide
●Compaq Service Training Guides
●Compaq Service Advisories and Bulletins
●Compaq QuickFind
●Compaq Service Quick Reference Guide
●Compaq Internet site at http://Compaq.com
1.800.AT.COMPAQ
privacy and legal statement
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20checked%20ok/NOTEBOOKS/PRESARIO%20305/preface.html (3 of 3)6/27/2004 2:16:13 AM

Compaq.com Compaq Presario Maintenance and Service Guide - 305
United States June 27, 2004
COMPAQ
STORE | PRODUCTS | SERVICES | SUPPORT | CONTACT US |
SEARCH
Maintenance & Service Guide
Presario 305 Model
MSG Index | Home Page | Notice | Preface | Product Description | Troubleshooting
Illustrated Parts Catalog | Removal & Replacement Procedures |Specifications
Pin Assignments |Battery Pack Operations
Product Description
Models and
Features
Upper Unit
Components
Front
Components
Left Side
Components
Right Side
Components
Bottom of
Unit
Rear
Connectors
Multi-media
Expansion
Unit
Power
Management
for Windows
98
The Compaq
Presario 305
Computer
provides
industry-
leading
features in a
uniquely
designed
ultraportable.
The ultra-
light 3.1 to
3.3 pound
(1.4 to 1.5
kg) notebook
(depending
on
configuration)
allows users
high mobility,
provides a
full set of
system ports,
and when
paired with
the Mobile
Expansion
Unit (MEU),
can
transform
into an All-In-
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20checked%20ok/NOTEBOOKS/PRESARIO%20305/product.html (1 of 2)6/27/2004 2:16:14 AM

Compaq.com Compaq Presario Maintenance and Service Guide - 305
One portable
with CD-ROM
or DVD and
floppy
functionality.
1.800.AT.COMPAQ
privacy and legal statement
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20checked%20ok/NOTEBOOKS/PRESARIO%20305/product.html (2 of 2)6/27/2004 2:16:14 AM

Compaq.com Compaq Presario Maintenance and Service Guide - 305
United States June 27, 2004
COMPAQ
STORE | PRODUCTS | SERVICES | SUPPORT | CONTACT US |
SEARCH
Maintenance & Service Guide
Presario 305 Model
MSG Index | Home Page | Notice | Preface | Product Description | Troubleshooting
Illustrated Parts Catalog | Removal & Replacement Procedures |Specifications
Pin Assignments |Battery Pack Operations
Troubleshooting
Preliminary
Steps
Clearing the
Power-On
Password
Power-On Self
Test (POST)
Compaq
Diagnostics
Diagnostic Error
Codes
Troubleshooting
Without
Diagnostics
Solving Minor
Problems
Contacting
Compaq
Support
This section covers troubleshooting information for the Compaq Presario 305
Model Portable Computer. The basic steps in troubleshooting include:
1. Follow the Preliminary Steps.
2. Run the Power-On Self Test (POST).
3. Follow the recommended actions described in the diagnostic
tables, if you are unable to run POST or if POST displays an error
message.
When following the recommended actions in the Sections on POST
and Diagnostic Error Codes perform them in the order listed.
Rerun POST after each recommended action until the problem is
solved and no error message occurs. Once the problem is solved,
do not complete the remaining recommended actions.
NOTE: If the problem is intermittent, check the
computer several times to verify that the
problem is solved.
1.800.AT.COMPAQ
privacy and legal statement
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20checked%20ok/NOTEBOOKS/PRESARIO%20305/trouble.html6/27/2004 2:16:14 AM

Compaq.com Compaq Presario Maintenance and Service Guide - 305
United States June 27, 2004
COMPAQ
STORE | PRODUCTS | SERVICES | SUPPORT | CONTACT US |
SEARCH
Maintenance & Service Guide
Presario 305 Model
MSG Index | Home Page | Notice | Preface | Product Description |
Troubleshooting
Illustrated Parts Catalog | Removal & Replacement Procedures |Specifications
Pin Assignments |Battery Pack Operations
Illustrated Parts Catalog
System
Components
System Unit
External Cables
Miscellaneous
Plastics Kit
Screw Kit
Miscellaneous
Parts
Documentation
and Software
This section provides illustrated parts and a
reference for spare parts numbers for Compaq
Presario 305 Series Personal Computers.
When requesting information or ordering spare
parts, the computer serial number should be
provided to Compaq.
1.800.AT.COMPAQ
privacy and legal statement
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20checked%20ok/NOTEBOOKS/PRESARIO%20305/illust.html6/27/2004 2:16:14 AM

Compaq.com Compaq Presario Maintenance and Service Guide - 305
United States June 27, 2004
COMPAQ
STORE | PRODUCTS | SERVICES | SUPPORT | CONTACT US |
SEARCH
Maintenance & Service Guide
Presario 305 Model
MSG Index | Home Page | Notice | Preface | Product Description |
Troubleshooting
Illustrated Parts Catalog | Removal & Replacement Procedures |Specifications
Pin Assignments |Battery Pack Operations
Removal and Replacement Procedures
This section explains the removal and replacement procedures for the computer.
Removal
Sequence
Serial
Number
Location
Preparing for
Disassembly
Electrostatic
Discharge
Service
Considerations
Cables and
Connectors
Multi-media
Expansion
Unit
Report the computer serial number, located on the bottom
of the unit, when requesting information or ordering spare
parts from Compaq.
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20checked%20ok/NOTEBOOKS/PRESARIO%20305/rmvrep.html (1 of 2)6/27/2004 2:16:15 AM

Compaq.com Compaq Presario Maintenance and Service Guide - 305
Battery Pack
Hard Drive
Modem Card
RTC Battery
Keyboard
Memory Board
Switch Cover
Display Panel
Deck
Voltage
Converter
Board
Modem
Connector
Board
PC Card
PC Card
Assembly
System Board
1.800.AT.COMPAQ
privacy and legal statement
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20checked%20ok/NOTEBOOKS/PRESARIO%20305/rmvrep.html (2 of 2)6/27/2004 2:16:15 AM

Compaq.com Compaq Presario Maintenance and Service Guide - 305
United States June 27, 2004
COMPAQ
STORE | PRODUCTS | SERVICES | SUPPORT | CONTACT US |
SEARCH
Maintenance & Service Guide
Presario 305 Model
MSG Index | Home Page | Notice | Preface | Product Description |
Troubleshooting
Illustrated Parts Catalog | Removal & Replacement Procedures |Specifications
Pin Assignments |Battery Pack Operations
Specifications
This section covers the following specifications of Compaq Presario 305 Model
Portable Computers:
Physical and environmental System Interrupts System DMA
System I/O Address System Memory Catalog Display
Diskette drive Hard drive CD drive
Battery pack
U.S. Metric
Dimensions
Height
Depth
Width
0.89 in
8.5 in
10.4 in
22.6 mm
216 mm
264 mm
Weight 3.07 - 3.26 lb 1.39 - 1.48 kg
AC Adapter
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20checked%20ok/NOTEBOOKS/PRESARIO%20305/spec.html (1 of 4)6/27/2004 2:16:16 AM

Compaq.com Compaq Presario Maintenance and Service Guide - 305
Operating Voltage
Operating Current
Operating Frequency Range
Maximum Transient
90 to 260 VAC RMS
1.1 A RMS
47-63 Hz AC
4/50 kV
Temperature
Operating
Nonoperating 41° to 95 °F -22° to 140 °F 5° to 35 °C -30° to 60 °C
Relative Humidity (noncondensing)
Operating
Nonoperating (tw = 38.7°C max) 10 to 90% 5 to 90%
101.6 °F
10 to 90%
5 to 90%
38.7 °C
Altitude (nonpressurized environment)
Operating
Nonoperating 0 to 10,000 ft 0 to 30,000 ft 0 to 3.05 km 0 to 9.14 km
Shock
Operating
Non operating -10 G, 11 ms, half sine 60 G, 2 ms, half sine
Vibration
Operating
Nonoperating
0.25 G, 50 to 500 Hz sine, 1/2 Oct/
Min sweep rate
1 G, 50 to 500 Hz sine, 1/2 Oct/Min
sweep rate
NOTE: Applicable product safety standards specify thermal limits for plastic surfaces.
The computer operates well within this range of temperatures.
System Interrupts
Hardware IRQ System Function
IRQ1 Timer Interrupt
IRQ2 Cascaded
IRQ3 PCMCIA
IRQ4 Modem (COM1)
IRQ5 Audio (default)*
IRQ6 Diskette Drive
IRQ7 Parallel
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20checked%20ok/NOTEBOOKS/PRESARIO%20305/spec.html (2 of 4)6/27/2004 2:16:16 AM

Compaq.com Compaq Presario Maintenance and Service Guide - 305
IRQ8 RTC
IRQ9 Infrared
IRQ10 PCMCIA
IRQ12 Internal Point Stick or External Mouse
IRQ13 Coprocessor (Not available to any peripheral)
IRQ14 IDE Interface (Hard Disk)
NOTES:
PCMCIA cards may assert IRQ3,IRQ4, IRQ5, IRQ7, IRQ9, IRQ10,
IRQ11, or IRQ15. Either the infrared or the serial port may assert
IRQ3 or IRQ4.
*Default configuration; audio possible configurations are: IRQ5,
IRQ7, IRQ9, IRQ10 or none.
System DMA
Hardware
DMA System Function
0Available for audio
1Entertainment Audio (Default;
Alternate =DMA0, DMA3, None)
2Diskette Drive
3ECP Parallel Port LPT1 (Default;
Alternate =DMA0, None)
4DMA Controller Cascading (Not
available)
5Available for PC Card
6Not assigned
7Not assigned
NOTE: PC Card controller can use DMA1, 2 or 5.
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20checked%20ok/NOTEBOOKS/PRESARIO%20305/spec.html (3 of 4)6/27/2004 2:16:16 AM

Compaq.com Compaq Presario Maintenance and Service Guide - 305
1.800.AT.COMPAQ
privacy and legal statement
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20checked%20ok/NOTEBOOKS/PRESARIO%20305/spec.html (4 of 4)6/27/2004 2:16:16 AM
