QuickSpecs Compaq Evo Notebook N1000v
DA-11371 World Wide —Version 6 — October3, 2002 1
Overview
What's New
•IntelPentium4 processors–
up to 2.2 GHz; Intel Celeron
processors– up to 1.5 GHz
•400-MHzbus
•4X AGP Graphics
•MultiPort wireless communication
options
•Choice of Touchpad or Dual
Pointing Device
At A Glance
•Intel Pentium4processors– up to
2.2GHz;IntelCeleronprocessors
– up to 1.5 GHz
•15-inch XGA, SXGA+ and
14.1-inch XGA display
•Configurations as light as
6.6 lb/3.0 kg weight
(14-inch panel)
•1.55 in/3.95 cm thin
•256-MBDDRSDRAM(266MHz),
Upgradeable to 1024 MB
•Up to 40-GB SMART hard drives
•Mini PCI modem and integrated
NIC
•Full-size keyboard
•MicrosoftWindowsXP Proand
Microsoft Windows2000
•Includes a One-year, Worldwide
Warranty. —Certain restrictions
and exclusions apply. Consult
the Compaq Customer Support
Center for details.
What’s Special
•Intel Pentium 4 processors
•All-in-one convenientdesign
•LatestUSB interface
•Wireless featuresthru award-
winning MultiPort
•Common Docking Options

QuickSpecs Compaq Evo Notebook N1000v
DA-11371 World Wide —Version 6 — October3, 2002 2
Standard Features
Processor and Panel 15-inch color TFT SXGA+ with 1400 x 1050 resolution (up to 16.7M colors internal)
15-inch color TFT XGA with 1024 x 768 resolution (up to 16.7M colors internal)
14.1-inch color TFT XGA with 1024 x 768 resolution (up to 16.7M colors internal)
One of the following: 2.2 GHz Intel Pentium 4 processor with 512-KB L2 cache
2.0 GHz Intel Pentium 4 processor with 512-KB L2 cache
1.4 GHz Intel Celeron with 256-KB L2 cache
1.5 GHz Intel Celeron with 256-KB L2 cache
NOTE: Intel Pentium 4 processors, speed denotes maximum performance mode on AC power; processor speed
on battery power is approximately 64% of maximum performance mode. Mobile Intel Pentium 4
processors featuring Intel SpeedStep technology, speed denotes maximum performance mode; battery
optimization mode is approximately 80% of maximum performance mode.
Memory
Standard/Maximum 256 MB (266 MHz) DDR SDRAM (256 MB SODIMM in slot 1)
1024 MB (266 MHz) DDR SDRAM (512 MB SODIMMs in slots 1 and 2)
NOTE:Due to the non-industry standard nature of some third-party memory modules, we recommend Compaq
branded memory to ensure compatibility.
Communications 10/100 NICis integrated on the system board
Type III Mini PCI 56K (V.92) modem
NOTE: Designed only to allow faster downloads from V.92 compliant sources. Maximum achievable download
transmission rates currently do not reach 56 KB/s, and will vary with line conditions.
NOTE: Modem availability is subject to country regulatory approval
Keyboard 102-key compatible keyboard with isolated, inverted-T cursor control keys, and right-control key, special feature
hotkeys for instant access to power conservation, toggle between internal and external, or simultaneous displays,
and control brightness and contrast.
Easy Access Internet
Buttons The EvoNotebook N1000 comes with three Easy Access Buttons (EAB) designed to increase customer productivity by providing one-touch access to helpful Compaq information, favorite Internet destinations, or default
e-mail application. The EAB portion of the keyboard deck also includes dedicated hardware volume control and a
quick-launch button for CD/DVD play.
Pointing Device Choice of touchpad with 4-way scroll or dual pointing devices (both pointstick and touchpad)
PC Card Slots One Type II PC Card Slot which supports both 32-bit CardBusand 16-bit PC Cards
Storage Fixed Diskette Drive 1.44-MB Diskette Drive
Primary Hard Drive 40 GB or
30 GB or
20 GB
Fixed Optical Drive DVD/CD-RW Combo Drive
DVD-ROM Drive
CD-ROM Drive

QuickSpecs Compaq Evo Notebook N1000v
DA-11371 World Wide —Version 6 — October3, 2002 3
Standard Features
Multimedia JBL Pro Speakers with bass reflex and 16bit stereo sound
Integrated microphone
Dedicated Hardware volume controls
Headphone-out port
Microphone in port
Software MPEG1 support, MPEG2 and DVD
8X DVD/CD-RW Combination Drive (on select models)
8X DVD-ROM Drive with movie playback software (on select models)
24X CD-ROM Drive (on select models)
S-video Port
IEEE 1394 Port
4X AGP graphics
32-MB of DDR (Double Date Rate) SDRAM
Interfaces PC Card One Type II
Enhanced Parallel EPP/ECP 1
PS/2 1
S-Video 1
VGA 1
1394 1
Port Replicator 1
Headphone/Line-out 1
Microphone in 1
DC Power 1
RJ-11 (modem) 1
RJ-45 (NIC) 1
Infrared Port 1 (4 Mb/s support)
(IrDA 4 MB compliant. IR performance will vary depending on performance of IR
peripherals and application used.)
USB Port 2
LED status indicators 6
Graphics ATI Mobility Radeon 7500, 64-bit video graphics with 32-MB VRAM for increased color depth and graphics
performance
Display (External) Up to 32-bit per pixel color depth
Supports 640 x 480, 800 x 600, 1024 x 768, 1280 x 1024, 1400 x 1050, 1600 x 1200, or 2048 x 1536 resolutions
up to 160-Hz refresh rate, dependent upon monitor capability, resolution and color depth settings
Display (Internal) 14.1-inch color TFT XGA with 1024 x 768 resolution (up to 16.7M colors internal)
15-inch color TFT XGA with 1024 x 768 resolution (up to 16.7M colors internal)
15-inch color TFT SXGA+with 1400 x 1050 resolution (up to 16.7M colors internal)
Operating System Microsoft Windows XP Pro, Microsoft Windows 2000, or Microsoft Windows XP Home
(limited language availability) preinstalled
Software Diagnostics for Microsoft Windows
DVD Playback Software
Compaq Security Management
Safety and Comfort Guide
Acrobat Reader
Reference Guide
Norton Internet Security
Compaq Easy Access Button Software

QuickSpecs Compaq Evo Notebook N1000v
DA-11371 World Wide —Version 6 — October3, 2002 4
Standard Features
System Recovery Each unit is shipped with a CD kit for quick recovery (erases hard disk and restores manufacturer installed image)
and software recovery (installs only selected standard software)
Security Configuration Control Hardware
Memory Change Alert
Ownership Tag
Set-up Password
Power-On Password
DriveLock
Enabled for PC SmartCard options
Kensington Lock
Power Supply External 90-watt AC adapter, power cord included.
Battery Standard 8-cell Lithium-Ion battery.
The Evo Notebook N1000v provides over 2 hours of battery life using the standard 8-cell Lithium-Ion battery..
NOTE: Actual results may vary with product model, configuration, and individual usage. Compaq results of 2:20
(hr:min) were achieved running the Business Winstone 2001 Battery Mark1.0 on a N1000v with a Intel
Pentium 4 2.0 GHz CPU, 15-inch XGA panel, 256-MB RAM, 30-GB HDD, 8X DVD, 8-cell Lithium-Ion
battery, and NIC/modem. System parameters were set according to eTesting Labs’ recommendations:
panel brightness 50%, hard drive timerthree minutes.
NOTE: This test was performed without independent verification by eTesting Labs Inc. eTesting Labs Inc. makes
no representations or warranties as to the result of the test. BatteryMark is a trademark of Ziff Davis
Publishing Holdings Inc., and affiliate of eTesting Labs Inc., in the U.S. and other countries.
Power Conservation Hibernation
Instant-on via Standby
Pop-ups with three presets
One custom level of power conservation
ACPI compliant
MultiPort
MultiPort is a flexible, innovative solution providing customers the ability to connect to their choice of wireless standards such as 802.11b or Bluetooth™. This can be achieved by simply changing out the high-performance
wireless module, which is integrated into the top of the notebook. The award-winning MultiPort offers a cost
effective means to migrate to future wireless standards as they become available.
Docking NEW! Port replicator and Advanced Port Replicator. The sleek, new port replicator and advanced port replicator
designs provide simple and convenient port management. Features include NIC pass through, USB, and a 1394
digital port. Compatible across multiple platforms for lower total cost of ownership.
Service and Support Compaq Services includes a one-year, Worldwide Limited Warranty, pick-up or carry-in; upgraded warranty and
toll-free 7 x 24 hardware technical phone support available.
NOTE: Certain restrictions and exclusions apply. Consult the Compaq Customer Support Center for details.

QuickSpecs Compaq Evo Notebook N1000v
DA-11371 World Wide —Version 6 — October3, 2002 5
Standard Features
Naming Convention The Etymology of a Model name:

QuickSpecs Compaq Evo Notebook N1000v
DA-11371 World Wide —Version 6 — October3, 2002 6
Standard Features
Models
Display 15-inch color TFT SXGA+
Processor 2.2 GHz Intel Pentium 4 processor
Cache Memory 512-KB, L2 Cache
N1000vP220P530WC25O
Memory Standard 256 MB (266 MHz) DDR SDRAM
Maximum 1024 MB (266 MHz) DDR SDRAM
Optical Drive DVD/CD-RW
Hard Drive 30-GB SMART
Communications Type III Mini PCI 56K (V.92) modem, (LOM) integrated 10/100 NIC
Graphics ATI Mobility Radeon 7500, 64-bit video graphics
Video Memory 32-MB VRAM
Audio JBL Pro Speakers with bass reflex and 16-bit stereo sound
Operating System Microsoft Windows XP Professional
Warranty One Year
Display 15-inch color TFT SXGA+
Processor 2.2 GHz Intel Pentium 4 processor
Cache Memory 512-KB, L2 Cache
N1000vP220P530WC252
Memory Standard 256 MB (266 MHz) DDR SDRAM
Maximum 1024 MB (266 MHz) DDR SDRAM
Optical Drive DVD/CD-RW
Hard Drive 30-GB SMART
Communications Type III Mini PCI 56K (V.92) modem, (LOM) integrated 10/100 NIC
Graphics ATI Mobility Radeon 7500, 64-bit video graphics
Video Memory 32-MB VRAM
Audio JBL Pro Speakers with bass reflex and 16-bit stereo sound
Operating System Microsoft Windows 2000
Warranty One Year
Display 15-inch color TFT SXGA+
Processor 2.2 GHz Intel Pentium 4 processor
Cache Memory 512-KB, L2 Cache
N1000vP220P530WC25O
Memory Standard 256 MB (266 MHz) DDR SDRAM
Maximum 1024 MB (266 MHz) DDR SDRAM
Optical Drive DVD/CD-RW
Hard Drive 30-GB SMART
Communications Type III Mini PCI 56K (V.92) modem, (LOM) integrated 10/100 NIC
Graphics ATI Mobility Radeon 7500, 64-bit video graphics
Video Memory 32-MB VRAM
Audio JBL Pro Speakers with bass reflex and 16-bit stereo sound
Operating System Microsoft Windows XP Professional
Warranty Two Year

QuickSpecs Compaq Evo Notebook N1000v
DA-11371 World Wide —Version 6 — October3, 2002 7
Standard Features
Models (continued)
Display 15-inch color TFT SXGA+
Processor 2.2 GHz Intel Pentium 4 processor
Cache Memory 512-KB, L2 Cache
N1000vP220P530WC252
Memory Standard 256 MB (266 MHz) DDR SDRAM
Maximum 1024 MB (266 MHz) DDR SDRAM
Optical Drive DVD/CD-RW
Hard Drive 30-GB SMART
Communications Type III Mini PCI 56K (V.92) modem, (LOM) integrated 10/100 NIC
Graphics ATI Mobility Radeon 7500, 64-bit video graphics
Video Memory 32-MB VRAM
Audio JBL Pro Speakers with bass reflex and 16-bit stereo sound
Operating System Microsoft Windows 2000
Warranty Two Year
Display 15-inch color TFT XGA
Processor 2.0 GHz Intel Pentium 4 processor
Cache Memory 512KB, L2 Cache
N1000vP200X530WC25O
Memory Standard 256 MB (266 MHz) DDR SDRAM
Maximum 1024 MB (266 MHz) DDR SDRAM
Optical Drive DVD/CD-RW
Hard Drive 30-GB SMART
Communications Type III Mini PCI 56K (V.92) modem, (LOM) integrated 10/100 NIC
Graphics ATI Mobility Radeon 7500, 64-bit video graphics
Video Memory 32-MB VRAM
Audio JBL Pro Speakers with bass reflex and 16-bit stereo sound
Operating System Microsoft Windows XP Professional
Warranty One Year
Display 15-inch color TFT XGA
Processor 2.0 GHzIntel Pentium 4 processor
Cache Memory 512KB, L2 Cache
N1000vP200X530WC252
Memory Standard 256 MB (266 MHz) DDR SDRAM
Maximum 1024 MB (266 MHz) DDR SDRAM
Optical Drive DVD/CD-RW
Hard Drive 30-GB SMART
Communications Type III Mini PCI 56K (V.92) modem, (LOM) integrated 10/100 NIC
Graphics ATI Mobility Radeon 7500, 64-bit video graphics
Video Memory 32-MB VRAM
Audio JBL Pro Speakers with bass reflex and 16-bit stereo sound
Operating System Microsoft Windows 2000
Warranty One Year

QuickSpecs Compaq Evo Notebook N1000v
DA-11371 World Wide —Version 6 — October3, 2002 8
Standard Features
Models (continued)
Display 14.1-inch color TFT XGA
Processor 2.0 GHz Intel Pentium4 processor
Cache Memory 512-KB, L2 Cache
N1000vP200X420VC25O
Memory Standard 256 MB (266 MHz) DDR SDRAM
Maximum 1024 MB (266 MHz) DDR SDRAM
Optical Drive DVD
Hard Drive 20-GB SMART
Communications Type III Mini PCI 56K (V.92) modem, (LOM) integrated 10/100 NIC
Graphics ATI Mobility Radeon 7500, 64-bit video graphics
Video Memory 32-MB VRAM
Audio JBL Pro Speakers with bass reflex and 16-bit stereo sound
Operating System Microsoft Windows XP Professional
Warranty One Year
Display 14.1-inch color TFT XGA
Processor 2.0 GHz Intel Pentium 4 processor
Cache Memory 512-KB, L2 Cache
N1000vP200X420VC252
Memory Standard 256 MB (266 MHz) DDR SDRAM
Maximum 1024 MB (266 MHz) DDR SDRAM
Optical Drive DVD
Hard Drive 20-GB SMART
Communications Type III Mini PCI 56K (V.92) modem, (LOM) integrated 10/100 NIC
Graphics ATI Mobility Radeon 7500, 64-bit video graphics
Video Memory 32-MB VRAM
Audio JBL Pro Speakers with bass reflex and 16-bit stereo sound
Operating System Microsoft Windows 2000
Warranty One Year
Display 14.1-inch color TFT XGA
Processor 1.5 GHz Intel Celeron processor
Cache Memory 256-KB, L2 Cache
N1000vC150X420VC252
Memory Standard 256 MB (266 MHz) DDR SDRAM
Maximum 1024 MB (266 MHz) DDR SDRAM
Optical Drive DVD
Hard Drive 20-GB SMART
Communications Type III Mini PCI 56K (V.92) modem, (LOM) integrated 10/100 NIC
Graphics ATI Mobility Radeon 7500, 64-bit video graphics
Video Memory 32-MB VRAM
Audio JBL Pro Speakers with bass reflex and 16-bit stereo sound
Operating System Microsoft Windows 2000
Warranty One Year

QuickSpecs Compaq Evo Notebook N1000v
DA-11371 World Wide —Version 6 — October3, 2002 9
Standard Features
Models (continued)
Display 14.1-inch color TFT XGA
Processor 1.5 GHz Intel Celeron processor
Cache Memory 256-KB, L2 Cache
N1000vC150X420VC25O
Memory Standard 256 MB (266 MHz) DDR SDRAM
Maximum 1024 MB (266 MHz) DDR SDRAM
Optical Drive DVD
Hard Drive 20-GB SMART
Communications Type III Mini PCI 56K (V.92) modem, (LOM) integrated 10/100 NIC
Graphics ATI Mobility Radeon 7500, 64-bit video graphics
Video Memory 32-MB VRAM
Audio JBL Pro Speakers with bass reflex and 16-bit stereo sound
Operating System Microsoft Windows XP Professional
Warranty One Year
Display 14.1-inch color TFT XGA
Processor 2.0 GHz Intel Pentium 4 processor
Cache Memory 512-KB, L2 Cache
N1000vP200X420VC25O
Memory Standard 256 MB (266 MHz) DDR SDRAM
Maximum 1024 MB (266 MHz) DDR SDRAM
Optical Drive DVD
Hard Drive 20-GB SMART
Communications Type III Mini PCI 56K (V.92) modem, (LOM) integrated 10/100 NIC
Graphics ATI Mobility Radeon 7500, 64-bit video graphics
Video Memory 32-MB VRAM
Audio JBL Pro Speakers with bass reflex and 16-bit stereo sound
Operating System Microsoft Windows XP Professional
Warranty Two Year
Display 14.1-inch color TFT XGA
Processor 2.0 GHz Intel Pentium 4 processor
Cache Memory 512-KB, L2 Cache
N1000vP200X420VC252
Memory Standard 256 MB (266 MHz) DDR SDRAM
Maximum 1024 MB (266 MHz) DDR SDRAM
Optical Drive DVD
Hard Drive 20-GB SMART
Communications Type III Mini PCI 56K (V.92) modem, (LOM) integrated 10/100 NIC
Graphics ATI Mobility Radeon 7500, 64-bit video graphics
Video Memory 32-MB VRAM
Audio JBL Pro Speakers with bass reflex and 16-bit stereo sound
Operating System Microsoft Windows 2000
Warranty Two Year

QuickSpecs Compaq Evo Notebook N1000v
DA-11371 World Wide —Version 6 — October3, 2002 10
Standard Features
Models (continued)
Display 14.1-inch color TFT XGA
Processor 1.5 GHz Intel Celeron processor
Cache Memory 256-KB, L2 Cache
N1000vC150X420VC252
Memory Standard 256 MB (266 MHz) DDR SDRAM
Maximum 1024 MB (266 MHz) DDR SDRAM
Optical Drive DVD
Hard Drive 20-GB SMART
Communications Type III Mini PCI 56K (V.92) modem, (LOM) integrated 10/100 NIC
Graphics ATI Mobility Radeon 7500, 64-bit video graphics
Video Memory 32-MB VRAM
Audio JBL Pro Speakers with bass reflex and 16-bit stereo sound
Operating System Microsoft Windows 2000
Warranty Two Year
Display 14.1-inch color TFT XGA
Processor 1.5 GHz Intel Celeron processor
Cache Memory 256-KB, L2 Cache
N1000vC150X420VC25O
Memory Standard 256 MB (266 MHz) DDR SDRAM
Maximum 1024 MB (266 MHz) DDR SDRAM
Optical Drive DVD
Hard Drive 20-GB SMART
Communications Type III Mini PCI 56K (V.92) modem, (LOM) integrated 10/100 NIC
Graphics ATI Mobility Radeon 7500, 64-bit video graphics
Video Memory 32-MB VRAM
Audio JBL Pro Speakers with bass reflex and 16-bit stereo sound
Operating System Microsoft Windows XP Professional
Warranty Two Year
Display 15-inch color TFT SXGA+
Processor 2.2 GHz Intel Pentium 4 processor
Cache Memory 512-KB, L2 Cache
N1000vP220P540WC25O
Memory Standard 256 MB (266 MHz) DDR SDRAM
Maximum 1024 MB (266 MHz) DDR SDRAM
Optical Drive DVD/CD-RW
Hard Drive 40-GB SMART
Communications Type III Mini PCI 56K (V.92) modem (Global Controllerless), (LOM) integrated 10/100
NIC
Graphics ATI Mobility Radeon 7500, 64-bit video graphics
Video Memory 32-MB VRAM
Audio JBL Pro Speakers with bass reflex and 16-bit stereo sound
Operating System Microsoft Windows XP Professional
Warranty One Year

QuickSpecs Compaq Evo Notebook N1000v
DA-11371 World Wide —Version 6 — October3, 2002 11
Standard Features
Models (continued)
Display 15-inch color TFT XGA
Processor 2.0 GHz Intel Pentium 4 processor
Cache Memory 512-KB, L2 Cache
N1000vP200X520DC122
Memory Standard 128 MB (266 MHz) DDR SDRAM
Maximum 1024 MB (266 MHz) DDR SDRAM
Optical Drive CD
Hard Drive 20-GB SMART
Communications Type III Mini PCI 56K (V.92) modem (Global Controllerless), (LOM) integrated 10/100
NIC
Graphics ATI Mobility Radeon 7500, 64-bit video graphics
Video Memory 32-MB VRAM
Audio JBL Pro Speakers with bass reflex and 16-bit stereo sound
Operating System Microsoft Windows 2000
Warranty One Year
Display 15-inch color TFT XGA
Processor 2.0 GHz Intel Pentium 4 processor
Cache Memory 512-KB, L2 Cache
N1000vP200X520DC122
Memory Standard 128 MB (266 MHz) DDR SDRAM
Maximum 1024 MB (266 MHz) DDR SDRAM
Optical Drive CD
Hard Drive 20-GB SMART
Communications Type III Mini PCI 56K (V.92) modem (Global Controllerless), (LOM) integrated 10/100
NIC
Graphics ATI Mobility Radeon 7500, 64-bit video graphics
Video Memory 32-MB VRAM
Audio JBL Pro Speakers with bass reflex and 16-bit stereo sound
Operating System Microsoft Windows XP Professional
Warranty One Year
Display 14-inch color TFT XGA
Processor 1.5 GHz Intel Celeron processor
Cache Memory 256-KB, L2 Cache
N1000vC150X420DC122O
Memory Standard 128 MB (266 MHz) DDR SDRAM
Maximum 1024 MB (266 MHz) DDR SDRAM
Optical Drive CD
Hard Drive 20-GB SMART
Communications Type III Mini PCI 56K (V.92) modem (Global Controllerless), (LOM) integrated 10/100
NIC
Graphics ATI Mobility Radeon 7500, 64-bit video graphics
Video Memory 32-MB VRAM
Audio JBL Pro Speakers with bass reflex and 16-bit stereo sound
Operating System Microsoft Windows XP Professional
Warranty One Year

QuickSpecs Compaq Evo Notebook N1000v
DA-11371 World Wide —Version 6 — October3, 2002 12
Standard Features
Models (continued)
Display 14-inch color TFT XGA
Processor 1.5 GHz Intel Celeron processor
Cache Memory 256-KB, L2 Cache
N1000vC150X420DC1222
Memory Standard 128 MB (266 MHz) DDR SDRAM
Maximum 1024 MB (266 MHz) DDR SDRAM
Optical Drive CD
Hard Drive 20-GB SMART
Communications Type III Mini PCI 56K (V.92) modem (Global Controllerless), (LOM) integrated 10/100
NIC
Graphics ATI Mobility Radeon 7500, 64-bit video graphics
Video Memory 32-MB VRAM
Audio JBL Pro Speakers with bass reflex and 16-bit stereo sound
Operating System Microsoft Windows 2000
Warranty One Year
Display 14-inch color TFT XGA
Processor 1.5 GHz Intel Celeron processor
Cache Memory 256-KB, L2 Cache
N1000vC150X420DC122E
Memory Standard 128 MB (266 MHz) DDR SDRAM
Maximum 1024 MB (266 MHz) DDR SDRAM
Optical Drive CD
Hard Drive 20-GB SMART
Communications Type III Mini PCI 56K (V.92) modem (Global Controllerless), (LOM) integrated 10/100
NIC
Graphics ATI Mobility Radeon 7500, 64-bit video graphics
Video Memory 32-MB VRAM
Audio JBL Pro Speakers with bass reflex and 16-bit stereo sound
Operating System Microsoft Windows XP Home
Warranty One Year

QuickSpecs Compaq Evo Notebook N1000v
DA-11371 World Wide —Version 6 — October3, 2002 13
Standard Features
CPU 2.0 GHz Pentium 4 2.0 GHzPentium 4 2.2 GHzPentium 4 2.2 GHz Pentium 4 2.0 GHz Pentium 4
LCD 15.0-inch XGA 14.1-inch XGA 15.0-inch SXGA+ 15.0-inch SXGA+ 15.0-inch XGA
Memory256 MB 256 MB 256 MB 256 MB 128 MB
HDD 30 GB 20 GB 30 GB 40 GB 20 GB
Discrete Video
Memory32 MB 32 MB 32 MB 32 MB 32 MB
Optical DVD/CDRW 8X DVD DVD/CDRW DVD/CDRW 24XCD
Diskette Drive 1.44-MB floppy 1.44-MB floppy 1.44-MB floppy 1.44-MB floppy 1.44-MB floppy
Comm Modem/NIC Modem/NIC Modem/NIC Modem /NIC
(ControllessGlobal) Modem/NIC (ControllessGlobal)
Input Touchpad Touchpad Touchpad Touchpad Touchpad
Battery 8-cell 4.0Ah 8-cell 4.0Ah 8-cell 4.0Ah 8-cell 4.0Ah 8-cell 4.0Ah
U.S.
N1000vP200X530WC25O Windows XP Professional 470036-618
N1000vP200X530WC252 Windows2000 470036-621
N1000vP200X420VC25O Windows XP Professional 470036-628
N1000vP200X420VC252 Windows2000 470036-631
Fr Canada
N1000vP200X530WC25O Windows XP Professional 470036-619
N1000vP200X530WC252 Windows2000 470036-620
N1000vP200X420VC25O Windows XP Professional 470036-629
N1000vP200X420VC252 Windows2000 470036-630
Arabia
N1000vP200X420VC25O Windows XP Professional 470036-689
N1000vP200X420VC252 Windows2000 470036-690
N1000vP220P530WC25O Windows XP Professional 470036-692
N1000vP220P530WC252 Windows2000 470036-693
Belgium
N1000vP200X420VC25O Windows XP Professional 470036-694
N1000vP200X420VC252 Windows2000 470036-695
N1000vP220P530WC25O Windows XP Professional 470036-696
N1000vP220P530WC252 Windows2000 470036-697
Czech Republic
N1000vP200X420VC25O Windows XP Professional 470036-698
N1000vP200X420VC252 Windows2000 470036-699
N1000vP220P530WC25O Windows XP Professional 470036-700
N1000vP220P530WC252 Windows2000 470036-701

QuickSpecs Compaq Evo Notebook N1000v
DA-11371 World Wide —Version 6 — October3, 2002 14
Standard Features
CPU 2.0 GHz Pentium 4 2.0 GHzPentium 4 2.2 GHzPentium 4 2.2 GHz Pentium 4 2.0 GHz Pentium 4
LCD 15.0-inch XGA 14.1-inch XGA 15.0-inch SXGA+ 15.0-inch SXGA+ 15.0-inch XGA
Memory256 MB 256 MB 256 MB 256 MB 128 MB
HDD 30 GB 20 GB 30 GB 40 GB 20 GB
Discrete Video
Memory32 MB 32 MB 32 MB 32 MB 32 MB
Optical DVD/CDRW 8X DVD DVD/CDRW DVD/CDRW 24XCD
Diskette Drive 1.44-MB floppy 1.44-MB floppy 1.44-MB floppy 1.44-MB floppy 1.44-MB floppy
Comm Modem/NIC Modem/NIC Modem/NIC Modem /NIC
(ControllessGlobal) Modem/NIC (ControllessGlobal)
Input Touchpad Touchpad Touchpad Touchpad Touchpad
Battery 8-cell 4.0Ah 8-cell 4.0Ah 8-cell 4.0Ah 8-cell 4.0Ah 8-cell 4.0Ah
Denmark
N1000vP200X420VC25O Windows XP Professional 470036-702
N1000vP200X420VC252 Windows2000 470036-703
N1000vP220P530WC25O Windows XP Professional 470036-704
N1000vP220P530WC252 Windows2000 470036-705
France
N1000vP200X420VC25O Windows XP Professional 470036-709
N1000vP200X420VC252 Windows2000 470036-708
N1000vP220P530WC25O Windows XP Professional 470036-707
N1000vP220P530WC252 Windows2000 470036-706
Germany
N1000vP200X420VC25O WindowsXP Professional-
TWO YEAR 470036-632
N1000vP200X420VC252 Windows2000-TWO
YEAR 470036-633
N1000vP220P530WC25O WindowsXP Professional-
TWO YEAR 470036-634
N1000vP220P530WC252 Windows2000-TWO
YEAR 470036-635
Greece/Poland
N1000vP200X420VC25O Windows XP Professional 470036-710
N1000vP200X420VC252 Windows2000 470036-711
N1000vP220P530WC25O Windows XP Professional 470036-712
N1000vP220P530WC252 Windows2000 470036-713
Hungary
N1000vP200X420VC25O Windows XP Professional 470036-717
N1000vP200X420VC252 Windows2000 470036-716
N1000vP220P530WC25O Windows XP Professional 470036-715
N1000vP220P530WC252 Windows2000 470036-714

QuickSpecs Compaq Evo Notebook N1000v
DA-11371 World Wide —Version 6 — October3, 2002 15
Standard Features
CPU 2.0 GHz Pentium 4 2.0 GHzPentium 4 2.2 GHzPentium 4 2.2 GHz Pentium 4 2.0 GHz Pentium 4
LCD 15.0-inch XGA 14.1-inch XGA 15.0-inch SXGA+ 15.0-inch SXGA+ 15.0-inch XGA
Memory256 MB 256 MB 256 MB 256 MB 128 MB
HDD 30 GB 20 GB 30 GB 40 GB 20 GB
Discrete Video
Memory32 MB 32 MB 32 MB 32 MB 32 MB
Optical DVD/CDRW 8X DVD DVD/CDRW DVD/CDRW 24XCD
Diskette Drive 1.44-MB floppy 1.44-MB floppy 1.44-MB floppy 1.44-MB floppy 1.44-MB floppy
Comm Modem/NIC Modem/NIC Modem/NIC Modem /NIC
(ControllessGlobal) Modem/NIC (ControllessGlobal)
Input Touchpad Touchpad Touchpad Touchpad Touchpad
Battery 8-cell 4.0Ah 8-cell 4.0Ah 8-cell 4.0Ah 8-cell 4.0Ah 8-cell 4.0Ah
Israel (Hebrew)
N1000vP200X420VC25O Windows XP Professional 470036-718
N1000vP200X420VC252 Windows2000 470036-719
N1000vP220P530WC25O Windows XP Professional 470036-720
N1000vP220P530WC252 Windows2000 470036-721
Italy
N1000vP200X420VC25O Windows XP Professional 470036-725
N1000vP200X420VC252 Windows2000 470036-724
N1000vP220P530WC25O Windows XP Professional 470036-723
N1000vP220P530WC252 Windows2000 470036-722
Netherlands
N1000vP200X420VC25O Windows XP Professional 470036-727
N1000vP200X420VC252 Windows2000 470036-728
N1000vP220P530WC25O Windows XP Professional 470036-730
N1000vP220P530WC252 Windows2000 470036-731
Norway
N1000vP200X420VC25O Windows XP Professional 470036-735
N1000vP200X420VC252 Windows2000 470036-734
N1000vP220P530WC25O Windows XP Professional 470036-733
N1000vP220P530WC252 Windows2000 470036-732
Portugal
N1000vP200X420VC25O Windows XP Professional 470036-736
N1000vP200X420VC252 Windows2000 470036-737
N1000vP220P530WC25O Windows XP Professional 470036-739
N1000vP220P530WC252 Windows2000 470036-741

QuickSpecs Compaq Evo Notebook N1000v
DA-11371 World Wide —Version 6 — October3, 2002 16
Standard Features
CPU 2.0 GHz Pentium 4 2.0 GHzPentium 4 2.2 GHzPentium 4 2.2 GHz Pentium 4 2.0 GHz Pentium 4
LCD 15.0-inch XGA 14.1-inch XGA 15.0-inch SXGA+ 15.0-inch SXGA+ 15.0-inch XGA
Memory256 MB 256 MB 256 MB 256 MB 128 MB
HDD 30 GB 20 GB 30 GB 40 GB 20 GB
Discrete Video
Memory32 MB 32 MB 32 MB 32 MB 32 MB
Optical DVD/CDRW 8X DVD DVD/CDRW DVD/CDRW 24XCD
Diskette Drive 1.44-MB floppy 1.44-MB floppy 1.44-MB floppy 1.44-MB floppy 1.44-MB floppy
Comm Modem/NIC Modem/NIC Modem/NIC Modem /NIC
(ControllessGlobal) Modem/NIC (ControllessGlobal)
Input Touchpad Touchpad Touchpad Touchpad Touchpad
Battery 8-cell 4.0Ah 8-cell 4.0Ah 8-cell 4.0Ah 8-cell 4.0Ah 8-cell 4.0Ah
Russian
N1000vP200X420VC25O Windows XP Professional 470036-745
N1000vP200X420VC252 Windows2000 470036-744
N1000vP220P530WC25O Windows XP Professional 470036-743
N1000vP220P530WC252 Windows2000 470036-742
Slovenia
N1000vP200X420VC25O Windows XP Professional 470036-746
N1000vP200X420VC252 Windows2000 470036-747
N1000vP220P530WC25O Windows XP Professional 470036-748
N1000vP220P530WC252 Windows2000 470036-749
Spain
N1000vP200X420VC25O Windows XP Professional 470036-753
N1000vP200X420VC252 Windows2000 470036-752
N1000vP220P530WC25O Windows XP Professional 470036-751
N1000vP220P530WC252 Windows2000 470036-750
Sweden/Finland
N1000vP200X420VC25O Windows XP Professional 470036-754
N1000vP200X420VC252 Windows2000 470036-755
N1000vP220P530WC25O Windows XP Professional 470036-756
N1000vP220P530WC252 Windows2000 470036-757
Switzerland (GR/FR/IT)
N1000vP200X420VC25O Windows XP Professional 470036-761
N1000vP200X420VC252 Windows2000 470036-760
N1000vP220P530WC25O Windows XP Professional 470036-759
N1000vP220P530WC252 Windows2000 470036-758

QuickSpecs Compaq Evo Notebook N1000v
DA-11371 World Wide —Version 6 — October3, 2002 17
Standard Features
CPU 2.0 GHz Pentium 4 2.0 GHzPentium 4 2.2 GHzPentium 4 2.2 GHz Pentium 4 2.0 GHz Pentium 4
LCD 15.0-inch XGA 14.1-inch XGA 15.0-inch SXGA+ 15.0-inch SXGA+ 15.0-inch XGA
Memory256 MB 256 MB 256 MB 256 MB 128 MB
HDD 30 GB 20 GB 30 GB 40 GB 20 GB
Discrete
V
ideo
Memory32 MB 32 MB 32 MB 32 MB 32 MB
Optical DVD/CDRW 8X DVD DVD/CDRW DVD/CDRW 24XCD
Diskette Drive 1.44-MB floppy 1.44-MB floppy 1.44-MB floppy 1.44-MB floppy 1.44-MB floppy
Comm Modem/NIC Modem/NIC Modem/NIC Modem /NIC
(ControllessGlobal) Modem/NIC (ControllessGlobal)
Input Touchpad Touchpad Touchpad Touchpad Touchpad
Battery 8-cell 4.0Ah 8-cell 4.0Ah 8-cell 4.0Ah 8-cell 4.0Ah 8-cell 4.0Ah
Turkey
N1000vP200X420VC25O Windows XP Professional 470036-762
N1000vP200X420VC252 Windows2000 470036-763
N1000vP220P530WC25O Windows XP Professional 470036-764
N1000vP220P530WC252 Windows2000 470036-765
UK
N1000vP200X420VC25O Windows XP Professional 470036-769
N1000vP200X420VC252 Windows2000 470036-768
N1000vP220P530WC25O Windows XP Professional 470036-767
N1000vP220P530WC252 Windows2000 470036-766
Japan
N1000vP220P540WC25O Windows XP Professional 470036-636
N1000vP200X520DC122 Windows2000 470036-637
N1000vP200X520DC12O Windows XP Professional 470036-638
Japan (English)
N1000vP220P540WC25O Windows XP Professional 470036-639
N1000vP200X520DC122 Windows2000 470036-640
N1000vP200X520DC12O Windows XP Professional 470036-641

QuickSpecs Compaq Evo Notebook N1000v
DA-11371 World Wide —Version 6 — October3, 2002 18
Standard Features
CPU 2.0 GHz Pentium 4 2.0 GHzPentium 4 2.2 GHzPentium 4 2.2 GHz Pentium 4 2.0 GHz Pentium 4
LCD 15.0-inch XGA 14.1-inch XGA 15.0-inch SXGA+ 15.0-inch SXGA+ 15.0-inch XGA
Memory256 MB 256 MB 256 MB 256 MB 128 MB
HDD 30 GB 20 GB 30 GB 40 GB 20 GB
Discrete Video
Memory32 MB 32 MB 32 MB 32 MB 32 MB
Optical DVD/CDRW 8X DVD DVD/CDRW DVD/CDRW 24XCD
Diskette Drive 1.44-MB floppy 1.44-MB floppy 1.44-MB floppy 1.44-MB floppy 1.44-MB floppy
Comm Modem/NIC Modem/NIC Modem/NIC Modem /NIC
(ControllessGlobal) Modem/NIC (ControllessGlobal)
Input Touchpad Touchpad Touchpad Touchpad Touchpad
Battery 8-cell 4.0Ah 8-cell 4.0Ah 8-cell 4.0Ah 8-cell 4.0Ah 8-cell 4.0Ah
Latin America
N1000vP200X530WC25O Windows XP Professional 470036-616
N1000vP200X530WC252 Windows2000 470036-622
N1000vP200X420VC25O Windows XP Professional 470036-625
N1000vP200X420VC252 Windows2000 470036-626
Latin America – NAFTA
N1000vP200X530WC25ON WindowsXP Professional-
NAFTA 470036-617
N1000vP200X530WC252N Windows2000-NAFTA 470036-623
N1000vP200X420VC25ON WindowsXP Professional-
NAFTA 470036-624
N1000vP200X420VC252N Windows2000-NAFTA 470036-627

QuickSpecs Compaq Evo Notebook N1000v
DA-11371 World Wide —Version 6 — October3, 2002 19
Options
Memory 512-MB (266 MHz) DDR SDRAM Memory Upgrade 269087-B25
256-MB (266 MHz) DDR SDRAM Memory Upgrade 269086-B25
128-MB (266 MHz) DDR SDRAM Memory Upgrade 269085-B25
Monitors TFT8030 Flat Panel Color 18-inch (carbon/silver) 243362-xxx
TFT7020 Flat Panel Color 17-inch with integrated speakers (carbon/silver) 253217-xxx
TFT5015 Flat Panel Color 15-inch (carbon/silver) 234044-xxx
TFT5030 Flat Panel Color 15-inch (carbon/silver) 228134-xxx
V720 17-inch CRT (carbon/silver) 232944-xxx
S720 17-inch CRT (carbon/silver) 239287-xxx
V570 15-inch CRT (carbon/silver) 228113-xxx
Other Storage Devices IBM1-GB Microdrive(PC card Device) 217390-B25
USB Disk-on-Key – 8 MB 249552-B25
Connectivity Compaq Type III Mini PCI 56K (V.90) Modem 225640-B31
Compaq Type III Mini PCI 56K (V.90) Modem plus 10/100 NIC Combo 225642-B31
100BaseTX Ethernet Upgrade 225435-001
1394 PC Card 177593-B25
NOTE: Designed only to allow faster downloads from V.90 compliant sources. Maximum achievable download
transmission rates currently do not reach 56 KB/s, and will vary with line conditions.
Wireless Connectivity 802.11b MultiPort Wireless LAN module 233412-001
Bluetooth MultiPort module 228057-B21
Compaq WL110 Wireless LAN PC Card 191808-B21
Compaq WL510 Wireless Enterprise Access Point 216709-001
Compaq WL410 Wireless SMB Access Point 191811-001
Compaq WL310 Home Office Access Point 191813-001
Compaq Range Extender Antenna 230268-B21
CDPD WWAN PC Card (U.S. Only) 238111-001
Expansion Bases Port Replicator 269095-xx1
Advanced Port Replicator 269094-xx1
External MultiBay 217388-001/002
Monitor Stand 274407-B25
Power Evo Notebook N1000v 8 Cell primary battery (4Wh) 278418-B25
8 Cell primary battery (4.4Wh) 291369-B25
Common Power Solutions External Battery Charger 265603-xxx
External Battery Charger (Multiple Battery) 265604-xx1
AC Adapter 90W 283884-xxx
Aircraft Power Adapter 90w 291370-B25
AC Line Cord (10-ft/3.1 m) 217932-xx2
Input Devices External Enhanced III Keyboard (carbon) 118003-008
Compaq 2 Button Mouse (carbon) 103180-B21
USB 2 Button Scroll Mouse (carbon) 195255-B25
External 10-Key Numeric Keypad (carbon) 294317-B21
USB EZ Access Keyboard 222726-xxx
Wireless Keyboard and Mouse 251385-xx8

QuickSpecs Compaq Evo Notebook N1000v
DA-11371 World Wide —Version 6 — October3, 2002 20
Options
Security Biometric PC Card 146805-B25
Security Cable Lock 294316-B21
Compaq Smart Card PC Card Reader 135646-B25
Useful Accessories Compaq iPAQ Microportable Projector MP1200 261966-xxx
Compaq iPAQ Microportable Projector MP3800 262839-xxx
Compaq iPAQ Microportable Projector MP4800 257524-xxx
Lamp Module L20 for MP1200 266631-B24
Lamp Module L30 for MP3800 266633-B24
Home Theatre Kit HT150 for MP3800 292187-B24
Carrying Case for MP1200 295731-B24
Lamp Replacement Kit for MP1600 118052-001
Lamp Module for MP1800, MP1400 189789-001
Lamp Module for MP2800, MP2810 215464-001
Home Theater Kit HT110 for MP1410 246161-001
Multimedia Adapter & Remote Control Kit MMA110 for MP1410 246162-001
Multimedia Adapter & Remote Control Kit for MP1400, MP1800 174963-001
Deluxe Carrying Case for MP Series projectors 253364-001
Lamp Module for MP1410, MP1810 253365-001
Lamp Module L90 for MP4800 257892-001
Home Theater Kit HT180 for MP1200, MP4800 281729-001
CeilingMount Kit CM10 for MP1200, MP4800 281730-001
hp digital projector sb21 L1510A
hp digital projector xb31 L1511A
Ceiling Mount Kit for xb31 L1513A
M1-A to component/USB video cable for sb21, xb31 L1523A
M1-D to DVI/USB cable for sb21, xb31 L1529A
Lamp Module for sb21 L1515A
Lamp Module for xb31 L1516A
