Maintenance & Service Guide
Presario 1600 Series
Models: 1650 and 1655
| Home Page | Notice | Preface | Product Description | Troubleshooting
Illustrated Parts Catalog | Removal & Replacement Procedures |Specifications
Pin Assignments |Battery Pack Operations
Notice
Preface
Product
Description
Troubleshooting
Illustrated
Parts Catalog
Removal &
Replacement
Procedures
Specifications
Connector Pin
Assignments
Battery Pack
Operations
Click here to download the zip file for the following Maintenance & Service
Guide.
Welcome to the Maintenance & Service Guide (MSG). This online guide is designed to
serve the needs of those whose job it is to repair Compaq products. Many of the
components of the hardcopy MSG are contained in this online guide. The Notice,
contains the copyright and trademark information. The Preface shows symbol
conventions, Technician Notes and Serial Number locations on the unit.
This MSG will be periodically maintained and updated online as needed. For content
comments or questions, contact the Editor.
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20chec...201600%20SERIES%201650%20and%201655/index.html (1 of 2)6/27/2004 2:52:14 AM

"Compaq.com - Compaq Presario 1600 Series Maintenance and Service Guide - Models: 1650 and 1655
To report a technical problem, contact your Regional Support Center or IM Help Center.
1.800.AT.COMPAQ
privacy and legal statement
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20chec...201600%20SERIES%201650%20and%201655/index.html (2 of 2)6/27/2004 2:52:14 AM

"Compaq.com - Compaq Presario 1600 Series Maintenance and Service Guide - Models: 1650 and 1655
United States June 27, 2004
COMPAQ
STORE | PRODUCTS | SERVICES | SUPPORT | CONTACT US |
SEARCH
Maintenance & Service Guide
Presario 1600 Series
Models: 1650 and 1655
| Home Page | Notice | Preface | Product Description | Troubleshooting
Illustrated Parts Catalog | Removal & Replacement Procedures |Specifications
Pin Assignments |Battery Pack Operations
Notice
The information in this guide is subject to change without notice.
COMPAQ COMPUTER CORPORATION SHALL NOT BE LIABLE FOR TECHNICAL OR EDITORIAL
ERRORS OR OMISSIONS CONTAINED HEREIN, NOR FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES RESULTING FROM THE FURNISHING, PERFORMANCE, OR USE OF THIS MATERIAL.
This guide contains information protected by copyright. No part of this guide may be photocopied or
reproduced in any form without prior written consent from Compaq Computer Corporation.
Ó 1998 Compaq Computer Corporation.
All rights reserved. Printed in the U.S.A.
Compaq, Presario Registered U. S. Patent and Trademark Office.
Microsoft, MS-DOS, and Windows are registered trademarks of Microsoft Corporation.
Windows 95 is a trademark of Microsoft Corporation.
The software described in this guide is furnished under a license agreement or nondisclosure agreement.
The software may be used or copied only in accordance with the terms of the agreement.
Product names mentioned herein may be trademarks and/or registered trademarks of their respective
companies.
Maintenance and Service Guide
Compaq Presario 1600 Series Portable Computers
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20chec...01600%20SERIES%201650%20and%201655/notice.html (1 of 2)6/27/2004 2:52:20 AM

"Compaq.com - Compaq Presario 1600 Series Maintenance and Service Guide - Models: 1650 and 1655
First Edition (June 1998)
Compaq Computer Corporation
1.800.AT.COMPAQ
privacy and legal statement
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20chec...01600%20SERIES%201650%20and%201655/notice.html (2 of 2)6/27/2004 2:52:20 AM

"Compaq.com - Compaq Presario 1600 Series Maintenance and Service Guide - Models: 1650 and 1655
United States June 27, 2004
COMPAQ
STORE | PRODUCTS | SERVICES | SUPPORT | CONTACT US |
SEARCH
Maintenance & Service Guide
Presario 1600 Series
Models: 1650 and 1655
| Home Page | Notice | Preface | Product Description | Troubleshooting
Illustrated Parts Catalog | Removal & Replacement Procedures |Specifications
Pin Assignments |Battery Pack Operations
Preface
This Maintenance and Service Guide is a troubleshooting guide that can be used for reference when servicing the
Compaq Presario 1600 Series Portable Computers.
Compaq Computer Corporation reserves the right to make changes to the Compaq Presario 1600 Series Portable
Computers without notice.
Symbols
The following words and symbols mark special messages throughout this guide.
WARNING: Text set off in this manner indicates that failure to follow directions in the warning could result in bodily harm
or loss of life.
CAUTION: Text set off in this manner indicates that failure to follow directions could result in damage to equipment or
loss of data.
IMPORTANT: Text set off in this manner presents clarifying information or specific instructions.
NOTE: Text set off in this manner presents commentary, sidelights, or interesting points of information.
Technician Notes
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20chec...1600%20SERIES%201650%20and%201655/preface.html (1 of 2)6/27/2004 2:52:21 AM

"Compaq.com - Compaq Presario 1600 Series Maintenance and Service Guide - Models: 1650 and 1655
WARNING: Only authorized technicians trained by Compaq should repair this equipment. All troubleshooting and repair
procedures are detailed to allow only subassembly/module level repair. Because of the complexity of the individual boards
and subassemblies, the user should not attempt to make repairs at the component level or to make modifications to any
printed circuit board. Improper repairs can create a safety hazard. Any indications of component replacement or printed
circuit board modifications may void any warranty
Serial Number
When requesting information or ordering spare parts, the computer serial number should be provided to Compaq. The
serial number is located on the bottom of the computer.
Locating Additional Information
The following documentation is available to support this product:
●Compaq Presario 1600 Series Portable Computer documentation set
●Introducing Windows 98 Guide
●Service Training Guides
●Compaq Service Advisories and Bulletins
●Compaq QuickFind
●Compaq Service Quick Reference Guide
1.800.AT.COMPAQ
privacy and legal statement
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20chec...1600%20SERIES%201650%20and%201655/preface.html (2 of 2)6/27/2004 2:52:21 AM

"Compaq.com - Compaq Presario 1600 Series Maintenance and Service Guide - Models: 1650 and 1655
United States June 27, 2004
COMPAQ
STORE | PRODUCTS | SERVICES | SUPPORT | CONTACT US |
SEARCH
Maintenance & Service Guide
Presario 1600 Series
Models: 1650 and 1655
| Home Page | Notice | Preface | Product Description | Troubleshooting
Illustrated Parts Catalog | Removal & Replacement Procedures |Specifications
Pin Assignments |Battery Pack Operations
Product Description
Models and
Features
Controls and
Lights
Left Side
Components
Right Side
Components
Bottom of
Unit
Rear
Connectors
Port Replicator
Power
Management
for Windows
98
Compaq
Presario
1600 Series
Portable
Computer is
a
continuation
of the new
generation
of
multimedia
portable
computers
with an
innovative
integrated
design,
outstanding
audio and
video,
advanced
core
features,
and
attractive
styling. This
full-
function,
Pentium II -
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20chec...1600%20SERIES%201650%20and%201655/product.html (1 of 2)6/27/2004 2:52:21 AM

"Compaq.com - Compaq Presario 1600 Series Maintenance and Service Guide - Models: 1650 and 1655
based
series of
portable
computers
allows full
desktop
functionality
and
additional
connectivity
via the
optional
port
replicator.
1.800.AT.COMPAQ
privacy and legal statement
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20chec...1600%20SERIES%201650%20and%201655/product.html (2 of 2)6/27/2004 2:52:21 AM

"Compaq.com - Compaq Presario 1600 Series Maintenance and Service Guide - Models: 1650 and 1655
United States June 27, 2004
COMPAQ
STORE | PRODUCTS | SERVICES | SUPPORT | CONTACT US |
SEARCH
Maintenance & Service Guide
Presario 1600 Series
Models: 1650 and 1655
| Home Page | Notice | Preface | Product Description | Troubleshooting
Illustrated Parts Catalog | Removal & Replacement Procedures |Specifications
Pin Assignments |Battery Pack Operations
Troubleshooting
Preliminary Steps
Clearing the Power-On
Password
Power-On Self Test
(POST)
Compaq Diagnostics
Diagnostic Error Codes
Troubleshooting
Without Diagnostics
Solving Minor
Problems
Contacting Compaq
Support
This section covers troubleshooting information for the
Compaq Presario 1600 Series Portable Computers. The basic
steps in troubleshooting include:
1. Follow the Preliminary Steps.
2. Run the Power-On Self-Test
(POST).
3. Follow the recommended actions
described in the diagnostic tables, if
you are unable to run POST or if
POST displays an error message.
When following the recommended
actions in the Sections on POST and
Diagnostic Error Codes perform them
in the order listed. Rerun POST after
each recommended action until the
problem is solved and no error
message occurs. Once the problem is
solved, do not complete the
remaining recommended actions.
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20chec...1600%20SERIES%201650%20and%201655/trouble.html (1 of 2)6/27/2004 2:52:22 AM

"Compaq.com - Compaq Presario 1600 Series Maintenance and Service Guide - Models: 1650 and 1655
NOTE:
If the problem is
intermittent, check the
computer several times to
verify that the problem is
solved.
1.800.AT.COMPAQ
privacy and legal statement
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20chec...1600%20SERIES%201650%20and%201655/trouble.html (2 of 2)6/27/2004 2:52:22 AM

file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20checked%20ok/NOT...S/PRESARIO%201600%20SERIES%201650%20and%201655/illust.html
United States June 27, 2004
COMPAQ
STORE | PRODUCTS | SERVICES | SUPPORT | CONTACT US |
SEARCH
Maintenance & Service Guide
Presario 1600 Series
Models: 1650 and 1655
| Home Page | Notice | Preface | Product Description | Troubleshooting
Illustrated Parts Catalog | Removal & Replacement Procedures |Specifications
Pin Assignments |Battery Pack Operations
Illustrated Parts Catalog
System Unit
Boards
Display
Assembly
Mass Storage
Devices
Miscellaneous
Cable Kit
Cables
Miscellaneous
Hardware and
Plastics Kit
Miscellaneous
Parts
Documentation
and Software
This section provides an breakdown and identifies the spare parts ordering
number associated with each item(s) for the Compaq Presario 1600 Series
Portable Computers.
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20check...201600%20SERIES%201650%20and%201655/illust.html (1 of 2)6/27/2004 2:52:22 AM

file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20checked%20ok/NOT...S/PRESARIO%201600%20SERIES%201650%20and%201655/illust.html
1.800.AT.COMPAQ
privacy and legal statement
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20check...201600%20SERIES%201650%20and%201655/illust.html (2 of 2)6/27/2004 2:52:22 AM

Removal & Replace
United States June 27, 2004
COMPAQ
STORE | PRODUCTS | SERVICES | SUPPORT | CONTACT US |
SEARCH
Maintenance & Service Guide
Presario 1600 Series
Models: 1650 and 1655
| Home Page | Notice | Preface | Product Description | Troubleshooting
Illustrated Parts Catalog | Removal & Replacement Procedures |Specifications
Pin Assignments |Battery Pack Operations
Removal and Replacement Procedures
This section explains the removal and replacement procedures for the computer.
Serial Number Location
Disassembly
Sequence
Electrostatic
Discharge
Service
Considerations
Cables and
Connectors
Preparing the
Computer for
Disassembly
Battery Pack
Palmrest
Cover with
Touch Pad
Keyboard Report the computer serial number to Compaq when requesting
information or ordering spare parts.
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20chec...1600%20SERIES%201650%20and%201655/removal.html (1 of 2)6/27/2004 2:52:23 AM

Removal & Replace
Heatspreader
Modem
Processor
Status Panel
Interface
Board
Hard Drives
Battery
Charger Board
CD Drive
Display Panel
Assembly
Upper CPU
Cover
Speaker
Assembly
Diskette Drive
Fan Assembly
Audio Board
System Board
Memory
Module
1.800.AT.COMPAQ
privacy and legal statement
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20chec...1600%20SERIES%201650%20and%201655/removal.html (2 of 2)6/27/2004 2:52:23 AM

Specs
United States June 27, 2004
COMPAQ
STORE | PRODUCTS | SERVICES | SUPPORT | CONTACT US |
SEARCH
Maintenance & Service Guide
Presario 1600 Series
Models: 1650 and 1655
| Home Page | Notice | Preface | Product Description | Troubleshooting
Illustrated Parts Catalog | Removal & Replacement Procedures |Specifications
Pin Assignments |Battery Pack Operations
Specifications
This chapter covers the following specifications of Compaq Presario 1600 Series Portable Computers:
●Computer models
●Physical and environmental
●System Interrupts
●System DMA
●System I/O Address
●System Memory Catalog
●Display
●Memory expansion
●Diskette drive
●Hard drive
●CD drive
●Battery pack
Physical and Environmental
Computer Specifications
U.S. Metric
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20chec...%201600%20SERIES%201650%20and%201655/spec.html (1 of 9)6/27/2004 2:52:25 AM

Specs
Dimensions
Height
Depth
Width
1.97 in
12.20 in
10.08 in
4.95 cm
31.00 cm
25.40 cm
Weight
Model 1650
Model 1655 7.326 Ib
7.326 Ib 3.33 kg 3.33 kg
Stand-Alone (Battery Pack) Power
Requirements
Nominal Operating
Maximum Average
Peak Operating
NiMH
W @ 9.6 V
W @ 9.6 V
W @ 9.6 V
Li-ion
W @ 14.4 V
W @ 14.4 V
W @ 14.4 V
AC Power Requirements
Operating Voltage
Operating Current
Operating Frequency
Maximum Transient
100-240 V
0.8/0.4 A RMS
47-63 Hz
Meets IEC 801-4 and IEC801-5
1kV for 50 ns
Temperature
Operating 50° to 95 °F 10° to 35 °C
Nonoperating -4° to 140 °F -20° to 60 °C
Relative Humidity (noncondensing)
Operating 10 to 90% 35°C to 90%
Nonoperating (tw = 38.7°C max) 5 to 95% 60°C to 95%
Altitude
Operating 0 to 10,000 ft 0 to 3.15 km
Nonoperating 0 to 30,000 ft 0 to 9.14 km
Shock
Operating 10 G, 11 ms, half sine
Non operating 240 G, 2 ms, half sine
Vibration
Operating 0.5 G
Nonoperating 1.5 G
NOTE: Applicable product safety standards specify thermal limits for plastic surfaces. Compaq Presario 1600
Series Portable Computers operate well within this range of temperatures.
System Interrupts
System Interrupts
Hardware IRQ System Function
IRQ0 Timer Interrupt
IRQ1 Keyboard
IRQ2 Interrupt Controller Cascade
IRQ3 Internal Modem
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20chec...%201600%20SERIES%201650%20and%201655/spec.html (2 of 9)6/27/2004 2:52:25 AM

Specs
IRQ4 Communication Port (COM1)
IRQ5 Audio Controller
IRQ6 Diskette Drive
IRQ7 Parallel Port (LPT 1) (default)
IRQ8 System CMOS/Real-Time Clock
IRQ9 IRQ Holder for PCI Steering
IRQ9 PCI-1131 CardBus Controller
IRQ9 IRQ Holder for PCI Steering
IRQ9 IRQ Holder for PCI Steering
IRQ9 PCI-1131 CardBus Controller
IRQ9 Video Controller
IRQ11 Intel PCI to USB Universal Host Controller
IRQ11 IRQ Holder for PCI Steering
IRQ12 PS/2 TouchPad/Mouse
IRQ13 Numeric data processor
IRQ14 Intel PCI Bus Master IDE Controller
IRQ14 Primary IDE Controller (dual fifo)
IRQ15 Intel PCI Bus Master IDE Controller
IRQ15 Secondary IDE Controller (dual fifo)
System DMA
System DMA
Hardware DMA System Function
DMA 0 Audio Controller
DMA 1 Audio Controller
DMA 2 Diskette Drive
DMA 4 DMA Controller
System I/O Address
System I/O Address
I/O Address (Hex) System Function (Shipping Configuration)
0000h-000Fh DMA Controller
0020h-0021h Interrupt Controller
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20chec...%201600%20SERIES%201650%20and%201655/spec.html (3 of 9)6/27/2004 2:52:25 AM

Specs
0040h-0043h System timer
0060h-0060h Keyboard Controller
0061h-0061h System speaker
0064h-0064h Standard 101/102-Key or Microsoft Natural Keyboard
0070h-0071h System CMOS/real time clock
0080h-0080h Motherboard resources
0081h-008Fh DMA Controller
00A0h-00A1h Programmable interrupt controller
00C0h-00DFh DMA
00ECh-00EFh Motherboard resources
00F0h-00FFh Numeric data processor
0170h-0177h Intel PCI Bus Master IDE Controller
0170h-0177h Secondary IDE Controller (dual fifo)
01F0h-01F7h Intel PCI Bus Master IDE Controller
01F0h-01F7h Primary IDE Controller (dual fifo)
0201h-0201h Gameport Joystick
0220h-022Fh ES1869 Plug and Play AudioDrive
02F8h-02FFh Compaq Presario 56K-DF
0330h-0331h ES1869 Plug and Play AudioDrive
0376h-0376h Secondary IDE controller (dual fifo)
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20chec...%201600%20SERIES%201650%20and%201655/spec.html (4 of 9)6/27/2004 2:52:25 AM

Specs
0376h-0376h Intel PCI Bus Master IDE Controller
0378h-037Fh Printer Port (LPT1)
0388h-038Bh ES1869 Plug and Play AudioDrive
03B0h-03BBh Video Controller
03C0h-03DFh Video Controller
03F0h-03F5h Standard Floppy Disk Controller
03F6h-03F6h Intel PCI Bus Master IDE Controller
03F6h-03F6h Primary IDE controller (dual fifo)
03F7h-03F7h Standard Floppy Disk Controller
03F8h-03FFh Communications Port (COM1)
04D0h-04D1h Motherboard resources
0800h-0807h ES1869 Control Interface
0CF8h-0CFFh PCI bus
2180h-218Fh Motherboard resources
8000h-803Fh Motherboard resources
FCD0h-FCD7h Primary IDE controller (dual fifo)
FCD0h-FCDFh Intel PCI Bus Master IDEController
FCD8h-FCDFh Secondary IDE controller (dual fifo)
FCE0h-FCFFh Intel PCI to USB Universal Host Controller
file:///C|/SERVICE%20MANUALS/COMPAQ%20_%20chec...%201600%20SERIES%201650%20and%201655/spec.html (5 of 9)6/27/2004 2:52:25 AM
