Compaq Presario M2000 Mounting instructions

b
Hardware and Software
Guide
Compaq Notebook Series
Document Part Number: 383110-001
May 2005
This guide explains how to identify, access, and use the hardware
and software features available on your notebook.

© Copyright 2005 Hewlett-Packard Development Company, L.P.
Microsoft and Windows are U.S. registered trademarks of Microsoft
Corporation. SD Logo is a trademark of its proprietor. Bluetooth is a
trademark owned by its proprietor and used by Hewlett-Packard Company
under license. Adobe and Acrobat are trademarks of Adobe Systems
Incorporated.
The information contained herein is subject to change without notice. The
only warranties for HP products and services are set forth in the express
warranty statements accompanying such products and services. Nothing
herein should be construed as constituting an additional warranty. HP shall
not be liable for technical or editorial errors or omissions contained herein.
Hardware and Software Guide
Compaq Notebook Series
First Edition May 2005
Reference Number: M2000
Document Part Number: 383110-001

Hardware and Software Guide iii
Contents
1 Hardware
Top Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–1
Keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–1
TouchPad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–3
Power Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–4
Lights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–5
Wireless (Select Models Only) and
Volume Buttons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–7
Antennae (Select Models Only) . . . . . . . . . . . . . . . . 1–8
Front Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–9
Lights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–9
Speakers, Jacks and Display Release Button. . . . . . 1–10
Rear Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–11
Left-Side Components . . . . . . . . . . . . . . . . . . . . . . . . . . 1–12
Ports and Jacks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–12
PC Card Slot and Button . . . . . . . . . . . . . . . . . . . . . 1–13
Right-Side Components . . . . . . . . . . . . . . . . . . . . . . . . . 1–14
Bottom Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–16
Mini PCI and Memory Compartments . . . . . . . . . . 1–16
Bays, Battery Latch and Vents . . . . . . . . . . . . . . . . 1–17
Additional Components . . . . . . . . . . . . . . . . . . . . . . . . . 1–18
Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–18
Optical Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–19
Labels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–20

iv Hardware and Software Guide
Contents
2 TouchPad and Keyboard
TouchPad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–1
Identifying TouchPad Components. . . . . . . . . . . . . . 2–1
Using the TouchPad. . . . . . . . . . . . . . . . . . . . . . . . . . 2–2
Setting TouchPad Preferences . . . . . . . . . . . . . . . . . . 2–3
Hotkeys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–5
Identifying Hotkeys . . . . . . . . . . . . . . . . . . . . . . . . . . 2–5
Hotkey Quick Reference . . . . . . . . . . . . . . . . . . . . . . 2–6
Using Hotkey Procedures . . . . . . . . . . . . . . . . . . . . . 2–7
Using Hotkey Commands . . . . . . . . . . . . . . . . . . . . . 2–8
Keypads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–14
Using the Embedded Numeric Keypad . . . . . . . . . . 2–15
Using an External Numeric Keypad . . . . . . . . . . . . 2–18
3Power
Power Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–1
Selecting a Power Source . . . . . . . . . . . . . . . . . . . . . 3–1
Switching Between Battery and
External Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–3
Power Control and Light Locations . . . . . . . . . . . . . . . . . 3–4
Standby, Hibernation and Shutdown Overviews . . . . . . . 3–5
Standby . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–5
Hibernation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–6
Leaving Your Work. . . . . . . . . . . . . . . . . . . . . . . . . . 3–7
Interference with Drive Media . . . . . . . . . . . . . . . . . 3–7
Standby, Hibernation and Shutdown Procedures. . . . . . . 3–8
Turning the Notebook On or Off. . . . . . . . . . . . . . . . 3–8
Initiating or Resuming from Standby . . . . . . . . . . . . 3–9
Initiating or Restoring from Hibernation. . . . . . . . . 3–10
Using Emergency Shutdown Procedures . . . . . . . . 3–11
Power Preferences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–12
Using Power Schemes . . . . . . . . . . . . . . . . . . . . . . . 3–12
Prompting for Standby Password . . . . . . . . . . . . . . 3–12
Setting Other Power Preferences. . . . . . . . . . . . . . . 3–13

Contents
Hardware and Software Guide v
Battery Pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–14
Charging a Battery Pack . . . . . . . . . . . . . . . . . . . . . 3–14
Monitoring the Charge in a Battery Pack . . . . . . . . 3–15
Managing Low-Battery Conditions. . . . . . . . . . . . . 3–16
Calibrating a Battery Pack. . . . . . . . . . . . . . . . . . . . 3–18
Conserving Battery Pack Power . . . . . . . . . . . . . . . 3–22
Replacing a Battery Pack. . . . . . . . . . . . . . . . . . . . . 3–23
Storing a Battery Pack . . . . . . . . . . . . . . . . . . . . . . . 3–26
Disposing of a Used Battery Pack . . . . . . . . . . . . . . . . . 3–26
4Multimedia
Internal Speakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–1
Volume Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–2
External Audio Devices . . . . . . . . . . . . . . . . . . . . . . . . . . 4–3
Using the Audio-Out (Headphone) Jack . . . . . . . . . . 4–3
Using the Audio-In (Microphone) Jack. . . . . . . . . . . 4–4
External Video Devices . . . . . . . . . . . . . . . . . . . . . . . . . . 4–4
Connecting an S-Video Device
(Select Models Only). . . . . . . . . . . . . . . . . . . . . . . . . 4–4
Displaying a Video Image . . . . . . . . . . . . . . . . . . . . . 4–6
CD and DVD Procedures . . . . . . . . . . . . . . . . . . . . . . . . . 4–6
Inserting or Removing a Disc . . . . . . . . . . . . . . . . . . 4–6
Using Media Activity Hotkeys . . . . . . . . . . . . . . . . . 4–8
Setting AutoPlay Preferences . . . . . . . . . . . . . . . . . . 4–9
Protecting Playback . . . . . . . . . . . . . . . . . . . . . . . . . 4–10
Protecting a CD or DVD Write Process . . . . . . . . . 4–10
Multimedia Software . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–11
Observing the Copyright Warning . . . . . . . . . . . . . 4–12
Installing Software. . . . . . . . . . . . . . . . . . . . . . . . . . 4–13
Enabling AutoPlay. . . . . . . . . . . . . . . . . . . . . . . . . . 4–14
Changing DVD Region Settings . . . . . . . . . . . . . . . 4–14

vi Hardware and Software Guide
Contents
5 Wireless
(Select Models Only)
Wireless Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–1
Wireless Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–2
802.11 Wireless Devices (Select Models Only) . . . . . . . 5–3
Setting Up a WLAN in Your Home . . . . . . . . . . . . . 5–4
Connecting to a WLAN in Your Home. . . . . . . . . . . 5–5
Connecting to a Public WLAN . . . . . . . . . . . . . . . . . 5–6
Using Wireless Security Features . . . . . . . . . . . . . . . 5–6
Identifying an 802.11 Wireless Device . . . . . . . . . . . 5–7
Troubleshooting Devices. . . . . . . . . . . . . . . . . . . . . . 5–7
Bluetooth Wireless Devices (Select Models Only) . . . . . 5–8
Wireless Device Power States . . . . . . . . . . . . . . . . . . . . 5–10
Turning On the Devices. . . . . . . . . . . . . . . . . . . . . . 5–12
Turning Off and Disabling the Devices. . . . . . . . . . 5–13
6Security
Security Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–1
QuickLock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–3
Setup Utility and Windows Passwords . . . . . . . . . . . . . . 6–3
Coordinating Passwords . . . . . . . . . . . . . . . . . . . . . . 6–5
Choosing a Password. . . . . . . . . . . . . . . . . . . . . . . . . 6–5
Setup Utility Administrator Password . . . . . . . . . . . . . . . 6–6
Setting an Administrator Password . . . . . . . . . . . . . . 6–7
Entering an Administrator Password. . . . . . . . . . . . . 6–7
Setup Utility Power-On Password . . . . . . . . . . . . . . . . . . 6–8
Setting a Power-On Password . . . . . . . . . . . . . . . . . . 6–9
Entering a Power-On Password. . . . . . . . . . . . . . . . . 6–9
Setup Utility Device Security. . . . . . . . . . . . . . . . . . . . . 6–10
Antivirus Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–11
Critical Security Updates for Windows XP . . . . . . . . . . 6–12
Firewall Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–13
Optional Security Cable . . . . . . . . . . . . . . . . . . . . . . . . . 6–14

Contents
Hardware and Software Guide vii
7 Hardware Upgrades and Replacements
Device Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7–1
Connecting a Powered Device. . . . . . . . . . . . . . . . . . 7–1
Connecting a USB Device. . . . . . . . . . . . . . . . . . . . . 7–2
Connecting a 1394 Device
(Select Models Only). . . . . . . . . . . . . . . . . . . . . . . . . 7–3
Connecting a Communication Device. . . . . . . . . . . . 7–4
Digital Memory Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . 7–4
Using the Memory Reader Light . . . . . . . . . . . . . . . . 7–5
Inserting a Digital Memory Card. . . . . . . . . . . . . . . . 7–6
Removing a Digital Memory Card . . . . . . . . . . . . . . 7–7
PC Cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7–8
Inserting a PC Card . . . . . . . . . . . . . . . . . . . . . . . . . . 7–9
Stopping or Removing a PC Card . . . . . . . . . . . . . . 7–10
Drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7–11
Adding a Drive to the System . . . . . . . . . . . . . . . . . 7–11
Using the IDE Drive Light . . . . . . . . . . . . . . . . . . . 7–11
Caring for Drives . . . . . . . . . . . . . . . . . . . . . . . . . . . 7–12
Replacing the Internal Hard Drive. . . . . . . . . . . . . . 7–13
Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7–17
Increasing Memory . . . . . . . . . . . . . . . . . . . . . . . . . 7–17
Removing or Inserting a Memory Module . . . . . . . 7–18
8 Software Updates and Recoveries and
System Software
Software Updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8–1
Preparing for a Software Update . . . . . . . . . . . . . . . . 8–2
Downloading and Installing an Update . . . . . . . . . . . 8–4
Software Recoveries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8–8
Using System Restore . . . . . . . . . . . . . . . . . . . . . . . . 8–8
Repairing or Reinstalling Software . . . . . . . . . . . . . . 8–9

viii Hardware and Software Guide
Contents
Setup Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8–9
Opening the Setup Utility . . . . . . . . . . . . . . . . . . . . . 8–9
Changing the Language of the Setup Utility . . . . . . 8–10
Navigating and Selecting in the Setup Utility . . . . . 8–10
Displaying System Information. . . . . . . . . . . . . . . . 8–11
Restoring Default Settings in the Setup Utility . . . . 8–12
Using Advanced Setup Utility Features . . . . . . . . . 8–13
Closing the Setup Utility . . . . . . . . . . . . . . . . . . . . . 8–14
A Specifications
Operating Environment . . . . . . . . . . . . . . . . . . . . . . . . . . A–1
Rated Input Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–2
Expansion Port Input/Output Signals. . . . . . . . . . . . . . . . A–3
Index

Hardware and Software Guide 1–1
1
Hardware
Top Components
Keys
Component Description
1Function keys (12) Perform system and application tasks.
When combined with fn, the function
keys perform additional tasks as
hotkeys.
2Windows logo key Displays the Microsoft® Windows®
Start menu.
(Continued)

1–2 Hardware and Software Guide
Hardware
3fn key Combines with other keys to perform
system tasks. For example, pressing
fn+f7 decreases screen brightness.
4Keypad keys (15) Can be used like the keys on an
external numeric keypad.
5Windows applications key Displays a shortcut menu for items
beneath the pointer.
Component Description

Hardware
Hardware and Software Guide 1–3
TouchPad
Component Description
1TouchPad* Moves the pointer.
2Left TouchPad button* Functions like the left button on an
external mouse.
3Right TouchPad button* Functions like the right button on an
external mouse.
4TouchPad vertical and
horizontal scrolling regions*
Scrolls upward or downward, or left
or right.
*This table describes default settings. For information about changing the
functions of TouchPad components, refer to the “Setting TouchPad
Preferences” section in Chapter 2, “TouchPad and Keyboard.”

1–4 Hardware and Software Guide
Hardware
Power Controls
Component Description
1Display switch* If the notebook is closed while on, initiates
standby.
2Power/standby button* When the notebook is
■Off, press to turn on the notebook.
■On, briefly press to initiate hibernation.
■In standby, briefly press to resume from
standby.
■In hibernation, briefly press to restore
from hibernation.
✎If the system has stopped responding
and Windows shutdown procedures
cannot be used, press and hold for at
least 4 seconds to turn off the
notebook.
*This table describes default settings. For information about changing the
function of the display switch or power/standby button, refer to the “Setting
Other Power Preferences” section in Chapter 3, “Power.”

Hardware
Hardware and Software Guide 1–5
Lights
Component Description
1Caps lock light On: Caps lock is on.
2Wireless light
(select models only)*
On: One or more optional internal wireless
devices, such as a WLAN and/or a
Bluetooth® device (select models only),
are turned on.
3Power/standby light†On: Notebook is turned on.
Blinking: Notebook is in standby.
Off: Notebook is off.
(Continued)

1–6 Hardware and Software Guide
Hardware
Component Description
4Mute light On: Volume is muted.
5Num lock light On: Num lock or the embedded numeric
keypad is on.
*For information about establishing a wireless connection, refer to
Chapter 5, “Wireless (Select Models Only).”
†The notebook has 2 power/standby lights. The power/standby light on
the top of the notebook is visible only when the notebook is open; the
power/standby light on the front of the notebook is visible whether
the notebook is open or closed.

Hardware
Hardware and Software Guide 1–7
Wireless (Select Models Only) and
Volume Buttons
Component Description
1Wireless button
(select models only)
Turns the wireless functionality on or
off but does not create a wireless
connection.
✎To establish a wireless
connection, a wireless network
must already be set up. For
information about establishing
a wireless connection, refer to
Chapter 5, “Wireless (Select
Models Only).”
2Volume down button Decreases system volume.
3Volume up button Increases system volume.
4Volume mute button Mutes or restores volume.

1–8 Hardware and Software Guide
Hardware
Antennae (Select Models Only)
Component Description
Antennae (2)* Send and receive wireless device signals.
ÅExposure to Radio Frequency
Radiation. The radiated output
power of this device is below the
FCC radio frequency exposure limits.
Nevertheless, the device should be
used in such a manner that the
potential for human contact during
normal operation is minimized. To
avoid the possibility of exceeding
the FCC radio frequency exposure
limits, human proximity to the
antennae should be not less than
20 cm (8 inches) during normal
operation, including when the
notebook display is closed.
*The antennae (select models only) are not visible from the outside of the
notebook. For optimal transmission, keep the areas immediately around
the antennae free from obstructions.

Hardware
Hardware and Software Guide 1–9
Front Components
Lights
Component Description
1Power/standby light* On: Notebook is turned on.
Blinking: Notebook is in standby.
Off: Notebook is off.
2IDE (Integrated Drive
Electronics) drive light
On or blinking: The internal hard drive
or an optical drive is being accessed.
3Battery light On: The battery pack is charging.
Blinking: The battery pack has
reached a low-battery condition.
Off: The battery pack is fully charged
or not inserted.
*The light on the power/standby button and the power/standby light on
the front of the notebook display the same information. The light on the
power/standby button is visible when the notebook is open; the
power/standby light on the front of the notebook is visible whether the
notebook is open or closed.

1–10 Hardware and Software Guide
Hardware
Speakers, Jacks and Display Release Button
Component Description
1Stereo speakers (2) Produce stereo sound.
2Display release button Opens the notebook.
3Audio-in
(microphone) jack
Connects an optional monaural (single
sound channel) microphone.
4Audio-out
(headphone) jack
Connects optional headphones or
powered stereo speakers. Also connects
the audio function of an audio/video
device such as a television or VCR.

Hardware
Hardware and Software Guide 1–11
Rear Components
Component Description
Exhaust vent* Provides airflow to cool internal
components.
ÄTo prevent overheating, do not
obstruct vents. Do not allow a
hard surface, such as a printer,
or a soft surface, such as pillows
or thick rugs or clothing, to block
airflow.
*The notebook has 4 vents. This and all other vents are visible on the
bottom of the notebook. One vent is also visible on the left side of
the notebook.

1–12 Hardware and Software Guide
Hardware
Left-Side Components
Ports and Jacks
Component Description
1Power connector Connects the AC adapter cable.
2Monitor port Connects an optional VGA monitor or
projector.
3Expansion Port 2
(select models only)*†Connects the notebook to an optional docking device.
4RJ-45 (network) jack Connects an optional network cable.
5RJ-11 (modem) jack Connects the modem cable.
6USB port‡Connects an optional USB device.
*The notebook has only one expansion port. The term
Expansion Port 2
describes the type of expansion port.
†For expansion port signal information, refer to the “Expansion Port
Input/Output Signals” section.
‡Depending on the model, the notebook has 2 or 3 USB ports. The other
USB ports are on the right side of the notebook.
