Compaq Armada 7400 Series Technical specifications

Product Description 1-1
chapte
r
1
PRODUCT DESCRIPTION
1.1 Computer Features and Models
The Compaq Armada 7400 Series of Personal Computers offers advanced modularity,
an Intel Pentium II processor with 64-bit architecture, an industry-leading Accelerated
Graphics Port (AGP) implementation, and extensive multimedia support. The computer
provides desktop functionality and connectivity through the optional ArmadaStation II
and Armada MiniStation.
Figure 1-1. Compaq Armada 7400 Personal Computer

1-2 Product Description
Models
The Armada 7400 models are shown in Table 1-1. The computer model designation is
composed of a group of characters that define each model’s characteristics.
Table 1-1
Models and Model Naming Convention
Compaq Armada 7400 Series of Personal Computers
Key
78006366T10.0 V M 1
AB C D E F GH I
Key Description Options
A Line designator 7 = Performance
BSeries designator 4 = Armada 7400
C Processor type 6 = Intel Mobile Pentium II processor with MMX technology
D Processor speed 366 = 366-MHz processor
333 = 333-MHz processor 300 = 300-MHz processor 266 = 266-MHz processor
E Panel type T = 13.3” XGA TFT 1024 × 768 T14 = 14.1” XGA TFT 1024 × 768
F Hard drive capacity 10.0 = 10.0 GB 6.4 = 6.4 GB 4.0 = 4.0 GB
G Drive type D = CD-ROM V = DVD-ROM 0 = None
H Modem M =Internal or PC Card modem 0 = Audio only
I Operating system &
software version 0 = No operating system 1 = Windows 95 2 = Windows 98 3 = Windows NT 4.0

Product Description 1-3
Model Memory Config. Code SKU#
Armada 7400 6366 T14 10.0 V M 1 64 MB CH81 387070-XX2
Armada 7400 6366 T14 10.0 V M 3 64 MB CH82 387071-XX2
Armada 7400 6366 T14 10.0 V O 1 64 MB CH83 114400-022
Armada 7400 6366 T14 10.0 V O 3 64 MB CH84 114411-022
Armada 7400 6366 T 10.0 V M 1 64 MB CHS1 387068-XX2
Armada 7400 6366 T 10.0 V M 3 64 MB CHS2 387072-XX2
Armada 7400 6366 T 10.0 V 0 1 64 MB CHS3 387069-022
Armada 7400 6366 T 10.0 V 0 3 64 MB CHS4 114293-022
Armada 7400 6333 T 6.4 D 0 3 64 MB CDK4 386686-XX2
Armada 7400 6333 T 6.4 D M 3 64 MB CDK1 386687-XX2
Armada 7400 6333 T 6.4 D 0 1 64 MB CDK3 386691-XX2
Armada 7400 6333 T 6.4 D M 1 64 MB CDK2 341900-XX2
Armada 7400 6300 T 6.4 D M 1 64 MB BXL1 204200-XX2
Armada 7400 6300 T 6.4 D 0 1 64 MB BXL2 204250-XX2
Armada 7400 6300 T 6.4 D 0 2 64 MB BXL4 204500-XX2
Armada 7400 6300 T 6.4 D 0 3 64 MB BXL3
BXL5 204450-XX2 387593-001
Armada 7400 6300 T 6.4 V M 3 64 MB BXL8 102230-001
Armada 7400 6300 T 6.4 V M 1 64 MB CNN1 104920-XX2
Armada 7400 6300 T 6.4 V M 3 64 MB CNN2 105863-XX2
Armada 7400 6266 T 6.4 D 0 1 32 MB BXL6 402246-001
Armada 7400 6266 T 4.0 D 0 1 64 MB BXK3
BXK8
BXL7
204482-001
400589-081
402480-001
Armada 7400 6266 T 4.0 D 0 3 32 MB BXK1
BXK7 204300-XX2 387592-001
Armada 7400 6266 T 4.0 D 0 1 32 MB BXK2
BXL9 204150-XX2 104755-XX1
Configure to Order (CTO) model CDKZ 341821-999

1-4 Product Description
Features
The computer has the following standard features:
■Intel Mobile 366-, 333-, 300-, and 266-MHz Pentium II processor with 64-bit
architecture, MMX technology, and 512-KB, level-2 cache memory
■Industry-leading portable computer AGP implementation, featuring:
❏66-MHz dedicated graphics bus
❏frame made AGP
■4-MB SGRAM (synchronous graphics)
■32- or 64-MB of SDRAM (synchronous): populated in one slot; expandable to
256 megabytes
■Upgradable flash ROM BIOS
■14.1- and 13.3-inch XGA (1024 × 768) TFT color display, true color (24-bit)
support
■Keyboard with built-in EasyPoint III pointing device and mouse buttons
■Euro symbol provided on Europe/Middle East/Africa keyboards
■External AC adapter
■Lithium ion (Li-ion) battery pack
■Removable 10.0-, 8.1-, 6.4-, and 4.0-GB hard drives
■MultiBay that supports a diskette drive, CD-ROM drive, SuperDisk LS -120 drive,
DVD-ROM drive, or second hard drive (in Hard Drive MultiBay Adapter)
■Two PC Card slots that accept 32- and 16-bit Type I, II, and III PC Cards, with
zoomed video interface in the bottom slot
■IrDa-compliant infrared port1(4-Mbps standard) for wireless file transfer, printing,
and file synchronization
■Built-in stereo speakers providing Compaq PremierSound, microphone, and jacks
for stereo audio sound with electronic equalization and wave table synthesis
■Energy Star-compliant power saving features
■Ports and connectors for external equipment, including universal serial bus (USB),
serial, parallel, external monitor, and PS/2-compatible pointing device or keyboard
■Security features
■Desktop functionality available with the optional Compaq ArmadaStation II and
Armada MiniStation E/EX
■Integrated 56- or 33.6-Kbps data/14.4-Kbps fax modem (on modem models only;
availability varies by region)
1IrDa 4MB compliant. Infrared performance may vary depending on performance of infrared peripherals, distance
between infrared devices, and applications used.

Product Description 1-5
Intelligent Manageability
Intelligent Manageability consists of preinstalled software tools for the computer and
Compaq servers that assist in tracking, troubleshooting, protecting, and maintaining the
computer. It provides the following functions:
■Asset Management—provides detailed configuration and diagnostic information.
■Fault Management—prevents, predicts, and alerts of impending hardware
problems.
■Security Management—protects against unauthorized access to data and
components.
■Integration Management—uses industry-standard technologies such as DMI and
SNMP to integrate with PC management software providers.
■Configuration Management—optimizes the computer by providing the latest
drivers, utilities, and software, which are available on CD-ROM and the Compaq
web site at http://www.compaq.com.
NOTE: For further help with Intelligent Manageability, refer to Intelligent
Manageability Help. Click Start ➔Compaq Information Center ➔double-click
Intelligent Manageability Help.
Asset Management
AssetControl retrieves component information when on the road or connected to
the network.
AssetControl also enables the network administrator to remotely retrieve information
from any Compaq computer connected to the network. The information can be used to
assist in tracking and maintaining the computer and its components. It provides the
following information:
■Inventory information—The network administrator can retrieve information about
the computer over the network by using Compaq Insight Manager or any PC
management tool provided by Compaq Solution Partners. AssetControl information
retrieved from the computer includes:
❑Manufacturer, model, and serial number of Compaq computers, monitors, hard
drives, battery packs, memory boards, processor speeds, and operating systems.
❑Asset tag
❑System board and ROM revision levels
❑BIOS settings
■Diagnostic information—Diagnostics for Windows includes the information on hard
drives, ports, and video, sound, and other components. Compaq Diagnostics for
Windows can be accessed by clicking Start ➔Programs ➔Compaq Utilities ➔
Compaq Diagnostics.
All of the above information can be viewed, printed, or saved.

1-6 Product Description
Changing the Asset Tag Number
1. Turn on or restart the computer.
2. Press F10 when the cursor appears in the upper right corner of the screen.
3. Select Computer Setup ➔Intelligent Manageability.
4. Follow the instructions on the screen.
Fault Management
The Fault Management features minimize downtime and data loss by monitoring
system performance and generating the following alerts:
■Hard drive alert—provides warning up to 72 hours in advance of impending hard
drive problems and can automatically start optional backup software.
■System temperature alert—reports overheating. As the system temperature rises,
this feature first adjusts fan speed and other cooling components, then displays an
alert, then shuts down the system.
■Battery pack alert—reports charging problems and battery pack failure.
■Monitor alert—diagnoses and displays external monitor operational problems.
■Memory alert—reports memory board configuration changes when a memory
board is removed, added, or reconfigured. It also provides the previous and current
configurations for comparison.
The alerts work with or without network connection. Of course, if the computer is not
connected to the network, the network administrator cannot receive alerts from the
computer.
Fault Management Alerts
Alerts can be enabled, disabled, and tested, and software can be set to back up
information whenever a hard drive alert occurs.
■While the computer is connected to a network, alerts appear on the computer display
and are simultaneously reported to the network console.
NOTE: A battery charging problem alert is reported only on the computer display.
■When the computer is not connected to a network, the user will receive a local alert.
To set alerts, double-click the Intelligent Manageability icon.
Security Management Overview
Security Management features customize system security.
■Power-On and Setup Passwords—prevent unauthorized access to your
information and computer configuration.
■DriveLock—prevents access to hard drives.

Product Description 1-7
■Device disabling—prevents unauthorized data transfer through modems, serial
ports, parallel ports, and infrared ports on the computer and an optional docking
station.
■QuickLock/QuickBlank—locks the keyboard and clears the screen.
■Ownership Tag—displays ownership information during system restart.
Configuration Management
Configuration Management optimizes software upgrade and customer support
procedures. Compaq provides support software to optimize the performance of the
computer. This support software is accessible through a monthly subscription
CD-ROM. Support software can also be downloaded from the Compaq web site at
http://www.compaq.com. Support software includes:
■Locator browser—searches for the latest device drivers, utilities, ROM images, and
other support software on a CD-ROM and at the Compaq web site at
http://www.compaq.com.
■Decision Support—provides detailed information about drivers, utilities, and
software available on the computer. The information includes descriptions, features,
enhancements, dependencies, and necessary upgrades.
■InfoMessenger—provides notifications by email when support software for the
computer becomes available.
Power Management Utility
The Power Management utility (Power) allows you to monitor how AC and battery
power are used. It controls most computer components, including the hard drive,
processor, and display.
Power Management also allows you to preset or customize conservation of power
under the following tabs:
■Power
■Disk Drives
■PC Card Modems
■Resume Timer
■Battery Status
■Battery Conservation
■Hibernation

1-8 Product Description
To access Power Management, click Start ➔Settings ➔Control Panel ➔double-click
the Power icon.
NOTE: If you are using Windows NT 4.0, select Compaq Power instead of Power. If
you are using Windows 98, select Power Management.
The following table describes the actions that can be performed under each tab. A
description of each tab follows.
If You Want To: Click This Tab:
Show the battery meter on the taskbar; show the
status of batteries; show the Suspend command on
the Start menu
Power
Select how long Windows will wait before switching
the disk drive to low power mode Disk Drives
Turn off power to PC Card modems when not in use PC Card Modems
Select a date and time to be used to reset the
computer when all power is turned off Resume Time
Display the remaining life and status of installed
batteries Battery Status
Set battery conservation levels and settings;
enable/disable warning beeps Battery Conservation Settings
Select Hibernation Settings Hibernation
Power Tab
The Power Tab allows a shortcut to be created enabling the battery meter to appear on
the task bar. The current power status of the computer as well as the status of all
battery is also displayed.
Advanced Power Tab features include the ability to show the Suspend command on the
Start menu, whether the Suspend command appears when the computer is docked or
undocked, and whether the computer will wake up when the telephone rings (for
computers connected to phone lines). Troubleshooting options are also available under
the Advanced Power Tab features.
Disk Drives
The Disk Drives Tab is used to set up the time the Windows operating system waits
before switching the disk drive to low power mode when the computer is powered by
AC power and battery.
PC Card Modems Tab
When PC Card modems are installed, they draw power from the system even when
they are not in use. For optimum power conservation, follow this guideline when using
PC Card modems: if PC Card modems are kept in the computer, set the PC Card
Modems tab to turn off power to PC Card modems when they are not in use.
Otherwise, remove PC Card modems when they are not being used.

Product Description 1-9
Resume Time Tab
When all power sources (AC power, battery pack, auxiliary battery, and real time clock
(RTC) battery) to the computer are disconnected, the system date and time are reset to
the settings established in this tab.
Battery Status Tab
The Battery Status tab provides the following information:
■The position of possible battery pack locations in the computer
■An illustration of each battery pack and the bay where it is installed in the computer
■The status (high, low, critical, and charging) of each battery pack
■The percentage of charge remaining in each battery pack
■Which battery pack, if any, is currently charging
Battery Conservation Tab
The Battery Conservation tab allows you to select the level of battery conservation:
High, Medium, None (Drain), or Custom. Medium conservation is the default setting.
In addition to accessing this tab through the Power menu and Power Management, you
can press hotkeys Fn+F7 in any application. A popup window displays the current
battery level. Use the left or right arrow to select a different level.
➊High Conservation—Provides maximum battery conservation and the most battery
life from a single charge.
➋Medium Conservation (Default Setting)—Provides a balance between system
performance and battery life.
➌None (Drain)—Turns off the battery conservation features, which allows the system
to run at full speed. This setting also causes the computer to fail to initiate
Hibernation. At other conservation settings, the computer automatically initiates
Hibernation when it reaches a low-battery condition, even if Hibernation has been
manually disabled.
CAUTION: Before setting the battery conservation level to None (Drain), ensure that the
Hibernation feature has not been disabled.
➍Custom—Allows you to specify conservation settings for Suspend, system idle,
screen save, processor speed, and brightness. Refer the following section for
information on timeouts.

1-10 Product Description
Hibernation Tab
The Hibernation tab allows you to enable or disable Hibernation and to set the timeout
periods after which the system initiates Hibernation. For Hibernation to work, it must
allocate space on the hard drive equal to the amount of system memory. Turning off
Hibernation is not recommended by Compaq; however, it is possible to free up this
disk space by disabling Hibernation.
CAUTION: Turning off Hibernation is not recommended. If the computer reaches a
low-battery condition and Hibernation has been disabled, unsaved information is lost.
When the computer is restarted after adding memory, the system first upgrades the
memory, then allocates or updates the disk space to adjust to the new amount of
memory.
NOTE: If you experience problems with Hibernation after upgrading the memory, go to
the Power icon and click the Hibernation tab to reset the system memory.
Timeouts are specified periods of system or component inactivity designed to conserve
power. When a timeout period expires, battery conservation shuts down the system or
the specified components to save power.
For example, the hard drive idle default timeout is two minutes. If an application does
not access information on the hard disk for two minutes, the hard drive shuts down
until it is accessed again.
These guidelines can aid in choosing the most appropriate timeouts for the computer:
1. The preset timeout provides the medium (default) or high level of battery
conservation.
2. Customized timeouts, which are set through the custom level of battery
conservation, allow the computer to work more efficiently with applications on the
computer.
