Compaq Fast Ethernet Module NC3133 User instructions

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
11-19 DA-10306-01-001
Compaq NC3133
Fast Ethernet Module
100 FX
Overview
The NC3133, when plugged into a NC3131, adds a 100 Mbps Fast Ethernet network connection over fiber optic cable
for server backbones and campus-wide connectivity. This upgrade module is ideal for sites with extended distance
requirements, the need for added security, or EMI protection.
PERFORMANCE
32-bit Bus-mastering
The NC3133 offers the highest level 100 Mbps data transfer method available between the network and 32-bit slots
for high performance and low CPU utilization. The NC3133 uses bus-mastering technology to maximize throughput
and minimize CPU utilization.
Port Bonding
Adaptive Load Balancing (ALB) and Cisco’s Fast EtherChannel are two port bonding methods supported by the
NC3133. ALB provides both failover and balancing of transmit traffic across all NICs for increased performance. For
even higher performance, Cisco’s Fast EtherChannel provides port failover and balancing of transmit and receive
traffic across all NICs when used with a Fast EtherChannel enabled switch.
SECURITY/RELIABILITY
Network Fault Tolerance (NFT)
NFT support, sometimes called “NIC Redundancy” or "failover," enables the NIC to keep an active connection if
another NIC, switch or hub link fails by automatically switching to a backup NIC.
PCI Hot Plug
The NC3133 includes PCI Hot Plug support, which enables it to be replaced or added to a server without powering
down the system. This feature provides increased system availability and non-stop serviceability in business-critical
computing environments.
NETWORK MANAGEMENT
Standards-based
The NC3133 supports the following industry network management standards to work with a broad spectrum of
software utilities.
•SNMP
•DMI 2.0
•Web-Based Enterprise Management (WBEM)
Server Integration
Compaq’s SmartStart®configuration utility includes setup support for the NC3133 so the NIC can be configured as
part of the SmartStart configuration process. Compaq Insight Manager®can recognize the NC3133 individually or in
port bonded teams, and can collect and report SNMP statistics on the NIC events. The Compaq Network
Management System (CNMS) can also collect and report SNMP statistics on the NC3133.
Integrated Management Log (IML) support is provided by the NC3133 for critical event logging on Compaq servers.
Diagnostic LEDs
LEDs show link integrity and network activity for easy troubleshooting.
MODELS
Compaq NC3133
Fast Ethernet Module
100 FX Upgrade Module for
NC3131
338456-B25
With the NC3133 100 FX
Upgrade Module, Compaq
introduces 100 Mbps support for
environments requiring the
additional distance and security
available through fiber optic
cabling.
Optional Upgrade Modules
Fast Ethernet
NC3132: Dual 10/100
Upgrade Module
338456-B22
Gigabit
NC6132: 1000 SX
Upgrade Module
338456-B23
NC6133: 1000 LX
Upgrade Module
338456-B24
Fast Ethernet NIC Family
NC3120: PCI, 10/100
317600-B21
NC3123: PCI, 10/100 WOL
174830-B21
NC3122: PCI Dual 10/100
317450-B21
NC3131: Fast Ethernet NIC 64
PCI Dual Base 10/100
338456-B21
Gigabit Ethernet NIC Family
NC6134: 1000 SX 64 PCI
Gigabit NIC
174818-B21

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
11-20 DA-10306-01-001
Compaq NC3133
Fast Ethernet Module
100 FX
EASE OF USE
Plug and Play
Fully compliant with the 2.1 PCI specification, this NIC automatically configures its I/O address and interrupt (IRQ)
settings for easy installation.
CPQNTAC
The CPQNTAC (Compaq Network Teaming and Configuration) utility allows the user to run initial diagnostics and
configure NIC teams for NFT, ALB or Cisco Fast EtherChannel (when used with a Fast EtherChannel-enabled
switch).
Compaq Total Solutions
The NC3133 provides a 100Mbps fiber-based network connection between servers and the Compaq SW5226A,
SW3323, the GIGAswitch/Router, and the MultiSwitch 700. By integrating these Compaq solutions throughout a
network, users can apply the complete set of Compaq management tools across their enterprise.
Warranty1
Compaq supports this product with a limited lifetime warranty1. Technical support is available at your fingertips 24
hours a day, 7 days a week.
SPECIFICATIONS
Compliance IEEE 802.3z compliant 1000 Mbps Ethernet specification
PCI 2.1
General Specifications
Communications Processor Intel 82558
Full and half
On-board memory 6KB
Data path 32-bit/33MHz
Interrupt levels INTC
Bus architecture PCI bus-mastering
Connectors SC
Wavelength FX = (1,300nm)
Distance up to 2,000 meters
Wiring Multi-mode fiber (62.5 µm / 50µm)
Dimensions (LxW) 6 x 2.5 in/15 x 6.4 cm
Command usage optimization for advanced PCI commands (MWI and memory reads)
Software controlled global reset bit (resets everything except PCI configuration registers)
Power and Environmental Specifications
Operating
Temperature 32° to 131°F/0° to 55°C
Humidity 10% to 90%
Non-operating
Temperature –85° to 185°F/–65° to 85°C
Humidity 5% to 95%
Power requirement 1025 mA @ 5V max
Emissions standards FCC Class B
Safety compliance CE Mark

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
11-21 DA-10306-01-001
Compaq NC3133
Fast Ethernet Module
100 FX
SPECIFICATIONS (continued)
Operating System Support Windows NT 4.0
Windows NT 3.51
Novell NetWare 5.x Server
Novell NetWare 4.x Server
Novell NetWare 3.x Server
SCO UnixWare 7.x
SCO OpenServer 5.x
SCO UnixWare 2.1
Microsoft Windows 2000
Microsoft Windows 98
Microsoft Windows 95
NetWare DOS Client
MS DOS Client
OS/2 Warp Server
Software Feature Support by Operating System
Feature
Windows NT 3.51 Windows NT 4.0 UnixWare v2.x UnixWare 7.x O
p
en Server5.x
NetWare 3.12, 3.2 Server NetWare 4.11 Server NetWare 5.0 Server
ALB •
••
•••
GEC •
••
•••
NFT •
••
•••
PCI Hot Plug ••
CPQNTAC •
••
•
DMI 2.0 •
••
••
••
••••
SNMP •
••
••
••
••••
SmartStart •
••
••••
WBEM •
••
••
••
••
••
••
••
•••••
Insight Mgr. •
••
••
••
••
••
••
••
•••••
CNMS •
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
•
IML •
••
••
••
••
••
••
Kit Contents NC3133 100FX Upgrade Module
CD containing Drivers, User Guide, and Installation and Diagnostic Utility
Quick Install Card
Product Quality Statement
Product Warranty Statement
Warranty1Limited Lifetime
Year 2000 Compliant

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
11-22 DA-10306-01-001
Compaq NC3133
Fast Ethernet Module
100 FX
COMPATIBILITY
Workstations
Compaq Professional Workstation SP700
Servers
Compaq ProLiant 8500
Compaq ProLiant 8000
Compaq ProLiant 7000 Xeon™
Compaq ProLiant 6500 Xeon
Compaq ProLiant 6000 Xeon
Compaq ProLiant 5500R Xeon
Compaq ProLiant 5500 Xeon
Compaq ProLiant 3000R 6/450
Compaq ProLiant 3000 6/450
Compaq ProLiant 1850R
Compaq ProLiant 1600R (100 MHz)
Compaq ProLiant 1600 (100 MHz)
Compaq ProLiant 800 6/350E, 6/400, 6/450 MHz
Compaq ProLiant 400
1Certain restrictions and exclusions apply. Contact 800-OK-COMPAQ for details.
See Internet address http://www.compaq.com for overall information on Compaq Computer.
For further information on Compaq networking products, contact Compaq Sales at 1-800-544-5255 or the Compaq
Technical Support Center (post sales) at 1-800-386-2172. For customer support and information about Compaq and its
products, call 1-800-OK-COMPAQ.
