Component hardware Ks15-2020 User manual

KS15-2020

Electronic Gel Dispenser

User Manual

Thank you for choosing the KS15-2020 electronic gel dispenser

Please read this user manual carefully before installation and retain

for future reference

Component Hardware reserves the right to make any and all changes and to discontinue

any of its products without notice. Not responsible for typographical errors.

Features

Hygienic:

Touchless Technology assisting a safer and cleaner work and living

environment.

Material:

304 stainless steel shell and wall bracket.

Design:

Top cover can be locked, facilitating a tamper proof device.

Electronic parts are sealed, moisture and waterproof.

Installation:

Suitable for all public and domestic areas, including hotels, public

buildings, schools, stations, hospitals, bars, restaurants, health

care and households.

Adjustable distance:

Sensor distance can be adjusted according to requirement.

Dispensed liquid volume is adjustable:

Designed with SCM (Software Configuration Management).

Specification

Model

KS15-2020

Power supply

9V DC (6x 1.5V DC AA battery)

Liquid viscosity range [cp] 1-3500(*) (1800 recommended)

Liquid capacity [ml]

650

Liquid alcohol content [%]

Tested to 75%

Supply volume per drop [ml]

0,8 - 6,5 (adjustable)

Flowing time [s] 0,5-2 (adjustable)

Detecting distance [cm]

5-15cm (adjustable)

Ambient operating temperature [°C]

1-45

(*) at viscosities exceeding 1800cp, it is recommended to keep the liquid volume in the

dispenser above 50% of the gel container capacity.

Troubleshooting

Caution

1. The electronics are sensitive to mechanical shock, please refrain from any

mechanical or violent interference with any part of this dispensingunit.

2. To avoid corrosion of the product's surface or inner electric components

being damaged, please use soft cloth with neutral liquid to clean its surface.

Then use damp cloth to wipe off any residual liquid, dry off with soft cloth.

Don't use water or any soap detergent which includes abrasive powder

with high acidity / alkalinity. Avoid nylon brushes etc. Please make sure

that the glossy cover of the sensor window is not scuffed, scratched or

damaged in any way to prevent the sensitivity being reduced.

Problem

Cause

Solution

Led indicator

does not work

Dispenser is in dormant

state

Switch off dormant state (p.2)

Sensor distance is too

short

Adjust to longer sensor

distance

The batteries do not

function

Check batteries and change if

required

Sensor window is not

clean

Clean sensor window

Sensor failure

Replace sensor

Led indicator

works but liquid

is not dispensed

Sensor is switching

continuously

Remove any barriers in front

of the sensor

Sensor distance is too

long

Adjust to a shorter sensor

distance

Dispenser is clogged.

Run commisioning cycle (p.2)

Liquid volume <50%

Fill gel container.

Dispenser failure

Contact your supplier

Liquid volume is

not enough

Dispensing time is too

short

Adjust it according to this

manual

Liquid viscosity is too

high

Use lower viscosity liquid

Liquid is clogging

Use it continuously until it

works, if not working, call

your supplier

Gel container is empty

Refill the gel container

How to adjust distance and dispensing volume

Mount the KS15-2020 onto the wall (please see page 6). Then power on

the unit; the Led indicator will flash 5 times. If there is no object in the

sensor range for 30 seconds, the settings mode will be exited, and the

dispenser will go into the default factory setting.

1. Adjustment of sensor distance:

You can change the sensor distance if you require shorter or longer

distances:

a. Press and hold the reset/settings button for 15 seconds; the Led

indicator will start flashing first at a high frequency; once it drops to a

lower frequency, you can release the reset/settings button, now the

dispenser is in settings mode, which lasts for 10 seconds.

b. When in settings mode press and hold the reset/settings button

again for 5 seconds, the Led indicator will light up continuously then

flash fast for 5 seconds.

c. Within these 5 seconds, put your hand under the dispenser at the

desired distance to set. The Led indicator will confirm with 4 slow

flashes.

d. The sensor distance is now set to the required level.

Note: (The sensor distance should be 5-15cm)

2. Adjustment of dispensingvolume

You can change the dispensing volume if you require more or

less liquid.

a. Put the dispenser in settings mode, please note 1a above.

b. When in settings mode, press the reset/settings button twice, the

Led indicator will start flashing.

c. While the Led indicator is flashing, put your hand within sensor

range; the dispenser will start dispensing liquid in bursts while you

keep your hand within sensor range, with a maximum of 7 bursts

(there are 7 different liquid levels for this dispenser).

d. The moment it has dispensed the perfect amount of liquid, just move

your hand away

e. The dispensing volume is now set to the desired level.

Note: Please make sure that all adjustments of sensor distance or

dispensing volume are completed within 30 seconds, otherwise the

unit will exit settings mode and you will need to enter settings mode

again to complete adjustments.

Caution before installation

To make sure that the KS15-2020 functions well

during its lifetime, please assure the below:

1. Please read this user manual and installation instruction before

assembling.

2. Use 6 good qualityAAbatteries (alkaline). Do not use new and old

batteries together, nor use other batteries.

3. Please checkthe wall for evenness. Clean the wallbeforemounting the

unit.

4. Make sure the distance from thebottom of the dispenser to the closest

object or table beneathis greater than 25cm.

5. Please provide this manual to the user after installation is complete.

6. Don't putanybarriers in the sensor range.

7. To avoid sensor ghosting, don't put glossy (stainless steel) objects or

photoelectric sensors underneath the sensor window of the dispenser

(see installation instructions on page 5)

8. Please position the dispenser out of the sun's reach as much as possible.

WARNING:

1. The dispenser could arrive in dormant mode and will initially not

respond. In this case, please hold the reset/settings button for

more than 2 seconds, the Led indicator will show for 3 seconds,

putting the unit into normal operation mode.

2. Before first use, please run the commissioning cycle for 10 seconds:

press the reset/settings button 8 times. By pressing the

reset/settings button 1 time, the commissioning cycle can be

stopped. The commissioning cycle will stop automatically after 5

minutes.

3. If a longer period of non-usage (>72hrs) is expected, it is advised to

put the dispenser into dormant mode: press the reset/settings

button 5 times. In dormant mode, the dispenser runs one time

per 72 hours if not used to avoid clogging.

4. To avoid accidental operation during cleaning or maintenance, set

the machine into dormant mode.

Part name

KS15-2020

Key

Top cover

Battery Box

Seal

Battery Box Cover

el Container Cap

Usage instruction

1. Unlock the top cover using the key.

2. Unplug the connector from the batterybox.

3. Open the gel container and fill it with the liquid of your choice.

Please clean any spills immediately.

4. Reconnect the cable, put the top cover back in position and lock it

with the key provided.

5. Put your hand under the sensor window; when the sensor detects,

the Led indicator will flash and liquid dispensesautomatically.

6. Hold the reset/settings button for more than 2 seconds at first use

and activate the sensor until the liquid isdispensed.

Note:

Please remove the masking from the sensor lens before first use.

Protector

Led

ndicator

•

Please add liquid tothe

dispenser (as above).

•

Please put your hands in the

sensor area, the dispenser

will provide liquid

automatically.

Bottom View

Gel Dispensing nozzle

Sensor lens

eset

Settings

button

Gel Container

Wall Bracket

Replacing batteries

The Led indicator flashes continuously when battery life is ending.

Please change batteries at this time.

Select 6 AA alkaline batteries, new and old batteries can't be used

together.

Open the battery box cover, remove the batteries and replace all

batteries with new ones.

Please make sure you install the batteries in the right direction, the + and

- side are indicated in the battery holder.

Re-position the battery box (take especial care not to pinch the cable),

put the battery box cover back in place and tighten thescrews.

Follow the instructions for setting the sensor range and volume of liquid

if required.

Wall bracket dimensions

84,5mm

3,33

~ 205mm

8,07in

80mm

3,14in

•

Unplug the cable and

remove the battery box

cover.

•

Remove the old

batteries and

replace with new

ones.

•

Put the battery into the

battery box according

"+"

"-"

direction.

58mm

2,28in

28,5mm

1,12in

Installation drawing

Suggested positioning*

* If to be installed above glossy (stainless steel) surfaces, the

distance from sensor window to surface must

be over 35cm.

Installation guide

Unpack and position the wall bracket vertically against the wall and mark the

drill hole positions. Drill 3x Ø6mm holes and put the plastic plugs into these

holes.

Position the wall bracket and fix it to the wall with the screws supplied.

Position the dispenser onto the wall bracket.

Push the dispenser downwards, make sure it fits into the hook tightly.

Secure the dispenser on the wall bracket with the set screw.

Close the dispenser with the top cover and lock it with the key.

Installation drawing

Suggested positioning*

* If to be installed above glossy (stainless steel) surfaces, the

distance from sensor window to surface must

be over 35cm.

Installation guide

Unpack and position the wall bracket vertically against the wall and mark the

drill hole positions. Drill 3x Ø6mm holes and put the plastic plugs into these

holes.

Position the wall bracket and fix it to the wall with the screws supplied.

Position the dispenser onto the wall bracket.

Push the dispenser downwards, make sure it fits into the hook tightly.

Secure the dispenser on the wall bracket with the set screw.

Close the dispenser with the top cover and lock it with the key.

Replacing batteries

The Led indicator flashes continuously when battery life is ending.

Please change batteries at this time.

Select 6 AA alkaline batteries, new and old batteries can't be used

together.

Open the battery box cover, remove the batteries and replace all

batteries with new ones.

Please make sure you install the batteries in the right direction, the + and

- side are indicated in the battery holder.

Re-position the battery box (take especial care not to pinch the cable),

put the battery box cover back in place and tighten thescrews.

Follow the instructions for setting the sensor range and volume of liquid

if required.

Wall bracket dimensions

84,5mm

3,33

~ 205mm

8,07in

80mm

3,14in

•

Unplug the cable and

remove the battery box

cover.

•

Remove the old

batteries and

replace with new

ones.

•

Put the battery into the

battery box according

"+"

"-"

direction.

58mm

2,28in

28,5mm

1,12in

Part name

KS15-2020

Key

Top cover

Battery Box

Seal

Battery Box Cover

el Container Cap

Usage instruction

1. Unlock the top cover using the key.

2. Unplug the connector from the batterybox.

3. Open the gel container and fill it with the liquid of your choice.

Please clean any spills immediately.

4. Reconnect the cable, put the top cover back in position and lock it

with the key provided.

5. Put your hand under the sensor window; when the sensor detects,

the Led indicator will flash and liquid dispensesautomatically.

6. Hold the reset/settings button for more than 2 seconds at first use

and activate the sensor until the liquid isdispensed.

Note:

Please remove the masking from the sensor lens before first use.

Protector

Led

ndicator

•

Please add liquid tothe

dispenser (as above).

•

Please put your hands in the

sensor area, the dispenser

will provide liquid

automatically.

Bottom View

Gel Dispensing nozzle

Sensor lens

eset

Settings

button

Gel Container

Wall Bracket

How to adjust distance and dispensing volume

Mount the KS15-2020 onto the wall (please see page 6). Then power on

the unit; the Led indicator will flash 5 times. If there is no object in the

sensor range for 30 seconds, the settings mode will be exited, and the

dispenser will go into the default factory setting.

1. Adjustment of sensor distance:

You can change the sensor distance if you require shorter or longer

distances:

a. Press and hold the reset/settings button for 15 seconds; the Led

indicator will start flashing first at a high frequency; once it drops to a

lower frequency, you can release the reset/settings button, now the

dispenser is in settings mode, which lasts for 10 seconds.

b. When in settings mode press and hold the reset/settings button

again for 5 seconds, the Led indicator will light up continuously then

flash fast for 5 seconds.

c. Within these 5 seconds, put your hand under the dispenser at the

desired distance to set. The Led indicator will confirm with 4 slow

flashes.

d. The sensor distance is now set to the required level.

Note: (The sensor distance should be 5-15cm)

2. Adjustment of dispensingvolume

You can change the dispensing volume if you require more or

less liquid.

a. Put the dispenser in settings mode, please note 1a above.

b. When in settings mode, press the reset/settings button twice, the

Led indicator will start flashing.

c. While the Led indicator is flashing, put your hand within sensor

range; the dispenser will start dispensing liquid in bursts while you

keep your hand within sensor range, with a maximum of 7 bursts

(there are 7 different liquid levels for this dispenser).

d. The moment it has dispensed the perfect amount of liquid, just move

your hand away

e. The dispensing volume is now set to the desired level.

Note: Please make sure that all adjustments of sensor distance or

dispensing volume are completed within 30 seconds, otherwise the

unit will exit settings mode and you will need to enter settings mode

again to complete adjustments.

Caution before installation

To make sure that the KS15-2020 functions well

during its lifetime, please assure the below:

1. Please read this user manual and installation instruction before

assembling.

2. Use 6 good qualityAAbatteries (alkaline). Do not use new and old

batteries together, nor use other batteries.

3. Please checkthe wall for evenness. Clean the wallbeforemounting the

unit.

4. Make sure the distance from thebottom of the dispenser to the closest

object or table beneathis greater than 25cm.

5. Please provide this manual to the user after installation is complete.

6. Don't putanybarriers in the sensor range.

7. To avoid sensor ghosting, don't put glossy (stainless steel) objects or

photoelectric sensors underneath the sensor window of the dispenser

(see installation instructions on page 5)

8. Please position the dispenser out of the sun's reach as much as possible.

WARNING:

1. The dispenser could arrive in dormant mode and will initially not

respond. In this case, please hold the reset/settings button for

more than 2 seconds, the Led indicator will show for 3 seconds,

putting the unit into normal operation mode.

2. Before first use, please run the commissioning cycle for 10 seconds:

press the reset/settings button 8 times. By pressing the

reset/settings button 1 time, the commissioning cycle can be

stopped. The commissioning cycle will stop automatically after 5

minutes.

3. If a longer period of non-usage (>72hrs) is expected, it is advised to

put the dispenser into dormant mode: press the reset/settings

button 5 times. In dormant mode, the dispenser runs one time

per 72 hours if not used to avoid clogging.

4. To avoid accidental operation during cleaning or maintenance, set

the machine into dormant mode.

Features

Hygienic:

Touchless Technology assisting a safer and cleaner work and living

environment.

Material:

304 stainless steel shell and wall bracket.

Design:

Top cover can be locked, facilitating a tamper proof device.

Electronic parts are sealed, moisture and waterproof.

Installation:

Suitable for all public and domestic areas, including hotels, public

buildings, schools, stations, hospitals, bars, restaurants, health

care and households.

Adjustable distance:

Sensor distance can be adjusted according to requirement.

Dispensed liquid volume is adjustable:

Designed with SCM (Software Configuration Management).

Specification

Model

KS15-2020

Power supply

9V DC (6x 1.5V DC AA battery)

Liquid viscosity range [cp] 1-3500(*) (1800 recommended)

Liquid capacity [ml]

650

Liquid alcohol content [%]

Tested to 75%

Supply volume per drop [ml]

0,8 - 6,5 (adjustable)

Flowing time [s]

0,5-2 (adjustable)
