Installation, Operation and Servicing Manual Version 2.0.0
Models:
1350SLBFS | 2500HBFS | 3500VBFS | 6000VBFS | 10000VBFS | 15000VBFS


1
1. Introduction 2
2. Conditions of use 2
3. Safety 3
4. Product description 4
4.1 Productidentication 4
4.2 Productspecication 5
4.3 Product footprint 6
5. Transport & storage 12
6. Installation & commissioning 13
6.1 Installationguidelines 13
6.2 Systeminstallation 13
6.3 Systemlocation 13
6.4 Electricalrequirements 14
6.5 Electricalwiringdiagram 14
7. Operation of the system 16
7.1 Usingthesystem 16
7.2 Summaryofmainparts1350/1400/2500 16
7.3 Summaryofmainparts3500/6000/10000/15000 17
7.4 Fillingdieselfuelstation 18
7.5 Dispensingdieselintovehicle 18
7.6 Equipmentcomponents 19
8. Maintenance of the TUFFA TANKS 26
8.1Systemmaintenancetasks 27
8.2 Inspection by competent person 27
8.3Internalexaminationandcleaning 27
8.4Troubleshooting 28
8.5Tankmaintenancerecord 30
8.6Fueldeliverylog 32
9. Warranty 34
10. Contact 35
11. Guarantee Registration 35
CONTENTS PAGE

2
1. Introduction
Thismanualcontainsspecicinstructionsandinformationrelatingtotheinstallation,
operationandmaintenanceofTuaTankssystems.
2. Conditions of use
• Readthismanualbeforeinstallingthissystem.
• TuaTanksacceptsnoliabilityforpersonalinjuryorpropertydamageresultingfrom
workingonoradjustingtheequipmentincorrectlyorwithoutauthorisation.
• TuaTanksacceptsnoliabilityfordirect,indirect,incidental,special,or
consequentialdamagesresultingfromfailuretofollowanywarnings,instructions,and
proceduressetoutinthismanual.
• TuaTanksreservestherighttochangethespecicationsofitsproductsorthe
informationinthismanualwithoutnecessarilynotifyingitsusers.
• VariationsininstallationandoperatingconditionsmayaecttheTuaTanksystems
performance.TuaTanksmakesnorepresentationsorwarrantiesconcerningthe
performanceofthetanksystemundertheoperatingconditionsprevailingatthe
installation.
• OnlypartssuppliedbyorapprovedbyTuaTanksmustbeusedandno
unauthorisedmodicationstothehardwareorsoftwareshouldbemade.Theuseof
non-approvedpartsormodicationswillvoidallwarrantiesandapprovalsandcould
leadtohazardoussafetyconditions.
• Unlessotherwisenoted,referencestobrandnames,productnames,ortrademarks
constitutetheintellectualpropertyoftheownerthereof.
1. INTRODUCTION | 2. CONDITIONS OF USE

3
3. Safety
PLEASE READ THIS MANUAL CAREFULLY BEFORE USE & COMPLY WITH ALL
INSTRUCTIONS BELOW.
THIS MANUAL SHOULD BE KEPT WITH THE EQUIPMENT AT ALL TIMES.
1.Themajorhazardinvolvedwithinstallingandoperatingtheunitiselectricalshock.
Thishazardcanbeavoidedifyouadheretotheproceduresinthismanualandexercise
allduecare.
2.Installationanduseofthisproductshouldonlybecarriedoutbyproperlytrainedand
approvedpersonnel.
3.PleaserefertostoragemediaMSDSwhichshouldbesuppliedbytheproprietorofthis
systemwhichwilldetailthePPErequiredforhandlingandemergencyprocedures.
4.Theuserofthisproductisresponsibleforthesafeandcorrectuseofthisproduct.
5.Thisproductisonlysuitableforstorageand/ordispensingoftheliquidmedia
referencedatthepointofsale.
3. SAFETY

4
4. Product description
TuaFuelStationsaredesignedsolelyforstorageanddispensingofdiesel.Thestatic
bundedsystemsenablesafedieselstorageanddispensinginanoutdoorenvironmentand
ensuresyoumeetallstringentfuelstorageregulations.Thehighstandardofspecication
ensuresoptimumsafetyandfunctionality.Thisproduct’sstandardspecicationisnot
approvedfortheresaleofdiesel.
4.1 Productidentication
Theidenticationplateislocatedwithinthecabinetofeachsystemandwilldetailthe
capacity,serialnumber,modelnumberandyearofmanufacture.
4. PRODUCT DESCRIPTION

5
4.2Productspecication
1350SLBFS 2500HBFS 3500VBFS 6000VBFS 10000VBFS 15000VBFS
Capacity 1350litres 2500litres 3500litres 6000litres 10000litres 15000litres
Length 2680mm 2840mm - - - -
Width 870mm 1520mm - - - -
Diameter - - 2034mm 2580mm 2890mm 2860mm
Height 1665mm 1630mm 2520mm 2610mm 2600mm 3500mm
Cabinet depth - - 600mm 600mm 600mm 600mm
Weight (approx.) 220kgs 300kgs 350kgs 430kgs 500kgs 700kgs
Bund material LowerLinearDensityPolyethylene
Inner tank
material
LowerLinearDensityPolyethylene
Description Bundeddieselfuelstation
Fill point 2” BSP
Voltage 230V
Ventilation 2x2”vents
Flow rate Standardowrate-52LPM(approx.)
Highowrate-72LPM(approx.)
Flowmeter Mechanicalowmeter(accuracy+/-1%)
Delivery hose 6 metres
Hose reel
(optional)
N/A Hosereelavailable
Nozzle Automaticshutonozzle
Filtration 10micronwaterandparticulatelter
4. PRODUCT DESCRIPTION

6
4.3 Product Footprint
1350SLBFS
4. PRODUCT DESCRIPTION

7
2500HBFS
4. PRODUCT DESCRIPTION

8
3500VBFS
4. PRODUCT DESCRIPTION

9
6000VBFS
4. PRODUCT DESCRIPTION

10
10000VBFS
4. PRODUCT DESCRIPTION

11
15000VBFS
4. PRODUCT DESCRIPTION

12
5. Transport & storage
DO NOT TRANSPORT WITH LIQUID INSIDE THE TANK
1. Duringtransportationtheiplidandcabinetdoorsaresecuredby1xRclip.TheR
clipmustbeinstalledpriortotransportation.
2. Loadingando-loadingmustbecarriedoutbyacompetentpersonusingsuitable
ratedandmaintainedequipment,eitheraforkliftwithextendedforks/tinesoracrane.Iflifting
slingsareused,theymustbeattachedtotheliftingpointsasshowninthepicturesbelow
usingasteelliftingeyeinsert.Ifliftingfrombelowuseasuitableratedforkliftwithextended
forks.Ifliftingfromaboveuseasuitableratingliftingslings/chains.
3. 1350SLBFS/2500HBFS-Liftwithmainliftingeyehighlightedinredintheimage
beloworforkliftfromtheside.
4. 3500VBFS/6000VBFS/10000VBFS/15000VBFS-Liftwithx4equalspacedlifting
bracketsashighlightedinredintheimagebeloworforkliftfromonesideusingaratchet
straptosecurethetanktotheforkliftmast.
5. TuaFuelStationsmustneverbepushedorrolled.
6. Duringtransportandstorage,theiplidorcabinetdoorsmustbeclosedandsecured.
7. Loading,transportandstorageareasmustbesmoothandfreeofsharpedges.
5. TRANSPORT & STORAGE

13
6. Installation & commissioning
6.1 Installation guidelines
TheproprietoroftheTuaFuelStationisresponsibleforcomplyingwithalllegal
requirementsrelatingtotheinstallationanduseofthisproduct,aswellastheguidelines
issuedbylocalreghtingauthoritiesandenvironmentalauthorities.
OncetheTuaFuelStationhasbeenreceivedonsite,checkthatnodamagehasoccurred
whileintransit.Locatethetankinthedesiredlocationusingeitheracrane,forkliftorrollers.
6.2 System installation
Systemfoundation
Thesystemmustbeinstalledandfullysupportedonasmoothlevelledconcretebasebuiltin
accordancewithgoodbuildingstandardsandengineeringprinciples.Itisrecommendedthat
tanksbeinstalledonaconcretebaseatleast100mmthick.Pleaserefertodiagrambelow:
6.3 System location
Thelocationofthesystemshouldbepositionedbyaroadorpassingwithsucientwidth,
andloadingcapacitytoaccommodateatankerdeliveringdiesel.ProvisionfortheU-turnof
atankershouldbeconsidered.Potentialobstaclesintheformoftreebranches,highvoltage
lines,orparkedvehiclesmustbeminimized.
Thespacearoundthesystemshouldallowfreeandcollision-freemovementofserved
vehicles.
Provisionshouldbemadetoprotecttankfromimpactdamage.
6. INSTALLATION & COMMISSIONING

14
6.4 Electrical requirements
Onlyasuitablyqualiedelectricianaccordingtoapplicableregulationsmayworkontheelec-
tricwiringinstallation.Thesystemcomponentsunderservice,maintenance,andrepairwork
mustbedisconnectedfromthepowersupplybeforeanyworkinundertaken.
System power requirements:
• 220-240Volts,50Hz+/-10%
• 20ampcircuitbreakerrecommended
• Powercablerecommendation:3Core2.5mmexcable
6.5 Electrical wiring diagram
6.5.11350SLBFS/2500HBFS–KeySwitch
6. INSTALLATION & COMMISSIONING
PUMP
MCB1 6A
PUMP SWITCH
Dunford & Pearson SCHEMATIC
ST/WPS 21 of 1
213/05/2019 ISOLATOR REMOVED MB SDN
XXX TUFFA TANKS 14/12/2016 NTS
XXX XXXXXXXX

15
6.5.2 3500VBFS/6000VBFS/10000VBFS/15000VBFS–KeySwitch
PUMP
MCB16A
MCB22A
GAUGE
PUMPSWITCH
3CX0.5@1MTRLONG
2T1
6T3
1L1
5L3
ISOL16A
Dunford&Pearson PANELLAYOUT
LT/WPS 11 of 1
XXX/XX/XX XXXX MB SDN
XXX TUFFATANKS 14/12/2016 NTS
XXX XXXXXXXX
6. INSTALLATION & COMMISSIONING

16
7. Operation of the system
Thesystemanditscomponentsareintendedfordieselfuelonlyandforthepurposes
describedbelow.Useofthissysteminameansotherthandescribedbelowisregardedas
mis-useofthesystem,theuserofthesystemwillbeliableforanydefectsthatoccurdueto
its unintended use.
7.1 Using the system
Theoperationandmaintenancepersonnelmustbesuitablytrainedtousethesystem,the
usermustmakesuretheyfullyunderstandtheoperationandmaintenancesectionsofthis
manual.
7.2 Summary of main parts 1350 / 2500
7. OPERATION OF THE SYSTEM

17
7.3 Summary of main parts 3500 / 6000 / 10000 / 15000
7. OPERATION OF THE SYSTEM

18
7.4FillingaTuaFuelStation
1. Fillingshouldbeperformedonlyunderconstantsupervisionofanauthorisedperson.
2. Thistankcanonlybelledbyatankerequippedwitha2”femaleBSPcoupling.
3. On3500/6000/10000/15000modelsbeforellingthetankwithdiesel,please
checkthelevekofthetankandmakenoteofthetanklevelbeforellingandensurethe
high-levelalarmindicatorfunctionscorrectly.
4. Fittankerdeliveryhoseto2”BSPllcouplingontank.
5. Engagetankerpumpandbegintoll.Stopllingwhendesiredamounthasbeen
dispensedintotank,orwhenhigh-levelalarmsounds.
6. Duringthetankerllalwaysobservetanklevelgaugethroughoutthedurationofthe
llingprocess.Thetankerdrivermustobservethetankbeinglledatalltimesduringthis
process.
7. Oncecompletedisconnectdeliveryhosefromtankcoupling.
7.5 Dispensing diesel into vehicle
1. Resettheowmetertotalizerto0
2. Activatepumpusingoneofthefollowing:rockerswitch,keyswitch,auto-operational
nozzleholster
3. Removenozzlefromnozzleholsterandinsertthenozzlecompletelyintothediesel
tankllerneck
4. Pulltriggeronthenozzletoallowdieseltoowintothevehicledieseltank
5. Atthistimetheowmetercounterwillstartrecordingtheow,continuerefuelinguntil
thedesiredamountisreachedorwhenthevehicledieseltankisfull
6. Whenthefueltankisfullthenozzlewillautomaticallyswitcho
7. Releasethetriggerofthenozzleandreplacebackintotheholster
8. Deactivatepumpwithrockerswitch/keyswitch/autooperationalnozzleholster
7. OPERATION OF THE SYSTEM
