Component Hardware LED-3120RF Series Manual

INSTALLATION INSTRUCTIONS
LED RETROFIT KIT FOR FIXTURES WITH (2) T-8 FLUORESCENT LAMPS
LED-3120xxRF Series
• LED-312022RF (2)48”22wattlamps
• LED-312013RF (2)36”13wattlamps
• LED-312009RF (2)24”11wattlamps
TOOLS REQUIRED:
Flatscrewdriver,wirecutter/stripper,awlorotherpointedtool
  CAUTION:Riskofreorelectricalshock.Installationrequiresknowledgeofluminaireselectricalsystems.
  Thefollowingprocedureisintendedtobeperformedbyaqualiedelectrician.Ifnotqualied,donotattempt 
  installation.Contactaqualiedelectrician.

  Theelectricalratingoftheseproductsis120-277VAC.

  Topreventwiringdamageorabrasiondonotexposewiringtoedgesofsheetmetalorothersharpobjects.

  Luminaireswiring,ballastsorotherelectricalpartsmaybedamagedwhendrillingforinstallationofLED
  reectorkithardware.Checkforenclosedwiringandcomponents.

  Onlythoseopenholesindicatedinthedrawingsmaybemadeoralteredasaresultofkitinstallation.
  Donotleaveanyotheropenholesinanenclosureofwiringofelectricalcomponents.

  Notfordirectreplacementofuorescentlamps.

  Donotusewheredirectlyexposedtowater.
TheRetrotKitisacceptedasacomponentofaluminairewherethesuitabilityofthecombinationshallbedeterminedbyCSA
orauthoritieshavingjurisdiction. 

®
KIT INCLUDES:
(2)lamps
(1)label-powerend
(1)label-uorescentwarning
1890SwarthmoreAvenue•Lakewood,NJ08701•Tel800-526-3694,732-363-4700•Fax732-364-8110
www.componenthardware.com

INSTALLATION PROCEDURE
1. VerifyelectricalpowertounitisOFF.
2. Removelenscovertoexposeluminairelampsandelectronics.Ifequippedwithretainingcables,allowtohang.
 Note:Toassistwithreassembly,donotfullyremovescrewsfromlenscover.
3. Removeuorescentlamps.
4. Removeallscrewsfromretainingreector;removereectorandsetaside.Saveallassociatedhardware.
Ballastandwiringshouldnowbeexposed.Ifnot,removethewiringcompartmentcover.Theremaybelockingtabsorscrews
holdingthewiringcompartmentinplace.Removeandsaveallassociatedhardwareforreassembly.
5. Locatepowersupplytoballast,disconnectandpullaparttoseparate.Cutdisconnectleadwirestoballastandremove.
 Stripbothleads3/8”andsetaside.(Youwillre-usewireddisconnectinstep8.)Cliptheballastoutputleadsascloseto
 theballastaspossible.Clipthelampleadsasclosetothelampholdersaspossible.(Lampholderswillbeforsupportonly.)
6. Selecttwoadjacentlampholdersnearesttopowersupplyleadsandremovetheselampholdersbydepressingretainingtabs
 whilepushingdown.
7. Removeallwiresfrombothlampholders.Useanawlorotherpointedtooltogentlydepressthecopperstripadjacenttothe
 leadwhilepullingontheleadwire.
POWER SUPPLY DISCONNECT
PULL APART TO SEPARATE
POWER SUPPLY DISCONNECT
STEP 5
CUT WIRES NEAR TO BALLAST
AND NEAR TO LAMP HOLDERS
STEP 6
REMOVE LAMP HOLDERS
WIRING DIAGRAM
FROM STEP 5
BLACK
WHITE
BLACK
WHITE
RETAINING TAB
COPPER STRIP
STEP 8
REWIRE LAMP HOLDERS
STEP 9
INSTALL RE-WIRED
LAMP HOLDERS
FIXTURE ENCLOSURE
BALLAST-WIRING
FIXTURE ENCLOSURE
LED LAMP-WIRING
3 INCH
LED-3120xxRF Series

8. Using18AWG,600V,105°TYPEAWM1orCSA-TEWNsolidconductorwire,re-wirelampholdersasshowninthewiring
 diagram,includingpowersupplyleadsfromStep5.Verifyallleadsareretainedinlampholderportswithagentlepull.
9. Installre-wiredlampholdersetonthesameside.Insertfromundersideofretainingplate.Pushtolockretainingtabs.
 Thisisnowthelinesideoftheluminaire.
10. Reconnectdisconnect,separatedinStep5.
11. IMPORTANT:Applysuppliedself-adhesivelabel“POWERTOTHISENDONLY”abovere-wiredlampholders.
 Labelmustbevisibleforlampinstallation.
12. Replacewiringcompartmentand/orreectorremovedinStep4.
13. IMPORTANT:Applysuppliedself-adhesivelabel“NOTICENOTFORUSEWITHFLUORESCENTLAMPS.
 OrderreplacementLED-T8lamps–800.526.3694”.
14. InstallLEDlampswithpowerinputasmarkedonlamp,matchedtolabeledlampholders.
15. Reinstalllenscover.
16. Restorepowertoxture.
Note:OriginalballastcircuitwillbedisabledinStep5.Lampholdersoriginallywiredtoballastwillalsobeelectricallydisabled,
usedonlytosupportlampswheninstalled.Ballastwithrelatedwiringmayremaininplace,electricallydisabled.
POWER SUPPLY DISCONNECT
PULL APART TO SEPARATE
POWER SUPPLY DISCONNECT
STEP 5
CUT WIRES NEAR TO BALLAST
AND NEAR TO LAMP HOLDERS
STEP 6
REMOVE LAMP HOLDERS
WIRING DIAGRAM
FROM STEP 5
BLACK
WHITE
BLACK
WHITE
RETAINING TAB
COPPER STRIP
STEP 8
REWIRE LAMP HOLDERS
STEP 9
INSTALL RE-WIRED
LAMP HOLDERS
FIXTURE ENCLOSURE
BALLAST-WIRING
FIXTURE ENCLOSURE
LED LAMP-WIRING
3 INCH
POWER SUPPLY DISCONNECT
PULL APART TO SEPARATE
POWER SUPPLY DISCONNECT
STEP 5
CUT WIRES NEAR TO BALLAST
AND NEAR TO LAMP HOLDERS
STEP 6
REMOVE LAMP HOLDERS
WIRING DIAGRAM
FROM STEP 5
BLACK
WHITE
BLACK
WHITE
RETAINING TAB
COPPER STRIP
STEP 8
REWIRE LAMP HOLDERS
STEP 9
INSTALL RE-WIRED
LAMP HOLDERS
FIXTURE ENCLOSURE
BALLAST-WIRING
FIXTURE ENCLOSURE
LED LAMP-WIRING
3 INCH

1890SwarthmoreAvenue•Lakewood,NJ08701•Tel800-526-3694,732-363-4700•Fax732-364-8110
www.componenthardware.com
®
©2013ComponentHardware.Allrightsreserved.
INS-L82-LEDRev.07/2013
