Computec Door Drive 5.0 User manual

EN
PRJ1166_03_07_02_IUM
Rev.01
Computec
Computec
Door Drive 5.0
(CDD 5.0)
Lift door Controller
USER MANUAL
FW reference version: 02.00.000

Computec
CDD5.0
EN
CDD 5.0: user manual –Rev.01
Page 2/63
Index
Index of tables ................................................................................................................................................................ 4
Introduction ........................................................................................................................................................................ 5
Glossary .......................................................................................................................................................................... 6
1 Technical Specifications ............................................................................................................................................. 7
1.1 Standards and Codes References ...................................................................................................................... 7
1.2 Door Drive Data................................................................................................................................................. 7
1.3 Compatible Motors Data................................................................................................................................... 7
1.4 System mechanical data.................................................................................................................................... 7
2 Generalities ................................................................................................................................................................ 8
2.1 Intended use ..................................................................................................................................................... 8
2.2 System overview ............................................................................................................................................... 8
2.3 Compatibility for applications and motors........................................................................................................ 9
3 Installation ............................................................................................................................................................... 10
3.1 Preliminary mechanical checks ....................................................................................................................... 10
3.2 Mechanical Installation ................................................................................................................................... 11
3.3 Preliminary electrical checks........................................................................................................................... 11
3.4 Check of electrical parts .................................................................................................................................. 12
3.5 Door set-up, Learning and functional tests ..................................................................................................... 13
3.6 Installation trouble-shooting........................................................................................................................... 15
4 Functionalities.......................................................................................................................................................... 16
4.1 System ............................................................................................................................................................. 16
4.1.1 Working Modes ...................................................................................................................................... 18
4.2 Connections..................................................................................................................................................... 19
4.2.1 MLC signals connection .......................................................................................................................... 19
4.2.2 Direct connection of optical detector to the CDD 5.0 ............................................................................ 20
4.2.3 Connection of input signals from optional local contacts ...................................................................... 20
4.3 HMI: front panel user interface....................................................................................................................... 21
4.3.1 Display .................................................................................................................................................... 21
4.3.2 HMI user interface description............................................................................................................... 22
4.4 External handset user interface ...................................................................................................................... 23
4.4.1 Functional description and keys usage................................................................................................... 23
4.4.2 Handset menu-tree ................................................................................................................................ 24
4.5 Door Learning function ................................................................................................................................... 25
4.5.1 Standard Learning by HMI...................................................................................................................... 25
4.5.2 Standard Learning by external Handset ................................................................................................. 25
4.5.3 Auto-set procedure: automatic learning function.................................................................................. 26
4.6 Diagnostic Functions ....................................................................................................................................... 27
4.6.1 Diagnostic operations by HMI ................................................................................................................ 27
4.6.2 Diagnostic operations by Handset.......................................................................................................... 28
4.7 Firmware upgrade function............................................................................................................................. 29
5 Parameters............................................................................................................................................................... 30
5.1 Door operator configuration Parameters ...................................................................................................... 32
5.1.1 PC26: installed skate type....................................................................................................................... 32
5.1.2 PC90: installed motor type ..................................................................................................................... 33
5.1.3 PC22: closing rotation sense................................................................................................................... 33

Computec
CDD5.0
EN
CDD 5.0: user manual –Rev.01
Page 3/63
5.1.4 PC05: car door locking device settings ................................................................................................... 34
5.1.5 PC06: glass door settings ........................................................................................................................ 34
5.1.6 PC99: MLC interface logic settings ......................................................................................................... 34
5.2 Speed profiles.................................................................................................................................................. 36
5.2.1 P33: Pre-set Speed Profiles..................................................................................................................... 36
5.3 Reversing management in closing direction ................................................................................................... 37
5.3.1 PC00: reversing events management..................................................................................................... 37
5.3.2 PC34: RVS output activation type........................................................................................................... 37
5.3.3 PC42: Closing force limit Auto-set .......................................................................................................... 37
5.3.4 PC09: Closing force detection settings ................................................................................................... 38
5.3.5 Reversing Disabled offset at the end of closing ..................................................................................... 38
5.4 MLC interface management............................................................................................................................ 39
5.4.1 PC01: MLC commands check mode........................................................................................................ 39
5.4.2 PC02: reaction of door drive if no MLC command ................................................................................. 39
5.4.3 PC03: Alarm enabling if no MLC commands........................................................................................... 39
5.5 Input signals management .............................................................................................................................. 40
5.5.1 PC04: RVC input function ....................................................................................................................... 40
5.5.2 PC21: reversing inputs logic settings ...................................................................................................... 40
5.5.3 PC32: AUXC input function ..................................................................................................................... 41
5.5.4 PC27: RSC options................................................................................................................................... 41
5.5.5 PC19: FFC options................................................................................................................................... 42
5.5.6 PC20: EOD function time-out (based on EOC input) .............................................................................. 42
5.6 Output signals management ........................................................................................................................... 42
5.6.1 PC07: AUXS output options .................................................................................................................... 42
5.6.2 PC37: DOS output activation options ..................................................................................................... 43
5.6.3 PC38: DOS output activation threshold.................................................................................................. 43
5.7 Door Closed parking management.................................................................................................................. 44
5.7.1 PC25: Door Closed Parking mode .......................................................................................................... 44
5.7.2 PC44: Door closed Reduced torque relaxing tolerance.......................................................................... 45
5.7.3 PC45: Door closed Reduced torque activation delay ............................................................................. 46
5.8 Particular Parameters...................................................................................................................................... 46
5.8.1 PC43: Door open parking with reduced torque...................................................................................... 46
5.8.2 Reduced Speed value ............................................................................................................................. 46
5.8.3 Door Stopping space............................................................................................................................... 47
5.8.4 PC24: “smooth” reopening..................................................................................................................... 47
5.8.5 PC36: door opening maximum power option ........................................................................................ 47
5.9 Motor Thermal management.......................................................................................................................... 48
5.9.1 PC39: automatic opening speed profile reduction................................................................................. 49
5.9.2 Management of door blocked during opening....................................................................................... 50
6 Maintenance ............................................................................................................................................................ 51
6.1 Alarms ............................................................................................................................................................. 51
6.2 Troubleshooting (FAQ) .................................................................................................................................... 53
6.3 Correct working check sequence .................................................................................................................... 54
7 After sale.................................................................................................................................................................. 59
7.1 Customer support ........................................................................................................................................... 59
7.2 Replacements.................................................................................................................................................. 59
7.3 Material disposal ............................................................................................................................................. 59
8 General information................................................................................................................................................. 60
8.1 General considerations ................................................................................................................................... 60

Computec
CDD5.0
EN
CDD 5.0: user manual –Rev.01
Page 4/63
8.2 Confidentiality agreement .............................................................................................................................. 60
8.3 Safety............................................................................................................................................................... 60
8.4 Installation personnel Requirements .............................................................................................................. 61
8.5 User requirements .......................................................................................................................................... 61
8.6 Standard and codes reference ........................................................................................................................ 61
8.7 Warranty ......................................................................................................................................................... 62
8.8 Final considerations ........................................................................................................................................ 62
9 Annex ....................................................................................................................................................................... 63
9.1 Product conformity declaration (DDC)........................................................................................................... 63
Index of tables
- Table 1: door drive data ................................................................................................................................................... 7
- Table 2: compatible motors data ..................................................................................................................................... 7
- Table 3: system limits ...................................................................................................................................................... 7
- Table 4: list of connections/keys ...................................................................................................................................... 9
- Table 5: mechanical installation of the drive –............................................................................................................... 11
- Table 6: installation of electrical parts –......................................................................................................................... 13
- Table 7: configuration, learning and test sequence –.................................................................................................... 15
- Table 8: connections characteristics - ............................................................................................................................ 16
- Table 9: inputs types - .................................................................................................................................................... 17
- Table 10: outputs types –............................................................................................................................................... 18
- Table 11: door drive working modes -............................................................................................................................ 18
- Table 12: I/O signals connections vs MLC -..................................................................................................................... 19
- Table 13: direct connection of the optical detector -..................................................................................................... 20
- Table 14: mean visualizations on the front panel display - ............................................................................................ 21
- Table 15: functional table of the CDD5.0 front panel - .................................................................................................. 22
- Table 16: functional table of the external diagnostic tool - ........................................................................................... 23
- Table 17: standard learning sequence by HMI - ............................................................................................................. 25
- Table 18: auto-set learning procedure - ......................................................................................................................... 26
- Table 19: possible errors during auto-set learning procedure - ..................................................................................... 26
- Table 20: I/O signals reported - ...................................................................................................................................... 28
- Table 21: measurements reported in the monitor menu table - ................................................................................... 28
- Table 22: firmware upgrade sequence using usb Key - .................................................................................................. 29
- Tablle23: parameter list of the CDD5.0 door drive - ...................................................................................................... 31
- Table 24: main skate types - .......................................................................................................................................... 32
- Table 25: selectable motor list - ..................................................................................................................................... 33
- Table 26: CDD 5.0 alarms/warning list - ......................................................................................................................... 52
- Table 27: Trouble-shooting -.......................................................................................................................................... 53
- Table 28: functional check sequence - ........................................................................................................................... 58

Computec
CDD5.0
EN
CDD 5.0: user manual –Rev.01
Page 5/63
Introduction
The present user manual contains all the necessary information for a safe and correct installation,
configuration, use and maintenance of the lift door controller CDD 5.0.
Before proceeding with the installation of the CDD 5.0, it is necessary and strongly recommended that the
installation personnel have read and understood all the parts described in the present manual.
a non-correct installation of the system may cause serious danger and/or injury.
The present user manual is in any case integral part of the CDD 5.0 device, and it must be included to the
installation documentation.
All the references to the safety and responsibility are reported in the chapter 8 “General information”.
The present manual contains detailed information related to the firmware version 02.00.000, regarding all
descriptions about functional implementation.
NOTE: all the pictures, images, schematics reported in this manual have purely example purpose: the
components of the lift system may result different, based on the installed motor an door operator.

Computec
CDD5.0
EN
CDD 5.0: user manual –Rev.01
Page 6/63
Glossary
Symbol
Description
Notes
CDD 5.0
Computec Door Drive 5.0
E.C.
Elevator Controller
MLC
Main Lift Controller
HMI
Human to Machine Interface
User Interface on the CDD5.0 front panel
DOC
Door Opening Command
Same as KA, VST-O
DCC
Door Closing Command
Same as KC, VST-S
RSC
Reduced Speed Command
Same as KB, VRVRT
RVC
Reversing Command
Same as KN
FFC
Fire-Fighting Command
Same as KFF
AUXC
Auxiliary Command
Same as KAUX
DTBC
Double TB Command
Same as K2TB
EOC
Emergency Opening Command
Same as KEOD
DETC
Detector (barriers, photocell) Command
Same as Det.In.
DOS
Door Opened Signal
Same as LA, KET-O
DCS
Door Closed Signal
Same as LC, KET-S
RVS
Door Reversing Signal
Same as IM, KSKB
AUXS
Auxiliary Signal
Same as AUX
BUZS
Acoustic Signal
Same as BUZZ, PIN21, AUX2
SL
Door Self-learning active
Au
Auto-Setup procedure active
CL
Closing/Closed
OP
Opening/Opened
FSET
Reversing force setting
ms
Millisecond
mA
milliAmpère
Imp.
Space transducer pulses
PSO
Parking with Skate Opened
Important Note
S20
Aluminium Skate, 20mm space on the belt
S90
Iron Skate, 90mm space on the belt
S120
Iron Skate, 120mm space on the belt

Computec
CDD5.0
EN
CDD 5.0: user manual –Rev.01
Page 7/63
1Technical Specifications
1.1 Standards and Codes References
All the references to the standards and Codes are reported in paragraph 8.6 “Standard and codes
reference”.
1.2 Door Drive Data
Supply voltage
[100 ; 240]Vac 1-ph 50-60Hz, (115V –20%, 230V + 30%)
Vac
Available Peak output power
300
VA
Nominal output power
200
VA
Working Temperature
[-10; +60]
°C
Humidity
[20;80] non condensing
%
Electrical protection
[5x20, 4A] rapid fuse on main power supply line
[5x20, 8A] fuse on the battery supply line
Environmental protection
IP-54 case
- Table 1: door drive data
1.3 Compatible Motors Data
Motor type
Nominal power
Nominal voltage
Nominal Current
GR 63x25 + SG80K (15:1) + Enc100
50VA
24V
2.7A
GR 63x55 + SG120 (15:1) +Enc100
100VA
24V
4.9A
M63x50 + SN40 (15:1) + IGO100/2
100VA
24V
4.9A
M63x25 + SN31 (15:1) + IGO100/2
100VA
24V
2.7A
M48x60 + SN 22,6 (7:1) + IGO100/2
50VA
24V
1.5A
Moog 1Nm (4:1 belt) + Enc500
100VA
24V
2.7A
Moog 2Nm (4:1 belt) + Enc500
200VA
24V
1.5A
- Table 2: compatible motors data
1.4 System mechanical data
Motor type
Moving mass limit
Maximum Parking
force available during
parking with door
opened
Maximum force
available during
closing movement
GR 63x25 + SG80K (15:1) + Enc100
180kg
70N
250N
GR 63x55 + SG120 (15:1) +Enc100
300kg
90N
270N
M63x50 + SN40 (15:1) + IGO100/2
300kg
85N
280N
M63x25 + SN31 (15:1) + IGO100/2
180kg
70N
240N
M48x60 + SN 22,6 (7:1) + IGO100/2
120kg
40N
200N
Moog 1Nm (4:1belt) + Enc500
180kg
150N
290N
Moog 2Nm (4:1 belt) + Enc500
300kg
150N
290N
- Table 3: system limits

Computec
CDD5.0
EN
CDD 5.0: user manual –Rev.01
Page 8/63
2Generalities
2.1 Intended use
The CDD 5.0 (Computec Door Drive 5.0) device is an electronic system that permits to operate in practice all
the lift door operated by the motors described in the table “- Table 2: compatible motors data”.
The CDD 5.0 controls the lift door opening and closing automatically, according to the commands received
from the main lift controller of the lift system, and controls the time intervals, currents, speed profiles,
different external devices directly pluggable to the drive, and the possible anomalous behaviour as over-
voltages, connections interruptions, and so on.
2.2 System overview
The CDD 5.0 system is a part of the complete lift door operator, consisting in:
-Mechanical door operator:
oHeader
oCarriages
oBelt
oMotor
-Door Drive (the CDD 5.0)
-Contacts Interface to the main lift controller
Following it is reported the connection diagram of the device:
- Figure 2-1: connection diagram of the CDD 5.0

Computec
CDD5.0
EN
CDD 5.0: user manual –Rev.01
Page 9/63
- Figure 2-2: identification of keys and connections
The controller is equipped with:
N°
ID
Description
1
ON
Power on key
2
OFF
Power off key
3
Display
7-segment display (two digits) to show status/configuration
4
“1” “2” “3” “4”
Functional keys for visualization/movement/programming
5
X8
Plug for upgrade/configuration external device
6
X4
Plug for motor/battery
7
X5
RJ45 plug for motor encoder
8
X9
Direct connection of optical light curtains (including power)
9
X3.1
Plug for Elevator controller commands
10
X3.2
Plug for local inputs of the door operator
11
X2
Plug for drive output to the elevator controller
12
X1
Plug for main power supply
- Table 4: list of connections/keys
2.3 Compatibility for applications and motors
The CDD 5.0 can be applied to all the lift door operators that use the motors reported in the compatibility
table, in particular for that operator for which it is pre-set the configuration of the mechanical transmission
(skate, motor pulley, …).
It is possible in any case to adapt the system configuration to other door operator that uses the same
motors, setting manually the specified parameters values. It is strongly suggested, in this case, to previously
contact directly Computec technical support, for information about compatibility and configuration.

Computec
CDD5.0
EN
CDD 5.0: user manual –Rev.01
Page 10/63
3Installation
Before proceeding to the installation, verify the necessary safety devices:
In addition verify the necessary instruments to perform all the operations:
Be sure to work in full safe conditions, setting the inspection mode on the lift before starting any operation.
3.1 Preliminary mechanical checks
The installation of the door drive has to be performed by expert technical personnel, having all the
professional requirements expected, based on the active law in the installation country.
Before proceeding with the installation of the door drive it is necessary to:
-Check the correct and good status of the door operator installation:
oCorrect installation of the door panels
oCorrect installation of the carriages
oCorrect installation of the transmission (belt connection, belt)
oCorrect installation of the gear-motors, according to table “- Table 2: compatible motors
data”
-Check that the panels movement is free, without obstacles overall the complete door space.
-Check the material of the box:
oCDD 5.0 door controller
oRetrofit fixation bracket to be fixed on the controller, in case of retrofit

Computec
CDD5.0
EN
CDD 5.0: user manual –Rev.01
Page 11/63
3.2 Mechanical Installation
The mechanical installation of the door drive has to be executed according to the controller type to replace.
For this reason the CDD 5.0 is supplied with the retrofit fixation bracket. The following table shows the two
fixation possibilities.
Fixation type
Description
Installation with retrofit bracket
1. Switch off the main power supply
2. Remove all the connection from the old door
controller
3. Remove the door controller to be replaced
4. Remove the cover of the CDD 5.0. Apply the
retrofit bracket to the CDD 5.0
5. Install the door controller, using the fixation
holes aligned to the holes present on the
operator.
6. Apply the previous fixation screws
Installation on direct compatible systems
1. Switch off the main power supply
2. Remove all the connection from the old door
controller
3. Remove the door controller to be replaced
4. Remove the cover of the CDD 5.0
5. Apply the door drive using the four fixation
points present on the operator.
- Table 5: mechanical installation of the drive –
3.3 Preliminary electrical checks
Verify the presence of the correct supply voltage, as reported in the table “- Table 1: door drive data”.
Once the mechanical installation of the CDD 5.0 drive is completed, and the CDD 5.0 is fixated to its holding
(with retrofit bracket or directly), proceed as reported below.
4
4
4
4
6
6

Computec
CDD5.0
EN
CDD 5.0: user manual –Rev.01
Page 12/63
3.4 Check of electrical parts
STEP
Operation
Description
0
Preliminary checks
Press OFF button on the door drive front panel.
Be sure that no power supply is present.
1
Motor Connections
Connect the motor cable to the pins:
-43: positive, BROWN
-44: negative, WHITE
of the X4 connector.
Keep in any case the previous connection order, in case no numbering
rings are present, or in case the wires colour is different from the one
described.
Connect the encoder cable with its RJ45 male plug to the X5
connector.
If present, connect the external battery kit to the positive (+) and
negative (-) pins of the X4 connector..
2
MLC interface connection
In case of replacement of different controllers with different plugs
proceed as following reported, otherwise plug the previous
connectors as they are.
Check the common voltage used, and the used contacts:
Common
Connections
Controller 24V
Check the presence of the 37-38 bridge as
GND reference
External 24V
(MLC)
Remove the 37-38 bridge, only in case there
are no local contact installed on the car roof
For further information please refer to the paragraph 4.2.1
Connection of the MLC commands and of the local contacts:
PIN
Name
X3.1 Pin Description
15
24V
Auxiliary CDD 24V, available for MLC commands
5
DOC
Opening command
3
DCC
Closing command
22
RSC
Reduced speed command
23
RVC
Reversing command from detector
39
FFC
Fire-Fighting mode enable input
PIN
Name
X3.2 Pin Description
42
AUXC
Programmable Auxiliary input
41
DTBC
Second TB management input
40
EOC
Battery Evacuation floor input
38
0V_IN
GND input for the photo-coupled inputs
37
0V_DD
Auxiliary GND of the door drive for the inputs
21
BUZS
Contact for Acoustic signal
For further information please refer to the paragraph 4.2.1

Computec
CDD5.0
EN
CDD 5.0: user manual –Rev.01
Page 13/63
3
Power supply connection
4
Final Checks
Verify that ALL the signals are connected, then apply the cover.
For further information please refer to the paragraph 4.2
- Table 6: installation of electrical parts –
3.5 Door set-up, Learning and functional tests
Once the physical installation phase described in the previous paragraph is completed, it is possible to
proceed with the power on of the device and its configuration. In case of problems during the execution of
the phases, please refer to the paragraph 6.2. Refer to paragraph 4.3.2 for the front panel use.
STEP
Operation
Description
Notes
1
Power supply test
Connect the main power supply.
Press button on the door drive front panel
2
Door operator
configuration
Configure the parameters related to the installed door
operator (please refer to paragraph 5.1):
P05
Car door locking device (0=not present,
1=present)
P22
Motor Closing rotation
(0=clockwise,1=counter-clockwise)
P26
Skate type (0=S20, 1=S90, 2=S120)
P90
Installed motor type (00=self-recognized)
P99
MLC commands logic (0=H active and RSC
forced closing, 1=L active and RSC reduced
speed, 2=H active and RSC reduced speed)
Refer to paragraph
4.3.2 for the
information about
access to
Configuration Mode.
3
Self-learning
execution
Enter in the Door Drive Inspection mode, pressing key
and check that INSP led is on.
Press and keep pressed key and check the door
closing with reduced speed, if not closed.
The door completes the panels and skate closing.
Release key .
In case the movement direction is wrong or in case of
alarms, proceed with the checks suggested in the
paragraph 6.2.
Display visualization:
INSP led ON
“CL” blinking
“CL” fixed

Computec
CDD5.0
EN
CDD 5.0: user manual –Rev.01
Page 14/63
To optimize the execution of the learning procedure, it
is suggested to couple car and landing door, executing
the operations from the car roof in inspection mode.
Press key for at least 1s to enable Self-Learning.
Press shortly key . The door starts opening with
reduced speed until the door is completely opened.
The learning phase is completed.
“SL” fixed
“SL” blinking
“OP” fixed
4
Speed Profiles
check in Inspection
mode
Press continuously key to execute the door closing
with normal speed, until the door is completely closed.
Press continuously key to execute the door
opening with normal speed, until the door is completely
opened.
In case it is necessary to tune the speed profiles, please
refer to the paragraph 5.2.1
Display visualization:
“CL” blinking
“CL” fixed
“OP” blinking
“OP” fixed
5
Obstacle reversing
check in Inspection
mode
Put an obstacle at different points of the door access.
Press and keep pressed key to perform a door
closing.
When the panels meet the obstacle, the door drive will
immediately reverse the movement starting the
reopening.
Release key during the reopening movement and
wait until the door is completely opened.
Display visualization:
“CL” blinking
“IM” blinking
“OP” fixed or
“- -“ blinking

Computec
CDD5.0
EN
CDD 5.0: user manual –Rev.01
Page 15/63
6
Detector check in
Normal mode
Execute this step only if external optical detector, light
curtains or photocell are directly connected to the CDD
5.0, to the RVC input or to the X9 plug.
Activate the normal mode of the door drive, from the
Inspection mode, by pressing key and check the
NORMAL led is ON.
During the door closing, interrupt the light curtains and
check the immediate reopening of the door, until the
door is completely open.
Remove any obstacle from the detector activation zone,
and check the door closing until the door is completely
closed.
Display visualization:
NORMAL led
ON
“CL” blinking
“IM” blinking.
“IM” fixed.
“CL” blinking
“CL” fixed
7
Functional check in
Normal mode
Complete the door closing, if not performed: press and
keep pressed key until the door is completely
closed.
Release key .
Check the closing force limit for reversing, with
appropriate instrumentation.
Activate the NORMAL mode of the controller, from the
Inspection mode: press key and check the led
NORMAL is on.
Now the controller works in Normal mode, and executes
the commands received from the MLC, as well as the
reversing from detector directly connected to the door
controller.
Perform all the functional checks with the complete
system operating in Normal mode, from the car roof or
from the landing, according to the procedure active for
the involved maintenance people.
Display visualization:
led NORMAL
on
- Table 7: configuration, learning and test sequence –
3.6 Installation trouble-shooting
The installation sequence previously reported describes all the steps that have to be executed to operate a
correct and complete set-up of the door system.
In case of issues, or if anomalous behaviours happen during the installation, please refer to the paragraph
6.2 “Troubleshooting (FAQ)”. For any alarms, please refer to the paragraph 6.1 “Alarms”.

Computec
CDD5.0
EN
CDD 5.0: user manual –Rev.01
Page 16/63
4Functionalities
The present chapter describes in details the structure and the functionalities of the CDD 5.0 system.
4.1 System
The CDD5.0 lift door drive is a part of the lift door operator. Refer to the paragraph 2.2 for the description
of the different parts of the system. Refer to the paragraph 1.3 for the details about the compatible motors
that can be controlled by the CDD5.
Following it is reported the connection diagram of the device:
- Figure 4-1: connection diagram of the CDD 5.0 -
The connection details for every available plugs are reported below:
Terminal
N°
Connection
mode
Connection
type
Conductor type
Temperature
range
Fixation
torque
AWG UL/CL
section
X4
Screw
Load (motor
output power)
Use only copper
conductor
60°C (140°F)
Min 0.5 Nm
Max 0.6 Nm
Min 20
Max 18
X5
Plug
Motor Encoder
Use only copper
conductor
Not required
Not required
Not required
X9
Screw
Optical
Detector
Use only copper
conductor
Not required
Min 0.5 Nm
Max 0.6 Nm
Min 30
Max 12
X3.1
Screw
MLC commands
Use only copper
conductor
Not required
Min 0.5 Nm
Max 0.6 Nm
Min 30
Max 14
X3.2
Screw
Not required
Min 30
Max 12
X2
Screw
Outputs to MLC
Use only copper
conductor
Not required
Min 0.5 Nm
Max 0.6 Nm
Min 30
Max 12
X1
Insertion
Main power
supply
Flexible cable
according to UL ZJCZ
category.
60°C (140°F)
Not required
Min 18
Max 12
X8
Insertion
Handset/
Upgrade key
-
Not required
-
-
- Table 8: connections characteristics -
X2
X1
X4
X5
X9
X8
X3

Computec
CDD5.0
EN
CDD 5.0: user manual –Rev.01
Page 17/63
The following table reports all the INPUTS available on the controller:
Signal
Position
Description
Contact type
Default status
Notes
DOC
X3.1.5
Door Opening
Command (from MLC)
Dry contact
Open
DCC
X3.1.3
Door Closing
Command (from MLC)
Dry contact
Open
RSC
X3.1.22
Forced reduced speed
closing command or
Reduced speed enable
command (from MLC)
Dry contact
Open
The MLC may activate this
command when the light
curtains (connected to MLC)
are deactivated from the
MLC, after a timeout or
maximum closing retries
RVC
X3.1.23
Reversing external
source
Dry contact
Open
FFC
X3.2.39
Fire-Fighting mode
enable command
(from MLC)
Dry contact
Open
DTBC
X3.2.41
Second TB floor input
command
Dry contact
Open
This contact is installed on
the floor with a different
opening space. It is
necessary to execute a
second door learning during
installation phase
AUXC
X3.2.42
Auxiliary contact
(programmable)
Dry contact
Open
EOC
X3.2.40
Evacuation floor
contact
Dry contact
Open
This contact is installed at
the evacuation floor to
permit the automatic
opening cycle with drive
powered by batteries
- Table 9: inputs types -
The following table reports all the OUTPUTS available on the controller:
Signal
Position
Description
Contact type
Default status
Notes
DOS
X2.16
X2.17
Door Opened signal
(to MLC)
Dry contact
Closed
Contact open when the
door is completely opened.
Ratings: 3A 250Vac 30Vdc
DCS
X2.18
X2.19
Door Closed Signal
(to MLC)
Dry contact
Closed
Contact open when the
door is completely closed.
Ratings: 3A 250Vac 30Vdc
RVS
X2.1
X2.2
X2.4
Reversing source active
or reversing movement
active (to MLC)
Dry contact
Double contact
This contact switches,
closing the N.O. contact on
the common voltage, when
and obstacle is present
(from internal closing force
limiter or from external
sources)
Ratings: 3A 250Vac 30Vdc

Computec
CDD5.0
EN
CDD 5.0: user manual –Rev.01
Page 18/63
AUXS
X2.34
X2.35
X2.36
Auxiliary signal
(to MLC)
Dry contact
Double contact
Programmable functions
Ratings: 3A 250Vac 30Vdc
Acoustic
signal
X3.2.21
Acoustic signal
Open collector
100mA
Open
Activates the acoustic signal
in different condition,
based on the settings of
different parameters
- Table 10: outputs types –
4.1.1 Working Modes
The CDD 5.0 door drive can activate the following working modes:
MODE
DESCRIPTION
NORMAL
This is the normal automatic working mode.
The door drive after the power on enters in this working mode.
In this working mode the controller executes the movements requested from the
commands sent by the MLC.
INSPECTION
This is the Inspection mode of the door drive.
In this working mode the door drive does not accept commands from MLC, but executes
the opening/closing movements according to the pressure of “<>” and “><” buttons on
the door drive front panel.
ATTENTION: in this working mode the external reversing sources are disabled.
CONFIGURATION
This is the programming mode, where it is possible to configure and set all the
parameters accessible front the door drive front panel.
DIAGNOSTIC
The controller enters in this working mode, when a recognized device is connected to
the X8 plug.
The door drive recognizes the connection of the external device and, from any of the
previous working mode, enters in this one.
In this working mode, the controller communicates with the external device for all the
diagnostic/configuration/monitor/upgrade operations.
When the external device is disconnected, the controller returns automatically in
Normal mode.
UPGRADE
This is the mode in which the controller enters during the firmware upgrade.
- Table 11: door drive working modes -
Please refer to paragraph 4.3 “HMI: front panel user interface” about the use of the door drive front panel,
and how to move from one to another working mode.

Computec
CDD5.0
EN
CDD 5.0: user manual –Rev.01
Page 19/63
4.2 Connections
4.2.1 MLC signals connection
The present paragraph reports the connections between door drive and MLC, focusing the attention on the
connection for the common voltage to use, in case it is the common voltage from door drive (24_DD) or
from MLC (24_EC). The door drive has a 24Vdc auxiliary common voltage for the wiring of commands, with
maximum load limit current of 1A.
Common Voltage
Connection
Notes
24V_DD
The 37-38 bridge must be present.
The MLC uses the 24Vdc from the door drive as
common voltage for commands and door drive
outputs.
Commands: DOC, DCC, RSC, FFC. As example only the
first two are reported in the diagram: the others
follows the same connection rules.
The door drive outputs, being dry contacts, can be
connected to another common voltage, if requested by
the MLC.
The door drive outputs have a dedicated common
voltage available for each output.
In the diagram they have been grouped in a single pin,
that represents a series of bridges between X2.4,
X2.16, X2.18, X2.35
24V_EC
Remove the 37-38 bridge and connect the external 0V
from MLC to the 38 pin.
Commands: DOC, DCC, RSC, FFC. As example only the
first two are reported in the diagram: the others
follows the same connection rules.
If local wired contacts are present:
1. use the same common voltage active for the
commands.
2. use the auxiliary 24Vdc of the door drive, recovering
the 37-38 bridges. In this case check the compatibility
between 0V_DD and 0V_EC.
The door drive outputs keep the same common voltage
from MLC, used for the commands.
The door drive outputs have a dedicated common
voltage available for each output.
In the diagram they have been grouped in a single pin,
that represents a series of bridges between X2.4,
X2.16, X2.18, X2.35
- Table 12: I/O signals connections vs MLC -
Q.M.
(E.C.)
CDD5
X2.1 (RVS N.C.)
X2.17 (DOS)
X2.19 (DCS)
X2.34 (AUXS N.C.)
X2.4 X2.16
X2.18 X2.35
X3.1.15 (+24V)
X3.2.38 (0V IN)
X3.2.37 (0V DD)
X3.1.5 (DOC)
X3.1.3 (DCC)
Q.M.
(E.C.)
CDD5
0V EC
X2.1 (RVS N.C.)
X2.17 (DOS)
X2.19 (DCS)
X2.34 (AUXS N.C.)
X2.4 X2.16
X2.18 X2.35
X3.1.15 (+24V)
X3.2.38 (0V IN)
X3.2.37 (0V DD)
X3.1.5 (DOC)
X3.1.3 (DCC)
24V EC

Computec
CDD5.0
EN
CDD 5.0: user manual –Rev.01
Page 20/63
4.2.2 Direct connection of optical detector to the CDD 5.0
The present paragraph illustrates the connection of the external reversing sources (detector, light curtains,
photocells) directly to the door drive, both as dry contacts or as devices that need also supply voltage.
The X9 plug permits to directly connect a PNP device (N.O. or N.C.) to the CDD 5.0: the door drive gives the
supply voltage for the device, as reported in the following table:
PIN
DESCRIPTION
NOTES
33
GND
0V pin
32
DETC (IN)
Input pin: connect the status pin of the PNP N.O. or N.C. detector
31
+24Vdc
Voltage supply pin: 24Vdc, 100mA max
30
Free
Free pin: it may be used to fix the connection between RX and TX parts of the
detector
- Table 13: direct connection of the optical detector -
NOTE: if it is necessary to connect a detector with N.C. output, reverse the input signal polarity by the
parameter described in the paragraph 5.5.2 “PC21: reversing inputs logic settings”.
NOTE: if it is necessary to connect a NPN detector, please contact Technical support per the dedicated
instructions.
4.2.3 Connection of input signals from optional local contacts
The present paragraph describes how to connect to the door drive the signals from the special local
contacts: EOC, DTBC AUXC.
In this case a magnetic switch is normally installed on the door operator (car side), while on the floor side it
is installed a support plate with two magnets that permits the commutations of the magnetic switch, that
will be active only when the car is between the two magnets (car at the floor).
The magnetic switch should be then connected to the desired pin of the door drive. Refer to the paragraphs
related to the different functions, for the specific descriptions.
