COMSOL WCCM10 Instruction Manual

Wireless Car Charger Ver 1.2
Model: WCCM10
Qi Certified
Certification program ensures this
charger has passed rigorous tests
to guarantee safety, compatibility
and energy efficiency.

* Check with device manufacturer for Qi wireless compatibility
#
When connected to a QC 2.0 or QC 3.0 car charger (not included)
Compatible with Qi-enabled devices* including
Samsung S20/10/S9/S8
Samsung Note 10/9/8/5
Huawei P30 Pro
Huawei Mate 30/20 Pro
Google Pixel 3/3 XL
Sony Xperia XZ2
LG G7 ThinQ
LG V30+
iPhone 11 Pro/11
iPhone XS/XSMax/XR
iPhone X/8/8 Plus
Samsung Galaxy Fold
Compatible with Qi-enabled devices* including
Features
Supplied with ar vent mount or window/dash suction mount
Supports 7.5W Apple wireless fast charging for iPhone 8 or later#
Supports 10W wireless fast charging for compatible devices such
as Samsung Galaxy Series and more#
Supports 5W standard wireless charging for all Qi enabled devices
No need to remove your protective case. Works with most cases
up to 3mm thick
LED indicator to show charging status
Smart IC enables energy saving mode when device is fully charged
Full safety protection for your devices with Qi certified temperature
control, strict voltage regulation & short circuit protection
Includes 1m micro USB cable to connect wireless charger to USB
car charger (USB car charger not included)
Compatibility
Features
Compatibility

Choose either the air vent mount or the window/dash suction mount
and attach the accessory to the wireless charger by snapping the
ball into place and tightening the screw
Using the included micro USB cable, connect the wireless charger
to a USB car charger (USB car charger not included)
When connected to the USB charger, the red LED will be on for
3 seconds to indicate the wireless charger is powered on
Place your Qi enabled wireless phone into the cradle
Adjust the movable bottom phone bracket to suit the size of your
phone by pressing the bottom button on the back of the cradle
Close the cradle locking arms by pushing both sides together until
they are securely holding your phone in place
To remove your phone, press the top button on the back of the cradle
to release the locking arms
During charging, the green LED will be permanently on
Vent Mount
Window or
Dash Mount
Adjustable
Wireless Charging Cradle Operation

• Only use original or reputable third party chargers and cables
• Do not get wet to avoid causing short circuit damage and leakage
• Do not use in extreme hot, humid or corrosive environments to
avoid short circuit damage and leakage
• Do not place too close to magnetic strip or chip ID card to avoid
magnetic failure
• Do not clean with harmful chemicals or detergents
• Misuse, dropping or excessive force may cause damage to the
charging stand
Wireless Standard: WPC/Qi (v1.2.4)
Input: DC 5V 2A or 9V 2A
Output: 5W / 7.5W / 10W
Working Frequency: 110 to 205KHz
Charging Distance: 3 to 8mm
Charging Efficiency: >72%
Weight: 158g
Made in China
www.comsol.com.au
iPhone is a trademark of Apple inc., registered in the U.S. and other countries.
The ‘Qi’ Symbol is a trademark of the Wireless Power Consortium.
Specifications
Troubleshooting
• If your wireless charging does not work then please adjust the
feet of the cradle upwards or downwards. The wireless
charging coil in your phone needs to match the position of the
wireless charging coil in the charger. Slide the feet up and
down whilst the phone is sat in the cradle and the power is
connected until your two coils line up and charging
commences
Important Safety Instructions
