Comtrend Corporation PG-9182S4 User manual

! ! ! ! !Page 1
!
!
!
Quick Install Guide
PG-9182S4 G.hn 2000 Powerline Adapter with 4 Gigabit Ethernet Switch
!
Understanding Your Powerline Adapter
!
!
!
!
!
!
!
!
!
!
!
LED
Color
Mode
Description
Power LED
Green
On
The Adapter is powered on.
Off
Off
The Adapter is powered off or faulty.
Connection
LED
Green
On
The current connection (line rate) is more than 40Mbps.
Orange
On
The current connection (line rate) is between 5Mbps and
40Mbps.
Red
On
The current connection (line rate) is less than 5Mbps.
Off
Off
An Adapter connection does not exist.
Security LED
Green
On
The Adapter is secure (it has received or generated network
keys).
Blinking
The Adapter is in the process of being secure.
Off
Off
The Adapter is not secure.
A
Ethernet
Ports
LED Icons
Descriptions
are provided
below
Security Button
Enables Device
Synchronization
in Secure Mode
Reset Button
Press for more
than 10 seconds
for Factory Reset

! ! ! ! !Page 2
Initial Powerline Adapter Setup
NOTE: A minimum of two G.hn Powerline Adapters are required to create a connection. The following
instructions will use the PG-9182PT as the primary connection to connect to the Network Device
(Modem, Router, or Access Point), however, any Comtrend G.hn Powerline Adapter can be used.
à
If you are setting up a G.hn Powerline network for the first time, then follow the below steps.
à
If you are adding to an existing G.hn Powerline network, then skip to Steps 3-5.
1. Plug the PG-9182PT into a power outlet near your Network Device
(Modem, Router, or Access Point).
For maximum performance, please plug the Powerline Adapter directly
into the wall outlet. Do not plug into a power strip or surge protector, as
network performance could degrade significantly.
2. Connect the Powerline Adapter to your Network Device (Modem, Router, or
Access Point) with an Ethernet (RJ-45) cable. Wait 10 seconds for the
Ethernet LED to light up GREEN, which indicates a connection is established.
A flashing GREEN light indicates that the device is sending data.
Device Connection
3. Plug the PG-9182S4 into a power outlet near the Internet-enabled
device (ex. TV, PC, STB, DVR, etc.). Please wait for up to 30 seconds for
the Power LED and Security LED to remain solid GREEN.
4. Connect this Powerline Adapter to the Internet-enabled device (ex. TV, PC,
STB, DVR, etc.) with an Ethernet (RJ-45) cable.
B
PG-9182PT
Network Device
(Modem, Router, or Access Point)
Set-Top-Box
C
PG-9182S4

! ! ! ! !Page 3
Pairing the Powerline Adapters
5. Press the Security Button on the PG-9182PT until you see the Security LED start blinking
GREEN. Then you have up to 2 minutes to press the Security Button on the PG-9182S4 (hold the
button until you see the Security LED start blinking GREEN). The Security LED and the
Connection LED should be solid GREEN on both Adapters when they are successfully
paired. This could take up to 2 minutes.
Note: If you are adding to an existing G.hn Powerline network, then press the Security Button on the
adapter connected to your Network Device until you see the Security LED start blinking GREEN.
Then press the Security Button on the Powerline Adapter you are adding until you see the Security
LED start blinking GREEN. The Security LED and the Connection LED will light up GREEN on
all adapters within the G.hn Powerline network.
6. Repeat Steps 3 to 5 to add additional Powerline Adapters. Please note that up to 16 devices
can be connected within a Powerline G.hn network.
You Have Succesfully Set Up Your G.hn Powerline Network!
Troubleshooting
The following information should help you diagnose basic setup or installation problems.
Connection LED is OFF: The Connection LED shows that the Powerline Adapter is connected to
the G.hn Network. If the indicator is off, then plug both Powerline Adapters that you are attempting to
pair into power outlets that are located within the same room. The Connection LED should light
up GREEN. If not, then press the Reset Button on each adapter for more than 10 seconds. Afterwards,
you can plug the units back into their original location.
Security LED is OFF: If the Security LED is off, then it means the Powerline Adapter is not securely
paired. Press the Security Button on the Powerline Adapter for 3 seconds until you see the Security LED
start flashing GREEN.Repeat this on the other Powerline Adapter. The Security LED and the
Connection LED will light up GREEN on both adapters. This means the adapters are now securely paired
and have a strong connection.
To join an existing G.hn Powerline network, press the Security Button on any Powerline Adapter in the
E
F
D

! ! ! ! !Page 4
existing G.hn Powerline network for 2 seconds until you see the Security LED start flashing GREEN.
Then press the Security Button on the additional Powerline Adapter. The Security LED and the
Connection LED will light up GREEN on both adapters.
*If you have tried the above and are still experiencing problems, you can reset all devices to factory default
by pushing the Reset Button for more than 10 seconds (until all the LEDs on the device blink).
Power Specifications:
• I/P: 100-125Vac, 50/60Hz, 15A
WARNING
• For indoor use only
• Disconnect the PLC from the power source before servicing
• Do NOT open the casing
• Do NOT use near water
FOR MORE HELP: For instructions on advanced features, FAQ, etc., please visit the PG-9182S4 online Product
Webpage on our website.
