Comtrol ROCKETLINX ES7110 User manual

QUICK INSTALLATION GUIDE
2000550 Rev E | Release Date - August 2015
ROCKETLINX ES7110
ES7110/ES7110-VB

INTRODUCTION
The RocketLinx ES7110 series is an industrial Power over Ethernet (PoE)
switch with eight Fast Ethernet ports and two Gigabit uplink ports to ensure
high-bandwidth connecon. The ES7110 is compliant with the IEEE 802.3af
PoE standard to deliver a maximum of 15.4 W per port with a total output
power budget of 65W. The ES7110 series oers the following models:
• ES7110 - with eight Fast Ethernet PoE ports and two RJ45 Gigabit uplink
ports (48VDC)
• ES7110-VB - with eight Fast Ethernet PoE ports and two RJ45 Gigabit
uplink ports (12-24VDC)
To ensure the high quality of video data transmission, the ES7110 not only
provides Gigabit bandwidth uplink for large image trac, but also supports
QoS to adjust the priority of data transfer. Using the Fault Relay, the
ES7110 can automacally warn the administrator if there are any failures.
The compact IP30 rigid aluminum case allows the ES7110 to be reliably
operated in an extreme environment. Refer to the Comtrol website for more
informaon about specic ES7110 model features.
WIRE THE POWER
Use the following procedure to wire the power.
1. Insert the posive and negave wires (12-24AWG) into the PWR+ and
PWR- contacts.
Note: Power should be disconnected from the power supply before connecng it to
the switch. Otherwise, your screwdriver blade can inadvertently short your terminal
connecons to the grounded enclosure.
2. Tighten the wire-clamp screws to prevent the wires from coming loose.
1

WIRE THE ALARM RELAY OUTPUT AND GROUND
The ES7110 provides one alarm relay output. The relay contacts are
energized (open) for normal operaon and close under a faulty condion,
such as an Ethernet port link break. Congure the alarm relay output with
the DIP switches.
1. Insert posive and negave wires into Relay A and Relay B.
2. Tighten the wire-clamp screws to prevent the wires from coming loose.
3. Connect a ground wire between the chassis and earth ground using
12-24AWG wire to ensure that the ES7110 is not damaged by noise or
electrical shock.
a. Loosen the earth ground screw on the boom of the ES7110
with a screw driver.
b. Tighten the screw aer the earth ground wire is connected.
2
Relay PWR
DC Power output Power Supply
AC Power input
12 to 24AWG
Wire
Power Supply Requirements
ES7110 48VDC/96W (Min)
ES7110-VB 12-24VDC/96W (Min)
Electrical Specicaon ES7110 ES7110-VB
Power Input 48VDC 12-24VDC
Power Consumpon (without PD loading) 7W 11W@ 24VDC
Power Consumpon (with PD loading) 75W 80W @ 24VDC
Maximum Output/Power PoE Port 15.4W 15.4W
Total PoE Power Budget 65W 65W

SET THE DIP SWITCH
The ES7110 has a 10-pin DIP switch located on the boom panel to congure
the Port Link Alarm for the Ethernet ports. The following table shows the DIP
switch number mapping to the corresponding
PoE and Gigabit ports as follows.
Port G2 Port G1 Port 1 Port 2 Port 3 Port 4 Port 5 Port 6 Port 7 Port 8
DIP 1 DIP 2 DIP 3 DIP 4 DIP 5 DIP 6 DIP 7 DIP 8 DIP 9 DIP 10
The port break alarm is limited to an auto-negoaon 10/100 full-duplex
device.
3
Maximum 1A/24VDC
Alarm System
Extra Power
System
Port Alarm
Earth Ground

DIP Switch Status Descripon
1 - 2 On Enables the Gigabit port failure alarm for this port
O (Default) Disables the Gigabit port failure alarm for this port
3 - 10 On Enables the PoE port failure alarm for this port
O (Default) Disables the PoE port failure alarm for this port
MOUNT THE ES7110
The ES7110 can be mounted on a DIN rail or on a wall panel. The DIN rail clip
is already aached to the ES7110 at the factory.
Note: The ES7110 will disperse heat through the metal case during PoE port
operaon. The ES7110 should be installed and mounted onto a panel that
provides good heat dispersion.
You can use this procedure to mount the ES7110 on a DIN rail.
1. Insert the upper end of the DIN rail clip into the back of the DIN rail
track from its upper side.
2. Lightly push the boom of the DIN rail clip into the track.
3. Verify that the DIN rail clip is ghtly aached to the track.
CONNECT THE POE OR RJ45 UPLINK PORTS
You can use the following informaon to connect Ethernet cables between
the ES7110 ports and the network nodes.
• Ports G1 and G2 are Gigabit Ethernet ports that support 10BASE-T,
100BASE-TX, and 1000BASE-TX.
• Ports 1-8 are Fast Ethernet 10/100BASE-TX PoE ports that are IEEE
802.3af (PoE) compliant. The Fast Ethernet ports support 10BASE-T and
100BASE-TX, full- or half-duplex modes.
The following table shows the RJ45 pin-out assignments for the PoE and
Gigabit ports.
All ports automacally detect the signal from the connected devices to
negoate the link speed and duplex mode. Auto MDI/MDIX allows you to
connect another switch, hub, or workstaon without changing straight-
through or crossover cables. Crossover cables cross-connect the transmit
lines at each end to the received lines at the opposite end.
4

Connect one side of an Ethernet cable into any switch port and connect the
other side to your aached device. Make sure that the cables are less than
100 meters (328 feet).
• Uplink ports:
10BASE-T: 2-pair
Category 3, 4, 5
cable
• Uplink ports:
100BASE-TX:
2-pair Category 5
• Uplink ports:
1000BASE-TX:
4-pair Category 5
cable
• PoE ports: 4-pair
Category 5e / 6
cable
LEDs
This table provides informaon about the status LEDs.
LEDs Status Descripon
Power Green Valid DC input power applied
O No power
Alarm Red A power link failure has occurred
O No failure has occurred
RJ45 Pin 10/100BASE-TX PoE
(Alternave B)
1000BASE-TX
1RX+ BI_DA+
2 RX - BI_DA-
3 TX + BI_DB+
4 Vport+ BI_DC+
5 Vport+ BI_DC-
6 TX - BI_DB-
7Vport- BI_DD+
8 Vport- BI_DD-
5

This table provides details about the port status LEDs.
Port Status LED Descripon
PoE 1-8
Link/
Acvity
Green The port is connected
Blinking Transming or receiving
packets
O The port link is inacve
PoE 1-8
Full-
Duplex/
Collision
Yellow Full-duplex mode
connecon
Blinking Data collision
O The link is inacve or
operang in half-duplex
mode
G1/G2
Link/
Acvity
Green The port is connected
Blinking Transming or receiving
O The port link is inacve
G1/G2
Speed
Yellow Full-duplex mode
connecon
Blinking 3 blinks per cycle -
1000Mbps
2 blinks per cycle -
100Mbps
1 blink per cycle -
10Mbps
O The link is inacve
6
