Comway WG8010 User manual

WG8010 Cellular IP Modem User Guide
WG8010 Cellular IP Modem User Guide
Contact information, support
For general contact, technical support, to report documentation errors and to order
manuals visit:
www.comway.com.cn
Page 1 of 18

WG8010 Cellular IP Modem User Guide
Page 2 of 18
Document Information
Revision Date Document History
1.0 20 MAY 2009 Initial Release
GENERAL NOTE
The aim of this document is to support the application and engineering efforts of
COMWAY’s customers. This document is intended for testing, evaluation, integration,
and information purposes.
COMWAY makes every effort to ensure that the quality of the information is
available. The content of this documentation is provided on an “as is” basis and may
contain deficiencies or inadequacies.
COMWAY disclaims any warranty and all responsibility for the application of the
device(s) that is made in relation to the accuracy, reliability or contents of this
document. COMWAY is not liable for any injury, loss or damage of any kind incurred
for the use of or reliance upon information.
COMWAY reserves the right to make any modifications, additions and deletions to
this document due to typographical errors, inaccurate information, or improvements
to products at any time and without notice.

WG8010 Cellular IP Modem User Guide
Page 3 of 18
Index
1. Introduction...........................................................................................................................4
1.1 Overview ...................................................................................................................4
1.2 Package Checklist ...................................................................................................4
1.3 Product Features .....................................................................................................4
1.4 Product Specifications.............................................................................................4
2. Getting Started ......................................................................................................................5
2.1 Panel layout ..............................................................................................................5
2.2 SIM Card Installation...............................................................................................6
2.3 Connecting the Antenna .........................................................................................6
2.4 Connecting to a Serial Device................................................................................6
2.5 Connecting the Power.............................................................................................7
2.6 LED Indicators..........................................................................................................7
3. Pre-Deployment Considerations ...........................................................................................7
3.1 Cellular Network Connection .................................................................................7
3.2 Data Center IP address ..........................................................................................7
3.3 Operation Modes .....................................................................................................8
3.4 Transmission Protocol...........................................................................................10
4. Configure WG8010 with AT Command..............................................................................11
4.1 Determine which Com Port to Use......................................................................11
4.2 Start HyperTerminal...............................................................................................11
4.3 Cellular Network Connection Configuration.......................................................13
5. Configure WG8010 with Configuration tools.....................................................................13
5.1 Serial Port Configuration.......................................................................................13
5.2 Cellular Network Connection ...............................................................................15
5.3 Flexible Connection ...............................................................................................16
5.4 Others......................................................................................................................17

WG8010 Cellular IP Modem User Guide
Page 4 of 18
1. Introduction
1.1 Overview
The WG8010 is a compact, stand-alone wireless IP (GSM/GPRS) modem, which can be
used to connect any traditional serial (RS-232/485/422) device to a cellular network. The
WG8010 IP Modem comes pre-installed with the TCP/IP protocol suite to transmit data
back and forth between the serial device and GSM/GPRS network.
Traditional SCADA and data collection systems rely on serial ports to collect data from
various kinds of instruments, such as PLCs, meters, and sensors. Since the WG8010 IP
Modem network-enables instruments equipped with an RS-232, or RS-485
communication port, SCADA and data collection system will be able to access all
instruments connected to a standard TCP/IP network, regardless of whether the devices
are used locally or at a remote site.
The WG8010 IP Modem allows you to expand a serial port for a host computer on
demand. As long as your host computer supports the TCP/IP protocol, you will not be
limited by the host computer's bus limitation (such as ISA or PCI), nor will you be limited
if you do not have drivers for various operating systems.
1.2 Package Checklist
Each WG8010 IP Modem is shipped in a separate box with standard accessories. When
you receive your shipment, please check the contents of the box carefully, and notify
your COMWAY sales representative if any of the items are missing or appear to be
damaged.
WG8010 IP Modem is shipped with the following items:
·Document & Software CD.
·Rubber SMA Antenna.
·DC Power Supply.
·RS232 Serial Line.
1.3 Product Features
·Dual-band 900/1800 or 850 /1900 MHz GSM/GPRS
·Connects installed devices to Internet via serial port
·Adjustable baud rate feature for easy configuration of custom baud rates.
·Versatile operation modes, including Transparent, Transparent with Device ID,
COMWAY Manage and Virtual COM
·Port buffering function to prevent loss of serial data when communication is disrupted.
·No Internet programming required
·Auto-registration on start-up
·LED indicators for status and signal level.
1.4 Product Specifications
Cellular Interface
Standards GSM/GPRS
Band Options Dual-band 850/900 or 1800/1900 MHz
GPRS Multi-slot Class Class 10

WG8010 Cellular IP Modem User Guide
Page 5 of 18
GPRS Terminal Device Class Class B
GPRS Coding Schemes CS1 to CS4
SIM Interface
Number of SIMs 1
SIM Control 1.8V, 3 V
Serial Interface
Number of Ports 1
Serial Standards RS-232/485/422
ESD Protection 15 KV
Power EFT/Surge Protection 2 KV
Serial Communication
Parameters
Baud rate 300 bps to 115.2 Kbps
Data Bits 5, 6, 7, 8
Stop Bits 1, 1.5, 2 (when parity = None)
Parity None, Even, Odd, Space, Mark
Flow Control None
Operation Modes Transparent, Transparent with Device ID,
COMWAY Manage, Virtual COM
Transmission Protocol TCP, UDP
Physical Characteristics
Weight 130g
Dimensions 108 x 65 x 26 mm
Environmental Limits
Operating Temperature -30 to 70
0
C
Operating Humidity 5 to 95% RH
Storage Temperature -40 to 75
0
C
Power Requirements
Number of Power Inputs: 1 power jack
Input Voltage 5 to 16 VDC
Warranty
Warranty Period 2 years
2. Getting Started
This section describes how to connect the WG8010 IP Modem to a host PC or serial
device for first time testing purposes. We cover topics such as: Wiring Requirements,
SIM Installation, Connecting the Power, Connecting to a Serial Device, and LED
Indicators.
Note: Be sure to disconnect the power cord before installing and/or wiring your device.
2.1 Panel layout

WG8010 Cellular IP Modem User Guide
Page 6 of 18
2.2 SIM Card Installation
Insert SIM Card with the metallic part facing down and the clipped corner in the left.
Note: Not to pull out the SIM holder without pushing the eject button
2.3 Connecting the Antenna
The antenna is supplied with WG8010; connect it to the antenna connector on IP
modem.
2.4 Connecting to a Serial Device
The WG8010 support one RS-232 port that connects through a DB9 male connector on the
bottom panel.
Pin Signal Pin Signal
1 6

WG8010 Cellular IP Modem User Guide
Page 7 of 18
2 RXD 7
3 TXD 8
4 9
5 GND
2.5 Connecting the Power
Connect the 5 to 16 VDC power cord with the WG8010 IP Modem's power input. If the
power is properly supplied, the "PWR" LED will glow a solid green color to indicate that
the system is ready.
2.6 LED Indicators
The LED indicators on the front panel of the WG8010 IP Modem are described in the
following table.
LED status Device Status
DATA LED blinking Data
transmission
PWR, LINK LED blinking Not registered
PWR blinking Net search
LINK LED Permanently on Online
3. Pre-Deployment Considerations
3.1 Cellular Network Connection
APN
APN (Access Point Name) is the point where a mobile device can enter an IP network.
Operator offers a public APN, letting all customers access the internet, and private APNs for
direct access to a company LAN. Private APN settings can be customised to authenticate
users and even to provide monitored internet access via the company’s web proxy.
3.2 Data Center IP address
Public Fixed IP Address
Mobile applications require a routable or “reachable” Data Center IP address. One way to
accomplish this is with a public fixed IP address, which is generally reachable by anyone on
the Internet.
Dynamic Domain Name
The demand for public IP addresses continues to grow, yet there are a finite number of public

WG8010 Cellular IP Modem User Guide
Page 8 of 18
IP addresses available. To solve this problem, wireless carriers have resorted to handing out
dynamic IP addresses instead of static or fixed public addresses.
With dynamic IP addresses, each device is given an IP address for a limited period of time
(usually no more than a few hours), and then the IP address is changed.
A Dynamic Domain Name Services (DDNS) server maps a static hostname to the remote
device, so that no matter how often the IP address of that device changes, the hostname still
points to the same device.
3.3 Operation Modes
Transparent Mode
A key feature of the WG8010 is a plug-and-play Transparent Operating Mode, which is
perfect for retrofitting installed legacy devices with IP capability.
Once the Transparent mode is established, the link becomes a pipeline for streaming raw
serial data to WG8010. Data will continue to flow freely between the local and remote devices
until a predefined activity occurs to terminate the remote connection.
Transparent with Device ID Mode
Device ID: User assigned ID number for the WG8010.
If this parameter is enabled, every time when the socket is connected, WG8010 will
immediately report its device ID
COMWAY Manage Mode
Before deploying wireless devices in the field, consideration must be taken on how those
devices will be maintained and monitored. Sending technicians onsite to check status, or
modify a device’s configuration can be both expensive and time consuming.
COMWAY Manager is a server-based software toolset that eliminates these problems and
provides the following features:
• Ability to view all devices securely from anywhere
• Batch configuration changes to one device or a thousand devices
Virtual COM Mode
In addition to providing socket access, this enables you to preserve your existing
COM/TTY-based software without needing to invest in additional software.
The WG8010 IP Modem comes bundled with COMWAY drivers for Windows systems;
the bundled drivers are able to establish a transparent connection between a host and a
serial device by mapping the serial port on the WG8010 IP Modem to a local COM port
on the host computer.
The WG8010 COM driver intercepts data sent to the host's COM port, packs it into a
TCP/IP packet, and then redirects it to the Internet. At the other end of the connection,
the Host accepts the IP frame from the cellular network unpacks the TCP/IP packet, and
then transparently sends the data through the serial port to the attached serial device.

WG8010 Cellular IP Modem User Guide
Defined form data package mode
Under this mode, WG8010 sends three type data package to Data Center,
registration package, data package, heart beat package.
1、Registration package：
This package are only sent after first time login into Data center
Format：
ID PHONE_NUMBER 0 IP_ADD ETX
4byte 11byte 1byte 4byte 1byte
Description：
ID：ID, 8 bit HEX code
PHONE_NUMBER：Mobile phone number, 11 bit ASCII code
IP_ADD：Dynamic IP address, HEX code
ETX：End of Registration package, 0x00
Example:12 34 56 78 31 33 39 31 31 36 39 34 34 31 35 00 c0 a8 01 42 00
Explain：
12 345678 ID: 0x12345678
31 33 39 31 31 36 39 34 34 31 35 Mobile Phone：[phone]
c0a80142 IP Address：192.168.1.66
2、Data package：
Data to and from Data Center will be translated by following rules.
◆To Data Center, all “0xfd” change to “0xfd 0xed” “0xfe change to “0xfd 0xee”
◆From Data Center, all above change back
◆The application on Data center should process data reversely
3、Heart beat package：
WG8010 sends 1 byte length heart beat package “0xfe” periodically to keep
connection alive.
Page 9 of 18

WG8010 Cellular IP Modem User Guide
3.4 Transmission Protocol
Data coming from a remote Device is packetized by the WG8010 and sends it via TCP or
UDP to a remote host. The main difference between the TCP and UDP Socket protocols is
that TCP guarantees delivery of data by requiring the recipient to send an acknowledgement
to the sender. UDP does not require this type of verification, making it possible to offer faster
delivery.
TCP
In TCP mode, the WG8010 IP Modem can actively establish a TCP connection to a
pre-defined host computer when serial data arrives.
As illustrated in the figure below, data transmission proceeds as follows:
(1) The WG8010 IP Modem, requests a connection to the host.
(2) Once the connection is established, data can be transmitted in both directions
between the host and the WG8010.
UDP
Compared to TCP communication, UDP is faster and more efficient. In UDP mode, you
can unicast to one or multicast to multiple serial devices. These traits make UDP mode
especially well suited for message display Applications.
Page 10 of 18

WG8010 Cellular IP Modem User Guide
4. Configure WG8010 with AT Command
4.1 Determine which Com Port to Use
Step 1．On older computers, there is usually a built in Com port. This is normally Com1.
Step 2．If you are using a USB-to-serial converter, you will need to determine which Com
port it is installed on.
Note: If the USB-to-serial converter has not been installed, install the necessary
drivers per the instruction supplied by your USB-to-Serial device. Then
leave the device unplugged.
Step 3．Open up the System Properties window. This is done through the Control Panel
→System or right-click on My Computer and select Properties. Select the
Hardware Tab.
Step 4．Select the Device Manager button. Expand the Ports section by selecting the + sign
beside
Step 5．Plug in the USB-to-Serial converter. The window should change to show the
USB-to-Serial converter installed.
Step 6．Most devices will show the Com port next to the device name. Record this number.
Note: Make sure there is no “!” or “X” next to the USB device. If you see an “!” or
an “X,” the device is not properly installed and will not work.
4.2 Start HyperTerminal
Step 1．Connect the WG8010 IP Modem to the PC COM port and run HyperTerminal
software. From the Taskbar, click [Start], followed by “All Programs” →Accessories
→Communications →“HyperTerminal”.
Step 2．You will be prompted to enter a description for the new connection. Enter a name for
the connection (e.g. “WG8010 IP Modem”) and click [OK] to continue.
Step 3．In the “Connect to” dialog box, select the PC COM port number, which is connected
to the modem, and click [OK] to continue.
Page 11 of 18

WG8010 Cellular IP Modem User Guide
Step 4．In the next prompted dialog box; enter the port settings which is configured in the
modem click [OK] to continue.
Step 5．The “Connected” text in HyperTerminal status bar indicates that the PC is ready to
communicate with the modem. Perform a simple check on the connection between
HyperTerminal and the modem:
Enter AT<Enter> command.
An OK response (displayed on HyperTerminal) indicates that the connection is
Page 12 of 18

WG8010 Cellular IP Modem User Guide
successfully established.
4.3 Cellular Network Connection Configuration
Step 1．Configure serial port:
AT^BAUD=9600
Step 2．Give the WG8010 a unique name:
AT^ID=”WG8010_Test”
Step 3. Connect to your provider’s network
AT+CGDCONT=1,”IP”,”cmnet” // replace “cmnet” with your APN
ATDT*9
Step 4．Configure the WG8010 to talk with a specific server:
AT^SERVER=”test.COMWAY.com”:5656
Step 5．Setup transmission mode
AT^PKMD=0 //transparent mode
Step 6．Store the current configuration to memory:
AT^SAVE
5. Configure WG8010 with Configuration tools
WG8010 Configuration tool is a PC-based software tool for managing and configuring
WG8010 IP modem. With a full graphics mode and Windows-based environment; even
first time users will find it easy to learn how to use this new tool. WG8010 Configuration
tool can be used to configure the general parameters, without the need to look up AT
commands.
5.1 Serial Port Configuration
The serial parameters for the each serial port on the WG8010 IP Modem should match
the parameters used by the connected serial device. You may need to refer to your serial
device's user's manual to determine the appropriate serial communication parameters.
Page 13 of 18

WG8010 Cellular IP Modem User Guide
Page 14 of 18
Baud rate (default=115200 bps)
This field configures the port's baud rate. Select one of the standard baud rates from the
dropdown box.
Data bits (default=8)
This field configures the data bits parameter.
Stop bits (default=1)
This field configures the stop bits parameter.
Parity (default=none)
This field configures the parity parameter.
Flow control (default=none)
This field configures the flow control type.

WG8010 Cellular IP Modem User Guide
5.2 Cellular Network Connection
APN:
In order for your IP modem to connect to your provider’s network, you must tell the
modem the Access Point Name (APN) to which it will connect. The APN is a server
name that your account is setup on with your provider. You can setup it with AT
Command, for example.
AT+CGDCONT=1,”IP”,”cmnet”
ATDT*9
Main Server IP Address or Domain Name:
To connect to a host PC, the host PC must be configured with public fixed IP address or
Domain Name, if it is using a dynamic public IP name.
Port Number:
Backup Server: 1 through 4 (default=1)
Protocol: TCP, UDP
Page 15 of 18

WG8010 Cellular IP Modem User Guide
Page 16 of 18
Phone number: Use this field to configure the number used to dial out.
Operation Mode: Transparent, Transparent with Device ID, COMWAY Manage, Defined
form data package
5.3 Flexible Connection
The WG8010 IP Modem can be configured for one of four network connections:
always-on, wake-up on ring, dial-on demand, or on schedule.
Always on
The always-on network connection automatically establishes a wireless data connection
and allows for around the clock surveillance, monitoring or real-time data acquisition of
any remote device. If the data link is dropped in the event of poor reception or a
complete loss of service, it will automatically re-establish the data link
Keep-alive message:
Keep-alive period (default=15 minutes):
A periodic “keep-alive” or heart-beat message is sent from the device to the server to
update its current status. This small amount of traffic (typically about 160-170 bytes) will
refresh the carrier’s inactivity timer, thus helping maintain the persistent wireless
connection. The keep-alive period is by default 15 minutes, but can be changed
according to need.
Wake-up on ring

WG8010 Cellular IP Modem User Guide
The configuration allows the modem to “wake up” and initiate a connection when it
detects an incoming ring. For security reasons, you can setup the modem to wake up
based on the caller ID. This configuration is ideal for reducing the costs associated with
the WG8010 being online and available 24/7
Auth type (default=none): To allow Caller ID Authentication
Caller ID (1 through 4): Phone number should be specified.
If you don't use Caller ID authentication, the WG8010 IP Modem will allow all incoming
short messages as serial data to be forwarded to its serial port. This includes system
broadcasts and advertisements.
Dial-on demand
When configured for dial-on demand, the cellular modem only accesses the Internet
when data is present.
On schedule
5.4 Others
Hardware Reset Threshold
Hardware reset thresholds will proactively reset the IP modem if the device fails to
connect for any reason. This adds an extra level of robustness to the connection
attempts.
By default, the mobile interface reset is set to 3 failed attempts.
Save Configuration
To save your submitted configuration changes to the WG8010 IP Modem's flash memory.
Page 17 of 18

WG8010 Cellular IP Modem User Guide
Page 18 of 18
The configuration changes will be effective when the WG8010 is restarted. If you do not
save your changes before restarting, they will be discarded.
Configuration Import/Export
The WG8010 IP Modem can share or back up its configuration by exporting all settings
to a file. Remember to backup your configuration by exporting it to a file. Your
configuration can be easily restored by importing the file to the WG8010.
