Conair Sure Cut Rotary Knife Cutter SC-5 User manual

Sure Cut Rotary Knife Cutter
Instant Access
Parts and Service
[phone]
[phone]
www.conairnet.com
The Conair Group, Inc.
One Conair Drive
Pittsburgh, PA 15202
Phone: [phone]
Fax: [phone]
SC-5 Servo Model
UGE059/1003
Installation
Operation
Maintenance
Troubleshooting

It is important to record the model and serial number(s) of
your equipment and the date you received it in the User
Guide. Our service department uses this information, along
with the manual number, to provide help for the specific
equipment you installed.
Keep this User Guide and all manuals, engineering prints and
parts lists together for documentation of your equipment.
Date:
Document Number: UGE059/1003
Serial number(s):
Model number(s):
Power Specifications:
Amps
Volts
Phase
Cycle
DISCLAIMER: The Conair Group, Inc., shall not be liable for errors
contained in this User Guide or for incidental, consequential dam-
ages in connection with the furnishing, performance or use of this
information. Conair makes no warranty of any kind with regard to
this information, including, but not limited to the implied warranties
of merchantability and fitness for a particular purpose.
Record your equipment’s
model and serial num-
ber(s) and the date you
received it in the spaces
provided.
Copyright 2003 All rights reserved
THE CONAIR GROUP, INC.

UGE059/1003 SC-5 SURE CUT Servo Knife Cutters
TABLE OF
CONTENTS
INTRODUCTION . . . . . . . . . . . . . . . . . . .1-1
Purpose of the User Guide . . . . . . . . . . . . . . . . . . . . . . . . .1-2
How the Guide is Organized . . . . . . . . . . . . . . . . . . . . . . .1-2
Your Responsibilities as a User . . . . . . . . . . . . . . . . . . . . .1-2
ATTENTION: Read this so no one gets hurt . . . . . . . . . . .1-3
How to Use the Lockout Device . . . . . . . . . . . . . . . . . . . .1-5
DESCRIPTION . . . . . . . . . . . . . . . . . . . .2-1
What is the SC-5 Sure Cut? . . . . . . . . . . . . . . . . . . . . . . . .2-2
Typical Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4
How the SC-5 Sure Cut Works . . . . . . . . . . . . . . . . . . . . . .2-5
SC-5 Sure Cut Features . . . . . . . . . . . . . . . . . . . . . . . . . . .2-7
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-7
Optional Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-8
INSTALLATION . . . . . . . . . . . . . . . . . . . .3-1
Unpacking the Boxes . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
Preparing for Installation . . . . . . . . . . . . . . . . . . . . . . . . . .3-3
Positioning the SC-5 Sure Cut . . . . . . . . . . . . . . . . . . . . . .3-4
Connecting the Main Power Source . . . . . . . . . . . . . . . . . .3-6
Installing the Encoder . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-7
Installing the Cutter Blades . . . . . . . . . . . . . . . . . . . . . . . .3-8
Mounting the Cutter Bushings . . . . . . . . . . . . . . . . . . . .3-10
Checking Repeatability . . . . . . . . . . . . . . . . . . . . . . . . . .3-12
Preparing for Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-13
Testing the Installation . . . . . . . . . . . . . . . . . . . . . . . . . . .3-13
OPERATION . . . . . . . . . . . . . . . . . . . . . .4-1
The Cutter Control Feature . . . . . . . . . . . . . . . . . . . . . . . .4-2
Before Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3
Powering Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3
Main Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5
Preset to Run . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-10
Time Preset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-11
Cut Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-18
Maintenance Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-19
Encoder Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-20
Unit of Measure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-22
Scale Distance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-23
Homing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-25
Offset Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-26
Preventative Maintenance . . . . . . . . . . . . . . . . . . . . . . . . .4-27
Power On Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-28
Checking Cut Quality . . . . . . . . . . . . . . . . . . . . . . . . . . .4-29
Starting the SC-5 Sure Cut . . . . . . . . . . . . . . . . . . . . . . . .4-29
Making Adjustments During Operation . . . . . . . . . . . . . .4-30
Stopping the SC-5 Sure Cut . . . . . . . . . . . . . . . . . . . . . . .4-31
i

SC-5 SURE CUT Servo Knife Cutter UGE059/1003
MAINTENANCE . . . . . . . . . . . . . . . . . . . .5-1
Maintenance Features . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
Warnings and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
Maintenance Overview . . . . . . . . . . . . . . . . . . . . . . . . . . .5-4
Preventative Maintenance Schedule . . . . . . . . . . . . . . . . . .5-4
Checking the Blades . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-6
Inspecting Cutter Bushing Screws . . . . . . . . . . . . . . . . . . .5-7
Checking the Closure Latch . . . . . . . . . . . . . . . . . . . . . . . .5-7
Cleaning the Blade Tray . . . . . . . . . . . . . . . . . . . . . . . . . .5-8
Lubricating the Slide Rail System . . . . . . . . . . . . . . . . . . .5-8
Adjusting the Proximity Switches . . . . . . . . . . . . . . . . . . .5-9
Checking Electrical Connections . . . . . . . . . . . . . . . . . . .5-10
B-Loc Installation and Removal . . . . . . . . . . . . . . . . . . . .5-12
TROUBLESHOOTING . . . . . . . . . . . . . . . .6-1
Before Beginning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-2
A Few Words of Caution . . . . . . . . . . . . . . . . . . . . . . . . . .6-2
Identify the Cause of a Problem . . . . . . . . . . . . . . . . . . . . .6-3
Electrical Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-4
Product Quality Problems . . . . . . . . . . . . . . . . . . . . . . . . .6-8
Replacing Safety and Proximity Switches . . . . . . . . . . . .6-12
Checking the Servo Amplifier . . . . . . . . . . . . . . . . . . . . .6-12
Adjusting the Proximity Switches . . . . . . . . . . . . . . . . . .6-14
Checking the Encoder . . . . . . . . . . . . . . . . . . . . . . . . . . .6-15
Checking the Motor/Reducer Assembly . . . . . . . . . . . . . .6-17
Checking Repeatability . . . . . . . . . . . . . . . . . . . . . . . . . .6-18
APPENDIX . . . . . . . . . . . . . . . . . . . . . . . . .
Customer Service Information . . . . . . . . . . . . . . . . . . . . . .A-1
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-2
Cutter Blade Selection and Use . . . . . . . . . . . . . . . . . . . . .B-1
Cutting Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-3
Calculating Blade Interruption . . . . . . . . . . . . . . . . . . . . . .B-4
Conair Cutter Blades . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-6
All About Cutter Bushings . . . . . . . . . . . . . . . . . . . . . . . .C-1
Blade and Bushing Lubrication . . . . . . . . . . . . . . . . . . . . .D-1
Operator Display Overview . . . . . . . . . . . . . . . . . . . . . . . .E-1
PARTS/DIAGRAMS
This section has been provided for you to
store spare parts lists and diagrams.
ii

1-1
UGE059/1003 SC-5 SURE CUT Servo Knife Cutter
●●Purpose of the User Guide . . . .1-2
●●How the User Guide
is organized . . . . . . . . . . . . . . .1-2
●●Your Responsibilities
as a User . . . . . . . . . . . . . . . .1-2
●●ATTENTION: Read this so
no one gets hurt . . . . . . . . . . .1-3
●●How to Use the
Lockout Device . . . . . . . . . . . .1-5
INTRODUCTION

SC-5 SURE CUT Servo Knife Cutter UGE059/1003
1-2 INTRODUCTION
This User Guide describes the Conair SC-5 Sure Cut Servo
Knife Cutter and explains step-by-step how to install, operate,
maintain and repair this equipment.
Before installing this product, please take a few moments to
read the User Guide and review the diagrams and safety infor-
mation in the instruction packet.You also should review man-
uals covering associated equipment in your system. This
review won’t take long, and it could save you valuable instal-
lation and operating time later.
Symbols have been used to help organize the User Guide and
call your attention to important information regarding safe
installation and operation.
Symbols within triangles warn of conditions that could
be hazardous to users or could damage equipment.
Read and take precautions before proceeding.
Numbers within shaded squares indicate tasks or steps
to be performed by the user.
A diamond indicates the equipment’s response to an
action performed by the user.
An open box marks items in a checklist.
A shaded circle marks items in a list.
You must be familiar with all safety procedures concerning
installation, operation and maintenance of this equipment.
Responsible safety procedures include:
●Thorough review of this User Guide, paying particular
attention to hazard warnings, appendices and related dia-
grams.
●Thorough review of the equipment itself, with careful
attention to voltage sources, intended use and warning
labels.
●Thorough review of instruction manuals for associated
equipment.
●Step-by-step adherence to instructions outlined in this
User Guide.
PURPOSE OF
THE USER
GUIDE
HOW THE USER
GUIDE IS
ORGANIZED
1
◆
❒
●
YOUR
RESPONSIBILITY
ASAUSER

WARNING: Improper installation, oper-
ation, or servicing may result in
equipment damage or personal injury.
This equipment should only be installed, adjust-
ed, and serviced by qualified technical person-
nel who are familiar with the construction, oper-
ation, and potential hazards of this type of
machine.
All wiring, disconnects, and fuses should be
installed by qualified electrical technicians in
accordance with electrical codes in your region.
Always maintain a safe ground. Do not operate
the equipment at power levels other than what
is specified on the machine serial plate.
INTRODUCTION 1-3
We design equipment with the user’s safety in mind. You can
avoid the potential hazards identified on this machine by fol-
lowing the procedures outlined below and elsewhere in the
User Guide.
ATTENTION:
READ THIS SO NO
ONE GETS HURT
UGE059/1003 SC-5 SURE CUT Servo Knife Cutter
DANGER: Sharp blades!
Most injuries caused by knife blades occur
when the cutter has been turned off. Handle
blades with care at all times.
●Always lock out the cutter before opening the
cutting chamber.
●Always wear cut-resistant gloves when the
cutting chamber is open and when handling
blades.
SC-5 cutters are equipped with several safety
devices to ensure safe operation. Never remove
or disable these devices to sustain production.
Operating without these devices can cause
severe injury.
●When the knife guard is opened, the knife
guard switch stops the cutter.
●Two proximity-type safety switches prevent
operation unless the cutter bushings are in
place.
●The STOP button activates a circuit that
stops the knife. (Do not attempt to change a
blade or work in the cutting chamber with out
locking out the power.

In order to protect the operator from possible harm from the
rotating blade wheel, several safety features are built into this
cutter. They include:
Two electric switches make a contact between the side
and the clear polycarbonate sliding blade observation
windows such that the windows MUST BE CLOSED
in order to enable the blade wheel to spin.
●●This prevents someone from opening the windows and
having the blade wheel spin which can cause serious
injury. Tampering with this safety feature will VOID
ANY responsibility for safety.
A proximity switch is positioned on both the upstream
and downstream side of the bushing holder. If there
are no bushings in either side, the blade will not spin.
●●This prevents someone from inserting their hands or
fingers in the cutting mechanism while the blade wheel
is spinning. Tampering with this feature will also
VOID ANY responsibility for safety.
A safety switch is positioned on the bushing holder flip
up guard to prevent operation unless fully closed.
●●This prevents someone from inserting their hands or
fingers in the cutting mechanism while the blade wheel
is spinning. Tampering with this feature will also
VOID ANY responsibility for safety.
A lockable main power disconnect is provided to pre-
vent the possibility of hazardous electrical shock while
servicing the main electrical enclosure. (See How to
use the Lockout Device, in Section 1)
SC-5 SURE CUT Servo Knife Cutter UGE059/1003
1-4 INTRODUCTION
WARNING:Voltage Hazard
This equipment is powered by three-phase
alternating current, as specified on the machine
serial tag and data plate.
A properly-sized conductive ground wire from
the incoming power supply must be connected
to the chassis ground terminal inside the electri-
cal enclosure. Improper grounding can result in
severe personal injury and erratic machine
operation.
Always disconnect and lockout power before
opening the electrical enclosure or performing
non-routine procedures such as maintenance
and service.
ATTENTION:
READ THIS SO NO
ONE GETS HURT
CAUTION: It is always recommend
that the main power cord be dis-
connected and placed in clear view
of the operator or service person-
nel while changing blades or ser-
vicing the cutter in any capacity.

HOW TO USE
THE LOCKOUT
DEVICE
UGE059/1003 SC-5 SURE CUT Servo Knife Cutter INTRODUCTION 1-5
WARNING: Electrical hazard
Before performing maintenance or repairs on
this product, disconnect and lock out electrical
power sources to prevent injury from unexpect-
ed energization or start-up. A lockable device
has been provided to isolate this product from
potentially hazardous electricity.
Lockout is the preferred method of isolating machines or
equipment from energy sources.Your Conair product is
equipped with the lockout device pictured below. To use the
lockout device:
Stop or turn off the equipment. Do not stop the
cutter by turning off the disconnect. Always touch the off
soft key on the interface first.
Isolate the equipment from
electrical power.
Turn the rotary disconnect switch to
OFF or O position.
Secure the device with an
assigned lock or tag.
The equipment is now locked
out.
CAUTION: Moving parts
Before removing lockout devices and returning
switches to the ON position, make sure that all
personnel are clear of the machine, tools have
been removed and all safety guards are rein-
stalled.
3
4
O
1
2

2-1
●●What is the SC-5 Sure Cut
Knife Cutter . . .............2-2
●●Typical Applications . . . .......2-4
●●HowtheSC-5Works...........2-5
●●SC-5 Features . ...............2-7
●●Specifications . ...............2-7
●●Optional Equipment . . . . .......2-8
DESCRIPTION
UGE059/1003 SC-5 SURE CUT Servo Knife Cutter

The Conair SC-5 Sure Cut Series rotary knife cutter has been
designed to be “The most versatile cutter of the industry”.
With both capacity to cut small parts at high speeds or large
tubes or profiles at low speeds this cutter can eliminate the
need for moving cutters in and out of a line per application.
Today with custom profile houses potentially running 2-3 dif-
ferent profiles on one line in a given day, time is at a premi-
um. Having to move different cutters in and out of line is no
longer acceptable when time is money.
Mechanical Features
This series of servo rotary knife cutters use a 24 inch diameter
flywheel optimizing surface speed and power. This is in fact
the largest diameter wheel which could be used while still
allowing it’s mounting under the bushing holder.
Flywheel
With a 24 inch diameter flywheel which is 1inch thick, many
benefits become available.
Planetary Gear Reducer
A 10:1 in-line servo motor rated planetary gear reducer with 7
arc-minutes maximum backlash is mounted directly to a 3000
rpm brushless servomotor. A top flywheel speed of 300 rpm is
realized. Even though the flywheel appears to be moving
slowly, the actual surface speed at the blade at only 300
RPM’s is over 0.438 inch per millisecond. That’s twice the
surface speed of a typical clutch brake cutter.
Instead of mounting the cutter head directly to the servo motor
shaft, which is generally not designed for high radial load or
axial load due to small shaft diameters, the 24 inch flywheel is
mounted to the planetary gear reducer shaft which is designed
for just this type of application. At the gear ratio and output
speeds which this cutter was designed, radial load on the out-
put shaft of the reducer is in excess of 1000 lbs where the
servo motor shaft may only be 100 lbs or less. Potential wear
on the servo motor shaft bearings is minimized.
The high speed\low torque power of the servo motor is effi-
ciently converted into a low RPM\high surface speed\high
torque power more suitable for cutting applications.
WHAT IS THE
SC-5 SURE
CUT?
SC-5 SURE CUT Servo Knife Cutter UGE059/1003
2-2 DESCRIPTION
Continued

WHAT IS THE
SC-5 SURE
CUT?
CONTINUED
DESCRIPTION 2-3
UGE059/1003 SC-5 SURE CUT Servo Knife Cutter
The larger diameter flywheel used on the servo cutter offers
the potential of higher surface speeds at dramatically lower
blade rpm’s with high cutting torque. The typical grey area
between on-demand cutting and flywheel cutting (150 cpm
on-demand up to 300 cpm flywheel), typically seen in DC dri-
ven clutch\brake cutter is eliminated.
It should not be necessary to cut in on demand mode in excess
of 150 cuts per minute which will greatly save on premature
wear to the system. Not only does this cutter offer optimum
blade surface speed throughout an extremely wide cuts per
minute range, but extreme accuracy throughout.
The added benefit of the 24 inch diameter by one inch thick
aluminum wheel is the stored inertia which adds power for
cutting larger profiles and tubes. The size of the wheel actual-
ly adds horsepower to the system. Due to the use of 10:1 gear
reduction, the servomotor is made extremely efficient and eas-
ily able to handle this weight with out detrimental effects.

Cutting from Below the Bushing Holder
The SC-5 Sure Cut Servo Cutter housing maximizes versatili-
ty and operational ease. Due to the size of the flywheel it was
determined best to mount it directly below the bushing holder
keeping the center of gravity low and offering the following
benefits:
● Accessibility of the flywheel for ease of blade changes.
●Built in blade lubrication tray can be integral to the design
of the cutting chamber.
●An optional blade heating system can be added to give
optimum versatility to this cutter.
●With the bushing holder above the flywheel tremendous
cutting capacity is available without extreme blade length.
●Ease of discharge conveyor interface for part support and
automatic ejection systems is made simple with this layout.
●The optional slide system can enable the use of rigids and
flexibles.
To get the full benefit from the servo cutter Conair has provid-
ed several cutting modes, see Cutter Control, Section 4. The
Conair SC-5 Sure Cut servo rotary knife cutter is a truly inno-
vative cutter. Loaded with features and backed up by the most
extensive service support system in the industry.
SC-5 SURE CUT Servo Knife Cutter UGE059/1003
2-4 DESCRIPTION
TYPICAL
APPLICATIONS

Extruded material that has been sized and cooled enters the
cutter from the upstream side (See How the SC-5 Sure Cut
Works, Section 2, step 1). Typically, a puller is placed just
before the cutter; the puller pulls the extrudate through the
sizing and/or cooling tanks and feeds it into the cutter.
The positional servo motor, is direct coupled to the cutter
head, or an in-line planetary gear reducer that drives the cut-
ter head. The planetary gear reducer arrangement increases
cutting torque, improves servo motor efficiency, and offers
improved bearing load ratings.
The cutting knife, attached to the cutter head, is driven by
the servo motor (See How the SC-5 Sure Cut Works, Section
2, step 2). Two cutter bushings guide and support both the
extrudate and the cutting knife. The cutter head is mounted
directly to the in-line planetary gear reducer shaft using a B-
Loc coupling device, and may have as many as four optional
blade positions. See Installation and Removal of B-Loc,
Section 5.
Two types of cutting modes are available. On-demand cut-
ting modes (Timer, Encoder, Auto and Product) provide a
single rotation cut cycle. However, in continuous cutting
modes (Flywheel and Optional Follower) the cutting mecha-
nism rotates continuously.
The knife guard includes a stainless steel lower tray, which
can be used for blade lubrication. The upper knife guard
includes a clear polycarbonate window. This allows you to
watch the cutting blade during operation.
Cut pieces are collected or carried on to further processing
by an optional conveyor (See How the SC-5 Sure Cut Works,
Section 2, step 3).
Continued on next page.
HOW THE SC-5
SURE CUT
WORKS
UGE059/1003 SC-5 SURE CUT Servo Knife Cutter DESCRIPTION 2-5

SC-5 SURE CUT Servo Knife Cutter UGE059/1003
2-6 DESCRIPTION
The cutter head holds the
blade(s) as they rotate
and pass between the
bushings, cutting the
extrudate.
Extruded material enters the
cutter from the upstream side.
1
Cut pieces are collected or
carried away on a conveyor.
2
3
HOW THE SC-5
SURE CUT
WORKS
CONTINUED

The SC-5 Sure Cut Servo Cutter features: SC-5
FEATURES
DESCRIPTION 2-7
UGE059/1003 SC-5 SURE CUT Servo Knife Cutter
Swivel Casters
Parts discharge chute or
optional discharge conveyor
Optional slide base
assembly with position
locking mechanism
Wide Range of Cutter
Bushing Capacities
24-inch diameter fly-
wheel with multiple
blade mounting system
Polycarbonate blade
observation window
Optional blade
lubrication system
Heavy-duty leveling
screws and pads
CONAIR SERVO CUTTER
Version 1.0
The standard control:
●Large easy-to-read display.
●Soft keys allows the opera-
tor to select different func-
tions.
●Numeric keys permits data
entry for the operator.
●Fixed function keys contain
universal symbols and text.
MODELS SC-5
Performance characteristics
Extruder capacity in. {mm}
Tube diameters 2.25 - 5.25 {57 - 133}
Profile dimensions 2x4 - 2x10, 4x7 {51x102 - 51x254, 102x178}
Blade drive motor Hp {kW} 4.6 {3.4}
Feed direction right>left
Dimensions in. {mm}
A - Height 47 {1194}
B - Height to centerline 40±2 {1016±50.8}
C - Length 44 {1118}
D - Width 52 {1321}
Voltage/phase/frequency 230 V/3/60 Hz 0r 460 V/3/60 Hz
Cutter control Red Lion {CL01/FM4}
A
B
C D
● 24-inch flywheel
● Up to 150 cuts/minute on
demand with one blade
● Up to 300 cuts/minute with one
blade on Flywheel mode
● Blade speeds adjustable to
300 RPM
● Surface speeds to 0.438 inches
per millisecond
● Heavy-duty positional AC
brushless servo drive
● 10:1 planetary gear head
reducer
● 3,000 pulse bi-directional
encoder
SPECIFICATIONS

OPTIONAL
EQUIPMENT
SC-5 SURE CUT Servo Knife Cutter UGE059/1003
2-8 DESCRIPTION
Slide Base
This option is highly recommended for cutting flexible extru-
dates. While the cutter base is fixed and aligned with the
puller, the cutter itself is mounted on a set of linear slides that
allow as much as 12 inches of movement. The cutter can be
moved away from the puller for startup, then moved close to
the puller to enhance delivery to the cutter bushings.
Blade Wipe
The blade wipe system keeps the cutting blade clean by
removing lubricant and particles from the blade. A felt pad
sandwiched between two pieces of stainless steel and mounted
next to the bushing wipes the knife before each cut.
Custom Bushing Holder Sizes Available:
Heavy Duty Blade Positions
●●One blade position standard
●● Optional 2 or 4 blade positions available
●● Optional simitare blade available (see parts list for optional
blades.)
Round Profile
2.25 inch (standard) 2x4 inch
3.25 inch 2x6 inch
4.25 inch 2x8 inch
5.25 inch 2x10 inch
3x6 inch
4x7 inch

UGE059/1003 SC-5 SURE CUT Servo Knife Cutter DESCRIPTION 2-9
TIP: Conair strongly recom-
mends the use of an isolation
transformer. Ensuring clean
and proper power can help
avoid the need for costly ser-
vice calls.
Discharge Conveyor
A discharge conveyor facilitates the removal of cut parts.
Discharge conveyors are available in the following sizes:
●6 inches wide by 6 feet long
●6 inches wide by 10 feet long
●6 inches wide by 16 feet long
Isolation Transformer
The isolation transformer protects sensitive electronics from
incoming power, which helps prevent errors caused by electri-
cal noise. It also protects equipment from electrical noise gen-
erated by the servo motor and associated amplifier.
NOTE: An isolation transformer will not compensate for a
ground that does not meet code requirements.
Left to Right Machine Operation
This option changes the machine direction from the standard
right to left extrusion flow.
Special Paint Type or Color
This option covers any change from the standard Conair
paint.
Your Conair sales representative can analyze your needs and
recommend the options that are right for your system.
OPTIONAL
EQUIPMENT
