Quick Guide
Follow the guide here
or watch how to get
started directly on our
YouTube channel
Thank you for choosing
our icon solution for
your design.
To secure a good start and a great
experience please follow this quick
guide for the Plug & Play solution.
Please make sure to connect all parts
correctly before switching on power!
icon and accessories
1. Icon with or w/o 8 Pin
Molex Minit connector
2. conXion Box
3. conXion Box+ 4. conXion DIN
5. Programming cable
USB-RS485
6. conXion cable for
interconnection
In various lenghts
(0.25, 1, 5, 10, 20 m)
7. Handset with simple
dry contacts
8. Power supply cable
With various AC plugs
(EU, US, UK, AU)
Til accessories
Til midtersektion
4
1
14
AB
3
3
2
2

Til accessories
Til midtersektion
4
1
14
AB
3
3
2
2
2. 
connection on the conXion Box/Box+/DIN
For the Box+ version it is also possible to control the
actuator by using the controller function directly on
the conXion Box+
3. Plug USB-RS485 programming cable in to the
RJ45 connection marked A on the drawing,
on the conXion Box/Box+/DIN and the USB to
your computer. The RJ45 connection marked
B on the drawing is for interconnecting to
next conXion.
Please note all conXion Boxes and DIN are delivered
with jumpers. For jumper settings please see conXion
- Installation Guide, which can be found by using
this link: conXion – Installation guide or by using the
QR code on the last page of our Quick Guide.
4. 
connection on the conXion Box/Box+/DIN and
plug it with the correct AC plug (EU, US, UK,
AU) to the power socket, as soon as the small
LED on the conXion is illuminated you are
ready to start.
1. 
connection on the conXion Box/Box+/DIN
For the DIN version it is also possible to connect
wires directly to screw terminal or to PLC. For
correct wire connections according to the chosen
icon - User Manual or
by using the QR code on the last page of our Quick
Guide. You will need a slotted screwdriver (0,6 x 3,5).
Please make sure to connect wires before switching
on power!
icon - User Manual
conXion - Installation Guide
Download software CAS
(Concens Actuator Studio)
For additional assistance or further information,
please contact your local Concens actuator
partner. Find your local partner
Additional and related information
Icon - Quick Guide Web ver. October 2021
