Condair GS II Series User manual

OPERATION MANUAL
Gas-fired steam humidifier
Condair GS
Series II
2596643-B_EN_2010_Condair GS_OM
Humidication and Evaporative Cooling

Thank you for choosing Condair
Installation date (MM/DD/YYYY):
Commissioning date (MM/DD/YYYY):
Site:
Model:
Serial number:
Proprietary Notice
This document and the information disclosed herein are proprietary data of Condair Group AG. Neither this docu-
ment, nor the information contained herein shall be reproduced, used, or disclosed to others without the written
authorisation of Condair Group AG, except to the extent required for installation or maintenance of recipient's
equipment.
Liability Notice
Condair Group AG does not accept any liability due to incorrect installation or operation of the equipment or due
to the use of parts/components/equipment that are not authorised by Condair Group AG.
Copyright Notice
© Condair Group AG, All rights reserved.
Technical modications reserved

32596643-B_EN_2010_Condair GS_OM Contents
Contents
1 Introduction 5
1.1 To the very Beginning 5
1.2 Notes on the Operation Manual 5
2 For your safety 7
3 Product Overview 11
3.1 Model overview 11
3.2 Functional Description 13
3.3 System overviews 15
3.3.1 System overview compact units GS 23/45 15
3.3.2 System overview full-size units 16
4 Operator Interface 17
4.1 Display and operating elements 17
4.2 Control Software 18
4.2.1 Home Screen 18
4.2.2 Operating Status 19
4.2.3 Maintenance and Fault Status 19
4.2.4 Accessing support informations 20
4.2.5 Accessing system informations 20
4.2.6 Main Menu 23
4.2.7 Conguration Menu 24
4.2.7.1 Features Menu 25
4.2.7.2 Control Settings Menu 28
4.2.7.3 General Menu 32
4.2.7.4 Communications Menu 33
4.2.7.5 Service Menu 36
4.2.7.6 Setpoint 38
4.2.7.7 Administrator Menu 38
4.3 Software Conguration 40
4.3.1 Conguring the Control Software 40
4.3.2 Conguring for Multi-Unit Operation 41
5 Operation 42
5.1 General 42
5.2 Initial Commissioning 42
5.3 Operating Procedures 43
5.3.1 Filling the water tank of the humidier 43
5.3.2 Ignition Safety Shutoff Test 44
5.3.3 Starting the Humidier 45
5.3.4 Remote Monitoring 46
5.3.5 Inspections During Operation 46
5.3.6 Manually Initiate Tank Draining 47
5.3.7 Full Tank Blowdown 48
5.3.8 Shutting Down 48

4Contents 2596643-B_EN_2010_Condair GS_OM
6 Maintenance 49
6.1 General 49
6.2 Mandatory Maintenance Schedule 50
6.3 List of Consumables 51
6.4 Management of Scale and Chloride Levels 52
6.4.1 Adjusting Blowdown Settings 53
6.5 Maintenance Procedures 54
6.5.1 Removal and Installation of Access Panels 54
6.5.2 Cleaning the Tank 55
6.5.3 Cleaning the Secondary Heat-exchanger 56
6.5.4 Cleaning the Level Control Unit 58
6.5.5 Cleaning Hoses, Dual Fill Valves and Drain Pump 59
6.5.6 Cleaning the Burner Assembly 61
6.5.7 Replacing Backup Battery and the internal fuse 63
6.5.8 Resetting Service Reminder 64
6.5.9 Installing Software Updates 64
7 Fault Isolation 65
7.1 General 65
7.2 Fault Indication 65
7.3 General Troubleshooting 66
7.4 Warning and Fault List 67
7.5 Resetting Fault Status 73
8 Decommissioning of the Condair GS 74
8.1 General 74
8.2 Removal from Service for Disposal or Long-term Storage 74
8.3 Disposal/Recycling 74
9 Productspecications 75
9.1 Performance Data 75
9.2 Gas consumption at maximum power 75
9.3 Operating Data 76

52596643-B_EN_2010_Condair GS_OM Introduction
1 Introduction
1.1 To the very Beginning
We thank you for having purchased the CondairGSsteamhumidier.
The Condair GS steam humidier incorporates the latest technical ad van ces and meets all recognized
safety standards. Nevertheless, improper use of the Condair GS steam humidier may result in danger
to the user or third parties and/or damage to property.
To ensure a safe, proper, and economical operation of the Condair GS steam humidier, please observe
and comply with all information and safety instructions contained in the present documentation as well as
in the separate documentations of the components installed in the humidication system. Comply with
all national and local regulations dealing with gas, combustion air, ue gas, water, steam and electrical
installations.
If you have questions after reading this documentation, please contact your Condair representative.
They will be glad to assist you.
1.2 Notes on the Operation Manual
Limitation
ThesubjectofthisinstallationmanualistheCondairGSsteamhumidierinitsdifferentversions.
The various options and accessories are only described insofar as is necessary for proper operation of the
equipment. Further information on options and accessories can be obtained that are supplied with them.
This installation manual is restricted to the installation of the Condair GS steam humidier and is meant
for welltrainedpersonnelbeingsufcientlyqualiedfortheirrespectivework.
Other Related Publications
This installation manual is supplemented by various separate items of documentation (installation
manual, spare parts list, etc.), which are included in the delivery as well. Where necessary, appropriate
cross-references are made to these publications in the installation manual.

6Introduction 2596643-B_EN_2010_Condair GS_OM
Symbols used in this manual
CAUTION!
The catchword "CAUTION" used in conjunction with the caution symbol in the circle designates notes
in this installation manual that, if neglected, may cause damage and/or malfunction of the unit or
damage to property.
WARNING!
The catchword "WARNING" used in conjunction with the general caution symbol designates safety
and danger notes in this installation manual that, if neglected, may cause injury to persons. Other
specic warning symbols may also be used in place of the general symbol.
DANGER!
The catchword "DANGER" used in conjunction with the general caution symbol designates safety and
danger notes in this installation manual that, if neglected, may lead to severe injury or even death of
persons. Other specic warning symbols may also be used in place of the general symbol.
Storage of the manual
Please safeguard this operation manual in a safe place, where it can be immediately accessed. If the
equipment is moved to another location, make sure that the manual is passed on to the new user.
If the manual is lost or misplaced, contact your Condair representative for a replacement copy.
Language versions
This operation manual is available in other languages. Please contact your Condair representative for
information.

72596643-B_EN_2010_Condair GS_OM For your safety
2 For your safety
General
Every person, who is in charge of any work on the Condair GS must have read and understood the instal-
lation manual and the operation manual (this document) of the Condair GS before carrying out any work.
Knowing and understanding the contents of the installation manual and the operation manual is a basic
requirement for protecting personnel against any kind of danger, to prevent faulty operation, and to
operate the unit safely and correctly.
All labels, signs and markings applied to the Condair GS must be observed and kept in readable state.
Qualicationofpersonnel
All procedures described in this operation manual may only be carried out by specialists who are
welltrainedandadequatelyqualiedandareauthorisedbythecustomer.
For safety and warranty reasons any action beyond the scope of this manual must be carried out only
by qualied personnel authorized by Condair.
All personnel working with the Condair GS humidier must be familiar with, and comply with the appro-
priate regulations on work safety and the prevention of accidents.
Intended use
The Condair GS steam humidier is intended
exclusivelyforairhumidicationviaasteamdistributor
approvedbyCondairwithinspeciedoperatingconditions (see Condair GS operation manual). Any
other type of application, without the written consent of Condair, is considered as not conforming with
the intended purpose and may lead to the Condair GS becoming dangerous and will void any warranty.
In order to operate the equipment in the intended manner all the information contained in this manual,
in particular the safety instructions, must be observed closely.
Safety Precautions that must be observed
DANGER!
Risk of electric shock!
The Condair GS is mains powered. Live parts may be exposed when the unit is open. Touching
live parts may cause severe injury or even death.
Prevention: Before carrying out any work set the Condair GS out of operation as described in Section
5.3.8 (switch off the unit, disconnect it from the mains and stop the water supply) and secure the unit
against inadvertent power-up.
WARNING!
Wiringerrorscancauseimproperanddangerousoperationofthehumidier!
Prevention: Tag all wires before disconnecting them. Reconnect all wires correctly after servicing,
and check the unit functions properly.
CAUTION!
Electrostatic discharge (ESD)!
Theelectroniccomponentsinsidethecontrolcabinetinthehumidieraresensitivetoelec-
trostatic discharge (ESD).
Prevention: Take appropriate measures to protect the electronic components inside the unit against
damage caused by electrostatic discharge (ESD).

8For your safety 2596643-B_EN_2010_Condair GS_OM
DANGER!
Riskofreorexplosion!
TheCondairGSisagas-redhumidier.Improperoperationandmaintenanceas well as incor-
rect settings and unauthorized alteration can cause carbon monoxide poisoning, explosion,
reorotherhazardsthatcancauseseriousinjury,deathorpropertydamage.
If over-heating occurs or if the gas fails to shut off: Shut off the gas supply at the manual gas
shutoff valve before shutting off the electrical power supply
DO NOT use this appliance if any part has been under water. Call a qualied service technician imme-
diately to inspect and replace any part of the control system or gas control that has been under water.
Any work on the gas system must only be performed by a qualied installer, service agency or your
local gas supplier. Use only factory-authorized and listed kits or accessories when installing or modify-
ing this appliance.
Use only factory-authorized and listed kits or accessories when replacing part or modifying this appliance.
DO NOT store or use gasoline or other ammable vapours and liquids in the vicinity of the humidier.
What to do if you smell gas:
•DO NOT try to light any appliance.
• DO NOT touch any electrical switch.
• DO NOT use any phone in the building.
•Leave the building immediately.
• Call your gas supplier immediately from a location far away from the building with the gas
leak. Follow the gas supplier's instructions. If you cannot reach your gas supplier, call the
redepartment.
WARNING!
Risk of severe burns from contact with hot surfaces, steam or hot water!
The steam tank may contain steam or hot water at up to 100 °C. Contact with the hot surfaces,
steam vapors or hot water can result in severe burns.
Prevention: Always drain the tank, and allow the unit to cool down to a safe temperature before
cleaning the tank. Never open the tank until it has been fully drained. Never use the manual drain
valve until the unit has cooled down. Use the manual drain valve to verify that the tank is empty before
removing the tank cover.
WARNING!
Risk of severe burns from contact with hot steam vapors!
TheCondairGShumidierproduceshotsteamvaporsforhumidication.Bareskinincontact
with hot steam vapors can result in severe burns.
Prevention: Never perform any work on the steam system (including the steam lines, steam distribu-
tors, etc.) while the humidier is operating. Shut down the Condair GS humidier, as described in
Section 5.3.8 before carrying out any work on the steam system.

92596643-B_EN_2010_Condair GS_OM For your safety
WARNING!
Risk of severe burns from contact with hot surfaces!
The water tank, steam line and exhaust system in the Condair GS humidier get very hot during op-
eration. Bare skin in contact with hot surfaces can result in severe burns.
Prevention: Shut down the Condair GS humidier as described in Section 5.3.8 and wait for the com-
ponents to cool down before performing any work on the unit. Never use the manual drain valve until
the unit has cooled down. Use the manual drain valve to verify that the tank is empty before removing
the tank cover. Drain the tank as described in Section 5.3.8.
WARNING!
Risk of personal injury!
Wear a safety mask and clean the burner assembly in a well ventilated area.
CAUTION!
Riskofdamagetothehumidiercomponents!
Do not use solvents, aromatized or halogenized hydrocarbons, or other harsh chemicals for cleaning.
Disinfectants may only be used if they do not leave behind toxic residue. Rinse all parts thoroughly
with clean tap water after cleaning.
WARNING!
Riskofre!
DO NOT clean the sacricial anode with any chemicals. The anode can react with acids to create
ammable hydrogen gas.
WARNING!
Riskofdamagetothehumidiercomponentsorinjury!
DO NOT over-torque the bolts. Ensure the proper order of torquing is followed. Failure to do so may
cause damage to the humidier components or injury.
DANGER!
Risk of harm to personnel or damage to property.
Operatingadamagedorimproperlysecuredhumidierpresentsariskofdangertopersonnel
or damage to property.
Prevention: Do not start a damaged or improperly secured humidier.

10 For your safety 2596643-B_EN_2010_Condair GS_OM
Preventing Unsafe Operation
All persons working with the Condair GS must report any alterations to the unit that may affect safety to
the owner without delay. If it is suspected that safe operation is no longer possible, the Condair GS
should immediately be shut down and secured against accidental power-up according to Section
5.3.8. This can be the case under the following circumstances:
– if the Condair GS is damaged
– if the electrical installations are damaged
– if the Condair GS is no longer operating correctly
– if connections and/or piping (gas, water, exhaust gas) are not sealed
Prohibitedmodicationstotheunit
Nomodicationsmustbeundertaken on the Condair GS without the express written consent of Condair.
For the replacement of defective components use exclusively original accessories and spare parts
available from your Condair representative.
Safety labels on the unit
Various safety and identication labels are attached to the Condair GS. Please note and comply with
the relevant information on these labels.
1
23
4
1 Gas safety warning label
2 Keep cabinet closed warning label
3 General safety label
4 Specication label
Fig. 1: Position of the safety and identication labels

112596643-B_EN_2010_Condair GS_OM Product Overview
3 Product Overview
3.1 Model overview
Condair GS are available in two different housing designs ("Compact" for wall mounting and "Full-size"
for oor mounting), twoefciencyclasses (high efciency: with condensing heat exchanger (option
CS), standard efciency: without condensing heat exchanger) and maximum steam outputs ranging
from 23 kg/h up to 260 kg/h.
The humidier has an integrated controller that controls the humidier, and also allows the humidier to
be connected to a building automation system (via BACnet, Lonworks, Modbus), or the internet so the
humidier can be controlled and monitored remotely. In addition, up to four humidiers can be set up in
a "Main-Extension" conguration using Condair's Linkup system to satisfy large humidication needs.
Compact Standard
GS 23
GS 45 GS 65 GS 90 GS 130 GS 195 GS 260
max. steam capacity
23 kg/h or.
45 kg/h 65 kg/h 90 kg/h or. 130 kg/h 195 kg/h 260 kg/h
Detailed information on the unit specications can be found in Section 9.

12 Product Overview 2596643-B_EN_2010_Condair GS_OM
1
4
5
6
7
3
8
5
4
2
15
3 1
7
615
16
14
2
12
11
10
11
13
19
20
21
17
13
14
11
18
9
9
12
10
Fig. 2: Humidier Components (left: compact unit GS 23/45, right: Full-size unit GS 65), front, side
and top panels removed in the gure for clarity.
1Steam outlet
2Exhaust gas high limit temperature sensor
3Blower
4 Burner
5Tank door
6Gas inlet
7 Combustion air inlet
8 Exhaust Manifold (GS 90-260 only)
9Level control unit
10 Overow
11 Exhaust condensate trap (CS models only)
12 Secondary heat-exchanger (CS models only)
13 Drain valve
14 Dual ll valve
15 Silicone tube, exhaust outlet
16 Exhaust adapter
17 Remote fault board
18 Control board
19 Driver board
20 Control terminals (low voltage)
21 Terminal block mains voltage supply

132596643-B_EN_2010_Condair GS_OM Product Overview
Table 1: Components installed by models
Component Quantity
GS 23/45 GS 65 GS 90/130 GS 195 GS 260
Primary heat-exchanger 11234
Secondary heat-exchanger 1 *1 *1 *2 *2 *
Water tank 11111
Burner 1 1 2 3 4
Blower 11234
Gas valve 11234
Ignition control module 11234
Spark-igniter and ame sensor 11234
Dual ll valve 11122
* Secondary heat-exchanger on CS models only.
3.2 Functional Description
Combustion
The combustion system consists of a fully modulating forced-draft combustion air blower(s), a negative
pressure regulated gas valve(s), and a premix burner(s). On a call for humidity, the blower is energized
to purge the system. During this time the control software performs diagnostic checks of the safety
systems – the air proving switch (not shown), the high limit temperature switch in the exhaust vent, as
well as the blowers. If the air proving switch is open, the warning message "AP Open Warn" appears,
and escalates to the fault message "AP Open Fault" if three consecutive warnings occur. At the same
time, if the over-temperature switch is open, the fault message "Over-Temperature Fault" appears. In
addition, if any of the blowers fail to operate during this time, the fault message "Blower Not Operating"
appears. When the functions of the safety systems have been veried successfully, the gas valve(s)
open(s) and the gas-air mixture is pushed through the burner ports into the combustion chamber(s). The
spark-igniter(s) is/are simultaneously activated to ignite the gas-air mixture.
If a ame is not sensed by the ame sensor(s), the above sequence is repeated after 15 seconds. The
sequence is repeated up to a maximum of three times, after which the ignition control module(s) locks
out and the fault message "Ignition Fail" appears. If a ame is sensed by the ame sensor(s), the gas
valve(s) remain(s) open and combustion continues. The gas valve(s) continue(s) to maintain a constant
air-to-gas ratio independent of the blower speed or external conditions.
On the CS models, the hot ue gases pass through the primary heat-exchanger then the secondary
heat-exchanger, where it is cooled further before it exits through the exhaust vent. The heat recovered
by the secondary heat-exchanger is used to warm up the feed water. On the standard-efciency model,
the hot ue gases pass through the primary heat-exchanger and exit through the exhaust vent.

14 Product Overview 2596643-B_EN_2010_Condair GS_OM
Water Management
The humidier is equipped with a level control unit that monitors the water level in the tank. The tank
is supplied with water from the water supply, and from the secondary heat exchanger in CS models. A
vacuum break valve is used to prevent siphoning in the drain connection.
In the CS model, a secondary heat-exchanger promotes higher efciencies. This is achieved by using
the heat from the exhaust gas to pre-heat the cold ll water entering the tank.
The level control unit is connected to the top and bottom of the tank to monitor water level inside the
tank. The level control unit is equipped with a control board and consists of two magnetic oats (one is
the level oat and one is the safety oat) that measure the water level. The water levels in the tank are
indicated with 3 LEDs on the control board and are monitored by the control software.
Water Levels:
– L5 (yellow LED lights) – high water level
– L4 (green and yellow LED light) – intermediate water level
– L3 (green LED lights) – middle water level
– L2 (green and red LED light) – intermediate water level
– L1 (red LED lights) – low water level
On initial start-up, the dual ll valve lls the tank and the level control unit. A start-up test monitors the
water level as the tank and level control unit lls, and ensures proper functioning of the unit.
Note: A fault message "Float Level" may appear at any time. This indicates an invalid combination of
readings from the control software (for example, if L5 and L1 LEDs activate at the same time).
1. Water enters the level control unit via the hose connected to the tank The water level reaches rst
the safety oat, then the level oat.
2. As water lls the level control unit and reaches the L1 level, the control software performs a test to
verify proper functioning of the dual ll valve and the drain pump.
a) The ll valves lls the tank until the water level L5 is reached (detected by the level control unit).
b) Then, the drain pump energizes to lower the water level to just below L3.
Note: The water levels should appear in ascending then descending order; L1, L2, L3, L4, L5, L4,
L3. A fault message "Fill Check Fault" appears if the water level does not rise to level L5. A fault
message "Drain Check" appears if the water level does not drop below the level L3.
3. When the test is complete, the dual ll valve activates and the water level should rise to level L3.
4. If a demand signal is present, the humidier begins the combustion sequence.
5. The drain pump and dual ll valves maintain the water level between levels L2 and L5.
If "Float Check" is enabled during steam production, the control software will activate the drain sequence
every 24 hours (adjustable to any time of day) to verify proper functioning of the level control unit, dual
ll valve, and the drain pump.

152596643-B_EN_2010_Condair GS_OM Product Overview
3.3 System overviews
3.3.1 System overview compact units GS 23/45
23
22 21
20
19
18
12
30
29
13
17
16
28
1
4 1
2
3
5
6
27
26
31 15
11 10 9 8 7
14
6
24 25
Fig. 3: System overview compact units GS 23/45
1Humidity sensor or external humidity controller (installed
in the extract air duct for extract air humidity control or in
the supply air duct for supply air humidity control)
2Extract air duct
3Supply air duct
4Safety humidistat (external safety loop)
5Condensate drain line with trap
6Open funnel with trap
7 Water supply connector
8 Connector ue gas condensate drain
9Water drain connector
10 Combustion air supply connector
11 Gas supply connector
12 Water supply line
13 Sediment trap
14 Gas supply line
15 Shutoff valve gas supply line
16 Electrical isolator voltage supply (mandatory)
17 Connection tting gas supply line
18 Shutoff valve water supply line
19 Water lter
20 Connection tting water supply line
21 Water drain line
22 Flue gas condensate drain (CS only)
23 Steam line
24 Flue gas pipe (connected to exterior)
25 Combustion air supply pipe (connected to exterior –
optional)
26 Steam hose adapter
27 Steam distribution pipe DV81-..
28 Air ow monitor (external safety loop)
29 Pipe disconnector as backow preventer (optional, sup-
plied by others)
30 Water shock arrestor (supplied by others)
31 Gas test port (supplied by others)

16 Product Overview 2596643-B_EN_2010_Condair GS_OM
3.3.2 System overview full-size units
1
4 1
2
3
GS 90-260 -CSGS 65-CS
15
23
22
21
18
19
20
17
13
12 25
24
11
10
269 8
7
6
6
16
14
5
Fig. 4: System overview full-size units GS 65-260 (GS 65 unit is shown)
1Humidity sensor or external humidity controller (installed
in the extract air duct for extract air humidity control or in
the supply air duct for supply air humidity control)
2Extract air duct
3Supply air duct
4Safety humidistat (external safety loop)
5Condensate drain line with trap
6Open funnel with trap
7 Gas supply line
8 Shutoff valve gas supply line
9Connection tting gas supply line
10 Sediment trap
11 Water lter
12 Shutoff valve water supply line
13 Water supply line
14 Connection tting water supply line
15 Electrical isolator voltage supply (mandatory)
16 Water drain line
17 Flue gas condensate drain line (CS only)
18 Steam line
19 Combustion air supply pipe (connected to exterior –
optional)
20 Flue gas pipe (connected to exterior)
21 Steam hose adapter
22 Steam distribution pipe DV81-..
23 Air ow monitor (external safety loop)
24 Pipe disconnector as backow preventer (optional, sup-
plied by others)
25 Water shock arrestor (supplied by others)
26 Gas test port (supplied by others)

172596643-B_EN_2010_Condair GS_OM Operator Interface
4 Operator Interface
4.1 Display and operating elements
The Condair GS consists of the following display and operating elements (see Fig. 5 and Table 2).
1
4
3
2
Fig. 5: Display and operating elements
Table 2: Functions of the display and operating elements
Pos. Element Function
1Electrical isolator External fused electrical isolator installed in the mains voltage supply
2Touchscreen display Allows the user to monitor and control the Condair GS humidier – Refer to Section 4.2.
3LED status indicator The status LED is a multi-function LED, which lights up in different colors depending on
the operating status of the humidier.
– LED lights Green: indicates that the Condair GS humidier is operating normally and
humidifying.
– LED ashing green: indicates that the Condair GS humidier is in standby mode.
– LED lights yellow: indicates that a warning condition is present, or the humidier is due
for maintenance.
– LED lights red: indicates that a fault condition is present, and humidication is stopped.
4On/Off switch Allows the user to turn the Condair GS humidier on or off

18 Operator Interface 2596643-B_EN_2010_Condair GS_OM
4.2 Control Software
4.2.1 Home Screen
When the Condair GS humidier is turned on, it starts initializing and performs system checks. When
initialization and system checks are completed successfully, it goes into the normal operating mode.
The Home screen then appears on the touchscreen display. The major elements of the Home screen
are shown in Fig. 6.
10
9
1
2
3
4
5678
Fig. 6: Home Screen Elements
1 Current date and time
2Operating status message – refer to Section 4.2.2.
3Humidity control information – shows the type of control
signal and the steam output requested.
4Service/Warning/Fault status message – refer to Section
4.2.3.
5<Help> button – access technical support help information.
Refer to Section 4.2.4 for details.
6<Drain> button – manually initiate the drain function. Refer
to Section 5.3.6 for details.
7<About> button – access the system information. Refer to
Section 4.2.5 for details.
8<Menu> button – access the Main menu. Refer to Section
4.2.6 for details.
9Visual indication of current steam output level
10 Humidier model designation

192596643-B_EN_2010_Condair GS_OM Operator Interface
4.2.2 Operating Status
The operating status area of the Home screen shows the current operating status message and an associ-
ated status icon. The messages are described in Table 3, and the status icons are described in Table 5.
Table 3: Operating Status Descriptions
Message Description
Humidifying The humidier is generating steam.
Stopped The humidier is stopped because a condition with a "Fault" status is active.
Disabled The Condair GS humidier is disabled by the BMS (building management system).
Safety Loop One or more contacts in the external security loop is open, so the humidier has stopped produc-
ing steam.
Idle The humidier is in standby mode (no humidity demand). The humidier will remain in this state
until it receives a valid humidity demand signal.
Idle Drain The humidier is in standby mode (no humidity demand) and will remain in this state until a demand
signal is received, or until the "Idle Drain Time" has elapsed (and the "Idle Drain" function is active).
The humidier will drain when "Idle Drain Time" has elapsed.
Idle-Empty Indicates that the tank is empty during idle.
Keep Warm) The humidier is in standby mode, and the "Keep Warm" function is activated
Filling Indicates that the tank is being lled
Fill check The humidier is performing a ll check.
Drain Check The humidier is performing a drain check.
Draining The humidier is draining.
4.2.3 Maintenance and Fault Status
The Service/Warning/Fault status area of the Home screen (refer to Table 4) shows maintenance re-
minders, warning and fault status messages along with associated status icons (refer to Table 5). This
eld also allows access to the "Service" menu. When a maintenance reminder, warning or fault status
message is active, the list of current faults/warnings can be accessed directly from this eld to view
additional details.
Table 4: Maintenance/Fault Status Descriptions
Message Description
Service info No faults conditions present.
Main. Warning This maintenance reminder appears when the Service Interval time set in the control software
has elapsed. The unit can continue to operate for another 200 hours, after which a correspond-
ing fault message appears and the unit stops operating.
Perform the required scheduled maintenance, then reset the service reminder in the Service
menu. Refer to Section 6.5.
Warning Warning A condition with a "Warning" status is active. Depending on the warning condition, the
humidier will continue to produce steam when there is a demand (unless the warning relates
to a control signal).
In addition, the status LED turns yellow in color.
Fault Fault A condition with a "Fault" status is active. The humidier will not produce steam until the
fault condition is cleared.
In addition, the status LED turns red in color.

20 Operator Interface 2596643-B_EN_2010_Condair GS_OM
Table 5: Status Icon Descriptions
Symbol Description
This icon appears to the left of the operating status message or the maintenance/fault message
when the system is working normally.
Warning
This icon appears to the left of the maintenance/fault status message when a maintenance reminder
or a condition with a "Warning" status is active. The humidier will continue to produce steam when
there is a demand (unless the warning relates to a control signal fault).
Typically, these conditions are of a temporary nature, or conditions that cannot cause damage to
the system. Depending on the condition, the Condair GS humidier may be stopped (e.g. if the
warning relates to a control signal fault) or remains operable. If the cause of the condition clears
on its own accord, the warning message is automatically reset. If the condition becomes worse, a
fault message may be triggered.
When a warning message is active, the status LED lights yellow.
Fault
This icon appears to the left of the maintenance/fault status message when a condition with a "Fault"
status is active. The humidier stops producing steam.
Typically, these are conditions which prevent further operation of the humidier, or conditions that
can cause damage to the system. When a fault condition occurs, the Condair GS humidier stops
steam production immediately.
When a fault message is active, the status LED lights red.
4.2.4 Accessing support informations
Press the <Help> button in the home screen (refer to Fig. 6 on page 18). The screen with the support
information appears.
4.2.5 Accessing system informations
Select the <About> button on the home screen (refer to Fig. 6 on page 18) to view the system infor-
mation for your Condair GS humidier. The tab structure for this selection is shown below.
General Tab
– Serial Number: shows the serial number, which is also shown on the
specication label.
– HumidierModel: shows the model number, which is also shown on the
specication label on the right side of the humidier.
– HumidierCapacity: shows the total steam output capacity of the humidi-
er.
– Software Version: shows the current version of the control software.
Select the eld to update the control software – refer to"Software Settings
Tab" on page 39 for details.
– Driver Board A/B Version: shows the current version of the driver board.
– Graph: shows you a graph of the trend data.
– Export Trend Data: Select the eld to send the trend data to a connected
USB drive.
