CONIC ART LED TRIANGLE User manual

ART LED TRIANGLE
CONIC
!"#$%&'()"*+,"&,-*
使⽤说明书

prompt
Please read this safety rule carefully before use.
After the equipment has been transported to the destination of use, please carefully
open the package and take out the equipment. If you find any defects, you should
immediately contact the shipping company and complain according to the defect. Confirm
that this equipment is intact when it leaves the factory.
Please check whether the received equipment matches the goods registered in the
freightbill, and whether the goods registered in the freight bill match
The goods you ordered are consistent, if not, please contact your supplier immediately.
Overview
This lamp is a professional lighting equipment designed for indoor and outdoor
performances, etc. It is a professional special-effect background retro lamp. It must be
marked as a ground-level wire and ground wire.
Do not open the casing while this equipment is running to avoid electric shock.
Obvious defects are found in the glass lens, and the lens should be replaced
immediately and its power should be reduced, such as deep cracks or scratches. The
luminous body is damaged or distorted after high heat and should be replaced
immediately. If you need to perform inspection, maintenance, repairs and other
operations inside the lamp, you should turn it over to professionals.
In the event of an accident, unplug the power cord before opening the lamp housing.
The user should operate within the scope of the specified use of this equipment and check
whether the wiring of the equipment is correctly connected. Please do not place the lamp
in a changeable and harsh environment.
The manufacturer shall not be liable for damage caused by unauthorized replacement of
other types of light sources.
This luminaire is a kind of professional equipment. Although the improved design is
simpleand convenient to operate, it still needs professional installation and maintenance.
Point
The power cord and other connecting devices are very important to the equipment, and
their reasonable arrangement leads to the safe and convenient use of the equipment.
When unplugging and plugging in the power supply, you must hold the plug and pull it out.
Do not pull the power cord directly.
Do not use the power cord in harsh environments. It should be tested before installation,
and periodic testing should be maintained after installation. Do not tie the power cord
andother signal lines together to prevent confusion.
Power connection
This lamp adapts to the conventional voltage of various countries. For the safety of
users,be sure to keep the ground wire (yellow-green) grounded.
Warning: LETHAL VILTAGE PRESENT INSIDE

提示使⽤前请仔细阅读此安全规则。该设备已经通过运输到过使⽤⽬的地后，请⼩⼼打开包装并取出设备如发现任何缺损，应⽴即联系货运公司并按照缺损情况进⾏投诉。确认此设备在出⼚时为完好⽆损。请检查接收的设备是否与货运单中登记的货物相符，以及货运单中登记货物与您的订购的货物相符，如有不符请⽴即联系您的供货商。总述此灯具专为室内外演出活动等设计的专业照明设备，是⼀款专业的特效背景复古灯，必须将标记为地级的电线接地线。不要在此设备运⾏时打开外壳，以避免被电击。在玻璃镜⽚发现明显缺损，应⽴即更换镜⽚并降低其功率，⽐如深刻的裂痕或刮痕。发光体在⾼热后出现损坏或扭曲变形应⽴即更换。需要在灯具内部进⾏检查、维护、修理等操作时，都应交由专业⼈⼠。⼀旦出现事故，在打开灯具外壳前应⾸先拔去电源线插头。使⽤者应在此设备规定⽤途范围内进⾏操作，并核对设备的线路是否正确连接。请不要将该灯具置于多变的恶劣环境。⽣产商概不承担由于擅⾃更换其它类型光源⽽引起的损坏事故责任。此灯具是⼀种专业设备，虽设计改良后的操作简单⽅便，但仍需要专业⼈⼠进⾏安装维护。要点电源线及其它连接装置对于设备都是很重要的，因其合理安排才导致设备的安全便利运⽤。在拔插电源时必须⽤⼿持插头并拉出，切勿直接拉扯电源线。勿在恶劣的环境下使⽤电源线，在安装前应检测，并在安装后保持周期性的检测切勿将电源线及其他信号线扎在⼀起，以防混淆。电源连接此灯具适应各国的常规电压，为了使⽤者的安全，务必保持地线（⻩绿⾊）接地。警告∶内部带危险电压!
First of all, thank you for choosing our company's product. Please read this instruction
manualcarefully and completely, and keep it properly for reference during use. This manual
contains important information about the installation and use of this product. Please strictly
follow theserelated instructions during installation and use.
The appearance design is avant-garde, strong sense of balance, good stability effect,
generous and decent, and the overall internal structure is reasonable, simple and harmonious.
The products are designed and produced according to strict standards and fully comply with
the international standard DMX512 protocol. They can be controlled by a single unit or linked
to each other. They are suitable for large-scale theatrical performances, indoor and outdoor
activities, architectural landscape lighting and other places.
Benchengjie lamps use high-precision accessories. When you receive the product, please
handle it carefully and check whether the product may be damaged due to transportation.
Andcheck the following accessories:
1. Lamps-1 set
2. Power cord 1

3. Signal line --- 1
4. Instructions --- 1 copy
5. Hanger - 1 pair
⾸先感谢你选择了本公司的产品，请仔细完整地阅读这份使⽤说明⼿册，并妥善保管，以便使⽤时参考。本使⽤说明书中包含有关本产品的安装及使⽤⽅⾯的重要信息。安装及使⽤时请严格遵守这些相关的说明。外观设计前卫，平衡感强，很好的稳定效果，⼤⽅得体，内部整体构造合理，简单，和谐。产品按严格标准进⾏设计⽣产，完全符合国际标准DMX512 协议，既可单台控制，也可以互相联控使⽤，适⽤于⼤型⽂艺演出、室内外活动现场，建筑景观照明等场所使⽤。本成介灯采⽤⾼精密配件。在收到产品时，请⼩⼼取放，检查产品是否有因运输⽽可能造成的损坏。并检查以下配件：1.灯具1 台---
2.电源线---- 1 根3.信号线--- 1 根4.说明书1 份---
This product is a retro lamp with professional special effects.
If the product has gone through a large temperature difference (for example, after
transportation), do not start the product immediately
The product will be damaged due to thermal expansion and contraction. Please wait until the
device reaches normal room temperature before starting the product.
Pay attention to shocks. Avoid strong collisions during product installation.
When choosing an installation location, make sure that the product is not exposed to
excessive heat, humidity or dust. Please try not to put any wires on the ground and do a good
job of waterproofing, otherwise you may suffer the danger of electric shock.
Before installing the product, make sure that the installation point is safe.
If you need to hang it, please fasten the product with a safety rope, and check whether all the
screws are correct during installation
Please make sure the glass is in good condition. When the glass is damaged or scratched,
please replace the glass.
It is recommended that technicians familiar with this product operate this product. Non-
technical personnel are forbidden to operate this equipment, because many losses are the
result of non-professional operation.
Please keep the packing materials properly in case you need to carry out the second
transportation.
If there is no guidance from the manufacturer or distributor, please do not modify the product
without authorization.
Any equipment failure caused by the operation and use of this equipment not in accordance
with the provisions of the manual is not covered by the warranty. And any damage caused by
short circuit, injury, electric shock, ultraviolet rays, etc. caused by this are not covered by the
warranty.
4. Product hanging and installation

Note: For more safety, please hang and install this product away from aisles, seating areas, or
areas within reach of people.
Before hanging the product, make sure that the installation point can bear the weight of the
product 10 times.
Product installation must have double protection devices, such as safety ropes.
When hanging, removing or repairing this product, it is forbidden to stand under the installation
point
本产品是专业特效复古灯。假如产品在经过较⼤的温度差后（例如，运输后），则不要⻢上启动产品因为热涨冷缩会损坏到产品。请等到设备达到正常室温后再启动产品。注意防震。产品安装过程中避免强烈碰撞。选择安装地点时请确保产品未暴露在过热、太湿或多灰尘的地⽅。请尽量不要把任何电线置于地⾯，做好防⽔效果，否则可能会遭受电击的危险。安装产品前，请确保安装点安全。如需悬挂请将产品系上安全绳，并在安装时检查所有的螺丝是否正确请确保玻璃状态良好。当玻璃损坏或者划伤时，请更换玻璃。建议由熟悉本产品的技术⼈员去操作本产品。禁⽌⾮技术⼈员操作此设备，因为许多损失就是由于⾮专业操作的结果。请妥善保管包装材料以备需要进⾏⼆次运输。如果没有⽣产商或者经销商的指导，请勿擅⾃更改产品。未按照说明书规定操作使⽤此设备所引起的任何设备故障均不属于保修范围。⽽且由此所导致的任何由于短路、伤害、触电、紫外线导致的伤害、等均不在保修范围内。4.产品吊挂和安装注意：为更安全起⻅，请在远离⾛道，座位区域，或者⼈⼿可及的区域吊挂安装本产品。吊挂本产品前，请确保安装点可承受终于本产品10 倍的重量。产品安装必须有⼆重保护装置，例如安全绳。当挂，拆除或者维修本产品时，禁⽌站在安装点下Features:
This product is a retro triangle LED special effect background light. The main light uses 16
30W 1800K golden yellow LED lamp beads, and the auxiliary light uses 576 0.3W RGB three-
in-one LED lamp beads. Each main light is surrounded by 36 pieces. The lamp beads are
divided into 16 modules and can be individually controlled, the effect is outstanding and vivid.
This luminaire can seamlessly splice multiple luminaires or hang them for use, which can bring
dazzling and multi-style effects to the stage.
This product has a good LED refresh rate, no flicker, and can be suitable for various
occasions.
The lamp can be set with the signal hold function, when the signal is disconnected from the
console, the current effect can be maintained
The appearance design is avant-garde, strong sense of balance, good stability effect,
generous and decent, and the overall internal structure is reasonable, simple and harmonious.

特点：此产品是⼀款复古三⻆形./0**特效背景灯，主光使⽤12*颗345*16447*⾦⻩⾊./0*灯珠，辅光使⽤892*颗4:35*;<=*三合⼀./0*灯珠，每个主光周围都有32*颗，灯珠分12*模组单独可控，效果出众⽣动。此灯具可以将多个灯具进⾏⽆缝拼接，也可以悬挂使⽤，可给舞台带来炫⽬多样式的效果。
此产品有很好的./0*刷新频率>⽆闪烁，可以适合各种场合。灯具可以设置信号保持功能，当与控台断开信号后，可以保持当前效果外观设计前卫，平衡感强，很好的稳定效果，⼤⽅得体，内部整体构造合理，简单，和谐。technical parameter 技术参数Input voltage: AC100-240V, 50/60Hz
Light source: main light: 16 PCS 30W golden light
Auxiliary light: 576 0.3W RGB three-in-one LED lamp beads
Main light color temperature: 1800K (other color temperatures are
optional)Channel: 6/12/21/64/76 CH
Control mode: DMX512, master-slave, self-propelled, voice
controlLamp size: 79.5x15x69cm
Net weight: 8.3KG
输⼊电压：?@144ABC4D，84*E*24FG*
光源：主光：12*颗345*⾦⻩光辅光：892*颗4:35*;<=*三合⼀./0*灯珠主光⾊温：16447H可选其他⾊温）通道：2E1BEB1E2CE92*@F*
控制模式：0IJ81B，主从，⾃⾛，声控灯具尺⼨：9K:8L18L2K'+*
净重：6:37<*
Dimensions 尺⼨图

Menu operation instructions 菜单操作说明?．功能键=．加键@．减键0．确认键A B C D
Operation instructions: Press function key A to cycle out different functions,
press B or C key to modify its parameter value. Press D to confirm.
操作说明：按功能键?*会循环出不同的功能，按=*或@*键即可修改其参数值。按0*键确认即可。
Address(地址)
1-512
RUN(运⾏)
DMX512
Auto(⾃⾛)
Sound(声控)
DMX MODE
(模式)
CH4(4 通道模式)
CH6(6 通道模式)
CH12(12 通道模式)
CH21(21 通道模式)
CH64(64 通道模式)
CH76(76 通道模式)
TEST(测试)
ALL(灯珠测试)

Channel 通道4 channel mode 通道模式6channel mode 通道模式
SET(设置)
中⽂English
DISPLAY（屏幕反相）
No/Yes(否/
是)
Signal Keep(信号保持)
No/Yes(否/
是)
Slave（主从）
No/Yes(否/
是)
INFO（信息）
Version(软件版本)
Vx.xx
MANUAL（⼿动）
Red(红⾊)
Green(绿⾊)
Blue(蓝⾊)
white（暖⾊）
Strobe(频闪)
RESET(复位)
All Reset(整机复位)
No/Yes(否/是)
CH 通道
Function 功能
DMX Value 数值
Description 描述
1
Red/红
0-255
0-100%
2
Green/绿
0-255
0-100%
3
Blue/蓝
0-255
0-100%
4
White/⽩
0-255
0-100%
CH 通道
Function 功能
DMX Value 数值
Description 描述

1
Dimmer/总亮度
0-255
0-100%

12channel mode 通道模式
2
Strobe/频闪
0-19
No Effect/⽆作⽤
20-255
Strobe slow to fast/由慢⾄快
3
Red/红
0-255
0-100%
4
Green/绿
0-255
0-100%
5
Blue/蓝
0-255
0-100%
6
White/⽩
0-255
0-100%
CH 通道
Function 功能
DMX Value 数值
Description 描述
1
Dimmer/总亮度
0-255
0-100%
2
Strobe/频闪
0-19
No Effect/⽆作⽤
20-255
Strobe slow to fast/由慢⾄快
3
Red/红
0-255
0-100%
4
Green/绿
0-255
0-100%
5
Blue/蓝
0-255
0-100%
6
White/⽩
0-255
0-100%
7
Color Macro/
颜⾊宏
0-10
No Function
11-30
R 100%,G 50-100-50%,B 0
31-50
R 100%-0,G 100%, B,0
51-70
R 0,G 100%,B 0-100%
71-90
R 0,G 100%-0,B 100%
91-110
R 0-100%, G 0, B 100%

111-130
R 100%,G 0, B 100%-0
131-150
R 100% ,G 0-100% ,B 0-100%
151-170
R 100%-0 , G 100%-0 , B 100%
171-200
R 100%,G 100%, B 100%
201-205
Color 1（颜⾊）
206-210
Color 2（颜⾊）
211-215
Color 3（颜⾊）
216-220
Color 4（颜⾊）
221-225
Color 5（颜⾊）
226-230
Color 6（颜⾊）
231-235
Color 7（颜⾊）
236-240
Color 8（颜⾊）
241-245
Color 9（颜⾊）
246-250
Color 10（颜⾊）
251-255
Color 11（颜⾊）
8
Foreground
Dimmer/前景⾊调光
0-255
0-100%
9
Background/背景⾊
0-10
No Function/⽆功能
11-255
Background Color/背景⾊
10
Background
0-255
0-100%

Dimmer 背景⾊调光
11
Show/内置程序
0-10
No Function/⽆功能
11-15
Show1（场景）
16-20
Show2（场景）
21-25
Show3（场景）
26-30
Show4（场景）
31-35
Show5（场景）
36-40
Show6（场景）
41-45
Show7（场景）
46-50
Show8（场景）
51-55
Show9（场景）
56-60
Show10（场景）
61-65
Show11（场景）
66-70
Show12（场景）
71-75
Show13（场景）
76-80
Show14（场景）
81-85
Show15（场景）
86-90
Show16（场景）
91-95
Show17（场景）
96-100
Show18（场景）

101-105
Show19（场景）
106-110
Show20（场景）
111-115
Show21（场景）
116-120
Show22（场景）
121-125
Show23（场景）
126-130
Show24（场景）
131-135
Show25（场景）
136-140
Show26（场景）
141-145
Show27（场景）
146-150
Show28（场景）
151-155
Show29（场景）
156-160
Show30（场景）
161-165
Show31（场景）
166-170
Show32（场景）
171-175
Show33（场景）
176-180
Show34（场景）
181-185
Show35（场景）
186-190
Show36（场景）
191-195
Show37（场景）
196-200
Show38（场景）
201-205
Show39（场景）

21channel mode 通道模式
206-210
Show40（场景）
211-215
Show41（场景）
216-220
Show42（场景）
221-235
Show43（场景）
236-245
Sound1（声控）
246-255
Sound2（声控）
12
Show Speed/
程序速度
0-255
Show Speed Slow to Fast/速度由慢到快
CH 通道
Function 功能
DMX Value 数值
Description 描述
3
Dimmer/总亮度
0-255
0-100%
4
Strobe/频闪
0-19
No Effect/⽆功能
20-255
Strobe slow to fast/由慢到快
5
1 Color Select/
模块颜⾊1 选择
0-10
No Function/⽆功能
11-25
Red/红
24-40
Green/绿
41-55
Blue/蓝
56-70
White/⽩
71-85
R +G
86-100
R+B
101-115
G+B

116-130
R+W
131-145
G+W
146-160
B+W
161-175
R+G+W
176-190
R+B+W
191-205
G+B+W
206-255
R+G+B+W
：
...
...
18
16 Color
Select/
模块颜⾊16 选择
0-10
No Function
11-25
Red
24-40
Green
41-55
Blue
56-70
White
71-85
R +G
86-100
R+B
101-115
G+B
116-130
R+W
131-145
G+W
146-160
B+W
161-175
R+G+W
176-190
R+B+W

191-205
G+B+W
206-255
R+G+B+W
19
Backgroun
dDimmer
背景⾊调光
0-255
0-100%
20
Show 内置程序
0-10
No Function/⽆功能
11-15
Show1（场景）
16-20
Show2（场景）
21-25
Show3（场景）
26-30
Show4（场景）
31-35
Show5（场景）
36-40
Show6（场景）
41-45
Show7（场景）
46-50
Show8（场景）
51-55
Show9（场景）
56-60
Show10（场景）
61-65
Show11（场景）
66-70
Show12（场景）
71-75
Show13（场景）
76-80
Show14（场景）
81-85
Show15（场景）

86-90
Show16（场景）
91-95
Show17（场景）
96-100
Show18（场景）
101-105
Show19（场景）
106-110
Show20（场景）
111-115
Show21（场景）
116-120
Show22（场景）
121-125
Show23（场景）
126-130
Show24（场景）
131-135
Show25（场景）
136-140
Show26（场景）
141-145
Show27（场景）
146-150
Show28（场景）
151-155
Show29（场景）
156-160
Show30（场景）
161-165
Show31（场景）
166-170
Show32（场景）
171-175
Show33（场景）
176-180
Show34（场景）
181-185
Show35（场景）
186-190
Show36（场景）

64 channel mode 通道模式
191-195
Show37（场景）
196-200
Show38（场景）
201-205
Show39（场景）
206-210
Show40（场景）
211-215
Show41（场景）
216-220
Show42（场景）
221-225
Show43（场景）
226-230
Sound1（声控）
231-235
Sound2（声控）
236-245
No Function/⽆功能
246-255
Show1（场景）
21
Show Speed
程序速度
0-255
Show Speed Slow to Fast 由慢到快
CH 通道
Function 功能
DMX Value 数值
Description 描述
1
Red1 红
0-255
0-100%
2
Green1 绿
0-255
0-100%
3
Blue1 蓝
0-255
0-100%
4
White1 ⽩
0-255
0-100%
5
Red2 红
0-255
0-100%
6
Green2 绿
0-255
0-100%

76 channel mode 通道模式
7
Blue2 蓝
0-255
0-100%
8
White2 ⽩
0-255
0-100%
…
……
…
…
61
Red16 红
0-255
0-100%
62
Green16 绿
0-255
0-100%
64
Blue16 蓝
0-255
0-100%
64
White16 ⽩
0-255
0-100%
CH 通道
Function 功能
DMX Value 数值
Description 描述
1
Dimmer/总亮度
0-255
0-100%
2
Strobe/频闪
0-19
No Effect/⽆作⽤
20-255
Strobe slow to fast/由慢⾄快
3
Red/红
0-255
0-100%
4
Green/绿
0-255
0-100%
5
Blue/蓝
0-255
0-100%
6
White/⽩
0-255
0-100%
7
Color Macro/
颜⾊宏
0-10
No Function
11-30
R 100%,G 50-100-50%,B 0
31-50
R 100%-0,G 100%, B,0
51-70
R 0,G 100%,B 0-100%
71-90
R 0,G 100%-0,B 100%

91-110
R 0-100%, G 0, B 100%
111-130
R 100%,G 0, B 100%-0
131-150
R 100% ,G 0-100% ,B 0-100%
151-170
R 100%-0 , G 100%-0 , B 100%
171-200
R 100%,G 100%, B 100%
201-205
Color 1（颜⾊）
206-210
Color 2（颜⾊）
211-215
Color 3（颜⾊）
216-220
Color 4（颜⾊）
221-225
Color 5（颜⾊）
226-230
Color 6（颜⾊）
231-235
Color 7（颜⾊）
236-240
Color 8（颜⾊）
241-245
Color 9（颜⾊）
246-250
Color 10（颜⾊）
251-255
Color 11（颜⾊）
8
Foreground
Dimmer/前景⾊调光
0-255
0-100%
9
Background/背景⾊
0-10
No Function/⽆功能
11-255
Background Color/背景⾊
