Connected RFK-5000 Operating instructions
EN-20191104-A
This system must be installed by a professional.
COMPLETE INSTALLATION & PROGRAMMING GUIDE
NOTICE
The manufacturer will accept no responsability for any electrical damage resulng from
improper installaon of this product, be that either damage to the vehicle itself or to the
installed device. This device must be installed by a cered technician. Please review the
Installaon Guide carefully before beginning any work.
RFK-5000 Digital RF Kit system
HARDWARE PARTS ................................................................................................................................ 3
iDATASTART HCx.....................................................................................................................................4
iDATASTART VWx.................................................................................................................................... 6
iDATASTART BM or BZ .......................................................................................................................... 8
AKX or OEM............................................................................................................................................. 10
ADS-AL-CA / OL-MDB-ALL................................................................................................................12
FLASHLOGIC FL-CAN...........................................................................................................................14
FLASHLOGIC FL-CAN...........................................................................................................................16
FLASHLOGIC FLRS ................................................................................................................................18
FLASHLOGIC FLRSBA ........................................................................................................................ 20
FLASHLOGIC FLCMVW.......................................................................................................................22
COMPUSTAR CM7000 / CM7200 / POLARSTART PRS-16...................................................24
COMPUSTAR CM6200 .........................................................................................................................26
COMPUSTAR DC2..................................................................................................................................28
COMPUSTAR DC3................................................................................................................................. 30
POLARSTART PRS-13...........................................................................................................................32
DIRECTED DBALL 2..............................................................................................................................34
DIRECTED DB3.......................................................................................................................................36
DIRECTED 4X10 - 5X10 - AF-D600 - ASD200 - ASD-600....................................................38
DIRECTED DS4 - DS4+....................................................................................................................... 40
FORTIN EVO-ALL ..................................................................................................................................42
FORTIN EVO-ONE ................................................................................................................................ 44
PRESTIGE (E) Models.......................................................................................................................... 46
PRESTIGE (Z) Models.......................................................................................................................... 48
PURSUIT (E) Models ............................................................................................................................ 50
CODE SYSTEMS......................................................................................................................................52
OLDER CODE SYSTEMS......................................................................................................................54
OMEGA RS-X70......................................................................................................................................56
OMEGA AL-XX70-B ..............................................................................................................................58
OMEGA OL-RS ....................................................................................................................................... 60
MIDCITY SMARTKEY STARTER........................................................................................................62
DSE 503AIR 5R-85 ............................................................................................................................... 64
DSE iSTART2 - 3 .................................................................................................................................... 66
System LED Status & Protocol Reference Chart........................................................................68
Reset Procedure .....................................................................................................................................68
2
TABLE OF CONTENTS
HARDWARE PARTS
XTX-3000
IVU-CAB-4W HRN-CRF-02
CREATE AN ACCOUNT
Before begining the installation and setting the configurations of a Connected SmartControl system,
we strongly recommend downloading the Application from the App store and create a user ac-
count.
a. Go to the App store (Apple) or Play store (Android) and Search for “Connected SmartControl”.
Download and install the Free Application.
b. Launch the newly installed SmartControl Application on your smartphone or tablet
c. Click “Create an Account”
d. Fill in all the required fields
e. Once done, Log into the Application using your email and your newly created password.
RTX-3200
OL-ADAPTER-B2G
This Adapter is supplied ONLY inside
the Omega Research & Development
Technologies boxes.
4
PARTS REQUIRED FOR INSTALLATION OF : iDATASTART HCx
XTX-3000 IVU-CAB-4W iDatastart HCx
STEP 1. CONFIGURE THE REMOTE STARTER
The ADS Weblink (ADS-USB) is required to properly configure the iDatastart HCx remote starter to accept
the RF kit system. When flashing the iDatastart HCx remote starter, please follow this procedure in order
to configure correctly your remote starter.
a. Go to www.idatalink.com and click on “Flash your module”
b. Using the new Weblink configurator, Choose
vehicle Make, Year, Model, Trim.
c. In the Remote Configuration section, Select the Brand drop-
down and Choose “CONNECTED” and select the Connected RF
system you are using.
d. This will load a firmware starting with: “IDPP-XX(XX)-XXX (X.X)”
e. Click “Flash your device”
INSTALLATION, WIRING & PROGRAMMING GUIDE
Antenna: Cord length 9 feet
Installation:
Place antenna 3 inches
(minimum) from any obstructions
Orientation: Vertical; antenna
facing downwards (as seen in
diagram)
STEP 2. CONNECT
STEP 3. ADD A DEVICE/VEHICLE TO AN ACCOUNT
a. Download the App and Log into your account (see page 2 of this document for details)
b. Click the “+” sign at the bottom right of the Application screen. This will allow you to temporarily add
and configure your customers system inside your personal account. A system refers to the Antenna
being installed in the windsheild of the vehicle.
c. Before adding a system to your device, ensure the remote starter IS NOT armed/locked or in Valet
mode and set the ignition of the vehicle to the On position.
d. Then Tap to “Scan QR Code” and use the smartphone camera to scan the QR Code located on top of the
antenna.
e. Once connected, the system is in “Installer Mode”. Follow the on-screen instructions for configuring the
system.
STEP 4. PRE-CONFIGURE THE APPLICATION EXPERIENCE FOR YOUR CUSTOMER
a. Start by setting the protocol of the antenna being used. This is acheived by selecting the Brand, Model
and protocol used inside the Remote starter. When done, click on “Confirm”. System will now try to
communicate with the remote starter to confirm that all settings related to protocol are valid.
b. Once back in the control panel, click on the Settings Gear at the top right of the screen and edit the
Vehicle name, configure the Auxiliaries that might have been added (if applicable) and click “OK” when
done. Then choose the vehicle to display inside the control panel in the VEHICLE IMAGE section and
click OK.
c. When your configurations are all completed, click “OK” at the top right corner. All Configurations will
take eect.
STEP 5. TESTING THE SYSTEM
When the system is connected and fully configured, testing can begin. Test all the application functions
(Start, Stop, Lock, Unlock, Auxiliaries, Etc.) When testing is completed, tap on the “installer icon” at the top
of control screen. When prompted Click “Yes, and delete system from account” since this is the installer
mode and not the End User mode. This will make the system “Ready for Customer Delivery”.
Also make sure that the Owners Card is handed to the Owner of the vehicle or attached to the vehicle
keychain. Doing this will ensure that the instructions on how to setup their App, Account and add the Sys-
tem is done correctly by using the system QR Code axed on the windsheild mounted antenna.
NOTE : UNDER ANY CIRCUMSTANCES, PLEASE DO NOT REMOVE THE QR CODE FROM THE ANTENNA!
INSTALLATION, WIRING & PROGRAMMING GUIDE
6
PARTS REQUIRED FOR INSTALLATION OF : iDATASTART VWx
XTX-3000 IVU-CAB-4W iDatastart VWx
STEP 1. CONFIGURE THE REMOTE STARTER
The ADS Weblink (ADS-USB) is required to properly configure the iDatastart VWx remote starter to accept
the RF kit system. When flashing the iDatastart VWx remote starter, please follow this procedure in order
to configure correctly your remote starter.
a. Go to www.idatalink.com and click on “Flash your module”
b. Using the new Weblink configurator, Choose
vehicle Make, Year, Model, Trim.
c. In the Remote Configuration section, Select the Brand drop-
down and Choose “CONNECTED” and select the Connected RF
system you are using.
d. This will load a firmware starting with: “IDPP-XX(XX)-XXX (X.X)”
e. Click “Flash your device”
INSTALLATION, WIRING & PROGRAMMING GUIDE
STEP 2. CONNECT
STEP 3. ADD A DEVICE/VEHICLE TO AN ACCOUNT
a. Download the App and Log into your account (see page 2 of this document for details)
b. Click the “+” sign at the bottom right of the Application screen. This will allow you to temporarily add
and configure your customers system inside your personal account. A system refers to the Antenna
being installed in the windsheild of the vehicle.
c. Before adding a system to your device, ensure the remote starter IS NOT armed/locked or in Valet mode
and set the ignition of the vehicle to the On position.
d. Then Tap to “Scan QR Code” and use the smartphone camera to scan the QR Code located on top of the
antenna.
e. Once connected, the system is in “Installer Mode”. Follow the on-screen instructions for configuring the
system.
STEP 4. PRE-CONFIGURE THE APPLICATION EXPERIENCE FOR YOUR CUSTOMER
a. Start by setting the protocol of the antenna being used. This is acheived by selecting the Brand, Model
and protocol used inside the Remote starter. When done, click on “Confirm”. System will now try to
communicate with the remote starter to confirm that all settings related to protocol are valid.
b. Once back in the control panel, click on the Settings Gear at the top right of the screen and edit the
Vehicle name, configure the Auxiliaries that might have been added (if applicable) and click “OK” when
done. Then choose the vehicle to display inside the control panel in the VEHICLE IMAGE section and
click OK.
c. When your configurations are all completed, click “OK” at the top right corner. All Configurations will
take eect.
STEP 5. TESTING THE SYSTEM
When the system is connected and fully configured, testing can begin. Test all the application functions
(Start, Stop, Lock, Unlock, Auxiliaries, Etc.) When testing is completed, tap on the “installer icon” at the top
of control screen. When prompted Click “Yes, and delete system from account” since this is the installer
mode and not the End User mode. This will make the system “Ready for Customer Delivery”.
Also make sure that the Owners Card is handed to the Owner of the vehicle or attached to the vehicle
keychain. Doing this will ensure that the instructions on how to setup their App, Account and add the Sys-
tem is done correctly by using the system QR Code axed on the windsheild mounted antenna.
NOTE : UNDER ANY CIRCUMSTANCES, PLEASE DO NOT REMOVE THE QR CODE FROM THE ANTENNA!
Antenna: Cord length 9 feet
Installation:
Place antenna 3 inches
(minimum) from any obstructions
Orientation: Vertical; antenna
facing downwards (as seen in
diagram)
INSTALLATION, WIRING & PROGRAMMING GUIDE
8
PARTS REQUIRED FOR INSTALLATION OF : iDATASTART BM or BZ
XTX-3000 IVU-CAB-4W iDatastart BM or BZ
STEP 1. CONFIGURE THE REMOTE STARTER
The ADS Weblink (ADS-USB) is required to properly configure the iDatastart BM or BZ remote starter
to accept the RF kit system. When flashing the iDatastart BM or BZ remote starter, please follow this
procedure in order to configure correctly your remote starter.
a. Go to www.idatalink.com and click on “Flash your module”
b. Choose vehicle Make, Model, Year, Trim
c. Choose “CONNECTED RF KIT & Telematics”
d. This will load a firmware starting with: “IDPP-XX(XX)-XXX (X.X)”
e. Click “Flash!”
INSTALLATION, WIRING & PROGRAMMING GUIDE
Antenna: Cord length 9 feet
Installation:
Place antenna 3 inches
(minimum) from any obstructions
Orientation: Vertical; antenna
facing downwards (as seen in
diagram)
STEP 2. CONNECT
STEP 3. ADD A DEVICE/VEHICLE TO AN ACCOUNT
a. Download the App and Log into your account (see page 2 of this document for details)
b. Click the “+” sign at the bottom right of the Application screen. This will allow you to temporarily add
and configure your customers system inside your personal account. A system refers to the Antenna
being installed in the windsheild of the vehicle.
c. Before adding a system to your device, ensure the remote starter IS NOT armed/locked or in Valet mode
and set the ignition of the vehicle to the On position.
d. Then Tap to “Scan QR Code” and use the smartphone camera to scan the QR Code located on top of the
antenna.
e. Once connected, the system is in “Installer Mode”. Follow the on-screen instructions for configuring the
system.
STEP 4. PRE-CONFIGURE THE APPLICATION EXPERIENCE FOR YOUR CUSTOMER
a. Start by setting the protocol of the antenna being used. This is acheived by selecting the Brand, Model
and protocol used inside the Remote starter. When done, click on “Confirm”. System will now try to
communicate with the remote starter to confirm that all settings related to protocol are valid.
b. Once back in the control panel, click on the Settings Gear at the top right of the screen and edit the
Vehicle name, configure the Auxiliaries that might have been added (if applicable) and click “OK” when
done. Then choose the vehicle to display inside the control panel in the VEHICLE IMAGE section and
click OK.
c. When your configurations are all completed, click “OK” at the top right corner. All Configurations will
take eect.
STEP 5. TESTING THE SYSTEM
When the system is connected and fully configured, testing can begin. Test all the application functions
(Start, Stop, Lock, Unlock, Auxiliaries, Etc.) When testing is completed, tap on the “installer icon” at the top
of control screen. When prompted Click “Yes, and delete system from account” since this is the installer
mode and not the End User mode. This will make the system “Ready for Customer Delivery”.
Also make sure that the Owners Card is handed to the Owner of the vehicle or attached to the vehicle
keychain. Doing this will ensure that the instructions on how to setup their App, Account and add the Sys-
tem is done correctly by using the system QR Code axed on the windsheild mounted antenna.
NOTE : UNDER ANY CIRCUMSTANCES, PLEASE DO NOT REMOVE THE QR CODE FROM THE ANTENNA!
INSTALLATION, WIRING & PROGRAMMING GUIDE
10
PARTS REQUIRED FOR INSTALLATION OF : AKX or OEM
XTX-3000 IVU-CAB-4W AKX or OEM
STEP 1. CONFIGURE THE REMOTE STARTER
The ADS Weblink (ADS-USB) is required to properly configure the AKX or OEM remote starter to accept
the RF kit system. When flashing the AKX or OEM remote starter, please follow this procedure in order to
configure correctly your remote starter.
a. Go to www.idatalink.com and click on “Flash your module”
b. Choose vehicle Make, Model, Year, Trim
c. Choose “CONNECTED RF KIT & Telematics”
d. This will load a firmware starting with: “IDPP-XX(XX)-XXX (X.X)”
e. Click “Flash!”
INSTALLATION, WIRING & PROGRAMMING GUIDE
Antenna: Cord length 9 feet
Installation:
Place antenna 3 inches
(minimum) from any obstructions
Orientation: Vertical; antenna
facing downwards (as seen in
diagram)
STEP 2. CONNECT
STEP 3. ADD A DEVICE/VEHICLE TO AN ACCOUNT
a. Download the App and Log into your account (see page 2 of this document for details)
b. Click the “+” sign at the bottom right of the Application screen. This will allow you to temporarily add
and configure your customers system inside your personal account. A system refers to the Antenna
being installed in the windsheild of the vehicle.
c. Before adding a system to your device, ensure the remote starter IS NOT armed/locked or in Valet mode
and set the ignition of the vehicle to the On position.
d. Then Tap to “Scan QR Code” and use the smartphone camera to scan the QR Code located on top of the
antenna.
e. Once connected, the system is in “Installer Mode”. Follow the on-screen instructions for configuring the
system.
STEP 4. PRE-CONFIGURE THE APPLICATION EXPERIENCE FOR YOUR CUSTOMER
a. Start by setting the protocol of the antenna being used. This is acheived by selecting the Brand, Model
and protocol used inside the Remote starter. When done, click on “Confirm”. System will now try to
communicate with the remote starter to confirm that all settings related to protocol are valid.
b. Once back in the control panel, click on the Settings Gear at the top right of the screen and edit the
Vehicle name, configure the Auxiliaries that might have been added (if applicable) and click “OK” when
done. Then choose the vehicle to display inside the control panel in the VEHICLE IMAGE section and
click OK.
c. When your configurations are all completed, click “OK” at the top right corner. All Configurations will
take eect.
STEP 5. TESTING THE SYSTEM
When the system is connected and fully configured, testing can begin. Test all the application functions
(Start, Stop, Lock, Unlock, Auxiliaries, Etc.) When testing is completed, tap on the “installer icon” at the top
of control screen. When prompted Click “Yes, and delete system from account” since this is the installer
mode and not the End User mode. This will make the system “Ready for Customer Delivery”.
Also make sure that the Owners Card is handed to the Owner of the vehicle or attached to the vehicle
keychain. Doing this will ensure that the instructions on how to setup their App, Account and add the Sys-
tem is done correctly by using the system QR Code axed on the windsheild mounted antenna.
NOTE : UNDER ANY CIRCUMSTANCES, PLEASE DO NOT REMOVE THE QR CODE FROM THE ANTENNA!
INSTALLATION, WIRING & PROGRAMMING GUIDE
12
PARTS REQUIRED FOR INSTALLATION OF : ADS-AL-CA / OL-MDB-ALL
XTX-3000 IVU-CAB-4W ADS-AL-CA / OL-
MDB-ALL
HRN-CRF-02
STEP 1. CONFIGURE THE REMOTE STARTER
The ADS Weblink (ADS-USB) is required to properly configure the ADS-AL-CA remote starter to accept
the RF kit system. When flashing the ADS-AL-CA remote starter, please follow this procedure in order to
configure correctly your remote starter.
a. Go to www.idatalink.com and click on “Flash your module”
b. Choose vehicle Make, Model, Year, Trim
c. Choose “CONNECTED SmartControl”
d. This will load a firmware starting with: “RFP-XX(XX)-XXX (X.X)”
e. Click “Flash!”
INSTALLATION, WIRING & PROGRAMMING GUIDE
Antenna: Cord length 9 feet
Installation:
Place antenna 3 inches
(minimum) from any obstructions
Orientation: Vertical; antenna
facing downwards (as seen in
diagram)
HRN-CRF-02
(+) 12V BATTERY
(1)
GROUND
(1)
3
(1) Connect when using with ADS-AL-CA.
STEP 2. CONNECT
STEP 3. ADD A DEVICE/VEHICLE TO AN ACCOUNT
a. Download the App and Log into your account (see page 2 of this document for details)
b. Click the “+” sign at the bottom right of the Application screen. This will allow you to temporarily add
and configure your customers system inside your personal account. A system refers to the Antenna
being installed in the windsheild of the vehicle.
c. Before adding a system to your device, ensure the remote starter IS NOT armed/locked or in Valet mode
and set the ignition of the vehicle to the On position.
d. Then Tap to “Scan QR Code” and use the smartphone camera to scan the QR Code located on top of the
antenna.
e. Once connected, the system is in “Installer Mode”. Follow the on-screen instructions for configuring the
system.
STEP 4. PRE-CONFIGURE THE APPLICATION EXPERIENCE FOR YOUR CUSTOMER
a. Start by setting the protocol of the antenna being used. This is acheived by selecting the Brand, Model
and protocol used inside the Remote starter. When done, click on “Confirm”. System will now try to
communicate with the remote starter to confirm that all settings related to protocol are valid.
b. Once back in the control panel, click on the Settings Gear at the top right of the screen and edit the
Vehicle name, configure the Auxiliaries that might have been added (if applicable) and click “OK” when
done. Then choose the vehicle to display inside the control panel in the VEHICLE IMAGE section and
click OK.
c. When your configurations are all completed, click “OK” at the top right corner. All Configurations will
take eect.
STEP 5. TESTING THE SYSTEM
When the system is connected and fully configured, testing can begin. Test all the application functions
(Start, Stop, Lock, Unlock, Auxiliaries, Etc.) When testing is completed, tap on the “installer icon” at the top
of control screen. When prompted Click “Yes, and delete system from account” since this is the installer
mode and not the End User mode. This will make the system “Ready for Customer Delivery”.
Also make sure that the Owners Card is handed to the Owner of the vehicle or attached to the vehicle
keychain. Doing this will ensure that the instructions on how to setup their App, Account and add the Sys-
tem is done correctly by using the system QR Code axed on the windsheild mounted antenna.
NOTE : UNDER ANY CIRCUMSTANCES, PLEASE DO NOT REMOVE THE QR CODE FROM THE ANTENNA!
INSTALLATION, WIRING & PROGRAMMING GUIDE
14
PARTS REQUIRED FOR INSTALLATION OF : FLASHLOGIC FL-CAN
XTX-3000 IVU-CAB-4W Flashlogic FL-CAN HRN-CRF-02
STEP 1. CONFIGURE THE REMOTE STARTER
The ADS Weblink (ADS-USB) is required to properly configure the Flashlogic FL-CAN remote starter to
accept the RF kit system. When flashing the Flashlogic FL-CAN remote starter, please follow this proce-
dure in order to configure correctly your remote starter.
a. Go to www.flashlogic.com and click on “Flash your module”
b. Choose vehicle Make, Model, Year, Trim
c. Choose “ASCLBTLR”
d. This will load a firmware starting with: “CFLI-XX(XX)-XXX (X.X)”
e. Click “Flash!”
INSTALLATION, WIRING & PROGRAMMING GUIDE
Antenna: Cord length 9 feet
Installation:
Place antenna 3 inches
(minimum) from any obstructions
Orientation: Vertical; antenna
facing downwards (as seen in
diagram)
HRN-CRF-02
(+) 12V BATTERY
(1)
GROUND
(1)
3
(1) Connect when using with FL-CAN.
STEP 2. CONNECT
STEP 3. ADD A DEVICE/VEHICLE TO AN ACCOUNT
a. Download the App and Log into your account (see page 2 of this document for details)
b. Click the “+” sign at the bottom right of the Application screen. This will allow you to temporarily add and
configure your customers system inside your personal account. A system refers to the Antenna being
installed in the windsheild of the vehicle.
c. Before adding a system to your device, ensure the remote starter IS NOT armed/locked or in Valet mode
and set the ignition of the vehicle to the On position.
d. Then Tap to “Scan QR Code” and use the smartphone camera to scan the QR Code located on top of the
antenna.
e. Once connected, the system is in “Installer Mode”. Follow the on-screen instructions for configuring the
system.
STEP 4. PRE-CONFIGURE THE APPLICATION EXPERIENCE FOR YOUR CUSTOMER
a. Start by setting the protocol of the antenna being used. This is acheived by selecting the Brand, Model and
protocol used inside the Remote starter. When done, click on “Confirm”. System will now try to commu-
nicate with the remote starter to confirm that all settings related to protocol are valid.
b. Once back in the control panel, click on the Settings Gear at the top right of the screen and edit the Vehicle
name, configure the Auxiliaries that might have been added (if applicable) and click “OK” when done.
Then choose the vehicle to display inside the control panel in the VEHICLE IMAGE section and click OK.
c. When your configurations are all completed, click “OK” at the top right corner. All Configurations will take
eect.
STEP 5. TESTING THE SYSTEM
When the system is connected and fully configured, testing can begin. Test all the application functions
(Start, Stop, Lock, Unlock, Auxiliaries, Etc.) When testing is completed, tap on the “installer icon” at the top
of control screen. When prompted Click “Yes, and delete system from account” since this is the installer
mode and not the End User mode. This will make the system “Ready for Customer Delivery”.
Also make sure that the Owners Card is handed to the Owner of the vehicle or attached to the vehicle
keychain. Doing this will ensure that the instructions on how to setup their App, Account and add the Sys-
tem is done correctly by using the system QR Code axed on the windsheild mounted antenna.
NOTE : UNDER ANY CIRCUMSTANCES, PLEASE DO NOT REMOVE THE QR CODE FROM THE ANTENNA!
INSTALLATION, WIRING & PROGRAMMING GUIDE
16
PARTS REQUIRED FOR INSTALLATION OF : FLASHLOGIC FL-CAN
XTX-3000 IVU-CAB-4W Flashlogic FL-CAN HRN-CRF-02
STEP 1. CONFIGURE THE REMOTE STARTER
The ADS Weblink (ADS-USB) is required to properly configure the Flashlogic FL-CAN remote starter to
accept the RF kit system. When flashing the Flashlogic FL-CAN remote starter, please follow this proce-
dure in order to configure correctly your remote starter.
a. Go to www.flashlogic.com and click on “Flash your module”
b. Choose vehicle Make, Model, Year, Trim
c. Choose “ASCLBTLR”
d. This will load a firmware starting with: “CFLI-XX(XX)-XXX (X.X)”
e. Click “Flash!”
INSTALLATION, WIRING & PROGRAMMING GUIDE
Antenna: Cord length 9 feet
Installation:
Place antenna 3 inches
(minimum) from any obstructions
Orientation: Vertical; antenna
facing downwards (as seen in
diagram)
HRN-CRF-02
(+) 12V BATTERY
(1)
GROUND
(1)
3
(1) Connect when using with FL-CAN.
STEP 2. CONNECT
STEP 3. ADD A DEVICE/VEHICLE TO AN ACCOUNT
a. Download the App and Log into your account (see page 2 of this document for details)
b. Click the “+” sign at the bottom right of the Application screen. This will allow you to temporarily add
and configure your customers system inside your personal account. A system refers to the Antenna
being installed in the windsheild of the vehicle.
c. Before adding a system to your device, ensure the remote starter IS NOT armed/locked or in Valet mode
and set the ignition of the vehicle to the On position.
d. Then Tap to “Scan QR Code” and use the smartphone camera to scan the QR Code located on top of the
antenna.
e. Once connected, the system is in “Installer Mode”. Follow the on-screen instructions for configuring the
system.
STEP 4. PRE-CONFIGURE THE APPLICATION EXPERIENCE FOR YOUR CUSTOMER
a. Start by setting the protocol of the antenna being used. This is acheived by selecting the Brand, Model
and protocol used inside the Remote starter. When done, click on “Confirm”. System will now try to
communicate with the remote starter to confirm that all settings related to protocol are valid.
b. Once back in the control panel, click on the Settings Gear at the top right of the screen and edit the
Vehicle name, configure the Auxiliaries that might have been added (if applicable) and click “OK” when
done. Then choose the vehicle to display inside the control panel in the VEHICLE IMAGE section and
click OK.
c. When your configurations are all completed, click “OK” at the top right corner. All Configurations will
take eect.
STEP 5. TESTING THE SYSTEM
When the system is connected and fully configured, testing can begin. Test all the application functions
(Start, Stop, Lock, Unlock, Auxiliaries, Etc.) When testing is completed, tap on the “installer icon” at the top
of control screen. When prompted Click “Yes, and delete system from account” since this is the installer
mode and not the End User mode. This will make the system “Ready for Customer Delivery”.
Also make sure that the Owners Card is handed to the Owner of the vehicle or attached to the vehicle
keychain. Doing this will ensure that the instructions on how to setup their App, Account and add the Sys-
tem is done correctly by using the system QR Code axed on the windsheild mounted antenna.
NOTE : UNDER ANY CIRCUMSTANCES, PLEASE DO NOT REMOVE THE QR CODE FROM THE ANTENNA!
INSTALLATION, WIRING & PROGRAMMING GUIDE
18
PARTS REQUIRED FOR INSTALLATION OF : FLASHLOGIC FLRS
XTX-3000 IVU-CAB-4W Flashlogic FLRS
STEP 1. CONFIGURE THE REMOTE STARTER
The ADS Weblink (ADS-USB) is required to properly configure the Flashlogic FLRS remote starter to accept
the RF kit system. When flashing the Flashlogic FLRS remote starter, please follow this procedure in order
to configure correctly your remote starter.
a. Go to www.flashlogic.com and click on “Flash your module”
b. Choose vehicle Make, Model, Year, Trim
c. Choose “ASCLBTLR”
d. This will load a firmware starting with: “CFLI-XX(XX)-XXX (X.X)”
e. Click “Flash!”
INSTALLATION, WIRING & PROGRAMMING GUIDE
Antenna: Cord length 9 feet
Installation:
Place antenna 3 inches
(minimum) from any obstructions
Orientation: Vertical; antenna
facing downwards (as seen in
diagram)
STEP 2. CONNECT
STEP 3. ADD A DEVICE/VEHICLE TO AN ACCOUNT
a. Download the App and Log into your account (see page 2 of this document for details)
b. Click the “+” sign at the bottom right of the Application screen. This will allow you to temporarily add
and configure your customers system inside your personal account. A system refers to the Antenna
being installed in the windsheild of the vehicle.
c. Before adding a system to your device, ensure the remote starter IS NOT armed/locked or in Valet mode
and set the ignition of the vehicle to the On position.
d. Then Tap to “Scan QR Code” and use the smartphone camera to scan the QR Code located on top of the
antenna.
e. Once connected, the system is in “Installer Mode”. Follow the on-screen instructions for configuring the
system.
STEP 4. PRE-CONFIGURE THE APPLICATION EXPERIENCE FOR YOUR CUSTOMER
a. Start by setting the protocol of the antenna being used. This is acheived by selecting the Brand, Model
and protocol used inside the Remote starter. When done, click on “Confirm”. System will now try to
communicate with the remote starter to confirm that all settings related to protocol are valid.
b. Once back in the control panel, click on the Settings Gear at the top right of the screen and edit the
Vehicle name, configure the Auxiliaries that might have been added (if applicable) and click “OK” when
done. Then choose the vehicle to display inside the control panel in the VEHICLE IMAGE section and
click OK.
c. When your configurations are all completed, click “OK” at the top right corner. All Configurations will
take eect.
STEP 5. TESTING THE SYSTEM
When the system is connected and fully configured, testing can begin. Test all the application functions
(Start, Stop, Lock, Unlock, Auxiliaries, Etc.) When testing is completed, tap on the “installer icon” at the top
of control screen. When prompted Click “Yes, and delete system from account” since this is the installer
mode and not the End User mode. This will make the system “Ready for Customer Delivery”.
Also make sure that the Owners Card is handed to the Owner of the vehicle or attached to the vehicle
keychain. Doing this will ensure that the instructions on how to setup their App, Account and add the Sys-
tem is done correctly by using the system QR Code axed on the windsheild mounted antenna.
NOTE : UNDER ANY CIRCUMSTANCES, PLEASE DO NOT REMOVE THE QR CODE FROM THE ANTENNA!
INSTALLATION, WIRING & PROGRAMMING GUIDE
20
PARTS REQUIRED FOR INSTALLATION OF : FLASHLOGIC FLRSBA
XTX-3000 IVU-CAB-4W Flashlogic FLRSBA
STEP 1. CONFIGURE THE REMOTE STARTER
The ADS Weblink (ADS-USB) is required to properly configure the Flashlogic FLRSBA remote starter
to accept the RF kit system. When flashing the Flashlogic FLRSBA remote starter, please follow this
procedure in order to configure correctly your remote starter.
a. Go to www.flashlogic.com and click on “Flash your module”
b. Using the new Weblink configurator, Choose
vehicle Make, Year, Model, Trim.
c. In the Remote Configuration section, Select the Brand drop-
down and Choose “Code Alarm, Prestige or Pursuit”.
d. This will load a firmware starting with:
“ICO-BA-XXX-XXX”
or
“IVO-BA-XXX-XXX”
e. Click “Flash your device”
INSTALLATION, WIRING & PROGRAMMING GUIDE
Table of contents
Popular Automobile Accessories manuals by other brands
BASETech
BASETech KUC-1000 operating instructions
Rear view safety
Rear view safety RVS-770613 Product manual instaliation instructions
Caliber
Caliber PMT 550BT user manual
RHINO
RHINO VSDS-RVM4.3 Installation & operation manual
Aldor Automotive
Aldor Automotive FOR1TRSU Assembly manual
IRONguard
IRONguard PowerTower Hitch Hauler Operators safety manual
