8
2Turn the end of the suction hose counter-clockwise, and
remove the end of the hose from the inlet of the vacuum
cleaner.
3Release the fastening of the upper cover (5), and open it.
4Remove the CYKLON dust container from the vacuum
cleaner. In order to do this hold the body of the vacuum
cleaner by one hand, grab the special handgrip situated on
the cover of the dust container by the other, and by holding
it like that gently remove the CYKLON dust container out of
the vacuum cleaner.
5Pull the fastenings on the cover of the CYKLON dust
container aside, and remove the cover from the container.
6Move the CYKLON dust container over a dustbin, and
empty its contents.
After doing this, check the HEPA basic lter,
and clean or replace it, if necessary.
7Place the cover of the CYKLON dust container on the
container in such a way that the fastening situated in the
front part of the cover is inserted into the projection of the
container. Press the back part of the cover in such a way that
the fastenings are shut tight on the body of the container.
The CYKLON dust container has to be shut
tight. Otherwise, the suction power of the
vacuum cleaner is going to drop.
8Place the emptied CYKLON dust container into the
chamber of the vacuum cleaner. Close the upper cover of the
vacuum cleaner by pressing it, until you hear a characteristic
“click.”
It is necessary to empty the CYKLON dust container, if you
notice that:
a) the vacuum cleaner works less efciently,
b) the CYKLON dust container is full.
Deinstalling the lters
The vacuum cleaner is equipped with the CYKLON dust
container based on cyclone ltration, making it possible to
use the vacuum cleaner without a dust bag. A cyclone lter
uses air stream swirling to separate solid dirt. Separation
of dirt is done in an O-shaped part of the container, where
the swirling air casts away dirt on the wall of the container,
and then through the hole into the adjacent chamber of the
container. This pre-ltered air is directed into the washable
HEPA conical lter stopping the tiniest fractions of dust.
A special ltration material used in the washable HEPA lter
makes it possible to rinse the lter with running water, if it is
dirty, and reuse it later.
At the outlet of the vacuum cleaner there is a microlter
installed.
In case the HEPA basic lter (14) or the outlet
microlter (13) are dirty, they can be replaced
with new ones, cleaned or rinsed with running
water.
It is forbidden to wash lters in washing
machines or dishwashers.
Filters may be dried only naturally.
Do not use hairdryers, heaters or radiators to
dry lters.
Before replacing the lters make sure the
vacuum cleaner is off, and the plug of the cord
is unplugged from the socket.
HEPA BASIC FILTER
It is necessary to periodically clean the HEPA basic lter to
remove small fractions of dust.
Remove the CYKLON dust container and empty it, as
described in para. C.
1Pull the fastenings on the cover of the CYKLON dust
container aside, and remove the cover from the container.
If the CYKLON dust container is full, empty it as described in
para. C.
2 Remove the protective casing of the HEPA basic lter out
of the dust container. In order to do this turn the protective
casing of the HEPA basic lter in the direction given on
the symbol “ ” (it is situated along with an arrow on the
protective casing of the HEPA basic lter).
●Clean, wipe, and carefully dry the casing.
3 Remove the HEPA basic lter from the container.
●Clean the pleats of the HEPA basic lter (14), and if the
lter is damaged, it should be denitely replaced with
a new one. If the HEPA basic lter (14) is dirty, you may
replace it with a new one, clean it or rinse it with running
water. Before reinstalling the lter, make sure it is dry.
For safety reasons it is unacceptable to install
a wet or damaged HEPA basic lter (14).
4 Place the new/rinsed HEPA basic lter (14) in the
previously determined spot in the dust container.
5 Situate the protective casing of the HEPA basic lter in
the chamber of the container, in the previously determined
spot. Pay attention that the protrusions situated on the ange
of the container are inserted in the sockets of the body of the
container.
6 Turn the protective casing of the HEPA basic lter in the
direction given on the symbol “ ” (it is situated along with
an arrow on the protective casing of the HEPA basic lter).
7Place the cover of the CYKLON dust container on the
container in such a way that the fastening situated in the
front part of the cover is inserted into the projection of the
container. Press the back part of the cover in such a way that
the fastenings are shut tight on the body of the container.
8Situate the CYKLON dust container with the installed
HEPA basic lter (14) in the chamber of the vacuum cleaner.
Close the upper cover of the vacuum cleaner by pressing it,
until you hear a characteristic “click.”
D
