Contec DS-280H Series User manual

Digital Signage Player
Athlon X2 2.8GHz, SSD, POSReady7, HDMIx4
DS-280H Series
User’s Manual
CONTEC CO.,LTD.

DS-280H Series User’s Manual i
Check Your Package
Thank you for purchasing the CONTEC product.
The product consists of the items listed below.
Check, with the following list, that your package is complete. If you discover damaged or missing items,
contact your retailer.
Product Configuration List
DS-280H-DC6413
Name Pcs.
The main body 1
AC adapter 1
AC cable *1 1
Product guide 1
Warranty Certificate 1
POSReady7 End User License Agreement 1
Setup Manual 1
Serial number label 1
GHOST End User License Agreement 1
Preinstall OS Recovery Procedures 1
Recovery Media 1
*1 Do not use this AC power cable with any devices except for an attached AC adaptor.
Product Configuration Image
* See the Product Configuration List to check if all the components are included for the specified number of units.

ii DS-280H Series User’s Manual
Copyright
Copyright 2012 CONTEC CO., LTD. ALL RIGHTS RESERVED.
No part of this document may be copied or reproduced in any form by any means without prior written
consent of CONTEC CO., LTD.
CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this
document.
The information in this document is subject to change without notice.
All relevant issues have been considered in the preparation of this document. Should you notice an
omission or any questionable item in this document, please feel free to notify CONTEC CO., LTD.
Regardless of the foregoing statement, CONTEC assumes no responsibility for any errors that may
appear in this document or for results obtained by the user as a result of using this product.
Trademarks
Intel, Intel Atom, Intel Core and Celeron are registered trademarks of Intel Corporation. MS, Microsoft
and Windows are trademarks of Microsoft Corporation. Other brand and product names are trademarks
of their respective holder.

DS-280H Series User’s Manual iii
Table of Contents
Check your package.................................................................................................................................i
Copyright.................................................................................................................................................ii
Trademarks..............................................................................................................................................ii
Table of Contents ...................................................................................................................................iii
1. INTRODUCTION 1
About the Product ...................................................................................................................................1
Features.............................................................................................................................................1
Supported OS ...................................................................................................................................1
Customer Support....................................................................................................................................2
Web Site ...........................................................................................................................................2
Limited One-Year Warranty...................................................................................................................2
How to Obtain Service............................................................................................................................2
Liability ...................................................................................................................................................2
Safety Precautions...................................................................................................................................3
Safety Information ...........................................................................................................................3
Caution on the DS-280H Series ......................................................................................................3
2. SYSTEM REFERENCE 5
Specification............................................................................................................................................5
Physical Dimensions...............................................................................................................................6
3. HARDWARE SETUP 7
Before Using the Product for the First Time..........................................................................................7
Hardware Setup.......................................................................................................................................8
Installation Requirements ................................................................................................................8
4. EACH COMPONENT FUNCTION 9
Component Name....................................................................................................................................9
Component Function.............................................................................................................................10
DC Power Input Connector: DC-IN..............................................................................................10
POWER SW: POWER-SW...........................................................................................................10
Display Interface: HDMI...............................................................................................................10
USB Ports.......................................................................................................................................10
Line in Interface: LINE IN ............................................................................................................10
Line out Interface: LINE OUT ......................................................................................................10
Giga bit-Ethernet: LAN A – B ......................................................................................................11
Serial Port Interface : SERIAL COM1/COM2.............................................................................12

iv DS-280H Series User’s Manual
5. BIOS SETUP 13
Introduction............................................................................................................................................13
Starting Setup .................................................................................................................................13
Using Setup.....................................................................................................................................13
Getting Help....................................................................................................................................13
In Case of Problems........................................................................................................................14
A Final Note About Setup..............................................................................................................14
Main .......................................................................................................................................................15
Standard CMOS Features......................................................................................................................16
Advanced BIOS Features...............................................................................................................18
Advanced Chipset Features............................................................................................................20
PCIE Configuration........................................................................................................................21
IGX Configuration.................................................................................................................................22
Integrated Peripherals............................................................................................................................23
Onboard Devices ...................................................................................................................................24
OnChip SATA Device...........................................................................................................................25
OnChip Azalia Device...........................................................................................................................26
USB Device setting ...............................................................................................................................27
Power Management Setup.....................................................................................................................28
PNP/PCI Configurations .......................................................................................................................29
PC Health Status....................................................................................................................................30
Frequency/Voltage Control...................................................................................................................31
Defaults Menu........................................................................................................................................32
Supervisor /User Password Setting.......................................................................................................33
Exit Selecting.........................................................................................................................................34
6. APPENDIX 35
Battery....................................................................................................................................................35
7. LIST OF OPTIONS 37

1. Introduction
DS-280H Series User’s Manual 1
1. Introduction
About the Product
This is STB for signage, working with AMD Athlon™ II 2.8G CPU and ATI Radeon™ E4690 GPU with
enhanced graphics performance helps Full-HD movie to be played smoothly with 4 ports HDMI interface.
SSD can be installed as storage. The body is so compact and supports SATA interface which can
transport data at high speed. It enables you to read high-quality movie, store so big data and transport data
at high bit rate.
DS Series are the products assumed to be used at ordinary environment and market as
"Digital Signage".Operating environment condition, supply period, maintenance period
and other conditions are different from ones of our industrial products (IPC Series,
BOX-PC, PT-Series and others).For details, please consult our retailer.
Features
- Equipped with four-port HDMI display output (Supported 1080p)
This product has four-port HDMI display output which supports 1080p. It makes it possible to
display on quad monitors.
- High performance dual core CPU
This product also has AMD Athlon II XLT V66C 2.8GHz (TDP45W). It supports applications which
require high-speed processing.
- Dual configuration with discrete GPU and GPU which features integrated chipset
This product is equipped with discrete GPU (Radeon E4690) and GPU (Radeon HD3200) which is
integrated with AMD 780E chipset. They support advanced graphics processing
- Major types of peripherals are supported with rich interfaces
It has a variety of extended interface such as HDMI x4, 1000BASE-T x1, USB2.0 x 4, serial
(RS-232C) x2.
So it can be used for various purposes.
- Pre-installed Windows Embedded POSReady 7
The OS, Windows Embedded POSReady 7 which is perfect for digital signage use, is pre-installed.
There are many functions on this product. Such as write filters (EWF: Enhanced Write Filter and
FBWF: File-Based Write Filter) and Microsoft Office Viewer that is a file browser for Word, Excel
and PowerPoint.
- Kinect for Windows Runtime (Pre-installed model)
The installed OS is already equipped with a Runtime module which is required on OS side to trip
Kinect for Windows sensor.You can use this product as an application controller which is equipped
with NUI (Natural User Interface ) that features a control with voice or gestures.
Supported OS
- Windows Embedded POSReady7

1. Introduction
2DS-280H Series User’s Manual
Customer Support
CONTEC provides the following support services for you to use CONTEC products more efficiently and
comfortably.
Web Site
Japanese http://www.contec.co.jp/
English http://www.contec.com/
Chinese http://www.contec.com.cn/
Latest product information
CONTEC provides up-to-date information on products.
CONTEC also provides product manuals and various technical documents in the PDF.
Free download
You can download updated driver software and differential files as well as sample programs available in
several languages.
Note! For product information
Contact your retailer if you have any technical question about a CONTEC product or need its price,
delivery time, or estimate information.
Limited One-Year Warranty
CONTEC products are warranted by CONTEC CO., LTD. to be free from defects in material and
workmanship for up to one year from the date of purchase by the original purchaser.
Repair will be free of charge only when this device is returned freight prepaid with a copy of the original
invoice and a Return Merchandise Authorization to the distributor or the CONTEC group office, from
which it was purchased.
This warranty is not applicable for scratches or normal wear, but only for the electronic circuitry and
original products. The warranty is not applicable if the device has been tampered with or damaged
through abuse, mistreatment, neglect, or unreasonable use, or if the original invoice is not included, in
which case repairs will be considered beyond the warranty policy.
How to Obtain Service
For replacement or repair, return the device freight prepaid, with a copy of the original invoice. Please
obtain a Return Merchandise Authorization number (RMA) from the CONTEC group office where you
purchased before returning any product.
* No product will be accepted by CONTEC group without the RMA number.
Liability
The obligation of the warrantor is solely to repair or replace the product. In no event will the warrantor be
liable for any incidental or consequential damages due to such defect or consequences that arise from
inexperienced usage, misuse, or malfunction of this device.

1. Introduction
DS-280H Series User’s Manual 3
Safety Precautions
Understand the following definitions and precautions to use the product safely.
Safety Information
This document provides safety information using the following symbols to prevent accidents resulting in
injury or death and the destruction of equipment and resources. Understand the meanings of these labels
to operate the equipment safely.
DANGER DANGER indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injury.
WARNING WARNING indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury or in property damage.
Caution on the DS-280H Series
Handling Precautions
DANGER
- This product supports an attached AC adapter and AC cable only.
WARNING
- Always check that the power supply is turned off before connecting or disconnecting power cables
and other cables.
- Users should not attempt to disassemble or modify this equipment, or to replace components. The
manufacturer may not be able to provide service for equipment that has been modified by the user.
- This product is not intended for use in aerospace, space, nuclear power, medical equipment, or other
applications that require a very high level of reliability. Do not use the product in such applications.
- If using this product in applications where safety is critical such as in railways, automotive, or
disaster prevention or security systems, please contact your retailer.
- Do not attempt to replace the battery as inappropriate battery replacement poses a risk of explosion.
- For battery replacement, contact your retailer as it must be performed as a process of repair.
- When disposing of a used battery, follow the disposal procedures stipulated under the relevant laws
and/or municipal ordinances.

1. Introduction
4DS-280H Series User’s Manual
CAUTION
- Do not use or store this product in a location exposed to high or low temperature that exceeds range
of specification or that is susceptible to rapid temperature changes.
Example: - Exposure to direct sun - In the vicinity of a heat source
- Do not use this product in extremely humid or dusty locations. It is extremely dangerous to use this
product when it is in concact with water or any other fluid or conductive dust. If this product must be
used in a dusty environment, install it on a dust-proof control panel, for example.
- Avoid using or storing this product in locations subject to shock or vibration that exceeds range of
specification.
- Do not use this product in the vicinity of devices that generate strong magnetic force or noise. Such
products will cause this product to malfunction.
- Do not use or store this product in the presence of chemicals.
- To clean this product, wipe it gently with a soft cloth dampened with either water or mild detergent.
Do not use chemicals or a volatile solvent, such as benzene or thinner, to prevent pealing or
discoloration of the paint.
- This product’s case may become hot. To avoid being burned, do not touch the case while this product
is in operation or immediately after turning off the power. Avoid installation in a location where
people may come into contact with the case.
- CONTEC does not provide any guarantee for the integrity of data on any recording media such as
SSD.
- Always remove the power cable from the power outlet before changing hardware configurations such
as the connection of connectors, and/or the setting of jumpers and switches.
- To prevent corruption of files, always shutdown the OS before turning off this product.
- CONTEC reserves the right to refuse to service a product modified by the user.
- In the event of failure or abnormality (unusual smells or excessive heat generation), unplug the power
cord immediately and contact your retailer.
- To connect with peripherals, use a grounded, shielded cable.
- When transporting this equipment, be careful to protect it against direct vibration and physical shock.
- You cannot clear the BIOS settings on CMOS of this product. The product must be repaired if it
becomes unbootable after the change of BIOS settings.
- Regarding “VCCI Class A Notice”
The HDMI Cable must be used in the following so that this product may suit the above-mentioned
standard.
HDMI Cable: IPC-HDMI-015 (Options)
- Caution on the VCCI Class A
この装置は、クラスA情報技術装置です。この装置を家庭環境で使用すると電波妨害を
引き起こすことがあります。この場合には使用者が適切な対策を講ずるよう要求されるこ
とがあります。 VCCI-A

2. System Reference
DS-280H Series User’s Manual 5
2. System Reference
Specification
Table 2.1. Functional Specification
Model DS-280H
CPU AMD Athlon™II 2.8GHz
Chipset AMD 780E + SB710 Chipset
BIOS Manufactured by Award
Memory 2GB, DDR2
Port 1,2
Integrated:
AMD HD3200 Graphics Core w/ side-port 128MB GDDR3 memory
-DirectXR10 & OpenGL 2.0 capable
-UVD2.0 video & display engines for HD, Blu-ray & 3D
GPU*1
Port 3,4
Discrete:
AMD E4690 GPU (320 Cores @ 600MHz; 31W) w/ 512MB GDDR3 memory (128-bit wide)
-DirectXR10.1, Shader 4.1, OpenGL 3.0 capable
-UVD2.0 video & display engines for HD, Blu-ray & 3D
Interface
Display 4port (HDMI connector x 1)
Audio Line-out x 1, 3.5 φStereo mini jack
Line-in x 1, 3.5 φStereo mini jack
Serial ATA 1-slot, 2.5inch SATA SSD, 16GB (SLC)
LAN 1port (RJ-45 Connector)
Realtek RTL8111C PCI-E Gigabit LAN Controller
USB 4ports (TYPE-A Connector x 4)
USB 2.0-compliant
RS-232C 2port (RJ-50 Connector), RI (Ring Indicator) none
Power Supply
(AC adapter specification) This product supports an attached AC adapter and AC cable ONLY.
Input voltage 100V-240VAC, 50-60Hz
Input current 2A
Rated output voltage 12VDC
Rated output current 12.5A(Max.)
Longevity*2 30,000H (temperature 25 °C FullHD movie playing)
8,700H (temperature 40 °C FullHD movie playing)
Physical dimensions (mm) 250(W) x 210(D) x 35(H) (No protrusions)
Weight About 2.1kg
Operating temperature 0 - 40 °C
Storage temperature -10 - 60 °C
Humidity 10 - 90%RH (No condensation)
Floating dust particles Not to be excessive
Corrosive gases None
*1: Clone display between port 1, 2 (HD3200) and port 3, 4 (E4690) is not available.
*2 This product are designed to use under the good condition.

2. System Reference
6DS-280H Series User’s Manual
Physical Dimensions
Figure 2.1. Physical Dimensions

3. Hardware Setup
DS-280H Series User’s Manual 7
3. Hardware Setup
- Before you start, be sure that the power is turned off.
Before Using the Product for the First Time
Follow the next steps to set up this product:
STEP1 By referring to the information in this chapter, install, connect and set this product.
STEP2 Connect cables.
Connect the cable of necessary external devices, such as keyboard and a display, to this
product using appropriate cables.
STEP3 Turn on the power.
Check if STEP1-2 were correctly done, again.
Check that AC plug is not connected, then insert DC jack of AC adapter into the product.
Insert AC plug into AC inlet. The product will wake up.
If you feel any abnormality after connection, pull out AC plug quickly,
and then check if all installation was correctly done.
*.This product supports an attached AC adapter and AC cable ONLY.
STEP4 Set up BIOS.
By referring to Chapter 5, set up BIOS. This setup requires a keyboard and a display.
* Before using this product, be sure to execute "LOAD SETUP DEFAULTS" to initialize
the BIOS settings to their default values.
(See Chapter 5, "Main Menu.")
CAUTION
Be sure to connect the keyboard and mouse to it before turning the power on for the first time.

3. Hardware Setup
8DS-280H Series User’s Manual
Hardware Setup
- Before you start, be sure that the power is turned off.
Installation Requirements
Figure 3.1. Installation Requirements
You can install this product on plastic (LCD monitor), wood, drywall surface over studs, or a solid
concrete or metal plane directly. Ensure the installer uses four M3 length 8mm screws to secure the
system on wall.
Fasteners are not included with the unit, and must be supplied by the installer. The types of fasteners
required are dependent on the type of wall construction.

4. Each Component Function
DS-280H Series User’s Manual 9
4. Each Component Function
Component Name
Figure 4.1. Component Name
Table 4.1. Component Function
Name Function
DC-IN This product supports an attached AC adapter and AC cable ONLY.
Check that AC plug is not connected, then insert DC jack of AC
adapter into the product.
Insert AC plug into AC inlet. The product will wake up.
POWER-SW Power switch
POWER LED Power ON display LED
ACCESS LED Disk access display LED
HDMI(E4690/HD3200) Display(HDMI x4)
USB USB port connector x2
LINE IN Line in (3.5φPHONE JACK)
LINE OUT Line out (3.5φPHONE JACK)
LAN Ethernet 1000BASE-T/100BASE-TX/10BASE-T RJ-45 connector
COM1 / COM2 Serial port RJ-45 connector x2

4. Each Component Function
10 DS-280H Series User’s Manual
Component Function
DC Power Input Connector: DC-IN
This product supports an attached AC adapter and AC cable only.
POWER SW: POWER-SW
POWER SW is provided.
Display Interface: HDMI
This product can be connected with HDMI input external device.
We connect the HDMI input terminal of the video equipment and the external HDMI output terminal of
this unit HDMI cable.You can connect HDMI output terminal of this product and HDMI input terminal of
external video equipment with HDMI cable.
USB Ports
This product is equipped USB 2.0 interface.
Table 4.2. USB Connector
Pin No. Signal name
1 USB_VCC
2 USB-
3 USB+
4 USB_GND
Line in Interface: LINE IN
A line in connector is provided. You can plug a microphone to this connector for sound input.
Line out Interface: LINE OUT
A line output connector is provided. You can plug a headphone or amplifer-integrated speakers into this
connector.

4. Each Component Function
DS-280H Series User’s Manual 11
Giga bit-Ethernet: LAN A – B
Connector for Giga bit-Ethernet Interface is provided.
Table 4.3. Giga bit-Ethernet Connector
Connector type RJ-45
Signal name
Pin No. 100BASE-T 1000BASE-T
1 TX+ TRD+(0)
2 TX- TRD-(0)
3 RX+ TRD+(1)
4 N.C. TRD+(2)
5 N.C. TRD-(2)
6 RX- TRD-(1)
7 N.C. TRD+(3)
8 N.C. TRD-(3)
LEDs for display of network statuses:
Right LED: Link LED
Opertion: Green Blinking
Left LED: Operation LED
10M, 100M: Green, 1000M: Orange

4. Each Component Function
12 DS-280H Series User’s Manual
Serial Port Interface : SERIAL COM1/COM2
Connector for Serial Port Interface is provided.
Table 4.4. Serial Port Interface
Connector type RJ-45
Pin No. Signal name
1 RTS Request to send
2 DTR Data terminal ready
3 TXD Transmit data
4 GND ground
5 DCD Data carrier detect
6 RXD Receive data
7 DSR Data set ready
8 CTS Clear to send
CAUTION
Do not Insert LAN Cable into Serial Port.
This product may malfunction or cause a failure.

5. BIOS Setup
DS-280H Series User’s Manual 13
5. BIOS Setup
Introduction
This chapter discusses Award’s Setup program built into the product. The Setup program allows users to
modify the basic system configuration.
Starting Setup
The Award BIOS is immediately activated when you first power on the computer.
By pressing <DEL> immediately after switching the system on, or
If the message disappears before you respond and you still wish to enter Setup, restart the system to try
again by turning it OFF then ON. You may also restart by simultaneously pressing <Ctrl>, <Alt>, and
<Delete> keys.
Using Setup
In general, you use the arrow keys to highlight items, press <Enter> to select, use the F5 and F6 keys to
change entries, press <F1> for help and press <Esc> to quit. The following table provides more detail
about how to navigate in the Setup program using the keyboard.
Table 5.1. Using Setup
Key Function
Up Arrow Move to the previous item
Down Arrow Move to the next item
Left Arrow Move to the item on the left
Right Arrow Move to the item on the right
Enter Move to the item you desired
PgUp Increase the numeric value or make changes
PgDn Decrease the numeric value or make changes
F1 key General help on Setup navigation keys
F5 key Load previous values from CMOS
F7 key Load the optimized defaults
F10 key Save all the CMOS changes and exit
Esc Main Menu : Quit without saving changes
Submenus : Exit Current page to the next higher level menu
Getting Help
Press F1 to pop up a small help window that describes the appropriate keys to use and the possible
selections for the highlighted item. To exit the Help Window press <Enter> key.

5. BIOS Setup
14 DS-280H Series User’s Manual
In Case of Problems
If, after making and saving system changes with Setup, you discover that your computer no longer is able
to boot, we should repair it
The best advice is to only alter settings which you thoroughly understand. To this end, we strongly
recommend that you avoid making any changes to the CPU defaults and the chipset defaults. These
defaults have been carefully chosen by both Insyde and your systems manufacturer to provide the
absolute maximum performance and reliability. Even a seemingly small change to them has the potential
for causing you to be repaired.
A Final Note About Setup
The information in this chapter is subject to change without notice.

5. BIOS Setup
DS-280H Series User’s Manual 15
Main
Once you enter the Award BIOS CMOS Setup Utility, the Main Menu will appear on the screen.
The Main Menu allows you to select from several setup functions and two exit choices. Use the arrow
keys to select among the items and press <Enter> to accept and enter the sub-menu.
Note that a brief description of each highlighted selection appears at the bottom of the screen.
Table 5.2. Main Menu (Display only)
Phoenix – Award WorkstationBIOS CMOS Setup Utility
▶Standard CMOS Features
▶Advanced BIOS Features
▶Advanced Chipset Features
▶Integrated Peripherals
▶Power Management Setup
▶PnP/PCI Configurations
▶PC Health Status
▶Frequency/Voltage Control
Load Fail-Safe Defaults
Load Optimized Defaults
Set Supervisor Password
Set User Password
Save & Exit Setup
Exit Without Saving
Esc : Quit ↑↓←→ : Select Item
F10 : Save & Exit Setup
