Overview
FT1 FT2 FT3
The FeatherTouch FT1, FT2, and FT3 panels, offered in 1-, 2-, and 3-button models, deliver a small
touch of custom control, ranging from 2.3" to 3.1" wide and mounting within a .75 inch depth. All
three panels easily interface with custom control systems with simple closures, each button sends one
closure to an input, and single control closure switches LED colors for feedback. Panel logic and
always-on button illumination is driven by a 5 VDC power supply. A fully custom control solution, each
panel is computer-machined from aircraft-quality aluminum.
•Features computer machined aluminum enclosure, custom-plated in a variety of metal finishes
•Snap-mounts into wood, metal and plastic surfaces
•Operates using 1-3 always-illuminated, custom-engraved buttons, select from amber/green or
red/green LEDs
•Simple contact-closure operation
•Design Forms available to define engraving, LED colors, finish, and cable
Contemporary Research 3 FT1-3

FT1-3 Specifications
Physical
FT1: 2.28" [57.91mm] wide x 1.30" [33.02mm] high x .75" [19.05mm] deep
Cut-Out: 2.06" [52.33mm] wide x 1.07" [27.18mm] high
FT2: 2.28" [57.91mm] wide x 1.30" [33.02mm] high x .75" [19.05mm] deep
Cut-Out: 2.06" [52.33mm] wide x 1.07" [27.18mm] high
FT3: 3.10" [78.74mm] wide x 1.30" [53.98mm] high x .75" [19.05mm] deep
Cut-Out: 2.88" [73.15mm] wide x 1.07" [27.18mm] high
Weight: 4 oz [113 g]
Enclosure: Machined aluminum enclosure, plated with custom finish
Mounting: Surface mounted, friction-fit, spring clips included
User Interface
Buttons: Backlit via dual-color LEDs, color indicates status
Options include amber/green or red/green LEDs
Custom-engraved keycaps
Connections
Control/Power DB-9 male connector, installed on 12” cable
Power: 5VDC (4.85V - 5.15V), FT1-23 mA, FT1-45 mA, FT1-70 mA
Switch Output: 1-3 switch closures, 330 ohms to GND when closed
Switch Input: 1-3 closure inputs for LED feedback, 3.3K ohm pull-up to +5VDC supply
Wiring: Pin 1 Chassis GND is connected to the metal bezel and should be tied to earth or
airframe GND, or left unconnected.
