Nexcom APPD 1205T User manual

NEXCOM International Co., Ltd.
NEXCOM International Co., Ltd.
Published May 2018 www.nexcom.com
IoT Automation Solutions Business Group
Applied Panel Display
APPD 1200T/1205T/1500T/1700T/1900T
User Manual

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. ii APPD 1200T/1205T/1500T/1700T/1900T User Manual
Content
Contents
Preface
Copyright ............................................................................................. iv
Disclaimer.............................................................................................. iv
Acknowledgements ............................................................................... iv
Regulatory Compliance Statements........................................................ iv
Declaration of Conformity...................................................................... iv
RoHS Compliance ................................................................................... v
Warranty and RMA ................................................................................ vi
Safety Information ................................................................................viii
Installation Recommendations...............................................................viii
Safety Precautions.................................................................................. ix
Technical Support and Assistance............................................................ x
Conventions Used in this Manual............................................................ x
Global Service Contact Information........................................................ xi
Package Contents.................................................................................xiii
Ordering Information .............................................................................xv
Chapter 1: Product Introduction
Overview - APPD 1200T/1205T ...............................................................1
Key Features ...........................................................................................1
Overview - APPD 1500T..........................................................................2
Key Features ...........................................................................................2
Overview - APPD 1700T..........................................................................3
Key Features ...........................................................................................3
Overview - APPD 1900T..........................................................................4
Key Features ...........................................................................................4
Specifications..........................................................................................5
APPD 1200T........................................................................................5
Specifications..........................................................................................6
APPD 1205T........................................................................................6
Specifications..........................................................................................7
APPD 1500T........................................................................................7
Specifications..........................................................................................8
APPD 1700T........................................................................................8
Specifications..........................................................................................9
APPD 1900T........................................................................................9
Knowing Your APPD Series ...................................................................10
Front Top View of APPD 1200T/1205T...............................................10
Front Top View of APPD 1500T..........................................................10
Front Top View of APPD 1700T..........................................................10
Front Top View of APPD 1900T..........................................................10
Front Top View in Detail.....................................................................11
Rear Bottom View of APPD 1200T/1205T ..........................................12
Rear Bottom View of APPD 1500T.....................................................12
Rear Bottom View of APPD 1700T.....................................................12
Rear Bottom View of APPD 1900T.....................................................12
Rear Bottom View in Detail................................................................13
Rear View of APPD 1200T/1205T.......................................................14
Rear View of APPD 1500T .................................................................15
Rear View of APPD 1700T .................................................................16
Rear View of APPD 1900T .................................................................17
Mechanical Dimensions.........................................................................18
APPD 1200T/1205T ...........................................................................18

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. iii APPD 1200T/1205T/1500T/1700T/1900T User Manual
Content
APPD 1500T......................................................................................19
APPD 1700T......................................................................................20
APPD 1900T......................................................................................21
Chapter 2: Connector Pin Definitions
External I/O Interfaces ...........................................................................22
USB Port............................................................................................22
COM Port..........................................................................................22
DVI Port (DVI-D).................................................................................23
VGA Port...........................................................................................23
12 – 24V DC Input ............................................................................24
Chapter 3: System Setup
Panel Mounting ....................................................................................25
Installing the Power Adapter Bracket.....................................................28
Chapter 4: Adjusting the Display
OSD Menu Functions ............................................................................33
Chapter 5: Touch Driver Settings...........................49
Appendix A: Power Consumption.........................50
Appendix B: Extended Display Identification
Data Timing Support..............................................51

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. iv APPD 1200T/1205T/1500T/1700T/1900T User Manual
Preface
Preface
Copyright
This publication, including all photographs, illustrations and software, is
protected under international copyright laws, with all rights reserved. No
part of this manual may be reproduced, copied, translated or transmitted in
any form or by any means without the prior written consent from NEXCOM
International Co., Ltd.
Disclaimer
The information in this document is subject to change without prior notice and
does not represent commitment from NEXCOM International Co., Ltd. However,
users may update their knowledge of any product in use by constantly checking
its manual posted on our website: http://www.nexcom.com. NEXCOM shall
not be liable for direct, indirect, special, incidental, or consequential damages
arising out of the use of any product, nor for any infringements upon the rights
of third parties, which may result from such use. Any implied warranties of
merchantability or fitness for any particular purpose is also disclaimed.
Acknowledgements
APPD 1200T/1205T/1500T/1700T/1900T is a trademark of NEXCOM
International Co., Ltd. All other product names mentioned herein are
registered trademarks of their respective owners.
Regulatory Compliance Statements
This section provides the FCC compliance statement for Class B devices and
describes how to keep the system CE compliant.
Declaration of Conformity
FCC
This equipment has been tested and verified to comply with the limits for
a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference
to radio communications. Operation of this equipment in a residential area
(domestic environment) is likely to cause harmful interference, in which
case the user will be required to correct the interference (take adequate
measures) at their own expense.
CE
The product(s) described in this manual complies with all applicable
European Union (CE) directives if it has a CE marking. For computer systems
to remain CE compliant, only CE-compliant parts may be used. Maintaining
CE compliance also requires proper cable and cabling techniques.

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. vAPPD 1200T/1205T/1500T/1700T/1900T User Manual
Preface
RoHS Compliance
NEXCOM RoHS Environmental Policy and Status
Update
This publication, including all photographs, illustrations
and software, is protected under international copyright
laws, with all rights reserved. No part of this manual
may be reproduced, copied, translated or transmitted in any form or by any
means without the prior written consent from NEXCOM International Co.,
Ltd.
RoHS restricts the use of Lead (Pb) < 0.1% or 1,000ppm, Mercury (Hg) < 0.1%
or 1,000ppm, Cadmium (Cd) < 0.01% or 100ppm, Hexavalent Chromium
(Cr6+) < 0.1% or 1,000ppm, Polybrominated biphenyls (PBB) < 0.1% or
1,000ppm, and Polybrominated diphenyl Ethers (PBDE) < 0.1% or 1,000ppm.
In order to meet the RoHS compliant directives, NEXCOM has established
an engineering and manufacturing task force to implement the introduction
of green products. The task force will ensure that we follow the standard
NEXCOM development procedure and that all the new RoHS components
and new manufacturing processes maintain the highest industry quality
levels for which NEXCOM are renowned.
The model selection criteria will be based on market demand. Vendors and
suppliers will ensure that all designed components will be RoHS compliant.
How to recognize NEXCOM RoHS Products?
For existing products where there are non-RoHS and RoHS versions, the
suffix “(LF)” will be added to the compliant product name.
All new product models launched after January 2006 will be RoHS compliant.
They will use the usual NEXCOM naming convention.

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. vi APPD 1200T/1205T/1500T/1700T/1900T User Manual
Preface
Warranty and RMA
NEXCOM Warranty Period
NEXCOM manufactures products that are new or equivalent to new in
accordance with industry standard. NEXCOM warrants that products will
be free from defect in material and workmanship for 2 years, beginning on
the date of invoice by NEXCOM. HCP series products (Blade Server) which
are manufactured by NEXCOM are covered by a three year warranty period.
For NEXCOM Panel PC product lines (the APPC, MPPC series), they are also
guaranteed against defect in materials and workmanship for the period of
twenty-four (24) months in their motherboard design. For 3rd party parts,
it follows with original suppliers’ standard: 12 months for battery pack and
LCD, 24 months for adapter / add on modules (including GSM module, RFID
module, and antenna).
NEXCOM Return Merchandise Authorization (RMA)
▪Customers shall enclose the “NEXCOM RMA Service Form” with the
returned packages.
▪Customers must collect all the information about the problems
encountered and note anything abnormal or, print out any on-screen
messages, and describe the problems on the “NEXCOM RMA Service
Form” for the RMA number apply process.
▪Customers can send back the faulty products with or without accessories
(manuals, cable, etc.) and any components from the card, such as CPU
and RAM. If the components were suspected as part of the problems,
please note clearly which components are included. Otherwise, NEXCOM
is not responsible for the devices/parts.
▪Customers are responsible for the safe packaging of defective products,
making sure it is durable enough to be resistant against further damage
and deterioration during transportation. In case of damages occurred
during transportation, the repair is treated as “Out of Warranty.”
▪Any products returned by NEXCOM to other locations besides the
customers’ site will bear an extra charge and will be billed to the customer.
Repair Service Charges for Out-of-Warranty Products
NEXCOM will charge for out-of-warranty products in two categories, one is
basic diagnostic fee and another is component (product) fee.
System Level
▪Component fee: NEXCOM will only charge for main components such as
SMD chip, BGA chip, etc. Passive components will be repaired for free,
ex: resistor, capacitor.
▪Items will be replaced with NEXCOM products if the original one cannot
be repaired. Ex: motherboard, power supply, etc.
▪Replace with 3rd party products if needed.
▪If RMA goods can not be repaired, NEXCOM will return it to the customer
without any charge.
Board Level
▪Component fee: NEXCOM will only charge for main components, such
as SMD chip, BGA chip, etc. Passive components will be repaired for free,
ex: resistors, capacitors.
▪If RMA goods can not be repaired, NEXCOM will return it to the customer
without any charge.

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. vii APPD 1200T/1205T/1500T/1700T/1900T User Manual
Preface
Warnings
Read and adhere to all warnings, cautions, and notices in this guide and
the documentation supplied with the chassis, power supply, and accessory
modules. If the instructions for the chassis and power supply are inconsistent
with these instructions or the instructions for accessory modules, contact
the supplier to find out how you can ensure that your computer meets
safety and regulatory requirements.
Cautions
Electrostatic discharge (ESD) can damage system components. Do the
described procedures only at an ESD workstation. If no such station is
available, you can provide some ESD protection by wearing an antistatic
wrist strap and attaching it to a metal part of the computer chassis.

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. viii APPD 1200T/1205T/1500T/1700T/1900T User Manual
Preface
Installation Recommendations
Ensure you have a stable, clean working environment. Dust and dirt can get
into components and cause a malfunction. Use containers to keep small
components separated.
Adequate lighting and proper tools can prevent you from accidentally
damaging the internal components. Most of the procedures that follow
require only a few simple tools, including the following:
▪A Philips screwdriver
▪A flat-tipped screwdriver
▪A grounding strap
▪An anti-static pad
Using your fingers can disconnect most of the connections. It is recommended
that you do not use needle-nose pliers to disconnect connections as these
can damage the soft metal or plastic parts of the connectors.
Safety Information
Before installing and using the device, note the following precautions:
▪Read all instructions carefully.
▪Do not place the unit on an unstable surface, cart, or stand.
▪Follow all warnings and cautions in this manual.
▪When replacing parts, ensure that your service technician uses parts
specified by the manufacturer.
▪Avoid using the system near water, in direct sunlight, or near a heating
device.
▪The load of the system unit does not solely rely for support from the
rackmounts located on the sides. Firm support from the bottom is highly
necessary in order to provide balance stability.

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. ix APPD 1200T/1205T/1500T/1700T/1900T User Manual
Preface
Safety Precautions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a
damp cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the
equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a stable surface during installation. Dropping it or
letting it fall may cause damage.
7. The openings on the enclosure are for air convection to protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting
the equipment to the power outlet.
9. Place the power cord in a way so that people will not step on it. Do not
place anything on top of the power cord. Use a power cord that has been
approved for use with the product and that it matches the voltage and
current marked on the product’s electrical range label. The voltage and
current rating of the cord must be greater than the voltage and current
rating marked on the product.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical
shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by
service personnel:
a. The power cord or plug is damaged.
b.Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d.The equipment does not work well, or you cannot get it to work
according to the user’s manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. Do not place heavy objects on the equipment.
16. The unit uses a three-wire ground cable which is equipped with a third
pin to ground the unit and prevent electric shock. Do not defeat the
purpose of this pin. If your outlet does not support this kind of plug,
contact your electrician to replace your obsolete outlet.
17. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER. DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS.

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. xAPPD 1200T/1205T/1500T/1700T/1900T User Manual
Preface
Technical Support and Assistance
1. For the most updated information of NEXCOM products, visit NEXCOM’s
website at www.nexcom.com.
2. For technical issues that require contacting our technical support team or
sales representative, please have the following information ready before
calling:
– Product name and serial number
– Detailed information of the peripheral devices
– Detailed information of the installed software (operating system,
version, application software, etc.)
– A complete description of the problem
– The exact wordings of the error messages
Warning!
1. Handling the unit: carry the unit with both hands and handle it with care.
2. Maintenance: to keep the unit clean, use only approved cleaning products
or clean with a dry cloth.
3. CompactFlash: Turn off the unit’s power before inserting or removing a
CompactFlash storage card.
Conventions Used in this Manual
Warning:
Information about certain situations, which if not observed,
can cause personal injury. This will prevent injury to yourself
when performing a task.
CAUTION!
CAUTION!CAUTION! Caution:
Information to avoid damaging components or losing data.
Note:
Provides additional information to complete a task easily.

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. xi APPD 1200T/1205T/1500T/1700T/1900T User Manual
Preface
Global Service Contact Information
Headquarters
NEXCOM International Co., Ltd.
9F, No. 920, Chung-Cheng Rd.,
ZhongHe District, New Taipei City, 23586,
Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
www.nexcom.com
America
USA
NEXCOM USA
2883 Bayview Drive,
Fremont CA 94538, USA
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.com
Asia
Taiwan
NEXCOM Intelligent Systems
Taipei Office
13F, No.920, Chung-Cheng Rd.,
ZhongHe District,
New Taipei City, 23586, Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.com.tw
NEXCOM Intelligent Systems
Taichung Office
16F, No.250, Sec. 2, Chongde Rd.,
Beitun Dist.,
Taichung City 406, R.O.C.
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.com.tw
Japan
NEXCOM Japan
9F, Tamachi Hara Bldg.,
4-11-5, Shiba Minato-ku,
Tokyo, 108-0014, Japan
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom-jp.com
China
NEXCOM China
Floor 5, No.4, No.7 fengxian middle Rd.,
(Beike Industrial Park), Haidian District,
Beijing, 100094, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. xii APPD 1200T/1205T/1500T/1700T/1900T User Manual
Preface
Europe
United Kingdom
NEXCOM EUROPE
10 Vincent Avenue,
Crownhill Business Centre,
Milton Keynes, Buckinghamshire
MK8 0AB, United Kingdom
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.eu
Italy
NEXCOM ITALIA S.r.l
Via Lanino 42,
21047 Saronno (VA), Italia
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcomitalia.it
NEXCOM Shanghai
Room 603/604, Huiyinmingzun Plaza Bldg., 1,
No.609, Yunlin East Rd.,
Shanghai, 200333, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn
NEXCOM Surveillance Technology Corp.
Room202, Building B,
the GuangMing Industrial Zone Zhonghua Rd.,
Minzhi Street, Longhua District,
Shenzhen 518131, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn
NEXCOM United System Service
Hui Yin Ming Zun Building Room 1108,
Building No. 11, 599 Yunling Road, Putuo District,
Shanghai, 200062, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. xiii APPD 1200T/1205T/1500T/1700T/1900T User Manual
Preface
Package Contents
Before continuing, verify that the package you received is complete. The APPD series package, APPD 1200T/1205T/1500T/1700T/1900T, should have all the
items listed in the table.
APPD 1200T/1205T/1500T/1700T
Item Description Qty
1 Panel Mount Kit 12
2 Driver CD 1
3 Touch Pen 1
4 VGA Cable (1.8m) 1
5 USB Cable (1.8m) 1
6 Serial Cable (1.8m) 1
7 Terminal blocks 3-pin Phoenix Contact Plug 1
Panel Mount Kit Driver CD Touch Pen
Terminal blocks
3-pin Phoenix
Contact Plug VGA Cable
USB Cable Serial Cable
Note: Package contents may vary depending on your country
region, some items may be optional. Please contact your local
distributor for more information.

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. xiv APPD 1200T/1205T/1500T/1700T/1900T User Manual
Preface
Item Description Qty
1 Panel Mount Kit 14
2 Driver CD 1
3 Touch Pen 1
4 VGA Cable (1.8m) 1
5 USB Cable (1.8m) 1
6 Serial Cable (1.8m) 1
7 Terminal blocks 3-pin Phoenix Contact Plug 1
APPD 1900T
Panel Mount Kit Driver CD Touch Pen
Note: Package contents may vary depending on your country
region, some items may be optional. Please contact your local
distributor for more information.
Terminal blocks
3-pin Phoenix
Contact Plug VGA Cable
USB Cable Serial Cable

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. xv APPD 1200T/1205T/1500T/1700T/1900T User Manual
Preface
Ordering Information
The following provides ordering information for the Applied Panel Display series.
• Barebone
APPD 1200T-B (P/N: 10IA1200T01X0)
12.1” SVGA industrial 4:3 LED Backlight flush touch monitor with VGA, and DVI-D input, 12~24VDC input, RS-232 and USB touch screen interfaces
APPD 1205T-B (P/N: 10IA1205T01X0)
12.1” XGA industrial 4:3 LED Backlight flush touch monitor with VGA, and DVI-D input, 12~24VDC input, RS-232 and USB touch screen interfaces
APPD 1500T-C (P/N: 10IA1500T00X0)
15” XGA industrial 4:3 LED Backlight flush touch monitor with VGA, and DVI-D input, 12~24VDC input, RS-232 and USB touch screen interfaces
APPD 1700T-C (P/N: 10IA1700T00X0)
17” SXGA industrial 5:4 LCD flush touch monitor with VGA and DVI-D input, 12~24VDC input, RS-232 and USB touch screen interfaces
APPD 1900T-C (P/N: 10IA1900T02X0)
19” SXGA industrial 5:4 LED Backlight flush touch monitor with VGA, and DVI-D input, 12~24V DC input, RS-232 and USB touch screen interfaces
• Optional
12V, 60W AC/DC power adapter w/o power cord (P/N: 7400060011X00)
US Power Cord (P/N: 60233POW17X00) UK Power Cord (P/N: 60233POW19X00) EU Power Cord (P/N: 60233POW18X00) 1.8m DVI-D Cable (P/N: 60233DVI28X00)

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. 1
Chapter 1: Product Introduction
APPD 1200T/1205T/1500T/1700T/1900T User Manual
Chapter 1: Product Introduction
Key Features
▪IP65 compliant plastic front bezel with flush panel by 5-wire touch screen
▪Dual display input interface: analog VGA and DVI-D
▪Shares identical appearance with APPC series
▪Dual touch screen interface: RS232 and USB
▪Ultra slim in depth
▪OSD Multilanguage function
Overview - APPD 1200T/1205T

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. 2
Chapter 1: Product Introduction
APPD 1200T/1205T/1500T/1700T/1900T User Manual
Key Features
▪IP65 compliant plastic front bezel with flush panel by 5-wire touch screen
▪Dual display input interface: analog VGA and DVI-D
▪Shares identical appearance with APPC series
▪Dual touch screen interface: RS232 and USB
▪Ultra slim in depth
▪OSD Multilanguage function
Overview - APPD 1500T

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. 3
Chapter 1: Product Introduction
APPD 1200T/1205T/1500T/1700T/1900T User Manual
Key Features
▪IP65 compliant plastic front bezel with flush panel by 5-wire touch screen
▪Dual display input interface: analog VGA and DVI-D
▪Shares identical appearance with APPC series
▪Dual touch screen interface: RS232 and USB
▪Ultra slim in depth
▪OSD Multilanguage function
Overview - APPD 1700T

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. 4
Chapter 1: Product Introduction
APPD 1200T/1205T/1500T/1700T/1900T User Manual
Key Features
▪IP65 compliant plastic front bezel with flush panel by 5-wire touch screen
▪Dual display input interface: analog VGA and DVI-D
▪Shares identical appearance with APPC series
▪Dual touch screen interface: RS232 and USB
▪Ultra slim in depth
▪OSD Multilanguage function
Overview - APPD 1900T

Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved. 5
Chapter 1: Product Introduction
APPD 1200T/1205T/1500T/1700T/1900T User Manual
Specifications
APPD 1200T
Panel
▪LED Size: 12.1”, 4:3
▪Resolution: SVGA 800 x 600
▪Luminance: 500cd/m2
▪Contrast ratio: 700
▪LCD color: 16.7M
▪Viewing Angle: 65 (U), 75 (D), 80 (L), 80 (R)
▪Backlight: LED
Touch Screen
▪5-wire resistive (flush panel type)
▪Light transmission: 80%
▪Interface: USB and RS232
Rear I/O
▪Touch screen interface port: RS-232 (1x DB9) / USB Type A
▪Video port: VGA (1x DB15) / DVI-D (1x DVI-I connector)
▪DC power input connector: 3-Pin Phoenix terminal blocks
OSD Function
▪OSD keypad
▪Multilanguage OSD
Mechanical & Environment
▪Color: Pantone black and black silver PC box
▪IP protection: IP65 front
▪Mounting: panel/ wall/ stand/ VESA 100mm x 100mm
▪Power input: 12V~24VDC
▪Power adapter: optional AC to DC power adapter (+12V, 60W)
▪Vibration:
– IEC 68 2-64
– 2Grms @ sine, 5~500Hz, 1hr/axis (Operating)
– 2.2Grms @ random condition, 5~500Hz, 0.5hr/axis (Non-operating)
▪Shock:
– IEC 68 2-27
– 20G@wall mount, half sine, 11ms
– Operating temperature: -5°C to 50°C
– Storage temperature: -20°C to 75°C
▪Operating humidity: 10%~90% relative humidity, non-condensing
▪Dimension: 317 x 243 x 53.5mm
▪Weight: 2.8kg
Certifications
▪CE approval
▪FCC Class B
