Christie FHD551-X Series Administrator Guide

LCD PANEL
135-001102-XX (FHD551-X)
135-002103-XX (FHD551-XG)
135-002103-XX (FHD551-XG)
GORILLA GLASS BONDED
ON THIS SIDE
1215.30
47.85
686.10
27.01
5.70
.22
DONOT OBSTRUCT THE AIRFLOW
HANDLE, 4PLACES
DONOT OBSTRUCT THE AIRFLOW
(SEE GENERAL NOTE)
THICKNESS
POWER
CONNECTION
POWER SWITCH
(ROCKER TYPE)
DONOT OBSTRUCT
THE AIRFLOW
LENGTH OF SCREW ENGAGEMENT : 10MM (MIN), 15MM (MAX)
M8 X4 MOUNTING HOLES,
400.00
15.75
600.00
23.62
This side up
in LANDSCAPE mode
This side up in PORTRAIT mode
EXHAUST & POWER SUPPLY LOCATION
DO NOT OBSTRUCT THE AIR FLOW
CHRISTIE LOGO
599.30
23.59
DISPLAY PORT
HDMI 1
HDMI 2
DVI-D IN
VGA IN
DVI-D OUT
VGA OUT
COMP AUDIO
RS232 IN
RS485 IN
RS485 OUT
PC AUDIO IN
IR EXTENDER
LINE OUT
S-VIDEO
VIDEO OUT
VIDEO IN
L VIDEO/S-V
AUDIO
R VIDEO/S-V
AUDIO
GENERAL NOTES:
NET WEIGHT : 135-001102-XX (FHD551-X) - 34KG (W/O MOUNTS),
135-002103-XX (FHD551-XG) - 41KG (W/O MOUNTS)
OPERATING TEMPERATURE : 5 TO 40 C
POWER SOURCE REQUIREMENTS : 100 T0 240 10% VAC ~50/60HZ, 5A CURRENT, INRUSH CURRENT 100A (MAX)
POWER CONSUMPTION : <275W (NON-AUDIO) MAXIMUM
THICKNESS : 135-001102-XX (FHD551-X) - 108.6MM(4.28")
135-002103-XX (FHD551-XG) - 111.0MM(4.37")
8 7 6 5 4
3 2 1
H
G
F
E
D
C
B
A
8 7 6 5 4
3 2 1
H
G
F
E
D
C
B
A
CHRISTIE DIGITAL SYSTEMS
USA, INC.
CHRISTIE DIGITAL SYSTEMS
CANADA, INC.
PART DESCRIPTION
DWG LINE FHD551-X / FHD551-XG
SIZE
PART NUMBER
020-100627-02
REVISION
SCALE
1:4
MASS
- LBS [- KG]
SHEET 1 OF 3
PROPRIETARY
NOT TO BE DISCLOSED OR REPRODUCED IN
ANY MANNER WITHOUT THE EXPRESS
WRITTEN PERMISSION OF
CHRISTIE
THIRD ANGLE PROJECTION
REVISION HISTORY OF: 020-100627-02
DESCRIPTION OF CHANGE
BY
REV DATE
E
UNLESS OTHERWISE SPECIFIED
DECIMAL PLACES
INCHES
MILLIMETRES
.XXX
.XX
.X
± .063
± .125
± .250
± 1.6
± 3.1
± 6.3
ANGULAR DIMENSIONS
XX°
XX.X°
±1.0°
±0.5°
INTERPRET DIMENSIONS AND TOLERANCES
PER ASME Y14.5M-1994
TOLERANCES APPLY AS SHOWN BELOW
INCHES UNITS
MILLIMETRES
APPROVED BY:
APPROVAL DATE:
DRAWN DATE:
DRAWN BY: V. VARDHANAN
08/12/2011
B. HEMPHILL
09/04/2013
01
REV
01 INCLUDED FHD551-XG PANEL
VARIANT
VV 09/03/2013

2431
95.69
2287
90.02
A
PEDESTAL
P/N: 135-106108-XX
LCD PANEL
P/N
:
135-001102-XX (FHD551-X) OR
135-002103-XX (FHD551-XG)
FRAME
P/N: 135-105107-XX
235
9.23
5.70
.22
5.70
.22
DETAIL A
SCALE 1 : 3
MINIMUM 'IMAGE TO IMAGE GAP' DIMENSION
PANEL EXTENDED OUT FOR SERVICE
B
PULL STRAP TO
INCLINE THE PANEL
24°
DETAIL B
SCALE 2 : 15
294
11.57
PULL BRACKET EXTENSION HOOK ON EITHER
SIDE OF PANEL TO EXTEND THE DISPLAY CARRIAGE
GENERAL NOTES:
1) ALWAYS POWER DOWN AND DISCONNECT ALL POWER SOURCES TO THE PANEL BEFORE SERVICING
GENERAL NOTES:
1) REFER TO 'SPACER KIT INSTRUCTION SHEET' P/N: 020-100728 FOR WALL MOUNT APPLICATIONS
2) MOUNTS, FRAME, PEDESTAL SHOWN HERE ARE FOR LANDSCAPE ORIENTATION
3) MAXIMUM STACK HEIGHT IS SIX PANELS. ADDITIONAL COOLING REQUIRED FOR STACK OVER FIVE HIGH.
4) APPROXIMATE WEIGHT OF 135-001102-XX (FHD551-X) PANEL WITH ADAPTER PLATE & DISPLAY CARRIAGE - 52Kg(114.6lb)
5) APPROXIMATE WEIGHT OF 135-002103-XX (FHD551-XG) PANEL WITH ADAPTER PLATE & DISPLAY CARRIAGE - 59Kg(130.0lb)
6) APPROXIMATE WEIGHT OF THE FRAME - 16.7Kg(36.8lb)
7) APPROXIMATE WEIGHT OF THE PEDESTAL - 24.8Kg(54.7lb)
2X2 CONFIGURATION OF PEDESTAL, FRAME & LCD
PANEL WITH EXTENDED MOUNT FOR SERVICE
2X2 CONFIGURATION OF
PEDESTAL, FRAME & LCD PANEL
DIMENSION SHOWN HERE IS WITH FHD551-X, WHEN
'CORNER ADJUSTMENT KNOB' IN THE MOUNT
IS EXTENDED TO 14MM FROM ITS HOME POSITION.
8 7 6 5 4
3 2 1
D
C
B
A
8 7 6 5 4
3 2 1
D
C
B
A
CHRISTIE DIGITAL SYSTEMS USA, INC
CHRISTIE DIGITAL SYSTEMS CANADA, INC
SIZE
PART NUMBER REVISION
SCALE
D
1:20
020-100627-02
MASS
- LBS [- KG]
SHEET 2 OF 3
PROPRIETARY
NOT TO BE DISCLOSED OR REPRODUCED IN
ANY MANNER WITHOUT THE EXPRESS
WRITTEN PERMISSION OF
CHRISTIE
01

1215
47.85
69
2.71
1600
62.97
40.0
1.57
7.00
.28
560.8
22.08
406.4
16.00
406.4
16.00
861
33.88
FOOT 7.09" THREADED
RUBBER (3X)
FASTEN TO WALL (6X)
MAX TORQUE 9N.m (80lb.in)
HEIGHT ADJUSTMENT
KNOB - RIGHT
HEIGHT ADJUSTMENT
KNOB - LEFT
209
8.24
625.0
24.61
173.2
6.82
4X
8.00
SECURE ADJACENT PEDESTAL
WITH MAX TORQUE OF 13N.m (115lb.in)
WHEN USED WITH
LUBRICATED SCREWS
.31
35
1.39
10X M8
2.96
75.16
23.69
601.70
PANEL CAP (2X)
FASTEN FRAME WITH MAX TORQUE
15N.m (133lb.in)WHEN USED WITH
LUBRICATED SCREWS
ATTACHING DISPLAY CARRIAGE TO THE FRAME
686.1
27.01
1215.3
47.84
4X M8
2X ADAPTER PLATE
600
23.62
400
15.75
CORNER ADJUSTMENT
KNOB - LEFT
CORNER ADJUSTMENT
KNOB - RIGHT
2.91
73.96
16.44
417.66
13.78
350.00
ATTACHING PEDESTAL AND FRAME WITH M8 SCREWS, WASHERS
AND NUTS (6 EACH PER PEDESTAL AND FRAME ASSEMBLY)
GENERAL NOTES:
1) VIEWS SHOWN HERE ARE FOR PEDESTAL AND FRAME ASSEMBLY FOR LANDSCAPE ORIENTATION
2) MAXIMUM ADJUSTMENT POSSIBLE USING HEIGHT ADJUSTMENT KNOB IS 25mm (1in)
3) MAXIMUM HEIGHT ADJUSTMENT OF FEET IS
50mm (2in)
LCD PANEL WITH ADAPTER PLATE
ATTACHING PANEL WITH ADAPTER PLATE TO DISPLAY CARRIAGE
GENERAL NOTES:
1) MAXIMUM DEPTH ADJUSTMENT POSSIBLE USING CORNER ADJUSTMENT KNOB IS 19mm (0.75in)
2) FASTEN M8 SCREW WITH A MAXIMUM TORQUE OF 1.27N.m (11.284lb.in)
8 7 6 5 4
3 2 1
D
C
B
A
8 7 6 5 4
3 2 1
D
C
B
A
CHRISTIE DIGITAL SYSTEMS USA, INC
CHRISTIE DIGITAL SYSTEMS CANADA, INC
SIZE
PART NUMBER REVISION
SCALE
D
1:10
020-100627-02
MASS
- LBS [- KG]
SHEET 3 OF 3
PROPRIETARY
NOT TO BE DISCLOSED OR REPRODUCED IN
ANY MANNER WITHOUT THE EXPRESS
WRITTEN PERMISSION OF
CHRISTIE
01
