Continental Fireplaces CB36NTRE User manual

EN
FR
PG
73
W415-1679 / C / 12.11.17
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
NEVER LEAVE CHILDREN OR OTHER AT RISK INDIVIDUALS ALONE WITH THE APPLIANCE.
INSTALLATION AND
OPERATING INSTRUCTIONS
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada /
103 Miller Drive, Crittenden, Kentucky, USA, 41030
Phone [phone] • www.continentalfireplaces.com • ask@continentalfire.on.ca
1.24F
$10.00
SAFETY INFORMATION
!
WARNING
- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbour’s phone. Follow the gas supplier’s
instructions.
• If you cannot reach your gas supplier, call the
fire department.
- Installation and service must be performed by a
qualified installer, service agency or the supplier.
If the information in these instructions
are not followed exactly, a fire or
explosion may result causing property
damage, personal injury or loss of life.
LA VITRE CHAUDE CAUSERA
DES BRÛLURES.
NE PAS TOUCHER LA VITRE
AVANT QU’ELLE AIT REFROIDI.
NE JAMAIS LAISSER LES
ENFANTS TOUCHER LA VITRE.
HOT GLASS WILL CAUSE
BURNS.
DO NOT TOUCH GLASS UNTIL
COOLED.
NEVER ALLOW CHILDREN TO
TOUCH GLASS.
!
DANGER
!
AVERTISSEMENT
A barrier designed to reduce the risk of burns from
the hot viewing glass is provided with this appliance
and shall be installed for the protection of children
and other at-risk individuals.
Une barriére conçu à réduire le risque de brûlures
causées par le verre chaud est fourni avec l’appareil
et sera installé pour la protection des enfants et
d’autres personnes à risque.
This appliance may be installed in an aftermarket,
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless a
certified kit is used.
FOR INDOOR USE ONLY
CERTIFIED TO CANADIAN AND AMERICAN NATIONAL STANDARDS: CSA 2.22 AND ANSI Z21.50, FOR VENTED DECORATIVE GAS APPLIANCES.
CB36NTR / CB36NTRE &
CX36NTR-1 / CX36NTRE-1
NATURAL GAS MODEL
CB36 ILLUSTRATED
SAFETY BARRIER
ÉCRAN DE PROTECTION
CB36 ILLUSTRÉ
CB36PTR / CB36PTRE &
CX36PTR-1 / CX36PTRE-1
PROPANE GAS MODEL

2
W415-1679 / C / 12.11.17
EN
TABLE OF CONTENTS
1.0 INSTALLATION OVERVIEW 3
2.0 INTRODUCTION 4
2.1 DIMENSIONS 5
2.2 GENERAL INSTRUCTIONS 6
2.3 GENERAL INFORMATION 7
2.4 RATING PLATE INFORMATION 8
3.0 VENTING 9
3.1 VENTING LENGTHS AND COMPONENTS 10
3.2 TYPICAL VENT INSTALLATION 11
3.3 SPECIAL VENT INSTALLATIONS 13
3.3.1 PERISCOPE TERMINATION 13
3.3.2 CORNER TERMINATION 13
3.4 MINIMUM AIR TERMINAL LOCATION
CLEARANCES 14
3.5 VENTING APPLICATION FLOW CHART 15
3.6 DEFINITIONS 16
3.7 ELBOW VENT LENGTH VALUES 16
3.8 TOP EXIT HORIZONTAL TERMINATION 17
3.9 REAR EXIT HORIZONTAL TERMINATION 19
3.10 TOP AND REAR EXIT VERTICAL TERMINATION 21
3.11 REAR EXIT 23
3.12 REAR EXIT SHIELD (FOR REAR VENT ONLY) 23
3.13 TOP EXIT 24
4.0 INSTALLATION 25
4.1 WALL AND CEILING PROTECTION 25
4.1.1 HORIZONTAL INSTALLATION 26
4.1.2 VERTICAL INSTALLATION 26
4.2 USING FLEXIBLE VENT COMPONENTS 27
4.2.1 HORIZONTAL AIR TERMINAL INSTALLATION 27
4.2.2 VERTICAL AIR TERMINAL INSTALLATION 28
4.2.3 APPLIANCE VENT CONNECTION 29
4.3 USING RIGID VENT COMPONENTS 29
4.3.1 HORIZONTAL AIR TERMINAL INSTALLATION 29
4.3.2 VERTICAL AIR TERMINAL INSTALLATION 30
4.3.3 RESTRICTING VERTICAL VENTS 31
4.4 VERTICAL THROUGH EXISTING CHIMNEY 32
4.5 MOBILE HOME INSTALLATION 33
4.6 GAS INSTALLATION 34
4.7 OPTIONAL WALL SWITCH 34
5.0 FRAMING 35
5.1 FRAMING FOR CB36 / CX36-1 35
5.1.1 MINIMUM FRAMING DIMENSIONS FOR
CB36 / CX36-1 36
5.2 MINIMUM ENCLOSURE CLEARANCES 38
5.3 NON-COMBUSTIBLE FACING MATERIAL FOR
CB36 / CX36-1 42
5.4 ALCOVE CLEARANCES 42
5.5 RECESSED INSTALLATION 43
5.7 NAILING TAB INSTALLATION 44
5.6 MINIMUM MANTEL CLEARANCES 44
NOTE: Changes, other than editorial, are denoted by a vertical line in the margin.
6.0 FINISHING 45
6.1 SAFETY BARRIER & DOOR REMOVAL /
INSTALLATION 45
6.2 FRONT HOOD INSTALLATION 46
6.3 CB36 / CX36-1 LOG PLACEMENT 47
6.4 CHARCOAL EMBERS 48
6.5 GLOWING EMBERS 48
6.6 BATTERY BACK-UP INSTALLATION 48
7.0 WIRING DIAGRAM 49
7.1 WIRING REQUIREMENTS FOR CB36 / CX36-1 49
7.2 CB36 ELECTRONIC WIRING DIAGRAM 49
7.3 CX36-1 ELECTRONIC WIRING DIAGRAM 50
8.0 OPERATION (ELECTRONIC) 51
9.0 OPERATION (MILLIVOLT) 52
10.0 ADJUSTMENT 53
10.1 PILOT BURNER ADJUSTMENT 53
10.2 VENTURI ADJUSTMENT 53
10.3 FLAME CHARACTERISTICS 54
10.4 OPTIONAL ANTI CONDENSATION SWITCH
(MODELS CB36NTRE / CB36PTRE / CX36NTRE-1 /
CX36PTRE-1 ONLY) 54
11.0 MAINTENANCE 55
11.1 ANNUAL MAINTENANCE 56
11.2 DOOR GLASS REPLACEMENT 56
11.3 CARE OF GLASS 57
12.0 REPLACEMENTS 57
12.1 CB36 OVERVIEW 58
12.2 CB36 MILLIVOLT VALVE ASSEMBLY 59
12.3 CB36 ELECTRONIC VALVE ASSEMBLY 60
12.4 CX36-1 OVERVIEW 61
12.5 CX36-1 MILLIVOLT VALVE ASSEMBLY 62
12.6 CX36-1 ELECTRONIC VALVE ASSEMBLY 63
13.0 CB36 ACCESSORIES 64
14.0 CX36-1 ACCESSORIES 65
CX36-1 ACCESSORIES (PAGE 2) 66
15.0 TROUBLESHOOTING (ELECTRONIC) 67
16.0 TROUBLESHOOTING (MILLIVOLT) 69
17.0 WARRANTY 71

3
W415-1679 / C / 12.11.17
EN
1.0 INSTALLATION OVERVIEW
See “MINIMUM ENCLOSURE
CLEARANCES” section for
drywall (or other combustible
material).
See “MINIMUM MANTEL
CLEARANCES” section.
See “MINIMUM
FRAMING
DIMENSIONS” section.
Side
Wall
See “FRAMING”
section.
See “VENTING” and
“INSTALLATION” sections.
See “RATING PLATE
INFORMATION” section.
SAFETY BARRIER
CB36 ILLUSTRATED
Batteries must be disposed of according to the local laws and regulations. Some batteries may be
recycled, and may be accepted for disposal at your local recycling center. Check with your
municipality for recycling instructions.
Les piles doivent être mises au rebut conformément aux lois et à la réglementation locales.
Certaines piles peuvent être recyclées et acceptées dans votre centre de recyclage local. Rensei-
gnez-vous auprès de votre municipalité au sujet des directives de recyclage.
Las baterías deben desecharse de acuerdo con las leyes y regulaciones locales. Algunas baterías
pueden reciclarse, y es posible que su centro de reciclado local las acepte para desecharlas.
Consulte en su municipalidad sobre las instrucciones para el reciclado.

4
W415-1679 / C / 12.11.17
EN
2.0 INTRODUCTION
• THIS APPLIANCE IS HOT WHEN OPERATED AND CAN CAUSE SEVERE BURNS IF CONTACTED.
• ANY CHANGES TO THIS APPLIANCE OR ITS CONTROLS CAN BE DANGEROUS AND ARE PROHIBITED.
• Do not operate appliance before reading and understanding operating instructions. Failure to operate appliance according to
operating instructions could cause fi re or injury.
• Risk of fi re or asphyxiation do not operate appliance with fi xed glass removed.
• Do not connect 110 volts to the control valve.
• Risk of burns. The appliance should be turned off and cooled before servicing.
• Do not install damaged, incomplete or substitute components.
• Risk of cuts and abrasions. Wear protective footwear, gloves and safety glasses during installation. Sheet metal edges may be
sharp.
• Do not burn wood or other materials in this appliance.
• Children and adults should be alerted to the hazards of high surface temperature and should stay away to avoid burns
or clothing ignition.
• Young children should be carefully supervised when they are in the same room as the appliance.
Toddlers, young children and others may be susceptible to accidental contact burns. A physical barrier is
recommended if there are at risk individuals in the house. To restrict access to an appliance or stove, install an
adjustable safety gate to keep toddlers, young children and other at risk individuals out of the room and away from hot
surfaces.
• Clothing or other fl ammable material should not be placed on or near the appliance.
• Due to high temperatures, the appliance should be located out of traffi c and away from furniture and draperies.
• Ensure you have incorporated adequate safety measure to protect infants/toddlers from touching hot surfaces.
• Even after the appliance is out, the glass and/or screen will remain hot for an extended period of time.
• Check with your local hearth specialty dealer for safety screens and hearth guards to protect children from hot surfaces. These
screens and guards must be fastened to the fl oor.
• Any safety screen, guard or barrier removed for servicing the appliance, must be replaced prior to operating the
appliance.
• The appliance is a vented gas-fi red appliance. Do not burn wood or other materials in the appliance.
• The appliance area must be kept clear and free from combustible materials, gasoline and other fl ammable vapors and liquids.
• Under no circumstances should this appliance be modifi ed.
• This appliance must not be connected to a chimney fl ue pipe serving a separate solid fuel burning appliance.
• Do not use this appliance if any part has been under water. Immediately call a qualifi ed service technician to inspect the appliance
and to replace any part of the control system and any gas control which has been under water.
• Do not operate the appliance with the glass door removed, cracked or broken. Replacement of the glass should be done by a
licensed or qualifi ed service person.
• Do not strike or slam shut the appliance glass door.
• When equipped with pressure relief doors, they must be kept closed while the appliance is operating to prevent exhaust fumes
containing carbon monoxide, from entering into the home. Temperatures of the exhaust escaping through these openings can also
cause the surrounding combustible materials to overheat and catch fi re.
• Only doors / optional fronts certifi ed with the unit are to be installed on the appliance.
• Keep the packaging material out of reach of children and dispose of the material in a safe manner. As with all plastic bags, these
are not toys and should be kept away from children and infants.
• As with any combustion appliance, we recommend having your appliance regularly inspected and serviced as well as having a
Carbon Monoxide Detector installed in the same area to defend you and your family against Carbon Monoxide.
• Ensure clearances to combustibles are maintained when building a mantel or shelves above the appliance. Elevated temperatures
on the wall or in the air above the appliance can cause melting, discolouration or damage to decorations, a T.V. or other electronic
components.
• A barrier designed to reduce the risk of burns from the hot viewing glass is provided with this appliance or sold as a
mandatory option and shall be installed.
• If the barrier becomes damaged, the barrier shall be replaced with the manufacturer’s barrier for this appliance.
• Installation and repair should be done by a qualifi ed service person. The appliance should be inspected before use and
at least annually by a professional service person. More frequent cleaning may be required due to excessive lint from
carpeting, bedding material, etc. It is imperative that control compartments, burners and circulating air passageways of
the appliance be kept clean.
• The millivolt version of this appliance uses and requires a fast acting thermocouple. Replace only with a fast acting thermocouple
supplied by Wolf Steel Ltd.
3.1G
!
WARNING

5
W415-1679 / C / 12.11.17
EN
2.1 DIMENSIONS
34 5/8"
879mm
9 1/16" 230mm
15 3/8"
391mm
4"
102mm
7"
178mm
35"
889mm
SAFETY BARRIER
24"
610mm
2 3/16"
55.5mm
GAS INLET
15 3/4"
400mm
8"
203mm
