Continental Refrigerator ContiConnect User manual

ContiConnect™
Yard Reader Station
GB
Installation manual

3
Yard Reader Station
Table of Contents
1 General Information.............................................................................................................5
1.1 Subject of this installation manual ...................................................................................5
1.2 Target groups...............................................................................................................................5
1.3 Information on this installation manual ........................................................................6
1.4 Liability limitation......................................................................................................................9
1.5 Copyright ....................................................................................................................................10
1.6 Warranty provisions..............................................................................................................10
1.7 Manufacturer address..........................................................................................................10
1.8 Customer service....................................................................................................................10
2 Safety ........................................................................................................................................11
2.1 General information ..............................................................................................................11
2.2 Prohibition of modiications .............................................................................................11
2.3 Intended use..............................................................................................................................12
2.4 General safety instructions ...............................................................................................13
2.5 Speciic hazards.......................................................................................................................14
2.6 Personnel requirements .....................................................................................................15
2.7 Personal protective equipment ......................................................................................16
3 Technical Data......................................................................................................................17
3.1 General information ..............................................................................................................17
3.2 EU GSM Yard Reader Station ............................................................................................17
3.3 US GSM Yard Reader Station.............................................................................................18
3.4 Additional antenna.................................................................................................................18
3.5 Scope of delivery ....................................................................................................................19
4 Design and Functionality ...............................................................................................20
4.1 Description of function........................................................................................................20
4.2 General overview....................................................................................................................21
4.3 Yard Reader Station...............................................................................................................22
4.4 Additional antenna.................................................................................................................25
4.5 Spare parts .................................................................................................................................25
5 Mounting.................................................................................................................................26
5.1 Checking the delivery...........................................................................................................26

4
Table of Contents
5.2 Disposing of the packaging...............................................................................................26
5.3 Safety information..................................................................................................................27
5.4 Instructions regarding electrical connections........................................................28
5.5 Requirements regarding the place of installation ................................................29
5.6 Installation variants with the additional antenna..................................................30
5.7 Mounting and connecting the Yard Reader Station ............................................31
5.8 Mounting the additional antenna ..................................................................................35
5.9 Checks to perform following the mounting process...........................................39
6 Troubleshooting..................................................................................................................40
6.1 Safety information..................................................................................................................40
6.2 Troubleshooting for the Yard Reader Station..........................................................40
6.3 Troubleshooting for the additional antenna ...........................................................44
6.4 Troubleshooting for the mobile radio module ......................................................45
7 Dismounting and Disposal ............................................................................................46
7.2 Dismounting..............................................................................................................................47
7.3 Disposal........................................................................................................................................47
8 Certiications.........................................................................................................................49
8.1 Radio license .............................................................................................................................49
8.2 FCC information.......................................................................................................................49
8.3 Declaration of conformity..................................................................................................50
9 Color Code Tables ..............................................................................................................51
9.1 Color code for lexible cables...........................................................................................51
9.2 Color code for solid cables ................................................................................................51
10 Index..........................................................................................................................................54

5
General Information
1 General Information
1.1 Subject of this installation manual
This installation manual contains important information on
handling the Yard Reader Station during:
●mounting,
●commissioning,
●troubleshooting,
●dismantling and
●disposal.
In order to install the Yard Reader Station successfully and sa-
fely, it is necessary to comply with all of the warnings and inst-
ructions speciied.
Following these instructions will help prevent risks and increa-
se the reliability and service life of the Yard Reader Station.
Furthermore, regional accident prevention regulations and ge-
neral safety regulations applicable at the respective place of
use must be observed.
Please read the installation manual carefully before commissi-
oning; it is an integral part of the Yard Reader Station and must
be stored in an accessible location at all times.
If the Yard Reader Station is passed onto third parties, this ins-
tallation manual must be handed over as well.
1.2 Target groups
This installation manual is aimed at installers and operators of
the Yard Reader Station.

6
General Information
1.3 Information on this installation manual
1.3.1 Notes on use
1.3.1.1 Instructions
Action steps to be carried out by installation and operating per-
sonnel are described sequentially. The order of the steps must
be observed.
Example:
Action step
1.3.1.2 Lists
Lists that do not have to be actioned in a set order are presen-
ted with preceding bullet points.
Example:
●Point 1
●Point 2
1.3.1.3 References
Information on chapters or sections of text that contain proce-
dures, instructions or further information is shown as follows.
Example: (See chapter “x.x chapter”)

7
General Information
1.3.2 Symbols used
In this installation manual, warnings are also indicated by war-
ning symbols. The following warning symbols are used in this
installation manual:
Symbol Meaning
General warning
Danger due to electric current
General information and useful tips for
handling the equipment
Information on complying with
environmental regulations regarding
disposal
Electric/electronic components with
this symbol must not be disposed of
with normal domestic waste.
1.3.3 Abbreviations
The following abbreviations are used in this operating manual:
Abbreviation Meaning
GND Ground
GSM Global System for Mobile Communication
ITE Information Technology Equipment
LED Light Emitting Diode
LTE Long Term Evolution
MAC Media Access Control
UMTS Universal Mobile Telecommunications
System

8
General Information
1.3.4 Warnings
The following warnings are used in this instruction manual:
DANGER
A warning of this risk level indicates an im-
pending dangerous situation.
If the dangerous situation is not avoided, it will
result in death or severe injury.
►The instructions in this warning must be
followed to prevent the risk of death or
severe injury.
WARNING
A warning of this risk level indicates a dange-
rous situation.
If the dangerous situation is not avoided, it
could result in death or serious injury.
►The instructions in this warning must be
followed to prevent the possible risk of
death or serious injury.
ATTENTION
A warning of this risk level indicates a poten-
tially dangerous situation.
If the dangerous situation is not avoided, it
could result in slight or moderate injury.
►The instructions in this warning must be
followed to prevent injuries.

9
General Information
CAUTION
A warning of this risk level indicates potential
damage to property.
If the situation is not avoided, it could result in
damage to property.
►The instructions in this warning must be
followed to prevent damage to property.
NOTE
►A note indicates additional information that
is important for further work or makes the
work step described easier.
1.4 Liability limitation
The manufacturer does not accept any liability for damage or
malfunctions caused as a result of:
●failure to comply with this installation manual,
●improper use,
●use of untrained personnel or personnel who have not
received suicient or proper training,
●incorrect installation,
●failure to use original parts and accessories,
●technical changes and modiications or
●intentional damage.

10
General Information
1.5 Copyright
This installation manual and all of the documents supplied with
the Yard Reader Station are protected by copyright.
These documents may not be reproduced, either in whole or
in part, without the express permission of Continental Reifen
Deutschland GmbH.
1.6 Warranty provisions
The respective “General Terms and Conditions of Continental
AG” apply with the exception of any contractual provisions that
may dier.
The latest version is available from your
Continental sales partner.
1.7 Manufacturer address
Continental Reifen Deutschland GmbH
Büttnerstrasse 25
30165 Hanover
Germany
www.conticonnect.com
1.8 Customer service
If you have any technical questions regar-
ding the Yard Reader Station, please contact your
Continental sales partner.

11
Safety
2 Safety
2.1 General information
This chapter provides important information on all safety as-
pects.
In addition to the general safety information provided in this
chapter, each chapter that covers a particular set of actions
provides further safety information relevant to the respective
chapter.
Hazards that can occur during a speciic action step are descri-
bed before the respective action step.
WARNING
Danger caused by failure to comply with
safety instructions!
Failure to comply with the safety and handling
instructions speciied in this installation ma-
nual can result in serious risks.
►Observe the warnings and instructions
speciied in this manual.
2.2 Prohibition of modiications
Any modiications and changes to the Yard Reader Station are
prohibited.
The manufacturer does not accept any liability for damage re-
sulting from any modiications or changes made.

12
Safety
2.3 Intended use
The Yard Reader Station has been designed solely to receive
data from tire sensors and to transfer this data to the Conti-
Connect™ web portal via a mobile radio connection. The sensors
need to be in the reception range of the Yard Reader Station for
at least two minutes.
The system may only be used within the technical framework
and operating conditions deined by the manufacturer (see
Chapter «3 Technical Data»).
Any other use, or use above and beyond this, is deemed impro-
per and is prohibited.
WARNING
Danger due to improper use!
Any use beyond the intended use and/or other
use of the Yard Reader Station can result in
dangerous situations.
►The Yard Reader Station is to be used only
for the intended purpose.
►Comply with all of the information provided
in this installation manual.
Claims of any kind for damages resulting from improper use
are excluded.
The risk of not observing these instructions is borne solely by
the user.

13
Safety
2.4 General safety instructions
The Yard Reader Station has been built in accordance with the
latest applicable directive using state-of-the-art technology in
line with generally recognized safety rules and regulations.
Nevertheless, hazards can arise and damage can occur when
installing and using the Yard Reader Station.
The following safety instructions for the safe installation and
fault-free operation of the Yard Reader Station must be obser-
ved:
●Comply with the occupational safety regulations applicab-
le in the respective country.
●Check all of the parts and connecting cables of the
Yard Reader Station for visible signs of external da-
mage prior to starting work. Do not commission the
Yard Reader Station if it is damaged.
●Repairs to the Yard Reader Station must only be carried
out by trained specialist personnel. Repairs performed by
untrained persons can result in serious risks.
●Defective components may only be replaced with origi-
nal spare parts; only original parts ensure that the safety
requirements are met.

14
Safety
2.5 Speciic hazards
Danger due to electric current!
Contact with live cables or components poses a risk to life!
●Work on electrical equipment may be carried out only
by qualiied electricians or trained personnel under the
management and supervision of qualiied electricians in
accordance with electrical safety regulations.
●Any defects identiied on electrical systems/assemblies/
operating resources must be rectiied immediately. Until
defects are eliminated, there is a serious risk and the sys-
tem must therefore not be used in a defective condition.
●Never work on live parts! System components on which
repair work is to be carried out must be de-energized, if
speciied. First check that the disconnected parts are in
a de-energized state and then ground and short-circuit
these parts as well as isolate adjacent live parts.
●Fuses must not be repaired or bypassed. Use only original
fuses with the speciied current rating.
●If insulation is damaged, switch o the power supply im-
mediately and arrange for the insulation to be repaired.
●Keep live parts away from moisture to prevent short
circuits.

15
Safety
2.6 Personnel requirements
WARNING
Risk of injury due to inadequate qualiica-
tions.
Improper handling can cause serious injuries
and damage.
►Have all operations carried out by appropri-
ately qualiied personnel only.
This installation manual refers to the following qualiications:
●Specialist personnel
are able to carry out the work assigned to them and
independently identify and avoid potential dangers as
a result of their specialist technical training, knowledge
and experience as well as their awareness of the relevant
regulations.
●Electricians
are able to perform work on electrical equipment and
independently identify and avoid potential dangers as a
result of their specialist technical training, knowledge and
experience as well as their awareness of the relevant stan-
dards and regulations. The respective electrician is trained
for the speciic place of use in which they are working and
is familiar with the relevant standards and provisions.
Work may only be carried out by persons who can be expected
to perform the respective task reliably. Persons whose reac-
tions are impaired, e.g. as a result of drugs, alcohol or medicati-
on, are not authorized to perform work.

16
Safety
2.7 Personal protective equipment
WARNING
Danger of injury due to incorrect or no pro-
tective equipment!
During the installation process, it is necessary
to wear personal protective equipment to
minimize health risks.
►Wear the protective equipment required for
the respective operation during the installa-
tion process.
►Observe the signs mounted in the working
area regarding personal protective equip-
ment.
Wear the following protective equipment during the installati-
on process:
Symbol Meaning
Wear safety shoes.

17
Technical Data
3 Technical Data
3.1 General information
Operating temperature
range
-35°C to 55°C
-31°F to 131°F
Place of installation Wall mounting
Operating mode Continuous operation
(permanently connected)
Protection class II
Type of protection UL type 3
IP64
3.2 EU GSM Yard Reader Station
Dimensions (L x W x H) 312 x 130 x 410
12.28 x 5.11 x 16.14
mm
inch
Weight ~ 2.1
~ 74
kg
oz
Receiving frequency 433.92 MHz
Frequency ranges of the
mobile radio module
GSM:
UMTS/3G:
LT E :
900/1800
900/1800/2100
800/900/1800/
2100/2600
MHz
MHz
MHz
Input voltage range 100240 VAC
Mains frequency 5060 Hz
Power consumption at an
ambient temperature of
23°C (73.4°F)
Max. 6.6
Min. 2.2
W
W
Current consumption at
230 V Max. 45 mA

18
Technical Data
3.3 US GSM Yard Reader Station
Dimensions (L x W x H) 312 x 130 x 410
12.28 x 5.11 x 16.14
mm
inch
Weight ~ 2.1
~ 74
g
oz
Receiving frequency 433.92 MHz
Frequency ranges of the
mobile radio module
GSM:
UMTS/3G:
LT E :
850/900/
1800/1900
850/
AWS(1700/2100)/
1900
700/850/
AWS(1700/2100)/
1900
MHz
MHz
MHz
Input voltage range 120140 VAC
Mains frequency 5060 Hz
Power consumption at an
ambient temperature of
23°C (73.4°F)
Max. 6.6
Min. 2.2
W
W
Current consumption at
120 V Max. 87 mA
3.4 Additional antenna
Dimensions (L x W x H) 90 x 42 x 28
3.54 x 1.65 x 1.1
mm
inch
Weight 44
1.55
g
oz
Frequency 433.92 MHz
Number of connecting cycles 10

19
Technical Data
3.5 Scope of delivery
The Yard Reader Station is supplied with the following compo-
nents:
ACHTUNGgefärliche Spannung!
Nurvon Fachpersonal zu öffnen
ATTENTIONhaute tension!
Defensed‘ouvrirsauf des personnes
autorises
ATTENZIONNEalta tensione!
Aperturaconsentita solo al personale
autorizzato
ATTENTIONhigh voltage!
Openingby qualified personnel only
4. Internet Connection
3. Receiver II
2. Receiver I
1. Power Supply
5. GSM Status
www.conticonnect.com
12
5
87
9
3 4
6
1Yard Reader Station
2Additional antenna
3Bracket for additional antenna
4Protective cover for additional antenna
5Spacer for additional antenna
6Connecting cable for additional antenna
7Special wrench for opening the ferrite core
8Ferrite core for additional antenna
9Four screws for sealing the housing
10 Two cable ties (no image)
11 Installation manual (no image)

20
Design and Functionality
4 Design and Functionality
4.1 Description of function
The Yard Reader Station including the additional antenna is a
hardware component for the digital tire-monitoring platform
ContiConnect™.
The Yard Reader Station receives all of the data from the tire
sensors located in the reception area and transmits this infor-
mation to the Continental database via a mobile radio connec-
tion.
The Yard Reader Station is installed in an area in which vehic-
les stop for at least two minutes as the sensors automatically
send their data every two minutes. The additional antenna can
also be used to improve the reception range and is wired to the
Yard Reader Station.
The Yard Reader Station is a comfort system. It cannot be com-
pletely ruled out in the event of adverse conditions that the
Yard Reader Station does not receive tire sensor data or con-
versely, that the Yard Reader Station does not transmits the
data.
