Contro l4 HC-1000 V2 User manual

Home Controller HC-1000 V2
Installation Guide
Supported Model
C4-HC1000V2-E-B Home Controller HC-1000 V2
Graphical Symbols in This Guide
The following symbols and their descriptions draw your attention to important
safe practices and additional information that can help you avoid death, injury,
or loss of material or time.
WARNING! This indicates a potentially hazardous situation that, if not
avoided, may result in death or serious injury. DO NOT IGNORE A
WARNING!
IMPORTANT! This indicates information that will help you avoid
damage to your equipment, loss of materials, or loss of time. PAY
ATTENTION TO THESE IMPORTANT STATEMENTS!
NOTE: This indicates information related to the current topic.
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding
type plug has two blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug does not fit into
your outlet, consult an electrician for replacement of the obsolete outlet.
10.Protect the power cord from being walked on or pinched, particularly at
plugs, convenience receptacles, and the point where they exit from the
apparatus.
11.Only use attachments/accessories specified by the manufacturer.
12.Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
WARNING! To reduce the risk of electrical shock, do not expose this
apparatus to rain or moisture.
WARNING! This CLASS I apparatus must be connected to an AC IEC
socket outlet that has a protective earthing connection (i.e., third-prong
ground conductor). DO NOT DEFEAT THE PROTECTIVE EARTHING
CONNECTION!
Introduction to Home Controller HC-1000 V2
The Control4®Home Controller HC-1000 V2 provides the capability for
controlling lights, home theaters, distributed audio systems, and other devices.
It provides extensive Media Management services for audio sources, such as
CDs and DVDs stored in connected devices. It provides half a terabyte of
storage for media, and allows you to use an external storage device for
additional media storage. It also includes multi-zone audio capabilities,
distributing digital music to rooms throughout the home.
Control4 Supported Devices
NOTE: The HC-1000 V2 enhances existing system capabilities. It replaces the
main controller, running Director and Media Manager. You must have another
controller, such as a Home Controller HC-200, Home Controller HC-300, or
Home Controller HC-500 to run ZServer and to communicate with lighting and
other ZigBee devices.
The HC-1000 V2 enhances a system’s capability to control the following
Control4®devices:
*The HC-1000 V2 requires a Secondary Controller, for example, HC-200, HC-
300, or HC-500 configured to run ZServer.
For more information, see Products at http://www.control4.com.
Requirements and Specifications
Prior to installing this product, ensure that a wired Ethernet network is in place.
The HC-1000 V2 specifications include:
What’s in the Box
The following are included in your HC-1000 V2 box:
• Home Controller HC-1000 V2
• IEC 320 power cord
•Home Controller HC-1000 V2 Installation Guide (this document)
Additional Resources
The following resources are available to provide you with additional support.
• Your Control4®Reseller
• Control4®Web Site: http://www.control4.com
• Composer online help
Front View
1. Data—This LED indicates streaming audio is received.
2. Link—This LED indicates the HC-1000 V2 has been identified in a Control4
Composer project.
3. Power—Indicates that the device is powered on.
4. Identification button—Button used when identifying this device in
Composer.
NOTE: Blinking is not a default LED action; LEDs blink to convey information.
Back View
1. Power plug port—AC power receptacle for an IEC 320 power cord.
2. Ethernet—RJ-45 jack for a 10/100/1000 BaseT Ethernet connection.
3. USB (2 ports)—For external storage device with USB support (such as
USB hard drive or memory stick).
4. Power/Reset button—The Controller is configured to power on when
plugged in. If it doesn’t, press the Power/Reset button to power it on. To
reset the unit, hold the Power/Reset button down until the Controller powers
down, wait approximately 30 seconds, and then press the Power/Reset but-
ton again to power the unit back on.
Install the System
NOTE: The HC-1000 V2 is not intended for use in a home theater.
To install the HC-1000 V2:
1. Ensure that your home network is in place before starting your system
setup: The HC-1000 V2 requires a wired Ethernet network connection; use
all features as designed. When connected, the HC-1000 V2 can access
Web-based media databases and Control4®system updates.
2.Connect the HC-1000 Controller to the network: To connect using an
Ethernet connection, plug the data cable from the home network connection
into the HC-1000 V2 RJ-45 port (labeled “Ethernet”) at the network switch.
3. Power up the Controller: Plug the HC-1000 V2 power cord (provided) into
the HC-1000 V2 power plug port, and then into an electrical outlet.
4. Connect the system devices as described in the “Connect Devices” sec-
tion that follows.
5. Optional: Set up external storage devices as described in “Set up Exter-
nal Storage Device” on page 1.
Connect Devices
Connect all applicable devices to the HC-1000 V2 using one of the connection
options described in the following table.
Table 1. Connection Options
NOTE: The HC-1000 V2 has no Audio Out ports. Audio streaming is done
using the Ethernet connection.
Set up External Storage Device
You can store and access media from an external storage device, such as a
network hard drive or USB memory device. Simply plug the USB drive into one
of the USB ports and configure or scan the media from Composer.
Troubleshooting
• If the Data LED is flashing slowly, a drive integrity check or formatting is cur-
rently underway.
• If the Link LED is flashing quickly, the formatting or integrity check has
failed.
• To reset the device, press and hold the Identify button. When both LEDs illu-
minate momentarily, the device has been reset.
• To restore the network configuration, press and hold the Identify button
when the device is powered up until the LEDs illuminate.
• To maintain media drive integrity, the device may infrequently take an
extended period of time (up to 1 hour) to boot while a forced file system
integrity check occurs.
Touch Screen (Wireless or Wall-Mounted)
Mini Touch Screen
LCD Keypad*
Wireless 2, 3, & 6 Button Keypads*
Wireless Thermostat*
Speaker Point®
Supported third-party devices
Wireless Dimmer*
Wireless Switch*
Wireless Outlet Dimmer*
Wireless Outlet Switch*
Multi Channel Amplifier
Audio Matrix Switch
Multi Tuner
Model Number • C4-HC1000V2-E-B
Media Recognition • Online CD/DVD recognition and media
information service
Display • LED indicators
Power Requirements • 100-240 VAC, 60/50 Hz, 0.7 A MAX
Dimensions • H x W x D: 3 3/8” x 16 3/4” x 14”
Device Weight • 15.4 pounds
Shipping Weight • 20 pounds
1. 2. 3. 4.
1. 3.
2. 4.
Power plug port—For use with the IEC 320 power connector
(provided)
Ethernet—RJ-45 for a 10/100/1000 BaseT Ethernet connec-
tion.
USB (2 ports)—For external storage device with USB support
(such as FAT32 formatted devices)

Regulatory Compliance
This product complies with standards established by the following regulatory
bodies:
• Edison Test Lab (ETL)
• CE Declaration of Conformity
IMPORTANT! Any changes or modifications not expressly approved
by the party responsible for compliance could void the user’s
authority to operate this equipment.
North America
FCC Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
IMPORTANT! Changes or modifications not expressly approved by Control4
could void the user’s authority to operate the equipment.
Industry Canada Statement
This Class B digital apparatus complies with Canada ICES-003.
Cet appareil numérique de la classe B est conforme à la norme
NMB-003 du Canada.
Edison Test Lab (ETL)
This product has been tested by ETL and has been found to be in
compliance with:
UL60065, 7th Edition, 2006 + A1; 2006—Audio video and
similar electronic apparatus - safety requirements
CSA C22.2 No. 60065-03 1st Edition—Audio video and
similar electronic apparatus - safety requirements
Europe
CE Declaration of Conformity
Product: Home Controller HC-1000 V2
The undersigned hereby declares, on behalf of Control4®Corporation, that
the above-referenced product, to which this declaration relates, is in
conformity with the provisions of:
• Council Directive 89/336/EEC (May 3, 1989) on Electromagnetic Compat-
ibility
• Council Directive 1999/5/EC (Mar 9, 1999) on Radio & Telecommunica-
tion Terminal Equipment (R&TTE)
• Council Directive 73/23/EEC (Feb. 19, 1973) on Low Voltage Equipment
Safety
• Council Directive 93/68/EEC (Jul. 22, 1993) Amending Directives 89/336/
EEC and 73/23/EEC
and has been tested to the requirements of, and shown to be in compliance
with, the following requisite standards:
• IEC 60950-1:2001, EN 60950-1:2001+A11
• EN 55024:1998+A1+A2 Information technology equipment - Immunity
characteristics - Limits and methods of measurement
• EN 55022: 1994 + A1 & A2
The Technical Construction File required by these Directives is maintained at
the corporate headquarters of Control4®, Salt Lake City, Utah, U.S.A.
Signed,
Paul E. Nagel—Vice President of Engineering, October 2, 2007
Australian / New Zealand
This product has been tested to the requirements o, and shown to be in
compliance with, the following requisite standard:
• AS/NZS CISPR 22: 2002—Information Technology Equip-
ment—
Radio disturbance characteristics.
Recycling
For recycling information, please go to www.control4.com/
recycling.
About This Document
© 2009 Control4®. All rights reserved. Control4, the Control4 logo and
Everyday Easy are registered trademarks or trademarks of Control4
Corporation in the United States and/or other countries. All other names or
brands may be claimed as property by their respective owners. Pricing and
specifications subject to change without notice. Part Number: 200-00108
Rev C 6/25/2009
European Contact Information
Control4 UK Limited
Unit 3, Green Park Business Centre
Sutton-on-the-Forest, York
YO61 IET, United Kingdom
[phone]
[email protected]
United States Contact Information
Control4 Corporation
11734 S. Election Road, Suite 200
Salt Lake City, UT 84020-6432, USA
Tel [phone]
