Contro l4 CXM-RCR1-B User manual

Wireless
C o n ta c t / R e l a y E x t e n d e r
Installation Guide
Features.
The Wireless Contact/Relay Extender is intended for use with your Control4®
system. This product addresses the need for additional or remotely located
contacts and relays.
The Contact/Relay Extender includes four contact-sensing inputs and four
normally-open or normally-closed relays. The Contact/Relay Extender
communicates to the Control4 system using either an Ethernet connection or
a ZigBee wireless (IEEE 802.15.4) connection.
The Contact/Relay Extender is designed to be installed using any of three
methods: (1) free-standing on a horizontal surface, (2) vertical-standing
using the included mounting base, or (3) surface-mounted using the built-in
screw mounts.
Specifications
What’s in the Box
•Control4 Contact/Relay Extender
•AC power cord (2-prong)
•Vertical Mounting Base
•Two 12-conductor plug-in terminal blocks
•Wireless Contact / Relay Extender Installation Guide (this guide)
IMPORTANT! Using this product in a manner other than outlined in
this document voids your warranty. Further, Control4 is NOT liable for
any damage incurred with the misuse of this product. See “Limited 1
Year Warranty.”
WARNING! Important Safety Information
CAUTION! TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO
NOT OPEN THE CHASSIS. NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
1. Do not use this apparatus near water.
2. Clean only with dry cloth.
3. Do not block any ventilation openings. Install in accordance with the man-
ufacturer’s instructions.
4. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that product heat.
5. Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the
apparatus.
6. Only use attachments/accessories specified by the manufacturer.
7. Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use cau-
tion when moving the cart/apparatus combination to avoid injury from tip-
over.
8. Unplug this apparatus during lighting storms or when unsued for long
periods of time.
9. Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-sup-
ply cord or plug is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
WARNING! Do not expose the apparatus to dripping or splashing.
Do not place objects filled with liquids near the apparatus.
WARNING! To reduce the risk of fire or electrical shock, do not
expose this apparatus to rain or moisture.
About the Hardware
Front Panel
The front panel interface includes an ID button for identifying the unit on the
network, and LEDs to indicate power and communication status.
1. DATA LED: On = Ethernet link established
2. LINK LED: On = ZigBee link established
3. POWER LED: On = Power present
4. ID Button: When prompted by the Composer software during setup, press
this button to uniquely identify this Contact/Relay Extender to the network.
Models: CXM-RCR1-B Wireless Contact / Relay Extender
Power: 120 V~, 60/50 Hz, 14 W
Communications: Wireless: ZigBee mesh networking (802.15.4)
Wired: 10/100 Ethernet
Dimensions: Width = 7.10”
Height = 1.68”
Depth = 6.5”
Weight: 24 oz. with mounting base
22 oz. without mounting base
1 2 3 4

Back Panel
The back panel of the Contact/Relay Extender consists of:
1. Power plug port—For supplied power cord.
2. Relays 1-4—12 pin Plug-in Terminal Block connectors for switching up to
4 normally-closed or normally-open switchable connections, such as
blinds, fireplaces, or projector screens.
3. Contacts 1-4—12 pin Plug-in Terminal Block connectors for up to 4 dry
contact closure, logic input connections, door switches, or motion sen-
sors.
4. Ethernet—RJ-45 for a 10/100 BaseT Ethernet connection.
Installation Instructions
1 Ensure that the location and intended use meet the following
criteria:
• Install in accordance with all national and local electrical codes.
• The range and performance of the wireless control system is highly
dependent on the following:
Distance between devices
Layout of the home
Walls separating devices
Electrical equipment located near devices
2 Plan your connections. Use the following worksheet as needed.
3 Connect up to 4 relay outputs to the Contact/Relay Extender using
the Relay output ports found on the back of the device.
4 Connect up to 4 contact inputs to the Contact/Relay Extender
using the Contact input ports found on the back of the device.
5 (Optional) If you would like to communicate to the device via
Ethernet, plug the CAT 5 wire from the wall into the Ethernet port
(Ethernet 10/100 RJ45) on the back of the Contact/Relay Extender.
6 Plug the 2-prong AC power cord into the Contact/Relay Extender
and into a standard 120 VAC outlet. The Power LED on the front
panel should be on.
7 Configure this Contact/Relay Extender using the Control4
Composer software. (For more information, see “Design and Set Up a
Project with Interviewer” in the Composer User Guide.) When prompted
by Composer to identify this device, press the small button on the front
panel.
8 Test to see if it is working properly: Control any of the system contact
and relay devices that you connected to the Contact/Relay Extender in
the extended location.
You can use the many different interfaces available in a Control4
system (Remote Controls, Keypads, Touch Screens, or the On-Screen
GUI) to control devices attached to the Contact/Relay Extender.
Regulatory Compliance
This product complies with standards established by the following regulatory
bodies:
•Federal Communications Commission (FCC)
•Industry Canada
FCC
FCC ID: R33CXMRCR11
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful
interfence, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Industry Canada
This Class B digital apparatus complies with Canada ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du
Canada.
IMPORTANT! Changes or modifications not expressly approved by
Control4 could void the user’s authority to operate the equipment.
Limited 1 Year Warranty
This device has a limited one (1) year warranty on parts from the date of purchase. Control4 will
replace or repair any defective unit. Return unit to the place of purchase for replacement. For any
damages incurred, the warranty will never exceed the purchase price of the device. This warranty
does not cover installation, removal, or reinstallation cost. The warranty is not valid in cases where
damage was incurred due to misuse, abuse, incorrect repair, or improper wiring or installation. It does
not cover incidental or consequential damage. This warranty gives you specific legal rights, and you
might also be entitled to other rights that vary from state to state. Some states do not allow limitations
on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential
damages. In these cases, the above mentioned limitations might not apply to you. For complete
warranty information, see www.control4.com. To automatically receive notification of upgrades, return
the enclosed registration card or register online at www.control4.com.
About this Document
United States Patents Pending. Copyright © 2004-2005 Control4
Corporation. Control4 and the Control4 logo are registered trademarks of
Control4 Corporation. All trademarks are properties of their respective
owners. Part Number: 21-0060 Rev A .
Connection Description Reserved for:
Power—AC Input Included AC power
cord
Relays 1-4—12 pin Plug-in
Terminal Block connectors for
switching up to 4 normally closed
(NC) or normally open (NO)
switchable connections, such as
blinds, fireplaces, or projector
screens.
1.
2.
3.
4.
Contacts 1-4—12 pin Plug-in
Terminal Block connectors for up
to 4 dry contact closure, logic input
connections, door switches, or
motion sensors.
1.
2.
3.
4.
Ethernet—RJ-45 for a 10/100
BaseT Ethernet connection.
Ethernet connector
1 2 3 4
