Controlium NMR-WF01-FC-MN User manual

Model：NMR-WF01-FC-MN
Touch Screen Room Thermostat
User Guide
Welcome
Your new thermostat will provide year of reliable
service. Using this digital thermostat will provide
more uniform comfort in your home through the
seasons. Thank you for buying the product!
Please read this manual for complete instructions
on installing and operating your thermostat. If you
require further assistance, please feel free to
contact us.
Thermostat Screws
User Guide Wall plate
1pc 2pc
1pc 1pc
We offer the warranty of 24 months from the sales day.
If it is not the problem of quality or beyond the warranty
time, we will charge for the after-sale service.
In the box you will find
Service
About your thermostat
NMR-WF01-FC serie Modern Touch Screen
Room Thermostats are designed to control
the fans and valves in air conditioner applications
via comparison of the room temperature and
setting temperature as reaching the aim of
comfort and saving energy. NMR-WF01 are
microprocessor based thermostat with LCD
display.
Features of your thermostat
Modern desgin similar as a cell phone.
Beautiful Frame CHROME creates elegant life.
Acrylic lenses to avoid the finger scrath.
Touch Button makes simple operation.
Large screen display with backlight is easy to
read—even in the dark.
Precise comfort control keeps temperature within
1°C of the level you set.
Easy installation.
86mm hidden box and european 60mm round
box is selectable.
Model definition of your thermostat
A1: Two pipe; Control Fan Coil Unit and Two
wired Motorized valve.(when room temperature
reaches the setpoint, both will turn off)
A2: Two pipe; Control Fan Coil Unit and Two
wired Motorized valve.(when room temperature
reaches the setpoint, valve will turn off but fan will
turn to low speed)
B: Two pipe; Control on/off Motorized Damper
C: Two Pipe; Control Fan Coil Unit and Three
wired Motorized valve
M: Two pipe; Control 0-10V Motorized Valve
E: Four pipe; Control Fan Coil Unit and Two wired
Heat and Cool Motorized valve.
T: Clock
L: Backlight
P: Weekly Programmable
N: RS485/MODBUS RTU communication
K: Keycard
E: External sensor
Home screen quick reference
Power
On/off
Up
Fan
Mode
Clock
Auto Fan
Timing On/Off
Cooling
Energysaving
Network
Room
Temp.
Fan
Speed
Manual
Lock
Sleeping
Valve
On/off
Down
Set
Temp.
Operation
1. Setting the temperature
2. Setting Lock (optional function)
Press and hold for 3 sec. to lock the screen.
The icon will display on the screen.
Press and hold again for 3 sec. to unlock the
screen.
3. Setting the fan
Press to select the fan speed AUTO, HIGH,
MED, LOW.
Technical Data of your thermostat
Sensor：NTC Accuracy：±1℃
Temp. Range：5 -35℃Power Consumption：<1.5W
Timing error：<1％Power Supply：110~240V, 50 ~60Hz
Current Load：1A（Inductive）， 2A（Resistance）
Shell Material：PC （Fireproof）
Dimension：86x86x13.3mm
Installation box：86*86mm or European 60mm
Ambient Temp.：0 ~ 45℃，5 ~ 95％RH(Non condensing）
Storage Temp：-5~ 55℃
Press to set temperature.
“SET” will display in the corner.
4. Setting the system mode
Press Mto change the system mode HEATING,
COOLING and VENTILATION. In the mode of
VENTILATION, the valve is off but the fan runs.
For Example:NMR-WF01-FC-MN

6. Setting functions and options
During power off, press and hold at the same
time for 5 sec. to system functions. Then press M
to change the different items.
All the settings will confirm automatically when
M
Press or to set the relative values.
power is on.
Wiring your thermostat
L
N
hg
i
H
deM
Low
Fan
0-10V Valve
+
-
temperature for the output to go from 0 to 100%. It can be adjust from
1~10. Factory default is 2.
The P value is bigger, the change of valve output will be bigger;
The P value is smaller, the change of valve output will be smaller.
For example, when P=2, the temperature difference between
ambient temperature and setpoint is 5 ℃，the valve will open
about 10%; when P=4, the temperature difference between
ambient temperature and setpoint is 5 ℃, the valve will open 20%.
Heat mode (P-band: 2 )
When the ambient temperature is below the set point the output
is somewhere between 0~100%.
% of Output
100%
0-10V
10%
0%
-15 -10 -5
Set point
+5 +10 +15
Cool mode(P-band: 2 )
When the ambient temperature is above the set point the output
is somewhere between 0~100%.
loop will become sluggish. It can be adjust from 1S-60S. Factory Default
is 40S.
P=2
-20
20%
30%
...
+20
% of Output
100%
0-10V
10%
0%
-15 -10 -5
Set point
+5 +10 +15
P=2
-20
20%
30%
...
+20
Installing your thermostat
Your thermostat is suitable for installation within
a standard 86mm pattress box or European 60mm
round pattress box.
Step 1. Keep power off. See Fig 1.
Fig 1
Step 2. Remove the mounting Plate. See Fig 2.
Fig 2
Step 3. Connect power supply, load and external (floor) sensor
into the appropriate terminals if there is external sensor.
(see “Wiring your thermostat” for details and Fig 3).
Fig 3
Step 4. Fix the mounting plate into the wall with screws in
the box. See Fig 4
Fig 4
Step 5. Fasten body of thermostat and the mounting plate
through the groove. See Fig 5.
Fig 5
Step 6. Installation complete. See Fig 6.
Fig 6
RISK OF ELECTRICAL SHOCK. Disconnect/isolate
power supply prior to making electrical connections.
Contact with high voltage components can cause electrical
shock, severe injury or death.
No Func on Se ng & Op ons Default
1 Temp.
Calibra on -9℃to 9℃-2
2 Fan Control
00: When room temp. reaches
the setpoint, the fan will turn
off.
01: When room temp. reaches
the setpoint, the fan will keep
the same speed.
00
3 Lock
00：All the bu ons are locked
except POWER
01 ：All the bu ons are locked
01
4 Heat/Cool 00：Cool only
01: Heat/Cool 01
5 Min. Set Temp. 5-15℃5
6 Max. Set Temp. 15-35℃35
7 01
8 Display mode
01：display set temp. only
00：display both set temp. and
room temp. 00
9
A
B
P value 1-10
2
1S-60S 28I value
C
IP Address 01
Time Display 00:12 hours
01:24 hours
0X00-0XFF
5.Setting the Clock
Press and hold M to set Clock;Press M to set the
minutes of the time,press to adjust the relative
values.Same setting for hour and week of the time.
After that, all will be confirmed automatically.
D
INVALID
Modbus
BA
INVALID
