convenience concepts 151394 User manual

151394
ASSEMBLY INSTRUCTIONS
We have designed our furniture with you , the customer in mind . Our clear , easy to follow ,
step by step instructions will guide you through the project from start to finish .
Feel confident that this will be a fun and rewarding project . The final product will be a quality
piece of furniture that will go together smoothly and give years of enjoyment .
Please do not return to the store
. Broken or missing parts?
. Need help with assembly?
If you have any questions just call 1-800-468-6447 or email us at
[email protected]
STOP
LEXINGTON TV STAND

Gently screw the cam
clockwise into locked
position.
Do not overtighten.
Lightly glue dowel and
connect to second panel
by inserting dowels into
holes
Lightly glue one end of
wood dowel and tap into
hole.
Gently screw cam dowel
into the threaded anchor
Insert camlock，
camlock must face
bolt hole
Cambolt (23pcs) Metal Pin（4pcs）Nail (15pcs) Glue (1pc)
Knob&Knob Screw
（2pcs）
Wood dowel（36pcs）
Spring Insert（4pcs）
Magnet（2pcs）
Long Screw（15pcs）
Bracket（2pcs）
PAGE 2 OF 8
A H I J K
B
D
C
F
G
E
Top Panel
(1pc)
Back Panel
(1pc)
Small Panel
(1pc)
Bottom Panel
(1pc) Small Side Panel
(2pcs)
Large Divider Panel
(2pcs)
LEFT (4) & RIGHT (5)
Large Side Panel
(2pcs)
LEFT (8) & RIGHT (9)
Small Divider Panel
(2pcs)
Middle Panel
(1pc)
Support Panel
(1pc)
Door
(2pcs)
Part List
Please count and verify all parts before assembly
(1)
(2)
(3)
(4) (5)
(6)
(7) (8) (9)
(10)
(11)
(13)
(12)
Camlock (23pcs)

PAGE 3 OF 8
Exploded Views
1
2
3
7
8
9
7
2
10
6
12
11
13 4
5
C

step1
step2
step3
2
7
7
3
4
5
2
PAGE 4 OF 8
1.Insert wood dowels(B) into bottom panel (1)
as shown.
2.Insert camlocks(K) into panels (2、5、4、2)
as shown.
3.Insert metal pins(H) to panels (5 、4)
as shown.
1.Insert camlocks (K) into small divider
panels (7) and insert wood dowels (B)
into middle panel (3) as shown.
NOTE: Remember, comlocks arrows must face bolt holes.
1.Attach small side panels (2) and large divider panel (4)&(5)
to bottom panel (1) using long screws (D).
D
D
D
D
D
D
Bolt hole
Bolt hole
Forward bolt hole
K
B
B
K
K
K
K
H
BBBB
2
4
5
2
1
1
FRONT
FRONT
FRONT
(Bottom view)
2
FRONT
(Bottom view)
(Top view)

step4
step5
step6
7
6
6
3
7
7
3
D
B
D
3
7
DDD
A
B
A
B
A
B
B
A
PAGE 5 OF 8
1.Attach small divider
panels (7) to middle
panel (3) using long
screws (D) as shown.
2.Attach support panel (6) to middle
panel (3) using long screws (D).
1.Insert wood dowels (B) into middle
panel (3) as shown .
1.Turn unit over
carefully.
2.Screw cambolts (A)
and insert wood dowels
(B) into middle panel (3).
(Bottom view)
(Bottom view)
B

step7
step8
step9
6
4
5
9
9
8
8
6
K
K
K
K
K
A
B
B
A
2
2
1
3
77
PAGE 6 OF 8
Place top assembly
onto cabinet assembly
as shown and check
all camlocks and
dowels are in the correct
position.
Gently tighten
camlocks.
*REFER TO PAGE2 FOR CAM\DOWEL INSTRUCTION
Attach hardware to large side
panels (8) and (9).
1.Insert camlocks (K) into support panel (6) .
2.Attach large side panels (8)&(9) to
unit.
Gently tighten camlocks.
FRONT
FRONT

step10
step11
step12
11
11
12
45
A
A
B
A
A
B
B
B
G
PAGE 7 OF 8
Attach hardware to top
panel (11) as shown.
*REFER TO PAGE2 FOR CAM\DOWEL INSTRUCTION
1.Attach top panel (11) to
unit.
Check all cambolts and
dowels are in correct position
and gently tighten camlocks.
2.Check metal pins (H) are in
correct position of the large
divider panels (4) and (5).
1.Place small panel (12) onto metal pins.
2.Insert magnets (G) into
large divider panels (4)&(5)
as shown.
FTONT

step13
step14
step15
10
10
C
C
E
E
I
F
GE 8 OF 8
Doors (10) assembly.
1.Attach knob (C) to
door (10) using knob
screw (C) & bracket
(F) as shown.
2.Push spring pins (E)
into top and bottom
holes.
Attach door (10) to unit by placing
one end of spring pin into
hole,gently compress other end
of spring pin so that it will slide
into remaining hole.
1.Turn sample around and connect back panel
(13) to unit using nails (I).
2.Enjoy you new television stand!
