convenience concepts 5 Tier Bookcase with Drawer User manual

Assembly instrucons
We have designed our furniture with you,the customer in mind.Our clear,easy to follow
step by step instrucons will guide you through the project from start to finish.
Feel confident that this will be a fun and rewarding project. The final product will be a quality piece of
furniture that will go together smoothly and give years of enjoyment.
L
5 Tier Bookcase with Drawer
Please do not return to the store
Broken or missing Hardware?
Neen help with Assembly?

1 1PC 2 2PCS 3 4PCS 4 3PCS
A16PCS B16PCS C30PCS D 16PCS E30PCS F4PCS
5 1PC
6 1PC 7 1PC 8 1PC 9 1PC
G4PCS H 2PCS I2PCS
J6PCS K2PCS L 16PCS
Assembling the unit with cams .
A
Gently screw cam
threaded anchor.
Insert cam lock with
arrow pointing down.
Screw the cam firmly
into locked position.
D
10 1PC 11 1PC 12 1PC 13 1PC
14 1PC 15 1PC 16 1PC
M 2PCS N1PCS O1PCS
* Special Note:We recommend the use of a hand held screwdriver to avoid the stripping of screw heads*
Top Panel Top Support Bar Back Support Bar Shelves Middle Panel
Top Right Panel Top Le Panel Boom Right Panel Boom Le Panel
Back Support Bar Boom Drawer Support Bar Drawer Right Side Panel Drawer Le Side Panel
Drawer Back Panel Drawer Boom Panel Drawer Front Panel
Bolt Lock Nut Cam Bolt Cam Lock Screw Wood Dowel ScrewWood Dowel An-p Bracket
Small Screw Anchor Sckers Handle Le Glider Right Glider
Page 2 of 7
Skinny
bolt into the

Step 1
Step 2
2
3
A
A
B
B
C
D
D
2
4
A
AB
B
3
C
D
D
C
6
C
A
A
C
C
D
DA
A
C
C
D
D
B
B
B
B
2
2
3
3
4
7
NOTE: Assemble unit on carpet or other so surface to avoid scratching.
.
1.Screw Cam Bolts (C) into Top Right Panel .
2.Aach Shelf to Top Right Panel using Bolts (A) and Lock Nuts (B).
3.Aach Top Support Bars to Top Right Panel using Bolts (A) and Lock Nuts (B).
4.Aach Back Support Bars to Top Right Panel using Cam Bolts (C) and Cam Locks (D).
6
46
26
36
*Make sure threads of lock nut (B) face bolt (A) entrance hole.*
*Take extra care with Support Bars and while they are
awaing step 2.*
23
1.Screw Cam Bolts (C) into Top Le Panel .
2.Connect Top Le Panel to assembly using Cam Bolts (C), Cam Locks (D),
Lock Nuts (B), and Bolts (A).
7
7
Page 3 of 7
4 X (A)
4 X (B)
4 X (C)
4 X (D)
4 X (A)
4 X (B)
4 X (C)
4 X (D)

1E
E
EE
E
E
E
E
E
E
F
F
F
F
2
2
7
6
5
Step 4
8
J J
J
9
J
NO
Step 3
1.Insert Wooden Dowels (F) into Middle Panel .
2.Connect Top Panel and Middle Panel to assembly using Screws (E),as shown.
5
5
1
1.Aach Glider (N) to boom le 9 using screw (J).
2.Aach Glider (O) to boom right 8 using screw (J).
Page 4 of 7
4 X (J)
1 X (N)
1 X (O)
10 X
(E)
4 X (F)

Step 5
Step 6
D
D
10
C
C
CCD
D
C
C
3
4
3
4
8
C
D
D
A
AB
C
D
D
A
AB
B
B
D
D
B
B
C
C
D
DA
A
C
C
D
D
B
B
A
A
9
4
4
3
3
C
C
D
DC
C
C
10
11
11
1. Screw Cam bolts(C) into Boom Right Panel 8
2. Aach Shelves 4 to Boom Right Panel 8 using Bolts(A) and Lock Nuts(B).
3. Aach Back Supoprt Bars 10 & 3 to assembly using Cam Bolts (C) and Cam Locks (D).
* Take extra care with support bars 10 & 3 while they are awaing step 6.*
* Refer to page 2 for cam lock/bolt assembly.*
* Refer to page 2 for cam lock/bolt assembly*
1. Screw Cam Bolts (C) into boom le panel 9 .
2. Aach Boom le panel 9 to assembly
using cam bolts(C),Cam Locks(D),Lock Nuts(B),
and Bolts(A).
Page 5 of 7
4 X (A)
4 X (B)
8 X (C)
8 X (D)
4 X (A)
4 X (B)
8 X (C)
8 X (D)

D
J
I
JI
5
9
8
C
D
C
C
C
D
D
1
Step 8
G
G
G
G
C
C
D
D
H
H
M
M
E
E
E
E
12
13
14
12
13
15
12
13
16
Page 6 of 7
1.Screw Cam bolts (C) into Middle Panel
.
2.Connect the 2 assembles together using Cam Bolts
(C) and Cam Locks (D).
3.Attach Anti-Tip Bracket (I) to back of unit of using Screws (J).
5
2. Insert the drawer boom panel 15.
4.
5. Aach drawer front panel to assembly using Cam bolts (C) and Cam Locks (D).
6. Aach handles (M) to drawer front using screw (H).
Step 7
2 X (C)
2 X (D)
4 X (E)
4 X (G)
2 X (H)
2 X (M)
2 X (J)
2 X (I)
4 X (D)
4 X (C)
1. Connect Drawer Le 13 & Right 12 Side Panels to Drawer back panel 14 using screw (E).
into grooves of drawer assemly
3. Insert wooden dowels (G) into drawer side panels 12 & 13
Screw Cam bolts (C) into Drawer Front Panel 16.

If using oponal an-p bracket,fasten to
wall from underside of unit top.
Step 9
L
LL
L
L
L
L
L
L
L
L
L
L
L
L
L
L
E
K
E
K
Step 10
16
Page 7 of 7
1.If desired place Sckers (L) over bolt holes..
2.Place unit into desired locaon and mark
An-Tip bracket’s (I) holes with pencil and
remove unit..
3.Drill holes into wall slightly smaller then Anchors (K)
and gently tap Anchors (K) into wall.
4.Reposion unit and fasten to wall using Screws (E)
and An-Tip brackets (I).
16 X
(L)
2 X (K)
2 X (E)
1. Carefully slide drawer into unit.
