convenience concepts LAREDO 413199 User manual

ASSEMBLY INSTRUCTIONS
We have designed our furniture with you , the customer in mind . Our clear , easy to follow ,
step by step instructions will guide you through the project from start to finish .
Feel confident that this will be a fun and rewarding project . The final product will be a quality
piece of furniture that will go together smoothly and give years of enjoyment .
Please do not return to the store
Broken or missing parts?
Need help with assembly?
If you have any questions just call 1-800-468-6447 or email us at
[email protected]
STOP
LAREDO 2 TIER CONSOLE TABLE
413199

Panel List
Hardware List
Page 2 of 4
ABC
D E
Nut ( 16pcs )
Top panel ( 1pc )
Boom panel ( 1pc )
Leg ( 4pcs )
Wrench ( 1pc ) Cablee ( 2pcs )
Anchor ( 2pcs )
Eyelet screw ( 2pcs )
1
2
3

1
1
A
3
3
3
3
3
2
2
Page 3 of 4
Step 1
Step 2
X 8
X 1
B
A
X 8
X 1
B
using nuts (A) and wrench (B) .
1. Connect top panel to assembly as shown using nuts (A) and wrench (B) .
*.Place top panel upside down on carpet or other so� surface.
A
B
2.Tighten all the nuts (A) .
3.Turn unit over .
1
B
A

Page 4 of 4
Step 3
1.Drill holes slightly smaller than anchors (E)into drywall and gently tap anchors into
holes.
2.Insert eyelet screws (D) into anchors and fasten unit to wall using cable es (C) .
C
D
E
