Convergence System Limited CS461 User manual

Quick Start Guide – CS461 Read Tag to RS232 v1.00
1 Hardware Setup
CS461 can send all the received tag information to external device through RS232 port located in
DB25 connector.
RS232 setting:
-Speed: 9600
-Data bits: 8
-Parity: None
-Stop bits: 1
-Flow control: None
Page. 1

Quick Start Guide – CS461 Read Tag to RS232 v1.00
2 Reader Setup
1. Operation Profile
-Setup all parameter according to your needs.
2. Trigger
-Select which antennas will be used.
Page. 2

Quick Start Guide – CS461 Read Tag to RS232 v1.00
3. Resultant Action
-Select “Instant Alert to Server” in Action Mode.
-Select “SerialPort1 (Simplified)” or “SerialPort1” in Transport Type. We can support
Wiegand output by connecting a Wiegand Adaptor (Purchase separately) to DB25
connector.
4. Event management
-Once you click “Confirm Modification”, the reader will send tag information to RS232.
Page. 3

Quick Start Guide – CS461 Read Tag to RS232 v1.00
Page. 4
3 Data format
For SerialPort1 in Resultant Action, Trusted Server data format is used.
cmd=evtNtf&evt_id=DemoEvent&src_ip=192.168.25.224&ant=Antenna1&cp_id=CapturePoint1&
idx=A3&tag_id=100000000000000000000004&rssi=-35&time=1222650380&cnt=1&bank1=&fre
q=875&PC=3000&usec=158663
cmd=evtNtf&evt_id=DemoEvent&src_ip=192.168.25.224&ant=Antenna1&cp_id=CapturePoint1&
idx=A4&tag_id=100000000000000000000005&rssi=-35&time=1222650480&cnt=1&bank1=&fre
q=875&PC=3000&usec=100
For SerialPort1 (Simplified), the data format is shown below. The “$” is EPC start symbol. The “#”
is EPC end symbol.
$100000000000000000000004#$100000000000000000000005#
