Cooke & Lewis CLM1W-C User manual

CLM1W-C Free Standing Microwave Version:04
Barcode 5052931055708
GB IE
T
i
m
e
r
•
W
e
i
g
h
t
•
M
e
n
u
CLM1W-C

[04] x 1
[03] x 1
T
i
m
e
r
•
W
e
i
g
h
t
•
M
e
n
u
[01] x 1
[02] x 1

3
GB IE Free Standing Microwave 04
CLM1W-C

4
GB IE
Let's
get started...
Getting started... 05
Before you start 06
Safety 07
In more detail... 09
Product parts list
Operation
Care and maintenance
Troubleshooting
Recycling and disposal
Technical and legal information
Guarantee
CE Declaration of conformity
10
11
19
24
26
27
31
33

5
Getting
Started...
Getting
started...
GB IE
T
i
m
e
r
•
W
e
i
g
h
t
•
M
e
n
u
Before you start 06
Safety 07

6
Getting started...
GB IE Before you start
Before you start
To avoid the risks that are always present when you use
an electrical appliance it is important that this appliance is
installed correctly and that you read the safety instructions
carefully to avoid misuse and hazards. Please keep this
instruction booklet for future reference and pass it on to any
future owners. After unpacking the appliance please check
that it is not damaged. If in doubt, do not use the appliance
but contact Customer Services on 0844 800 1128 (UK),
1 800 535542 (Ireland) and 01 56 48 02 60 (France).
Check the package and make sure you have all of the parts
listed.
Decide on the appropriate location for your product.
If this product contains glass please take care when tting
or handling to prevent personal injury or damage to the
product.
The specications plate is available on this appliance. This
plate displays all the necessary identication information for
ordering replacement parts.
If you sell the appliance, give it away, or leave it behind
when you move house, make sure you also pass on this
manual so that the new owner can become familiar with the
appliance and its safety warnings.

7
Getting
started...
GB IE
Safety
These instructions are for your safety. Please read through
them thoroughly prior to installation and retain them for
future reference.
This appliance complies with all current European safety legislation,
however, the Manufacturer must emphasise that this compliance does
not prevent the surfaces of the appliance from heating up during use and
remaining hot during its operation.
Accessible parts may become hot during use. Young children should be kept
away. Care should be taken to avoid touching the appliance (e.g hob, cooker).
Therefore, the Manufacturer highly recommends that this appliance be kept
out of the reach of babies and small children.
Children should be supervised to ensure that they do not play with the
appliance.
This appliance is not intended for use by persons (including children) with
reduced physical sensory, or mental capabilities, or by those who lack
experience and knowledge, unless they have been given supervision and
instruction concerning the use of the appliance by a person responsible for
their safety.
Do not allow the electric cables to touch the hot parts of the appliance.
Make sure that the power cord is not caught under or in the appliance and
avoid damage to the power cable.
Do not remove the plug in the presence of ammable gas.
Do not install the appliance outdoors in a damp place or in an area which
may be prone to water leaks such as under or near a sink unit. In the event
of a water leak allow the machine to dry naturally.
Please dispose of the packing material carefully.
Do not use ammable sprays in close vicinity to the appliance.
• All installation work must be carried out by a
competent person or qualied electrician.
• This appliance must be installed correctly by a
suitably qualied person, strictly following the
manufacturer’s instructions.

8
Getting started...
GB IE Safety
We also recommend that great care be taken during use and cleaning.
Read the cleaning and maintenance sections for this appliance carefully.
A steam cleaner is not to be used.
The appliance is not intended to be operated by means of external timer or
separated remote-control system.
The appliance is for domestic use only.
The Manufacturer declines all liability for personal or material damage as a
result of misuse or incorrect installation of this appliance.
Precautions to avoid possible exposure to excessive microwave
energy
Do not attempt to operate this oven with the door open,
as this can result in harmful exposure to microwave
energy. It is important not to break or tamper with the
safety interlocks.
Do not place any object between the front face of the
oven and the door or allow dirt or cleaner residue to
accumulate on sealing surfaces.
If the door or door seals are damaged, the oven must
not be operated until it has been repaired by a qualied
person.
If the apparatus is not kept in a good state of cleanliness,
its surface could be damaged and the lifespan of the
apparatus affected, leading to a dangerous situation.
Make sure the appliance is attended when in operation.
WARNING: It is hazardous for anyone other then a competent person to carry out any
service or repair operation that involves the removal of a cover which gives protection
against exposure to microwave energy.
WARNING: Only allow children to use the oven without supervision when adequate
instructions have been given so that the child is able to use the oven in a safe way and
understands the hazards of improper use.
• Only use utensils that are suitable for use in microwave ovens.
• The oven should be cleaned regularly and any food deposits removed.
• The rear surface of appliance shall be placed agaisnt a wall.
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE

9
In more detail...
In more
detail...
GB IE
Operation 11
Care and maintenance 19
Troubleshooting 24
Recycling and disposal 26
Technical and legal information 27
Guarantee 28
CE Declaration of conformity 30

10
In
more
detail...
GB IE Operation
Parts list and accessories
Caution
This diagram may be slightly different from the layout of the
machine.
T
i
m
e
r
•
W
e
i
g
h
t
•
M
e
n
u
[04]
[02]
[03]
[01]
Reference Description Qty
[01] Microwave 1
[02] Glass tray 1
[03] Grill rack 1
[04] Turntable ring 1

11
In more detail...
GB IE
Operation
Cautions
> Liquids and other foods must not be heated in sealed
containers since they are liable to explode.
> When heating food in plastic or paper containers,
supervise the oven due the possibility of ignition.
> If smoke is observed, switch off and unplug the appliance
and keep the door closed.
> Remove wire twist-ties and metal handles from paper or
plastic containers / bags before placing them in the oven.
> The contents of feeding bottles and baby food jars shall
be stirred or shaken and the temperature checked before
consumption, in order to avoid burns.
> Microwave heating of beverages can result in delayed
eruptive boiling; therefore care must be taken when
handling the container.
Operation keys
Reference Description
Microwave / Grill / Combi
Start / Conrm
Weight / Time defrost
Stop / Clear
00:00
Display
Selector

12
In
more
detail...
GB IE Operation
Microwave cooking
1. Press Microwave / Grill /
Combi. The LED will display
“P100”.
2. Press Microwave / Grill
/ Combi for times or turn
Selector to choose the power
you require and “P100”, “P80”,
“P50”, “P30” or “P10” will be
displayed every time you press
it.
3. Press Start / Conrm to
conrm and turn Selector to
set cooking time from “0:05” to
“95:00”.
4. Press Start / Conrm again to
start cooking.
Example:
If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as follows:
1. Press Microwave / Grill / Combi. The LED will display “P100”.
2. Press Microwave / Grill / Combi again or turn Selector to select 80%
microwave power.
3. Press Start / Conrm to conrm and the screen displays “P80”.
4. Turn Selector to adjust the cooking time until the oven displays "20:00".
5. Press Start / Conrm again to start cooking.
NOTE: The step quantities for the adjustment time of the cooking switch are
as follow:
0 — 1 min : 5 seconds
1 — 5 min : 10 seconds
5 — 10 min : 30 seconds
10 — 30 min : 1 minute
30 — 95 min : 5 minutes
Reference Description
Microwave / Grill /
Combi
Start / Conrm
Weight / Time defrost
Stop / Clear
00:00
Display
Selector

13
In more detail...
GB IE
Operation
"Micro / Grill / Combi"
Order
Pad instuctions
Display
Microwave
Power
Grill
Power
1 P100 100%
2 P80 80%
3 P50 50%
4 P30 30%
5 P10 10%
6 G 0% 100%
7 C-1 55% 45%
8 C-2 36% 64%
Grill or Combi cooking
1. Press Microwave / Grill /
Combi. The LED will display
“P100”.
2. Press Microwave / Grill /
Combi for times or turn
Selector to select the power
you require and “G”, “C-1” or
“C-2” will be displayed every
time you press or turn.
3. Press Start / Conrm to
conrm and turn Selector to
set cooking time from “0:05” to
“95:00”.
4. Press Start / Conrm again to
start cooking.
Example:
If you want to use 55% microwave power and 45% grill power (C-1) to cook
for 10 minutes, you can operate the oven as follows:
1. Press Microwave / Grill / Combi. The LED will display “P100”.
2. Press Microwave / Grill / Combi once or turn Selector to choose
“combi 1 mode”.
3. Press Start / Conrm to conrm, and the screen displays "C-1".
4. Turn Selector to adjust the cooking time until the oven displays "10:00".
5. Press Start / Conrm again to start cooking.
Reference Description
Microwave / Grill /
Combi
Start / Conrm
Weight / Time defrost
Stop / Clear
00:00
Display
Selector

14
In
more
detail...
GB IE Operation
NOTE: Once half the grill time has passed, the oven will sound twice, which
is normal. For better grilling, turn the food over, close the door and the
oven will continue cooking if no other operation is selected.
Quick Start
1. In standby mode, press Start/
Conrm to start cooking at
100% power. Every time you
press it you will increase the
cooking time by 30 seconds, up
to 95 minutes.
2. In microwave cooking or defrost
by time mode, every time you
press Start / Conrm you will
increase the cooking time by 30
seconds.
3. In standby mode, turn Selector
left to set cooking time at 100%
microwave power, then press
Start / Conrm to start cooking.
Defrost By Weight
1. Press Weight / Time defrost
once, and the oven will display
"dEF1".
2. Turn Selector to select the
weight of food from 100 to
2000 g.
3. Press Start / Conrm to start
defrosting.
Reference Description
Microwave / Grill /
Combi
Start / Conrm
Weight / Time defrost
Stop / Clear
00:00
Display
Selector
Reference Description
Microwave / Grill /
Combi
Start / Conrm
Weight / Time defrost
Stop / Clear
00:00
Display
Selector

15
In more detail...
GB IE
Operation
Defrost By Time
1. Press Weight / Time defrost
twice, and the oven will display
"dEF2".
2. Turn Selector to select the
defrost time. The MAX time is
95 minutes.
3. Press Start / Conrm to start
defrosting. The defrost power
is P30 and this cannot be
changed.
Auto Menu
1. Turn Selector right to select the
menu and "A-1" to "A-8" will be
displayed, which means auto
reheat, vegetable, sh, meat,
pasta, potato, pizza and soup.
See table "The automatic menu
procedure”.
2. Press Start / Conrm to
conrm.
3. Turn Selector to select the
default weight from the menu
chart.
4. Press Start / Conrm to start
cooking.
Reference Description
Microwave / Grill /
Combi
Start / Conrm
Weight / Time defrost
Stop / Clear
00:00
Display
Selector
Reference Description
Microwave / Grill /
Combi
Start / Conrm
Weight / Time defrost
Stop / Clear
00:00
Display
Selector

16
In
more
detail...
GB IE Operation
Example:
If you want to use "Auto Menu" to cook 350g of sh, you can operate the
oven as follows:
1. Turn Selector clockwise until "A-3" is displayed.
2. Press Start / Conrm to conrm.
3. Turn Selector to select the weight of sh until "350" is displayed.
4. Press Start / Conrm again to start cooking.
The automatic menu procedure
Menu Weight (g) Display
A1 Auto Reheat
200 g 200 g
400 g 400 g
600 g 600 g
A2 Vegetable
200 g 200 g
300 g 300 g
400 g 400 g
A3 Fish
250 g 250 g
350 g 350 g
450 g 450 g
A4 Meat
250 g 250 g
350 g 350 g
450 g 450 g
A5 Pasta 50 g (with cold water 450 g) 50 g
100 g (with cold water 800 g) 100 g
A6 Potato
200 g 200 g
400 g 400 g
600 g 600 g
A7 Pizza 200 g 200 g
400 g 400 g
A8 Soup 200 ml 200
400 ml 400

17
In more detail...
GB IE
Operation
Multi-section cooking
A maximum of 2 sections can be set for cooking. In multi-section cooking, if
one section involved defrosting then defrosting shall be in the rst section.
Example:
If you want to defrost food for 5 minutes and then cook at 80% microwave
power for 7 minutes, operate it as follows:
1. Press Weight / Time defrost
twice. The LED will display
“DEF2”.
2. Turn Selector to enter the
correct time “5:00”.
3. Press Microwave / Grill /
Combi. The LED will display
“P100”.
4. Press Microwave / Grill /
Combi again or turn Selector
to select 80% microwave
power.
5. Press Start / Conrm to
conrm and the screen will
display "P80".
6. Turn Selector to adjust the
cooking time until the oven
displays "7:00".
7. Press Start / Conrm again to start cooking. The buzzer will sound
once for the rst section and the defrosting time counts down. The
buzzer will then sound again and the second cooking stage is started.
Once cooking is complete, the buzzer will sound ve times.
Reference Description
Microwave / Grill /
Combi
Start / Conrm
Weight / Time defrost
Stop / Clear
00:00
Display
Selector

18
In
more
detail...
GB IE
Query Function
In microwave, grill and combination
cooking mode, press Microwave /
Grill / Combi and the current power
will be displayed for 3 seconds. After
3 seconds, the oven will switch back
to its former mode.
Lock-out Function for Children
>Lock:
In standby mode, press Stop /
Clear for 3 seconds and a long
beep will be heard to indicate
children-lock mode. The current
time will be displayed if set,
otherwise the LED will display
" ".
>Lock removal:
In locked mode, press Stop /
Clear for 3 seconds and a long
beep will indicate that the lock
has been released.
Operation
Reference Description
Microwave / Grill /
Combi
Reference Description
Microwave / Grill /
Combi
Start / Conrm
Weight / Time defrost
Stop / Clear
00:00
Display
Selector

19
In more detail...
GB IE
Care and maintenance
Care
Damaged power cables should be replaced by a
competent person or qualied electrician.
For domestic use only.
NOTE: If the appliance is not in use for a long period of time, disconnect
power, clean the inside parts, place the appliance in a dry area
and leave the door slightly open.
Protection from moisture
Warning
Always switch off the electricity supply before
performing maintenance work.
In the event of a fault, contact customer services.
Spraying the appliance with water is forbidden.
> Avoid placing the appliance in a place when heavy moisture is present in
order to minimise the possibility of its metal parts becoming rusted.
Protection from heat
> The appliance should be kept away from any heat source or direct
sunlight.
OFF

20
In
more
detail...
GB IE Care and maintenance
Materials you can use in microwave oven
Caution
> When heating food in plastic or paper containers, keep an
eye on the oven due to the possibility of ignition.
> Do not overcook food.
> Remove wire twist-ties and metal handles from paper or
plastic containers/bags before placing them in the oven.
> Eggs in their shells and whole hard-boiled eggs should not
be heated in microwave ovens as they may explode, even
after microwave heating is complete.
> The contents of feeding bottles and baby food jars shall
be stirred or shaken and the temperature checked before
consumption in order to avoid burns.
> Microwave heating of beverages can result in delayed
eruptive boiling. Therefore, care must be taken when
handing the container.
Aluminium foil
> Cover only. Small, smooth pieces can be used to cover thin parts of meat
or poultry to prevent overcooking. Arcing can occur if foil is too close to
oven walls. The foil should be at least 1 inch (2.5 cm) away from oven
walls.
Browning dish
> Follow the manufacturer’s instructions. The bottom of the browning dish
must be at least 3/16 inch (5 mm) above the turntable. Incorrect usage
may cause the turntable to break.
Dinnerware
> Microwave-safe only. Follow the manufacturer's instructions. Do not use
cracked or chipped dishes.
Glass jars
> Always remove lid. Use only to heat food until just warm. Most glass jars
are not heat resistant and may break.
