CoolAutomation CoolMasterNet User manual

Warning
Read these Safety Precautions carefully to ensure correct installation.
This manual classies precautions into WARNING and CAUTION.
WARNING
Only qualied personnel must carry out the installation work.
Ask your dealer or technical representative to install the unit.
Any deciency caused by your own installation may result in an electric shock or re.
All electrical work must be performed by a licensed technician, according to local
regulations and in accordance with the instructions in the installation manual.
Any lack of electric circuit or any deciency caused by installation may result in an electric
shock or re.
Do not relocate or reinstall the CoolMasterNet by yourself.
Any deciency caused by your own re-installation may result in an electric shock or re.
Make sure that all wiring is secured, that specied wires are used and that no external
forces act on terminal connections or wires. Improper wiring connections or installation
may produce heat and result in re.
Before touching electrical parts, turn o the unit.
To dispose of this product, consult your dealer.
Failure to follow WARNING is very likely to result in such grave consequences as
death or serious injury

Caution
CAUTION
Do not allow children to play with the CoolMasterNet and supervise them not to get access
to the appliance.
CoolMasterNet is not to be used by persons with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge.
Do not disassemble, modify or repair the CoolMasterNet.
Any deciency caused by your modication or repair may result in an electric shock or re.
Never let the CoolMasterNet to get wet.
Water can cause damage to the CoolMasterNet, and may cause an electric shock or re.
Do not use ammable materials (e.g. hairspray or insecticide) near the CoolMasterNet.
Do not clean the CoolMasterNet with organic solvents such as paint thinner. The use of
organic solvents may cause cracking, damaging the CoolMasterNet, causing electrical
shock or re.
Do not apply AC110V or AC220V to the CoolMasterNet. The maximum voltage that can be
applied to the unit directly is 24V DC.
If damaged CoolMasterNet can generate heat and cause a re.
Failure to follow CAUTION may result in serious injury or property damage,
and in certain circumstances, may result in a grave consequence.

Caution
DO NOT INSTALL THE COOLMASTERNET IN THE FOLLOWING LOCATIONS:
a) Where a mineral oil mist or oil spray or vapor is produced, for example, in a kitchen.
Plastic parts may deteriorate and fall o or result in water leakage.
b) Where corrosive gas, such as sulfurous acid gas, is produced.
c) Near machinery emitting electromagnetic waves.
Electromagnetic waves may disturb the operation of the CoolMasterNet and cause the unit
to malfunction.
d) Where ammable gas may leak, where there is carbon ber or ignitable dust
suspensions in the air, or where volatile ammable such as thinner or gasoline are
handled.
Operating the CoolMasterNet in such conditions can cause a re.
e) High temperature area or directly amed point.
Heating and/or re can occur.
f) Moist area, where there is exposure to water.
If water enters the inside of the CoolMasterNet, it may cause electric shock and electrical
components may fail.
Failure to follow CAUTION may result in serious injury or property damage,
and in certain circumstances, may result in a grave consequence.

What’s in the box
CoolMasterNet
1 RS232 DB9
Male to Female
cable
Optional
1 USB-Mini USB
cable
1 Ethernet
cable
AC Power supply adapter
100V-240V 50/60hz to 12V

CoolMasterNet
L8 – HVAC Line 8 (USB Host)
Power
Power Plug
RS232 Port
L1 – HVAC Line 1
L2 – HVAC Line 2
RS485
Ethernet Port
GPIOs
L7 – HVAC Line 7
L6 – HVAC Line 6
L5 – HVAC Line 5
L4 – HVAC Line 4
USB Device Port
DIP Switches P, Q, R, S
LCD Touch Screen
L8 — HVAC Line 8 (USB Host)
Power
Power Plug
RS232 Port
L1 — HVAC Line 1
L2 — HVAC Line 2
 RS485
Ethernet Port
GPIOs
L7 — HVAC Line 7
L6 — HVAC Line 6
L5 — HVAC Line 5
L4 — HVAC Line 4
USB Device Port
DIP Switches P, Q, R, S
LCD Touch Screen
1 2 3 4 5 6 7 8
15
13 12 11 10
14 9
16
All Units
21 L1.101
23 L1.102
25 L1.103
25 L7.101
MACADDR00001
L6 L8L5L4L3L2
192.168.0.1
DK 9/10 LG 128
All Off

Precongured CoolMasterNet
Type label
This label uniquely identies the manufacturer’s con-
guration of CoolMasterNet.
Located on the back of the enclosure.
Type label with Conguration sticker
A precongured label example:
congured for LG on L7
Conguration stickers for HVAC line L1
Daikin
Mitsubishi Electric
Panasonic (Sanyo)
Toshiba
Hitachi
Optional Support for service and diagnostics functions.
Conguration stickers for HVAC line L7
LG
Mitsubishi Heavy
Gree
Samsung
Midea
Trane
Kentatsu
Conguration stickers for HVAC line L8
Fujitsu

HVAC connectivity — on L1
HVAC Communication Terminals
Connect to the communication terminals on the
HVAC equipment:
HVAC communication terminal’s names*
* For Heat Recovery systems the connection is
at outdoor units only.
* Polarity is not required on the HVAC
communication line.
** Centralized (group) address required.
Connecting to the line plug
Secure the cables in the L1 line plug.
Plugging to the CoolMasterNet
Insert the plug in to the CoolMaster L1 socket
HVAC Terminal

HVAC connectivity — on L7
HVAC Communication Terminals
Connect to the communication terminals on the:
HVAC outdoor only
HVAC indoor or outdoor
Connecting to the line plug
Secure the cables in the L7 line plug. Plugging to
the CoolMasterNet
Plugging to the CoolMasterNet
Insert the plug in to the CoolMaster L7 socket.
HVAC Terminal

HVAC connectivity — on L8
HVAC Communication Terminals
Connect to the communication terminals on the
HVAC equipment:
HVAC communication terminal’s names*
* For Heat Recovery systems the connection is
at outdoor unit only.
Connecting to the Echelon adapter
Echelon U10 USB Network Interface (TP/FT-10)
adapter is required for connecting to Fujitsu
VRF. (Not supplied by CoolAutomation)
Connect Echelon via USB Extension cable
Connect the USB Extension cable (A-Male to
A-Female) to the Echelon adapter.
(Not supplied by CoolAutomation).
Plug in to the CoolMasterNet L8
Insert the USB cable in to the L8 USB host.
HVAC Terminal

CoolMasterNet installation complete
CoolMasterNet Unit screen
After successful installation, units screen will show all
the detected indoor units and their statuses.
Active HVAC line (DK 9/10) (Groups/Units)
Inactive HVAC line
All ON/OFF operation button
Scrollbar
Connected indoor unit with it’s address and
Set-Point temperature indication.
Indoor unit operation button (on/o)
Service settings button
CoolMasterNet MAC address
CoolMasterNet IP address
CoolRemote connectivity status
Connected - Communicating
Connected - Idle
Disconnected - with error code
To download the latest rmware www.coolautomation.com/support/coolmasternet
Firmware update FAQ www.coolautomation.com/support/faq/coolmasternet

Home Automation, BMS & CoolRemote
Home Automation / BMS
RS232 RS485 Ethernet
Router
CoolRemote App
Internet

Power supply
Option A
AC Power supply adapter
(Included in the Box)
100V-240V AC
50/60hz
Option B
Direct DC power supply
12V-24V DC
Direct DC power supply from local
electrical panel
12V DC

Option A - Manual
Go to: https://coolremote.net/register
Enter CoolMasterNet S/N number and PIN code,
printed on the sticker.
Register your user-name (email) and password to
remotely control & monitor all your HVAC units.
CoolRemote App
Option A - Automatic
Scan the QR code from the type label to auto ll-in
all the CoolMasterNet details forCoolRemote App.
Register your user-name (email) and password to
remotely control & monitor all your HVAC units.
Please connect the device to the Internet for successful registration and setup

Non-VRV HVAC system conguration on L1
Changing the dip switches , while DC voltage is present on L1, may damage
the CoolMasterNet.
For Daikin/Mitsubishi Electric Non-VRV/VRF equipment, DC voltage supply by CoolMasterNet might be required
for proper operation.
Make sure CoolMasterNet is disconnected from power and HVAC line.
Measure DC voltage on HVAC communication line L1
If no DC voltage. Daikin 14-16V DC, Mitsubishi 28-30V DC, change the dip switches as shown below
Turn ON the power for CoolMasterNet and connect it to HVAC line.
Mitsubishi Non-VRVDaikin Non-VRV

Appendix: Dip switches setup for VRV/VRF HVAC system on L1
HVAC systems setup on L1
Daikin
Panasonic (Sanyo)
Mitsubishi Electric
Hitachi
Toshiba
Changing HVAC System setup requires activation
For more info, see http://coolautomation.com/support/coolmasternet/activation

Appendix: Dip switches setup for VRV/VRF HVAC system on L7
HVAC systems setup on L7
Mitsubishi Heavy
Midea / ChigoGree
LG
Trane Kentatsu
Samsung
Changing HVAC System setup requires activation
For more info, see http://coolautomation.com/support/coolmasternet/activation

Appendix: GPIOs application
All On/O operation by external signal
All On All O

Mounting on a DIN rail
Place the device mounting feet
on the DIN rail
Push on the lower part of the
device onto the the DIN rail
to lock it in place
To unmount,
pull the mounting
lock down.
