CoolAutomation CoolPlug User manual

CoolPlug / CooLinkHub
HVAC Bridge
Version 2.7.0
Quick Installation Guide

2
CoolPlugs and CooLinkHub
System Overview
Wired connection - PBUS (Plug Bus) Topology
Wireless Connection Topology
CoolPlug Models
What’s in the box
Connecting CoolPlug DK (Daikin)
DK (Daikin) - P1 P2
DK (Daikin) - S21 (Old Rev.)
DK (Daikin) - S21 (New Rev.)
DK (Daikin) - S403
DK (Daikin) - Siesta Series
Connecting CoolPlug PN/SA/TO
Panasonic|Sanyo|Toshiba
Panasonic CAPRA
Connecting CoolPlug FJ (Fujitsu/General)
FJ (Fujitsu/General) - Option 1 - 3 wires
FJ (Fujitsu/General) - Option 2 - 3 wires
FJ (Fujitsu/General) - Option 3 - 2 wires
FJ (Fujitsu/General) - Option 4 - 3 wires to adapter
Connecting CoolPlug ME (Mitsubishi Electric)
ME (Mitsubishi Electric) Option 1 – [1] [2]
ME (Mitsubishi Electric) Option 2 – CN-105
5
10
15
21
17
23
24
25
26
28
31
32
34
35
38
36
Connecting CoolPlug MH (Mitsubishi Heavy)
Connecting CoolPlug HT (Hitachi)
Connecting CoolPlug LG (LG)
Connecting CoolPlug MD (Midea)
CoolPlug GRTS (Gree)
Gree - Option 1 - When WRC connect to indoor units board
Gree - Option 2 - When WRC connect to indoor units cable
Gree - Option 3 - 2 wires
Connecting CoolPlug Gree GMV5 (GR)
Connecting CoolPlug Samsung (SM)
Samsung - Option 1 - 2 wires
Samsung - Option 2 - 4 wires
Connecting Home Automation,
BMS & ControlApp
Control App
CoolPlug Operation
Wireless CoolPlug & CooLinkHub - Installation
Guidelines
How to pair and connect CoolPlug to CooLinkHub
Rebuilding the wireless mesh network
Mounting the CoolPlug
Contents
41

3
Safety Guidelines, Warnings and Cautions
Read and understand the following guidelines to ensure safe installation.
This equipment is to be installed by an accredited electrician
or equivalent technical person, as per these installation
instructions.
Read the installation instructions before connecting the system
to the power source.
All electrical work must be performed by a licensed technician,
according to local regulations.
Ultimate disposal of this product should be handled according
to all national laws and regulations.
Installation of the equipment must comply with local and
national electrical legislation for the installation of electric
equipment.
Do not install the devices outdoors or exposed to direct solar
radiation, water, high relative humidity, or dust.
Install the equipment only in a restricted access location.
When wall mounting, be sure to x rmly on a stable surface and
in accordance with the instructions below.
Failure to follow these WARNINGS may result in injury or death
When DIN rail mounting, x the devices properly to the DIN rail
following the instructions below.
When mounting on DIN rail inside a metallic cabinet be sure to
properly connect to the ground.
Unplug from power when connecting the wires.
Pay attention to the polarity of power and communication
cables during connection.
Disconnect power of any bus or communication cable before
connecting the system.

4
Cautions
Failure to follow these CAUTIONs may result in serious injury.
Do not allow children to play with the CoolPlug or CooLinkHub.
Do not disassemble, modify, or repair the CoolPlug or
CooLinkHub. Unauthorized modications or repairs may result
in electric shock or re. For support, contact CoolAutomation.
Do not expose the CoolPlug or CooLinkHub, to moisture.
Water can damage the CoolPlug or CooLinkHub resulting in an
electrical components failure, electric shock or re.
Do not use ammable materials (e.g. hairspray or insecticide)
near the CoolPlug or CooLinkHub. Do not clean with organic
solvents such as paint thinner.
Use only a dry cloth to wipe if necessary. The maximum voltage
that can be directly applied to the CooLinkHub is 24V DC.
Do not plug into AC110V or AC220V.
DO NOT INSTALL the COOLINKHUB or COOLPLUG IN THE
FOLLOWING LOCATIONS:
a) Where mineral oil mist or oil spray or vapor is produced, such
as in a kitchen. Plastic parts may deteriorate and fall off.
b) Where corrosive gas, such as sulfurous acid gas, is produced.
c) Near machinery emitting electromagnetic waves.
Electromagnetic waves may disturb or damage the operation of
the CooLinkHub.
d) Where ammable gas may leak, where there is carbon
ber or ignitable dust suspensions in the air, or where volatile
ammables such as thinner or gasoline are handled. Operating
the CooLinkHub or CoolPlug in such conditions may cause a re.
e) In high temperature areas or near any ame.
f) In moist areas, or where there is exposure to water.

5
The CoolPlugs & CooLinkHub solution allows seamless
integration of Split, Multi-Split and Mini-Split HVAC
units with Home Automation, BMS and Smart IOT
products and services; or full control and monitoring,
using a standalone CoolAutomation cloud-based App
(ControlApp).
Once connected, it allows full control of the indoor unit
including the following functions: on/off, operation
mode (cool/heat/fan/dry/auto), set points, adjust fan
speed and activate swivel.
The solution allows bidirectional communication with
the indoor unit for receiving error codes from the unit as
well as feedback about actual status of the HVAC unit.
CoolPlug connects directly to the HVAC indoor unit on
one end, and to the CooLinkHub on the other.
CooLinkHub - aggregates multiple CoolPlug devices
and provides wide interface options for controlling and
monitoring each of the CoolPlugs, either over the wired
network (PBUS) or a proprietary wireless mesh network.
CoolPlugs and CooLinkHub
System Overview

6
The PBUS is CoolAutomation's proprietary Bus, running on a shielded twisted pair cable (20-24AWG).
The PBUS utilizes daisy chain network topology. No loops are allowed.
Up to 10 CoolPlugs can be connected to a single CooLinkHub.
Wired connection - PBUS (PlugBus) Topology

7
WRLS Cool Plugs and WRLS CooLinkHub communicate with each other using CoolAutomation's 2.4 GHz proprietary and secured
mesh network.
Each WRLS CooLinkHub creates a network and automatically connects to all paired devices within this network (WRLS CoolPlugs).
Paring of the WRLS CoolPlugs with the specic WRLS CooLinkHub can be factory pre-set (prior to shipment) or congured locally
(please refer to pairing instructions at page 35).
Up to 10 CoolPlug devices can be connected to a single CooLinkHub.
The recommended distance between each of the two devices (CoolPlug/ CooLinkHub) is up to 20m (50 ft) line of sight. Please
note, that concrete walls, ceilings and other types of obstacles or noise caused from electro-magnetic elds (generated by power
cables or other sources), can signicantly impact signal strength and will result in reduced distance.
The network topology is a mesh type network, meaning that each device acts as a receiver and a transmitter, and repeats the
signal. For planning purposes, make sure you have connectivity between each of the two devices (CoolPlug with its neighbor
CoolPlug, or CoolPlug with the CooLinHub).
Wireless connection - PBUS (PlugBus) Topology

8
CoolPlug models are HVAC manufacturer specic. Each CoolPlug has a small round sticker with letters on its back (DK, DKS, etc.)
indicating the HVAC manufacturer that the CoolPlug is compatible with.
CoolPlug Models
HVAC Daikin S21, S21 narrow S21, P1 P2, S403
HVAC Daikin Siesta Series Siesta
HVAC Sanyo | Toshiba | Panasonic A B, R1 R2
HVAC Panasonic Capra CAPRA CN-CNT
HVAC Fujitsu/General FJ003 2 wires, 3 wires
HVAC Mitsubishi Electric CN105 CN105, 1 2
HVAC Mitsubishi Heavy 2 wires only
HVAC Hitachi VRF only
HVAC Midea X Y E
HVAC LG LG split cable
HVAC Gree GMV5 VRF only
HVAC Gree 4 wire x 4 4 wires, 2 wires
HVAC Samsung 4 wires, 2 wires
DK
FJ
MD
PNTOSA
MH
GR
SM
DKS
ME
LG
CAPRAPN
HT
GRTS
CoolPlug Model HVAC Vendor Cable included Terminals/comments

9
CooLinkHubCoolPlug
• CooLinkHub device
• USB cable
• RS-232 cable (optional)
• RJ45 Ethernet cable
• CoolPlug device
• Flat plastic back plate
• DIN rail plastic back plate
• 2 sticky bands
• 2 magnets
* Cables - only for specific brands. See table on P.8 above.
** For Midea wireless model - Power Adapter may be included if ordered seperately.
What is in the box?

10
Connecting the CoolPlug to the Daikin unit
Connect the CoolPlug's [P1], [P2] terminals to the
[P1], [P2] terminals on the indoor unit. Use the HVAC
manufacturer's Installation Manual for instructions on
the location of P1 P2 terminals on the Daikin unit.
Connecting the CoolPlug to the CooLinkHub
Wireless Mode: Check the devices were paired
successfully. See how to pair on page 35.
Wired Mode: Connect the signal wires of the PBUS
cable coming from the [VDC-], [1] and [2] terminals on
the CooLinkHub to the corresponding [-], [1] and [2]
terminals on the CoolPlug, respectively.
Please refer to the PBUS connection diagram on page 6.
Optional: Connect the Wired Remote Controller (WRC) in
parallel with CoolPlug.
Connecting CoolPlug DK (Daikin)
DK (Daikin) – When connecting to P1 P2
** Master/Slave conguration will be done by the CoolPlug
automatically.
* The connection is nonpolar.

11
Connecting the CoolPlug to the Daikin unit
Connect the S21 cable supplied with the CoolPlug,
between the CoolPlug RJ-11 connector and the S21 port on
the indoor unit's PCB. Use Daikin's installation manual for
the location of the S21 socket on the Daikin indoor PCB.
Connecting the CoolPlug to the CooLinkHub
Wireless Mode: Check the devices were paired
successfully. See how to pair on page 35.
Wired Mode: Connect the signal wires of the PBUS
cable between CoolPlug terminals [-], [1] and [2], and
CooLinkHub terminals [VDC-], [1] and [2], respectively.
Please refer to the PBUS connection diagram on page 6.
Optional: For connecting the Daikin Wired Remote
controller (WRC) in parallel with CoolPlug, the S21
Splitter is required. (This part can be purchased
from CoolAutomation).
** A different Daikin version might have a smaller 5 pin
connector, in that case use EKRS 21 adapter.
Connecting CoolPlug DK (Daikin)
DK (Daikin) – When connecting to s21 (Old Rev.)
* Master/Slave conguration will be done by the CoolPlug
automatically.
4

12
Connecting the CoolPlug to the Daikin unit.
Connect the S21 cable supplied with the CoolPlug,
between the CoolPlug Indoor connector (bottom S21
socket on CoolPlug) and the S21 port on the indoor unit's
PCB. Use Daikin's installation manual for the location of
the S21 socket on the Daikin indoor PCB.
Connecting the CoolPlug to the CooLinkHub.
Wireless Mode: Check the devices were paired
successfully. See how to pair on page 35.
Wired Mode: Connect the signal wires of the PBUS
cable between CoolPlug terminals [-], [1] and [2], and
CooLinkHub terminals [VDC-], [1] and [2], respectively.
Please refer to the PBUS connection diagram on page 6.
Optional: For connecting the Daikin Wired Remote
Controller connect the cable from controller to CoolPlug
WRC (Wired Remote Controller) socket (top S21 socket).
* On Some Daikin indoor models, you will need the cable with the
smaller 5 pin S21 connector. This cable is also provided with the
CoolPlug as an option were needed.
Connecting CoolPlug DK (Daikin)
DK (Daikin) – When connecting to S21 (New Rev. started from Q4 2021)

13
Connecting CoolPlug DK (Daikin)
DK (Daikin) – When connecting to S403 using KRP980B1
CoolPlug
Indoor Unit
KRP980B1
S403
PBUS network cable S21 cable
CooLinkHub
WRC
WRC
Indoor
Connecting the CoolPlug to the Daikin unit.
Connect the S21 cable supplied with the CoolPlug, between
the CoolPlug Indoor connector (bottom S21 socket on
CoolPlug) and the S21 port on KRP980B1 adapter's PCB.
Use Daikin's installation manual to install KRP980B1
adapter into the Daikin indoor unit. Connect adapter to the
S403 socket inside.
Connecting the CoolPlug to the CooLinkHub.
Wireless Mode: Check the devices were paired
successfully. See how to pair on page 35.
Wired Mode: Connect the signal wires of the PBUS
cable between CoolPlug terminals [-], [1] and [2], and
CooLinkHub terminals [VDC-], [1] and [2], respectively.
Please refer to the PBUS connection diagram on page 6.
Optional: To connect the Daikin Wired Remote Controller
connect the cable from controller to CoolPlug WRC
(Wired Remote Controller) socket (top S21 socket).
* KRP980B1 adapter should be purchased seperately from your
Daikin rep.

14
Connecting the CoolPlug to the Daikin Indoor Unit
Connect the cable (supplied with the CoolPlug) to
the port labeled “Indoor” on the CoolPlug and the
corresponding connector on the indoor unit.
Use Daikin's Installation Manual for instructions on
where to connect to on the Daikin indoor PCB.
Connecting the CoolPlug to the CooLinkHub
Wireless Mode: Check the devices were paired
successfully. See how to pair on page 35.
Wired Mode: Connect the signal wires of the PBUS
cable, using [VDC-], [1] and [2] terminals on the
CooLinkHub, to the corresponding [-], [1] and [2]
terminals on the CoolPlug.
Please refer to the PBUS connection diagram on page 6.
Optional: Connect the wired remote to the WRC socket
on the CoolPlug. The cable is supplied with the WRC.
Connecting CoolPlug DK (Daikin)
DKS (Daikin) – Siesta Series

15
Connecting the CoolPlug to the PN/SA/TO Indoor Unit
Connect the CoolPlug's [A], [B] terminals to [A], [B]
terminals to the indoor unit (Sanyo/Toshiba) or to [R1],
[R2] (Panasonic). Use HVAC manufacturer's Installation
Manual for instructions on nding those terminals on
the indoor unit PCB.
Connecting the CoolPlug to the CooLinkHub
Wireless Mode: Check the devices were paired
successfully. See how to pair on page 35.
Wired Mode: Connect the signal wires of the PBUS
cable coming from the [VDC-], [1] and [2] terminals on
the CooLinkHub to the corresponding [-], [1] and [2]
terminals on the CoolPlug.
Please refer to the PBUS connection diagram on page 6.
Optional: Connect the wired remote to the WRC socket
on the CoolPlug. The cable is supplied with the WRC.
Connecting CoolPlug PN|SA|TO
CoolPlug Panasonic/Sanyo/Toshiba
** Master/Slave conguration will be done by the CoolPlug
automatically.
* The connection is nonpolar.

16
Connecting CoolPlug PN|SA|TO
CoolPlug Panasonic CAPRA
Connecting the CoolPlug to the Panasonic units with
CAPRA connectors
Connect the CAPRA cable (supplied with the CoolPlug)
between the CoolPlug RJ-11 connector (CN - CNT) and
the CN - CNT port on the indoor unit’s PCB. Use HVAC
manufacturer’s installation manual for location of CN -
CNT connector on the indoor unit’s PCB.
Connecting the CoolPlug to the CooLinkHub
Wireless Mode: Check the devices were paired
successfully. See how to pair on page 35.
Wired Mode: Connect the signal wires of the PBUS
cable coming from the [VDC-], [1] and [2] terminals on
the CooLinkHub to the corresponding [-], [1] and [2]
terminals on the CoolPlug.
Please refer to the PBUS connection diagram on page 6.

17
Connecting the CoolPlug to the Fujitsu Indoor Unit
Connect the CoolPlug's [W1], [BIY], [RIY] terminals to
corresponding terminals on the indoor unit, keeping the
wiring consistent by colors.
Connecting the CoolPlug to the CooLinkHub
Wireless Mode: Check the devices were paired
successfully. See how to pair on page 35.
Wired Mode: Connect the signal wires of the PBUS cable,
using the [VDC-], [1] and [2] terminals on the CooLinkHub,
to the corresponding [-], [1] and [2] terminals on the
CoolPlug.
Please refer to the PBUS connection diagram on page 6.
Connecting CoolPlug FJ
FJ (Fujitsu/General) -Option 1: 3 wires
*** Reset power of the Fujitsu Indoor unit, once the CoolPlug is installed.
* For indoor units that work with APG000 or compatible WRC models.
** Room temperature will not be shown if original WRC is not connected.
Optional: Connect the Wired Remote Controller (WRC) in
parallel with CoolPlug.
**** Master/Slave conguration will be done by the CoolPlug automatically.

18
Connecting the CoolPlug to the Fujitsu Indoor Unit
Connect the CoolPlug's [W1], [BIY], [RIY] terminals to the
corresponding terminals (for WRC) on the indoor unit.
Use Fujitsu's Installation manual for instructions on
how to locate those terminals for WRC.
Connecting the CoolPlug to the CooLinkHub
Wireless Mode: Check the devices were paired
successfully. See how to pair on page 35.
Wired Mode: Connect the signal wires of the PBUS
cable from the [VDC-], [1] and [2] terminals on the
CooLinkHub to the corresponding [-], [1] and [2]
terminals on the CoolPlug.
Please refer to the PBUS connection diagram on page 6.
Connecting CoolPlug FJ
FJ (Fujitsu/General) - Option 2: 3 wires
*** Room temperature will not be presented if original WRC
is not connected.
** Reset power of AC indoor unit, once the CoolPlug is
installed.
* For indoor units that work with EZ-099 or compatible type
wired remote controllers.
Optional: Connect CoolPlug's [W2], [B2], [R2] terminals
to the Fujitsu Wired Remote Controller (WRC).

19
Connecting the CoolPlug to the Fujitsu Indoor Unit
Connect the CoolPlug's [B1/Y], [R1/Y] terminals to the
Y1 Y2 terminals on the indoor unit accordingly.
Connecting the CoolPlug to the CooLinkHub
Wireless Mode: Check the devices were paired
successfully. See how to pair on page 35.
Wired Mode: Connect the signal wires of the PBUS
cable, using the [VDC-], [1] and [2] terminals on the
CooLinkHub, to the corresponding [-], [1] and [2]
terminals on the CoolPlug. Please refer to the PBUS
connection diagram on page 6.
Connecting CoolPlug FJ
FJ (Fujitsu/General) - Option 3: 2 wires
* Reset power of AC indoor unit, once the CoolPlug is
installed.
*** The connection is nonpolar.
** If indoor unit has V1, V2, V3 terminals, connect the
CoolPlug and WRC to terminals V1, V2.
Optional: Connect the Wired Remote Controller (WRC) in
parallel with CoolPlug.
**** Master/Slave conguration will be done by the CoolPlug
automatically.

20
Connecting CoolPlug FJ
FJ (Fujitsu/General) -Option 4: Wall mounted units - 3 wires to adapter
* To get the room temperature use external Thermo sensor.
The sensor is purchased separately from CoolAutomation.
Connecting the CoolPlug to the Fujitsu UTY-XCBXZ1/UTY-
XCBXZ2/UTY- TWBXF adapter
Connect the FJ-003 cable supplied with the CoolPlug to
[W1], [BY], [RY] ports on the the CoolPlug side, and the
5 pin cable connector to the UTY-XCBXZ1/UTY-XCBXZ2/
UTY- TWBXF adapter.
Connecting the CoolPlug to the CooLinkHub
Wireless Mode: Check the devices were paired
successfully. See how to pair on page 35.
Wired Mode: Connect the signal wires of the PBUS cable,
using the [VDC-], [1] and [2] terminals on the CooLinkHub,
to the corresponding [-], [1] and [2] terminals on the
CoolPlug.
Please refer to the PBUS connection diagram on page 6.
Optional: Connect the Wired Remote Controller (WRC) in
parallel with CoolPlug.
