Cooper & Hunter CH-HP30MFNM User manual

Direct & Circulating Air Source
Heat Pump Water Heater Technical
Service Manual
Air Conditioners
Service Manual
Thank you for choosing Commercial Air Conditioners, please read this
service manual carefully before operation and retain it for future reference.

CONTENTS
PRODUCT......................................................................................................2
1 Product List ................................................................................................................ 2
2 Rule of naming........................................................................................................... 2
3 Product characteristics............................................................................................... 3
4 Technical data table ................................................................................................... 4
5 Capacity correction chart ........................................................................................... 5
6 Operating principle....................................................................................................11
CONTROL....................................................................................................13
1 Unit Control .............................................................................................................. 13
2 Wired controller ....................................................................................................... 16
3 Dial code operation instructions of water heater mainboard.................................... 30
MAINTENANCE...........................................................................................33
6LJQL¿FDQFHRIPDLQWHQDQFH .................................................................................... 33
2 Regular Maintenance Items ..................................................................................... 33
3 Winter anti-freezing solution .................................................................................... 34
INSTALLATION............................................................................................36
1 List of Unit errors...................................................................................................... 36
2 Typical Troubleshooting ........................................................................................... 38
3 Power Distribution of Unit ........................................................................................ 45
4 Removal/Installation of Unit Parts............................................................................ 48
5 Common Maintenance Operations .......................................................................... 64
6 Unit Explosion View and Parts List .......................................................................... 65

1
Direct & Circulating Air Source
Heat Pump Water Heater
PRODUCT
QSPEVDU

2
Direct & Circulating Air Source
Heat Pump Water Heater
QSPEVDU
PRODUCT
1 Product List
Unit Model Product Code Heating
Capacity (kW)
Hot Water
Output
Volume (L/h)
Power Supply Refrigerant Outline Photo
CH-
HP30MFNM
ER01000080 31 667 380-415V
3N 50Hz R410A
CH-
HP40MFNM ER01000090 40 860 380-415V 3N 50Hz R410A
CH-
HP60MFNM ER01000100 60 1300 380-415V 3N 50Hz R410A
2 Rule of naming
([DPSOHCH-HP40MFNMPHDQVGLUHFWKHDWLQJPRGXODU¿[HGVSHHGKHDWSXPSZDWHUKHDWHUZLWKRXW
water tank, heating capacity of 40kW, refrigerant of R410A, rated voltage of 380-415V 3N/50Hz and applicable
for T1 climate.
CH-
1 234567
SN Description Options
1 Product code
Export heat pump water heater
2
M - modular
3 Nominal heating capacity 40
4 Type
5 Type of system F- fixed speed type
6 Refrigerant N- R410A
7 Power supply M:380-415V 3N~50Hz
Cooper&Hunter
Heat Pump Water Heater

3
Direct & Circulating Air Source
Heat Pump Water Heater
QSPEVDU
3 Product characteristics
The direct heating circulating air to water heat pump water heater uses an advanced waterway automatic-
control system. After entering the unit, cold water is heated to 55°C, and directly enters the heat accumulation
tank to be used by the user. In addition, when the water temperature drops in the tank, cyclic insulation can be
implemented automatically to ensure hot water temperature in it. The unit operates at all weather conditions all
year around in the range from -26°C to 46°C. It is widely applicable for various sites that require domestic water
VXFKDVKRWHOVIDFWRULHVÀDWVYLOODVKDLUVDORQVIRRWSDWKFHQWHUVDQGVZLPPLQJSRROV7KHZDWHUKHDWHUV
with three kinds of heating capacity are available: 31kW, 40kW, and 60kW. The modular unit combines 1 to 16
same or different unit modules to form series products with the heating capacity in the range from 31kW to
960kW and meet different engineering requirements.
ƇHigh outlet water temperature
The advanced waterway control system is used, and the outlet water temperature is high. The factory
setting is 55°C, but the maximum outlet water temperature can reach 70°C.
ƇHot water is generated rapidly and supplied upon start-up
The direct heating design ensures that cold water is immediately heated to the usable temperature after
entering the system. Hot water is supplied upon start-up. The hot water output is large and the speed is high.
ƇHigh EER
The EER is high.The average EER is above 4.0 and the maximum value is 5.8. At the same energy
consumption, the hot water output far surpasses that of other water heating devices.
ƇSafe and reliable operating
A heat pump is used to produce hot water for life. Different from the mode that electricity or fuel is used to
directly heat water, this mode eliminates dangers of traditional water heaters such as flammability, explosiveness,
gas poisoning, and electric shock. The cutting-edge microcomputer control system provides complete protection
functions and eradicates the hidden safety hazards such as leakage of electricity, dry burning, and ultra-high
temperature. After repeated researches and tests by experts, the optimized design features a compact and
pleasant structure, simple and convenient control, safe and reliable performance, and leading EER in the world.
All the key parts are supplied by renowned manufacturers in the world. By virtue of elaborate processing of
C&H, every unit has passed a strict performance test before delivery to ensure that it FDQRSHUDWHVWDEO\DQG
HI¿FLHQWO\IRUDORQJWHUP
ƇSimple and convenient control
The unattended microcomputer system implements automatic control. The user-friendly English man-
machine interface enables the user to know the system status at a glance. With the multi-module and network-
based control, a system can control as many as 16 master units, and implement convenient and fast control.
The user can press the button to get hot water.
ƇFlexible installation
The compact and small size of the unit facilitates transportation. A special equipment room is not required,
DQGLQVWDOODWLRQLVÀH[LEOH7KHPRGXODUGHVLJQUHDOL]HVIUHHFRPELQDWLRQDQGFRQYHQLHQWH[WHQVLRQ7KHVLPSOH
pipeline system makes maintenance easy and convenient, applicable to all kinds of projects.
ƇEnvironmental protection
The heat pump technology of reverse Carnot cycle is used to absorb heat in the air to heat water for life. No
gas is discharged during the operation, so the unit is a green environmental-protection product. This heating
mode is different from mineral fuel such as coal, oil, or gas that contaminates the environment in the burning
process.
Ƈ 3URWHFWLRQIXQFWLRQGLYHUVL¿FDWLRQ
The unit has multiple switches such as the high pressure switch, low pressure switch, high discharge
WHPSHUDWXUHSURWHFWLRQFRPSUHVVRURYHUORDGSURWHFWLRQLQVXI¿FLHQWZDWHUSUHVVXUHSURWHFWLRQDQGDXWRPDWLF
anti-freezing protection in winter, which secure normal operation of the system.

4
Direct & Circulating Air Source
Heat Pump Water Heater
QSPEVDU
4 Technical data table
Model CH-HP30MFNM CH-HP40MFNM CH-HP60MFNM
Heating capacity kW 31 40 60
Heating power input kW 8.1 10 15
Heating current input A 14.5 19 28
&RHI¿FLHQWRISHUIRUPDQFH W/W 3.83 4 4
Rated power input kW 10.5 13 20
Rated current input A 20 25 35.4
Nominal hot water output L/h 667 860 1300
Set temperature °C
1.Set temperature for direct heating outlet water:
(default)55°C,adjustable within the range of 35~70°C
2.Set temperature for circulating insulation:
(default)46°C,adjustable within the range of 30~51°C
Power 380-415V 3N~50Hz
Compressor Type Totally-enclosed vortex compressor
Quantiry Unit 1 1 1
Refrigrant Name R410A
Charge kg 3.9 4.73 6.5
Heat exchanger Air side Fin heat exchanger
Water side Tube in tube heat exchanger
Water System
Circulating
ZDWHUÀRZ m3/h 5.3 6.9 10.4
Circulating water
pressure drop kPa 120 150 120
Permissible
maximum pressure MPa 0.8
Maximum Inlet
water pressure MPa 0.4
Minimum Inlet
water pressure MPa 0.15
Diameter of external
water pipe
Direct model
inlet
mm
DN25 DN25 DN32
Cyclic model
inlet DN32 DN32 DN50
Outlet DN32 DN32 DN50
6SHFL¿FDWLRQ
of pipe joint
Direct model
inlet
inch
G 3/4 G 1 G 1-1/4
Cyclic model
inlet G 1-1/4 G 1-1/4 G 2
Outlet G 1-1/4 G 1-1/4 G 2
Outline size Width × depth
×height mm 930×800×1605 930×800×1605 1340×800×1605
Package size Width × depth
×height mm 1010×865×1775 1010×865×1775 1420×880×1775
Noise dB(A)   
Unit net weight /Gross weight kg 238/252 264/286 362/378
Remarks:
1) Rated testing conditions: outdoor ambient temperature 20°C DB/15°C WB, inlet temperature 15°C, outlet
temperature 55°C, voltage 380V/50HZ;
2) Usable range: ambient temperature -26 ~ 46°C
3) The listed water resistance is water resistance under rated working conditions. When there is a
difference between the ambient and inlet temperatures, unit hot water output will change accordingly, and the
water resistance may be different from the listed value.
4) ,IWKHVSHFL¿FDWLRQVDUHFKDQJHGGXHWRSURGXFWLPSURYHPHQWSOHDVHUHIHUWRWKHSDUDPHWHUVRQWKH
nameplate.

5
Direct & Circulating Air Source
Heat Pump Water Heater
QSPEVDU
5 Capacity correction chart
Model Water inlet temperature(°C)
&LUFXODWLQJZDWHUÀRZP3/h,Outdoor ambient temperature(DB/WB °C)
-20 -7/-8 7/6 20/15 30/22 35/24 46/28
CH-HP30MFNM
Heating
Capacity(kW)
40 9.71 15.55 21.98 28.12 33.00 32.67 36.28
45 9.51 15.49 21.95 27.86 32.47 32.45 36.25
50 9.23 15.02 21.79 27.41 31.85 32.17 36.01
Heating Power
Input(kW)
40 6.11 7.35 7.18 7.61 7.96 7.39 7.74
45 6.53 8.05 8.10 8.41 8.60 8.10 8.41
50 6.85 8.42 9.04 9.31 9.30 8.78 9.07
&RHI¿FLHQWRI
performance(W/W)
40 1.59 2.12 3.06 3.69 4.15 4.42 4.69
45 1.46 1.92 2.71 3.31 3.78 4.01 4.31
50 1.35 1.78 2.41 2.94 3.43 3.66 3.97
Model Water outlet temperature(°C)
&LUFXODWLQJZDWHUÀRZP3/h,Outdoor ambient temperature(DB/WB °C)
-20 -7/-8 7/6 20/15 30/22 35/24 46/28
CH-HP30MFNM
Heating
Capacity(kW)
45 9.51 15.43 22.35 28.02 33.00 32.49 36.70
50 9.51 15.41 22.10 27.86 32.47 32.45 36.42
55 9.27 15.20 21.96 27.72 31.85 32.04 36.03
Heating Power
Input(kW)
45 6.60 7.67 8.29 7.61 7.96 7.36 7.57
50 7.33 8.52 8.99 8.41 8.60 8.10 8.28
55 7.17 9.05 10.13 9.31 9.30 8.72 8.98
&RHI¿FLHQWRI
performance(W/W)
45 1.44 2.01 2.69 3.69 4.15 4.42 4.85
50 1.30 1.81 2.46 3.31 3.78 4.01 4.40
55 1.29 1.68 2.17 2.94 3.43 3.68 4.01
Model Water inlet temperature(°C)
Water outlet temperature 50°C,Outdoor ambient temperature(DB/WB°C)
-20 -7/-8 7/6 20/15 30/22 35/24 46/28
CH-HP30MFNM
Heating
Capacity(kW)
9 9.50 16.46 23.20 30.61 34.59 33.97 40.87
15 9.06 16.56 23.49 31.03 34.76 34.31 40.07
20 9.18 16.44 23.35 31.13 33.65 34.13 41.33
25 9.27 15.78 23.34 31.45 34.27 33.09 41.16
Heating Power
Input(kW)
9 6.06 7.05 7.02 7.26 7.64 7.01 7.06
15 6.21 7.00 7.34 7.69 7.71 7.12 7.14
20 6.38 7.33 7.41 7.73 7.75 7.19 7.23
25 6.68 7.30 7.46 7.74 8.12 7.28 7.39
&RHI¿FLHQWRI
performance(W/W)
9 1.57 2.33 3.31 4.22 4.53 4.84 5.79
15 1.46 2.37 3.20 4.04 4.51 4.82 5.61
20 1.44 2.24 3.15 4.03 4.34 4.75 5.72
25 1.39 2.16 3.13 4.06 4.22 4.54 5.57

6
Direct & Circulating Air Source
Heat Pump Water Heater
QSPEVDU
Model Water inlet temperature(°C)
Water outlet temperature 55°C,Outdoor ambient temperature(DB/WB°C)
-20 -7/-8 7/6 20/15 30/22 35/24 46/28
CH-HP30MFNM
Heating
Capacity(kW)
9 9.21 16.38 23.32 30.55 34.60 34.36 40.94
15 9.40 16.38 23.90 30.95 34.12 34.02 40.32
20 9.49 16.23 23.28 31.22 33.68 33.81 41.01
25 9.18 15.81 23.39 31.57 34.47 33.32 41.01
Heating Power
Input(kW)
9 6.39 7.45 7.66 7.84 8.24 7.63 7.57
15 6.61 7.33 7.85 8.08 8.26 7.69 7.74
20 6.70 7.65 8.03 8.19 8.32 7.82 7.81
25 7.06 7.71 8.05 8.32 8.66 7.85 7.99
&RHI¿FLHQWRI
performance(W/W)
9 1.44 2.20 3.04 3.90 4.20 4.50 5.41
15 1.42 2.24 3.04 3.83 4.13 4.43 5.21
20 1.42 2.12 2.90 3.81 4.05 4.32 5.25
25 1.30 2.05 2.91 3.80 3.98 4.25 5.13
Model Water inlet temperature(°C)
Water outlet temperature 60°C,Outdoor ambient temperature(DB/WB°C)
-20 -7/-8 7/6 20/15 30/22 35/24 46/28
CH-HP30MFNM
Heating
Capacity(kW)
9 9.46 16.19 23.60 30.29 34.63 34.14 /
15 9.33 16.17 23.71 31.00 34.01 34.44 /
20 9.62 16.47 23.26 31.27 33.79 34.07 /
25 9.39 15.97 23.44 31.84 34.56 33.46 /
Heating Power
Input(kW)
9 6.79 7.80 8.17 8.43 8.80 8.28 /
15 7.01 7.67 8.50 8.71 8.84 8.24 /
20 7.03 7.93 8.58 8.88 8.84 8.43 /
25 7.42 8.01 8.63 8.89 9.27 8.34 /
&RHI¿FLHQWRI
performance(W/W)
9 1.39 2.07 2.89 3.59 3.93 4.13 /
15 1.33 2.11 2.79 3.56 3.85 4.18 /
20 1.37 2.08 2.71 3.52 3.82 4.04 /
25 1.27 1.99 2.72 3.58 3.73 4.01 /
Model Water inlet temperature(°C)
Water outlet temperature 65°C,Outdoor ambient temperature(DB/WB°C)
-20 -7/-8 7/6 20/15 30/22 35/24 46/28
CH-HP30MFNM
Heating
Capacity(KW)
9 / / 23.56 30.84 / / /
15 / / 23.98 30.74 / / /
20 / / 23.22 31.59 / / /
25 / / 23.33 31.39 / / /
Heating Power
Input(KW)
9 / / 8.69 9.06 / / /
15 / / 9.05 9.26 / / /
20 / / 9.08 9.43 / / /
25 / / 9.25 9.49 / / /
&RHI¿FLHQWRI
performance(W/W)
9 / / 2.71 3.41 / / /
15 / / 2.65 3.32 / / /
20 / / 2.56 3.35 / / /
25 / / 2.52 3.31 / / /

7
Direct & Circulating Air Source
Heat Pump Water Heater
QSPEVDU
Model Water inlet temperature(°C) Water outlet temperature 70°C,Outdoor ambient temperature(DB/WB°C)
-20 -7/-8 7/6 20/15 30/22 35/24 46/28
CH-HP30MFNM
Heating
Capacity(kW)
9 / / 23.35 30.66 / / /
15 / / 23.69 31.21 / / /
20 / / 23.63 31.07 / / /
25 / / 23.27 31.72 / / /
Heating Power
Input(kW)
9 / / 9.24 9.60 / / /
15 / / 9.55 9.86 / / /
20 / / 9.63 10.05 / / /
25 / / 9.78 10.05 / / /
&RHI¿FLHQWRI
performance(W/W)
9 / / 2.53 3.19 / / /
15 / / 2.48 3.17 / / /
20 / / 2.45 3.09 / / /
25 / / 2.38 3.16 / / /
Model Water inlet temperature(°C) &LUFXODWLQJZDWHUÀRZP3/h,Outdoor ambient temperature(DB/WB°C)
-20 -7/-8 7/6 20/15 30/22 35/24 46/28
CH-HP40MFNM
Heating
Capacity(kW)
40 13.36 19.99 29.38 36.87 43.66 43.41 47.66
45 13.48 20.33 28.69 35.95 42.81 42.83 47.22
50 13.21 19.86 27.87 34.78 41.95 41.20 46.73
Heating Power
Input(kW)
40 8.29 9.24 9.36 9.50 9.95 9.29 9.71
45 9.25 10.37 10.25 10.30 10.72 10.07 10.51
50 9.99 10.98 11.31 11.11 11.55 10.92 11.40
&RHI¿FLHQWRI
performance(W/W)
40 1.61 2.16 3.14 3.88 4.39 4.67 4.91
45 1.46 1.96 2.80 3.49 3.99 4.25 4.49
50 1.32 1.81 2.46 3.13 3.63 3.77 4.10
Model Water outlet temperature(°C) &LUFXODWLQJZDWHUÀRZP3/h,Outdoor ambient temperature(DB/WB°C)
-20 -7/-8 7/6 20/15 30/22 35/24 46/28
CH-HP40MFNM
Heating
Capacity(kW)
45 13.10 20.60 27.34 36.87 43.66 43.41 47.75
50 13.47 19.46 28.28 35.95 42.81 42.83 47.31
55 13.60 19.82 27.92 34.78 41.95 41.20 46.82
Heating Power
Input(kW)
45 8.84 9.99 9.95 9.50 9.95 9.29 9.54
50 9.79 10.46 10.60 10.30 10.72 10.07 10.34
55 10.66 11.63 12.39 11.11 11.55 10.92 11.23
&RHI¿FLHQWRI
performance(W/W)
45 1.48 2.06 2.75 3.88 4.39 4.67 5.01
50 1.38 1.86 2.67 3.49 3.99 4.25 4.58
55 1.28 1.70 2.25 3.13 3.63 3.77 4.17
Model Water inlet temperature(°C) Water outlet temperature 50°C,Outdoor ambient temperature(DB/WB°C)
-20 -7/-8 7/6 20/15 30/22 35/24 46/28
CH-HP40MFNM
Heating
Capacity(kW)
9 12.93 22.65 32.41 40.45 46.79 46.86 52.58
15 13.39 22.80 33.23 40.25 46.83 46.05 51.21
20 13.37 22.53 32.62 39.71 47.20 45.94 51.58
25 13.24 21.82 32.35 39.21 46.74 45.52 51.12
Heating Power
Input(kW)
9 7.99 8.86 8.97 9.20 9.60 8.79 8.94
15 8.15 8.88 9.17 9.31 9.70 9.06 9.03
20 8.29 9.08 9.37 9.60 9.77 9.16 9.22
25 8.47 9.23 9.52 9.58 9.95 9.39 9.37
&RHI¿FLHQWRI
performance(W/W)
9 1.62 2.56 3.61 4.40 4.87 5.33 5.88
15 1.64 2.57 3.62 4.32 4.83 5.08 5.67
20 1.61 2.48 3.48 4.14 4.83 5.02 5.59
25 1.56 2.36 3.40 4.09 4.70 4.85 5.46

8
Direct & Circulating Air Source
Heat Pump Water Heater
QSPEVDU
Model Water inlet temperature(°C) Water outlet temperature 55°C,Outdoor ambient temperature(DB/WB°C)
-20 -7/-8 7/6 20/15 30/22 35/24 46/28
CH-HP40MFNM
Heating
Capacity(kW)
9 12.61 22.47 34.10 40.43 46.16 46.08 52.10
15 13.18 22.21 33.49 40.22 46.20 45.01 51.21
20 13.08 22.10 32.47 39.33 46.46 45.20 51.27
25 13.03 21.79 32.46 39.18 45.77 45.20 50.80
Heating Power
Input(kW)
9 8.33 9.23 9.51 9.75 10.15 9.37 9.46
15 8.49 9.32 9.76 9.88 10.29 9.58 9.57
20 8.68 9.44 9.96 10.12 10.33 9.72 9.74
25 8.84 9.53 9.98 10.18 10.56 9.77 9.94
&RHI¿FLHQWRI
performance(W/W)
9 1.51 2.41 3.59 4.15 4.55 4.92 5.51
15 1.55 2.38 3.43 4.07 4.49 4.70 5.35
20 1.51 2.34 3.26 3.89 4.50 4.65 5.26
25 1.47 2.29 3.25 3.85 4.33 4.63 5.11
Model Water inlet temperature(°C) Water outlet temperature 60°C,Outdoor ambient temperature(DB/WB°C)
-20 -7/-8 7/6 20/15 30/22 35/24 46/28
CH-HP40MFNM
Heating
Capacity(kW)
9 / 21.80 33.91 40.33 45.28 45.03 /
15 / 21.80 32.99 40.23 45.70 44.47 /
20 / 21.70 32.82 40.05 45.57 44.56 /
25 / 20.85 32.61 39.13 44.94 44.39 /
Heating Power
Input(kW)
9 / 9.60 10.12 10.26 10.76 9.96 /
15 / 9.85 10.36 10.41 10.91 10.18 /
20 / 9.80 10.55 10.60 10.94 10.20 /
25 / 9.96 10.74 10.92 11.08 10.28 /
&RHI¿FLHQWRI
performance(W/W)
9 / 3.23 3.35 3.93 4.21 4.52 /
15 / 2.21 3.18 3.86 4.19 4.37 /
20 / 2.21 3.11 3.78 4.17 4.37 /
25 / 2.09 3.04 3.58 4.06 4.32 /
Model Water inlet temperature(°C) Water outlet temperature 65°C,Outdoor ambient temperature(DB/WB°C)
-20 -7/-8 7/6 20/15 30/22 35/24 46/28
CH-HP40MFNM
Heating
Capacity(kW)
9 / / 33.97 40.37 / / /
15 / / 33.46 40.19 / / /
20 / / 33.16 39.68 / / /
25 / / 32.53 39.11 / / /
Heating Power
Input(kW)
9 / / 10.74 10.80 / / /
15 / / 10.90 11.01 / / /
20 / / 11.05 11.22 / / /
25 / / 11.23 11.50 / / /
&RHI¿FLHQWRI
performance(W/W)
9 / / 3.16 3.74 / / /
15 / / 3.07 3.65 / / /
20 / / 3.00 3.54 / / /
25 / / 2.90 3.40 / / /
Model Water inlet temperature(°C) Water outlet temperature 70°C,Outdoor ambient temperature(DB/WB°C)
-20 -7/-8 7/6 20/15 30/22 35/24 46/28
CH-HP40MFNM
Heating
Capacity(kW)
9 / / 32.51 40.35 / / /
15 / / 33.35 40.15 / / /
20 / / 32.52 39.47 / / /
25 / / 32.36 39.07 / / /
Heating Power
Input(kW)
9 / / 11.34 11.30 / / /
15 / / 11.52 11.63 / / /
20 / / 11.60 11.78 / / /
25 / / 11.80 12.32 / / /
&RHI¿FLHQWRI
performance(W/W)
9 / / 2.87 3.57 / / /
15 / / 2.89 3.45 / / /
20 / / 2.80 3.35 / / /
25 / / 2.74 3.17 / / /

9
Direct & Circulating Air Source
Heat Pump Water Heater
QSPEVDU
Model Water inlet temperature(°C) &LUFXODWLQJZDWHUÀRZP3/h,Outdoor ambient temperature(DB/WB°C)
-20 -7/-8 7/6 20/15 30/22 35/24 46/28
CH-HP60MFNM
Heating
Capacity(kW)
40 19.20 28.04 40.52 52.53 61.92 60.96 64.68
45 19.23 27.87 40.23 51.78 61.00 60.44 64.44
50 19.17 27.71 39.69 50.85 59.54 59.30 64.03
Heating Power
Input(kW)
40 12.68 13.49 13.32 13.83 14.38 13.33 13.85
45 14.15 14.85 14.84 15.24 15.39 14.51 15.14
50 15.66 16.11 16.67 16.86 16.66 16.06 16.57
&RHI¿FLHQWRI
performance(W/W)
40 1.51 2.08 3.04 3.80 4.31 4.57 4.67
45 1.36 1.88 2.71 3.40 3.96 4.17 4.26
50 1.22 1.72 2.38 3.02 3.57 3.69 3.86
Model Water outlet temperature(°C) &LUFXODWLQJZDWHUÀRZP3/h,Outdoor ambient temperature(DB/WB°C)
-20 -7/-8 7/6 20/15 30/22 35/24 46/28
CH-HP60MFNM
Heating
Capacity(kW)
45 19.26 27.65 40.62 52.53 61.92 60.96 64.68
50 19.20 27.51 40.45 51.78 61.00 60.44 64.44
55 19.02 27.49 40.27 50.85 59.54 59.30 64.03
Heating Power
Input(kW)
45 14.24 14.12 15.16 13.83 14.38 13.33 13.85
50 15.65 15.49 16.28 15.24 15.39 14.51 15.14
55 15.64 17.13 18.63 16.86 16.66 16.06 16.57
&RHI¿FLHQWRI
performance(W/W)
45 1.35 1.96 2.68 3.80 4.31 4.57 4.67
50 1.23 1.78 2.48 3.40 3.96 4.17 4.26
55 1.22 1.60 2.16 3.02 3.57 3.69 3.86
Model Water inlet temperature(°C) Water outlet temperature 50°C,Outdoor ambient temperature(DB/WB°C)
-20 -7/-8 7/6 20/15 30/22 35/24 46/28
CH-HP60MFNM
Heating
Capacity(kW)
9 19.66 28.71 47.60 59.35 67.57 66.60 72.50
15 19.54 27.37 48.08 59.31 67.42 67.18 72.39
20 19.51 28.37 47.89 59.16 67.33 67.00 72.43
25 19.48 28.33 47.81 59.26 67.05 66.96 72.32
Heating Power
Input(kW)
9 10.58 11.66 13.03 13.70 13.99 13.67 13.73
15 10.72 11.81 13.22 13.81 14.13 13.89 13.94
20 10.89 11.95 13.37 13.96 14.30 14.04 14.12
25 11.03 12.12 13.49 14.15 14.44 14.20 14.28
&RHI¿FLHQWRI
performance(W/W)
9 1.86 2.46 3.65 4.33 4.83 4.87 5.28
15 1.82 2.32 3.64 4.30 4.77 4.84 5.19
20 1.79 2.37 3.58 4.24 4.71 4.77 5.13
25 1.77 2.34 3.54 4.19 4.64 4.72 5.06
Model Water inlet temperature(°C) Water outlet temperature 55°C,Outdoor ambient temperature(DB/WB°C)
-20 -7/-8 7/6 20/15 30/22 35/24 46/28
CH-HP60MFNM
Heating
Capacity(kW)
9 19.66 28.78 48.28 59.60 67.62 67.26 72.66
15 19.56 28.67 48.23 59.48 67.56 67.20 72.64
20 19.54 28.56 48.08 59.32 67.52 67.08 72.53
25 19.50 28.48 47.93 59.32 67.46 67.03 72.33
Heating Power
Input(kW)
9 10.99 12.06 13.73 14.40 14.68 14.37 14.43
15 11.13 12.21 13.91 14.52 14.83 14.59 14.63
20 11.29 12.35 14.06 14.67 15.00 14.74 14.81
25 11.44 12.52 14.20 14.85 15.12 14.90 14.98
&RHI¿FLHQWRI
performance(W/W)
9 1.79 2.39 3.52 4.14 4.61 4.68 5.03
15 1.76 2.35 3.47 4.10 4.56 4.60 4.97
20 1.73 2.31 3.42 4.04 4.50 4.55 4.90
25 1.70 2.27 3.38 3.99 4.46 4.50 4.83

10
Direct & Circulating Air Source
Heat Pump Water Heater
QSPEVDU
Model Water inlet temperature(°C) Water outlet temperature 60°C,Outdoor ambient temperature(DB/WB°C)
-20 -7/-8 7/6 20/15 30/22 35/24 46/28
CH-HP60MFNM
Heating
Capacity(kW)
9 / 28.83 48.19 59.62 67.72 67.25 /
15 / 28.72 48.21 59.41 67.56 67.22 /
20 / 28.54 48.23 59.23 67.51 67.17 /
25 / 28.46 47.94 59.23 67.46 67.14 /
Heating Power
Input(kW)
9 / 12.47 14.44 15.12 15.38 15.07 /
15 / 12.63 14.63 15.21 15.55 15.30 /
20 / 12.76 14.78 15.38 15.71 15.46 /
25 / 12.94 14.91 15.55 15.84 15.62 /
&RHI¿FLHQWRI
performance(W/W)
9 / 2.31 3.34 3.94 4.40 4.46 /
15 / 2.27 3.30 3.91 4.35 4.39 /
20 / 2.24 3.26 3.85 4.30 4.35 /
25 / 2.20 3.21 3.81 4.26 4.30 /
Model Water inlet temperature(°C) Water outlet temperature 65°C,Outdoor ambient temperature(DB/WB°C)
-20 -7/-8 7/6 20/15 30/22 35/24 46/28
CH-HP60MFNM
Heating
Capacity(kW)
9 / / 48.12 59.51 / / /
15 / / 48.27 59.35 / / /
20 / / 48.21 59.31 / / /
25 / / 47.85 59.13 / / /
Heating Power
Input(kW)
9 / / 15.16 15.83 / / /
15 / / 15.35 15.91 / / /
20 / / 15.50 16.11 / / /
25 / / 15.63 16.26 / / /
&RHI¿FLHQWRI
performance(W/W)
9 / / 3.17 3.76 / / /
15 / / 3.15 3.73 / / /
20 / / 3.11 3.68 / / /
25 / / 3.06 3.64 / / /
Model Water inlet temperature(°C) Water outlet temperature 70°C,Outdoor ambient temperature(DB/WB°C)
-20 -7/-8 7/6 20/15 30/22 35/24 46/28
CH-HP60MFNM
Heating
Capacity(kW)
9 / / 48.24 59.55 / / /
15 / / 48.13 59.38 / / /
20 / / 48.14 59.34 / / /
25 / / 47.86 59.17 / / /
Heating Power
Input(kW)
9 / / 15.87 16.55 / / /
15 / / 16.05 16.63 / / /
20 / / 16.21 16.81 / / /
25 / / 16.34 16.96 / / /
&RHI¿FLHQWRI
performance(W/W)
9 / / 3.04 3.60 / / /
15 / / 3.00 3.57 / / /
20 / / 2.97 3.53 / / /
25 / / 2.93 3.49 / / /

11
Direct & Circulating Air Source
Heat Pump Water Heater
QSPEVDU
6 Operating principle
Air-source heat pump water heater is based on Inverse Kano circulation principle, driven by a small amount
of electrical power, with refrigerant as carrier, continuously absorbs low grade heat (-26~46°C) in the air, and
transforms them into usable high grade heat, which is then released into water so as to generate and secure
domestic hot water (with default temperature of 55°C, and 70°C at most), and finally transports hot water
through hot water pipes to users.
ƇSystem diagram
Cold air Hot air
Air source heat pump water heater
Cold water
High temperature water: 70ć
Water side heat exchanger
Hot water
Compressor
Expansion
valve
Air side heat
exchanger
High temperature
Low temperature
Heat insulating water tank
ƇSystem composition
The air source central hot water system generally comprises the air source heat pump water heater and the
heat insulating water tank, and the auxiliary devices such as the connected pipeline, water pump, and valve as
well.
The air source heat pump water heater consists of main parts such as the compressor, water side heat
exchanger, air side heat exchanger, throttling device, electronic hot water valve, liquid receiver, and gas liquid
separator.
Ƈ 'LUHFWKHDWLQJÀRZ
When the water level switch is at a low level, the unit is powered on to start. The pressure pump starts
and the water makeup valve is turned on. The high temperature and high pressure refrigerant gas discharged
from the compressor enters the tube in tube heat exchanger, and exchanges heat with tap water replenished
from the direct heating water inlet to heat water. After passing the electronic expansion valve for throttling,
the condensate refrigerant enters the evaporator to absorb heat and evaporate. The refrigerant returns to the
compressor from the gas liquid separator to implement the next cycle.
Ƈ &\FOLFLQVXODWLRQÀRZ
When the water level switch is at a high water level or drops from a high water level to a middle water
level and the temperature of the temperature sensor of water tank is lower than the set temperature, the cyclic
insulation function starts. The recycle pump starts and the recycle valve is opened. The high temperature
and high pressure refrigerant gas discharged from the compressor enters the tube in tube heat exchanger,
and exchanges heat with hot water withdrawn by the cyclic loop. After passing the electronic expansion valve
for throttling, the condensate refrigerant enters the evaporator to absorb heat and evaporate. The refrigerant
returns to the compressor from the gas liquid separator to implement the next cycle.
Ƈ 'HIURVWLQJÀRZ
:KHQRSHUDWLQJLQORZWHPSHUDWXUHFRQGLWLRQVWKHXQLWHQWHUVWKHGHIURVWLQJÀRZLIWKHGHIURVWLQJFRQGLWLRQ
LVVDWLV¿HG7KHZD\YDOYHLVSRZHUHGRQDQGUHYHUVHG7KHKLJKWHPSHUDWXUHDQGKLJKSUHVVXUHUHIULJHUDQW
gas discharged from the compressor is reversed, and then directly enters the evaporator for heat exchange and
defrosting. The defrosted and condensate refrigerant passes the electronic expansion valve, and enters the
tube in tube heat exchanger, and exchanges heat with hot water withdrawn by the cyclic loop to evaporate. The
gas is re-taken in the compressor to perform the next cycle.

12
Direct & Circulating Air Source
Heat Pump Water Heater
CONTROL
DPOUSPM

13
Direct & Circulating Air Source
Heat Pump Water Heater
DPOUSPM
CONTROL
1 Unit Control
1.1 Overall Control Thought of Unit
1.1.1 Schematic Diagram of Unit Control
Output control
Power supply
485 communication
Fan
Input control
Output control
Ambient temperature sensor
Outlet water temperature sensor Inlet water temperature sensor Inlet pipe temperature sensor Outlet pipe temperature sensor Discharge temperature sensor
Compressor overload protection switch Water pump overload protection switch High pressure protection switch
Low pressure protection switch
Water flow switch DIP switch
Liquid level switch Water pressure switch
4-way
valve Compressor Water pump
Electronic
expansion valve
Timer/Temp/
Level
Retur
Timer
nWater Outle
Temp
tWater Temp
CirculatingWater
E-heater Inquiry
Reset Exit Clock Level
Single/Multi
Lock Ok
Diagnose
1.1.2 Explanation of Schematic Diagram
Waterflow switch: The system judges whether water is available. When the waterflow is too low, the
ZDWHUÀRZVZLWFKLVGLVFRQQHFWHGDIDXOWLVGLVSOD\HGWKHZDWHUSXPSVWRSVDQGWKHXQLWLVQRWVWDUWHGXSRU
shuts down.
High/Low pressure switch: It detects high pressure and low pressure of the system. To protect the unit from
operating in an abnormal status, malfunction is displayed when high pressure of the system is higher than the
set value or low pressure is lower than the set value. The unit is not started up or shuts down.
Ambient temperature: It is used to control operating range of water heating. The ambient temperature range
is from -26°C to 46°C during water heating. Beyond this range, the unit cannot operate in the water heating
mode. The function also joins other related control, for example, control on gear shifting of fan.
Water pipeline temperature detection: The inlet water temperature sensor and outlet water temperature
sensor are provided. The corresponding algorithm adjustment is performed for opening of the electronic hot
water valve according to the temperature detected by the outlet water temperature sensor.
Refrigerant pipeline temperature detection: Refrigerant pipeline temperature detection covers the discharge
temperature sensor, outlet pipe temperature sensor, and inlet pipe temperature sensor. The discharge
temperature sensor is used to avoid unit fault or damage arising from over-high discharge temperature when
the system operates abnormally. When the discharge temperature sensor detects that the temperature exceeds
the safety range, the unit cannot operate and sends an alarm. The inlet pipe temperature sensor is one of
bases used by the system to judge frosting. The outlet pipe temperature sensor is one of important parameters
in control of the expansion valve.
Note: The inlet water temperature, outlet water temperature, pressure switch connection/disconnection
information, and wired controller information are transferred to the control mainboard. Based on the information,
the control mainboard controls actions of components such as the compressor, water pump, fan, and 4-way
valve.

14
Direct & Circulating Air Source
Heat Pump Water Heater
DPOUSPM
1.2 Overview of Key Control Logics
1) Compressor control
&RPSUHVVRURSHUDWLQJFRQGLWLRQVZKHQRQHRIWKHIROORZLQJFRQGLWLRQVLVVDWLV¿HG
(1) The tank water level is at a low level.
(2) 7KHF\FOLFLQVXODWLRQIXQFWLRQLVVWDUWHGDQGWKHF\FOLFLQVXODWLRQVWDUWXSFRQGLWLRQLVVDWLV¿HG
&RPSUHVVRUVKXWGRZQFRQGLWLRQVZKHQRQHRIWKHIROORZLQJFRQGLWLRQVLVVDWLV¿HG
a. In the water heating status, the compressor shuts down when the water tank reaches the high water
level.
b. When the compressor operates in the cyclic insulation status, the cyclic insulation exit condition is
VDWLV¿HG
2) Fan control
(1) In the water heating mode, the compressor runs, and the fan has run for 30s at a high speed:
(2) :KHQWKHRXWGRRUDPELHQWWHPSHUDWXUH7$PELHQW&WKHUXQQLQJRXWGRRUIDQVWDUWVWRUXQDWD
low speed.
(3) When the outdoor ambient temperature TAmbient < 29°C, the outdoor fan restores running at a high
speed.
(4) :KHQ&WKHRXWGRRUDPELHQWWHPSHUDWXUH7$PELHQW&WKHRULJLQDORSHUDWLQJVWDWXVLV
maintained.
3) Defrosting control
(1) Defrosting entry criteria: The continuous operating time, defrosting interval setting time, water tank
temperature, and pipe temperature all reach the set defrosting points at the same time.
(2) Defrosting exit criteria: The defrosting setting time comes or the pipe temperature reaches the
defrosting exit point.

15
Direct & Circulating Air Source
Heat Pump Water Heater
DPOUSPM
1.3 Unit Operating Flowchart
Power on the
main board
Start the unit
Handle the fault
Each load starts
successively
Operate automatically
accordingto water
level of the water tank
Judge the fault
Handle the faultJudge the fault
Shut down and
power off?
Shut down
Yes
Yes
Yes
NO
NO
NO

16
Direct & Circulating Air Source
Heat Pump Water Heater
DPOUSPM
2 Wired controller
2.1 Outline and installation size
2.1.1 Outline size
22.5
Timer/Temp/
Level
Timer
ReturnWater Temp
OutletWater Temp
Circulating
Water
E-heater Inquiry
Reset Exit Cl ock Level
Single/Multi
Lock Ok
Diagnose
120
120
2.1.2 Installation size
Installation of wired
controller screw hole
Cut part of the sponge at the
back of the baseboard with
blade or other tools when installing

17
Direct & Circulating Air Source
Heat Pump Water Heater
DPOUSPM
2.1.3 Connection of wired controller
2.1.4 Disassembly and assembly of wired controller
Tools are necessary to disassemble the wired controller. Manual disassembly can break the wired controller
buckle. Stretch straight screwdriver into the slot at the upper side of the wired controller, rotate the screwdriver
and the buckle will uncouple. The wired controller panel can be disassembled when two clasps have uncoupled.

18
Direct & Circulating Air Source
Heat Pump Water Heater
DPOUSPM
2.2 Operations of wired controller
2.2.1Panel and button instructions
Wired controller is as shown below. All items are displayed on the LED for illustration.
Timer/Temp/
Level
Ret Timer ur nWater Ou Temp
tl et Water Temp
CirculatingWater
E-heater Inqui r y
Reset Exit Cl oc k Level
Single/Multi
Loc k Ok
Diagnose
1
10
11
12
21
22
23
24
25
26
27
28
2345
67
13
14
15
16
17
18
19
20
89
wired controller components
1 Power indicator 11 User-side temperature indication 21 Increment button
2 ON / OFF button 12 VRF mark indication 22 Outlet water temperature
setting button
3Remote controller receiving
window (reserved) 13 Query button 23 Cycling temperature setting button
4Water temperature/water temperature setting/
query parameter indications 14 Auxiliary heating button 24 Decrement button
5 Time/timing/fault code indication 15 Return water time setting button 25 Clock setting button
6 Unit number indication 16 Exit button 26 Water level setting button
7 Selected unit mark indication 17 Reset button 27 OK button
8Timer /temperature setting/water
level setting function indication 18 Time/temperature setting/water level setting button 28 Single-unit/multi-unit control selection button
9 Water return timer indication 19 Lock button
10 Tank water level indication 20 Point-check button
