Cooper Lighting Shaper 420-RP SERIES User manual

Catalog #
Project
Comments
Prepared by
Type
Date
SPECIFICATION FEATURES
08/11/2008 11:09:53 AM
Consult your representative for additional options and finishes.
Specifications and Dimensions subject to change without notice.
ADS050002
ORDERING INFORMATION
DESCRIPTION
420-RP Starter Collection features an 18" pendant designed for low ceiling
applications and offers performance optics by Portfolio.
Material
Painted or natural aluminum
ringed baffle, supplied with a
painted white aluminum cube cell
louver. Solid brass or aluminum
cable finials. Solid aluminum
mounting ring and hardware with
cable.
Downlight: One piece precision die
cast aluminum 1-1/2" deep collar
accommodates varying dimen-
sions of ceiling materials. Precisely
formed one piece, clear Alzak®,
non-imaging optical reflector
ensures 55° cut-off to lamp and
lamp image.
Finish
Standard: Natural Aluminum (NA)
[Sustainable Design].
Premium: Matte White (MW),
Lacquered Satin Aluminum (SAL),
Satin Copper (SCP), Polished
Copper (PCP), Oxidized Copper
(OCP) or Custom Color (CC).
Specify finish for the mounting
ring and hardware.
Optics
Refer to www.shaperlighting.com
for complete photometrics.
Ballast/Integral Emergency
Battery Pack
One (1) integral, multi-voltage
(120V/277V), electronic CFL (347V
Canada)ballast for a 26W, 32W or
42W CFL lamps. Provides flicker
free and noise free operation and
starting.
Lamp/Socket
Two (2) 26W, 32W (GX24q-3) or
42W (GX24q-4) 4-pin triple CFL
lamps. Universal 4-pin CFL socket
injection molded plastic with
fatigue free stainless steel lamp
spring ensures positive lamp
retention. Lamps furnished by
others.
Installation
Decorative trim/finial/bowl
assembly is securely suspended
from the mounting ring by three
stainless steel cables (provided).
Listed for eight #12AWG (four in,
four out) 90°C conductors feed
through branch wiring. One 1/2"
and two 3/4" pry outs. Positioned
to allow straight conduit runs.
Installation (Con't.)
Access to junction box by
removing reflector. Accepts 1/2"
EMT, C Channel, T-bar fasteners,
and bar hangers. Adjusts 5"
vertically from above or below
ceiling. Positive reflector
mounting, without tools, pulls trim
tight to ceiling. No measuring,
cutting or adjustment of cables is
required to achieve standard
overall height and level mounting.
Contractor to provide appropriate
structural support for the fixture's
weight.
Options
Matte White Acrylic Lense (AL),
Refer to the downlight spec sheet
for options, MH Lamping - Contact
factory.
Labels
U.L. and C.U.L. listed. Downlight is
standard damp label.
Modifications
Contact the factory regarding scale
options, unique finishes,
mounting, additional materials/
colors, or decorative detailing.
420-RP SERIES
Recessed Pendant Luminaire
Starter Collection
SUSTAINABLE
DESIGN
Refer to the Icon Legend
Link on shaperlighting.com.
Shaper has a long-standing history of
offering environmentally-friendly fixtures.
The copper and bronze alloys used in our
exterior luminaires feature up to 98% re-
cycled content, contribute less undesirable
air emissions compared to painted alumi-
num and are easy to recycle.
Shaper’s exclusive Starter Collection fixtures
are featured throughout the Shaper product
line. The concept of offering highly styled,
affordable fixtures was introduced over
fourteen years ago and has become one of
our fastest growing lines. The design
premise, basic construction, clean lines
and unadorned shapes are highly desirable
in modern architectural environments.
STARTER
COLLECTION
Sample Number: 420-RP-CFL/2-277V-SAL
Ring/Hardware Finish
Standard
NA Natural Aluminum=
Premium
CC Custom Color=
MW Matte White=
SAL Lacquered
Satin Aluminum
=
OptionsVoltage
120V
277V
347V
Series
420-RP 18" Pendant
=
Lamp
CFL/2 (26/32/42W-Triple)
SCP
PCP
OCP
=
=
=
Satin Copper
Polished Copper
Oxidized Copper
AL = Matte
White
Acrylic
Lens
Pendant Finish
Standard
NA Natural Aluminum=
Premium
CC Custom Color=
MW Matte White=
SAL Lacquered
Satin Aluminum
=
SCP
PCP
OCP
=
=
=
Satin Copper
Polished Copper
Oxidized Copper
shaperlighting.com

Shaper Lighting • 1141 Marina Way South • Richmond, CA 94804 • ph 510.234.2370 • fax [phone]/2008 11:09:53 AM
Specifications and Dimensions subject to change without notice.
ADS050002
DIMENSIONS
420-RP SERIES
420-RP Standard
8”
4 1/2”
14” ø
18” ø
18” ø 14” ø
7 3/8”
COMPANION PRODUCTS
278 689 476420
