683 SERIES
683/4 SERIES
Interior Wall Luminaire
Starter Collection
Direct/Indirect
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
shaperlighting.com
Catalog # Type
Date
Project
Comments
Prepared by
683 Direct/Indirect Economical Wall Sconce features an aluminum
cylinder. 683/4 is ADA compliant.
SPECIFICATION FEATURES
Material
Painted, natural or plated solid
aluminum with a 1/8" matte
white acrylic panel. Open top
and bottom with a regressed
aluminum perf shield.
Finish
Standard Interior Location:
Natural Aluminum (NA)
[Sustainable Design], Damp
Location: White (WH). Premium
Interior Location: Matte White
(MW) or Custom Color (CC).
Damp Location: White (WH),
Black (BK), Grey (GY), Silver
Metallic (SM), Gold Metallic
(GM), Bronze Metallic (BM), Dark
Platinum (DP), Graphite Metallic
(GRM) or Custom Color (CC).
Optics
Refer to
www.shaperlighting.com for
complete photometrics.
Ballast
Integral electronic HPF, multi-volt
120/277V (347V Canada),
thermally protected with end-of-
life circuitry to accommodate the
specified lamp wattage.
Lamp/Socket
One (1) 13W (G24q-1) 4-pin quad
CFL lamp, one (1) 26W (GX24q-3)
triple tube CFL lamp or one (1)
60W A-19 lamp. CFL socket
injection molded plastic. INC
socket fired ceramic rated for
660W-250V. Lamps furnished by
others.
Installation
Supplied with a universal
circular strap for a standard 4"
J-box or plaster ring.
Options
Damp Location (DL): All Painted
Finishes finishes only, Custom
Cut-Out - Contact factory,
Remote Emergency Battery -
Supplied by others (REM).
Energy Star Rating - Contact
factory. MRI Applications (INC
only) - Contact Factory.
Labels
U.L. and C.U.L approved for
indoor and damp location. See
options for damp location
finishing requirements.The 683/4
is ADA compliant.
Modifications
Shaper's skilled craftspeople
with their depth of experience
offer the designer the flexibility
to modify standard wall
luminaires for project specific
solutions. Contact the factory
regarding scale options, unique
finishes, mounting, additional
materials/colors, or decorative
detailing.
DESCRIPTION
Sample Number: 683-CFL/1/26-277V-BK
Finish
BK Black
=
BM Bronze Metallic=
CC Custom Color=
DP Dark Platinum=
GM Gold Metallic=
GRM Graphite Metallic=
GY Grey=
MW Matte White=
NA Natural Aluminum=
SM Silver Metallic=
WH White=
Options
DL Damp Location
=
REM Remote Emergency Battery 2
=
Voltage
120V
277V 1
347V 1
Series
683 Wall Sconce
=
683/4 ADA Compliant
Wall Sconce
=
Lamp
CFL/1/13
CFL/1/26
INC/1/60
1Available with CFL only.
Notes:
2Supplied by others.
ORDERING INFORMATION
ADS042690
2008-09-17 12:37:06
MAGNETIC
RESONANCE
IMAGING (MRI)
ENERGY
STAR
SUSTAINABLE
DESIGN
Refer to the Icon Legend
Link on shaperlighting.com.
Lighting fixtures for MRI facilities are
specialized and unique, requiring non-
ferrous construction. Fluorescent fixtures
cannot be used due to the ferrous parts in
ballasts and lampholders. Modified incan-
descent fixtures meet the requirements.
Shaper now offers a wide variety
of fixtures that can be provided
with an Energy Star Rating.
Shaper has a long-standing history of
offering environmentally-friendly fixtures.
The copper and bronze alloys used in our
exterior luminaires feature up to 98% re-
cycled content, contribute less undesirable
air emissions compared to painted alumi-
num and are easy to recycle.
Shaper’s exclusive Starter Collection fixtures
are featured throughout the Shaper product
line. The concept of offering highly styled,
affordable fixtures was introduced over
fourteen years ago and has become one of
our fastest growing lines. The design
premise, basic construction, clean lines
and unadorned shapes are highly desirable
in modern architectural environments.
STARTER
COLLECTION
Shaper offers a large selection of ADA
interior and exterior wall luminaires.
ADA requires all fixtures below 68" to
have a maximum projection of 4".
AMERICAN DISABILITIES
ACT (ADA)

Specifications and dimensions subject to change without notice.
Shaper Lighting •1141 Marina Way South •Richmond, CA 94804 •ph 510.234.2370 •fax [phone]
9"
4-1/2"
5"
3-1/2"
683-WP
4"
4"
683/4-WP
5"
4"
683/4
5"
4"
9"
4-1/2"
5"
3-1/2"
683
4"
9"
4-1/2"
DIMENSIONS
ADS042690
2008-09-17 12:37:06
683 - 683/4 SERIES INTERIOR WALL LUMINAIRE
