Cooper Lighting FAIL-SAFE CFS User manual

Catalog #
Project
Comments
Prepared by
Type
Date
SPECIFICATION FEATURES
08/29/2007 2:09:42 PM
Consult your representative for additional options and finishes.
Specifications and Dimensions subject to change without notice.
ADC041650
LAMP CONFIGURATIONS
DOOR FRAME
MOUNTING DIMENSIONS
DESCRIPTION
The CFS Series is designed for use in non-laminar air flow clean rooms.
This surface mounted clean room luminaire has a hole-free design and is
enclosed and gasketed to protect against infiltration of particles and
airborne bacteria. The sealed housing and door frame allow relamping
without contamination of the clean areas. An emergency battery pack is
available as an option. These luminaires are U.L. listed and C.S.A. certified
for wet locations and are manufactured in accordance with U.S.D.A. and
F.D.A. All fixtures have been tested and reported in compliance with Federal
Standard 209E, Class 100 (M3.5). 200 PSI Rating is standard.
Application
The CFS Series is suitable for use
in I.E.S. Class 100, 1,000, 10,000
and 100,000 clean room environ-
ments. Applications include clean
rooms, technical and biomedical
labs, food processing/testing
centers and pharmaceutical labs.
Manufactured to IP65 Rating.
A ... Lens
(To be specified.) One-piece, clear
extruded lens with internal prism
pattern. Choice of prismatic acrylic,
prismatic polycarbonate, Radialens
or prismatic tempered glass on
environmental side. See Lens
Options.
B ... Fasteners
Flush mounted, stainless steel
machine screws secure through
captive cage nuts in housing and
are evenly spaced to compress
gasketing on all sides.
C ... Housing
Die-formed, 20 ga. CRS with tightly
butted and seam welded, sealed
Housing Cont.
end caps. Contains no holes that
would allow air passage. Standard
white high reflectance polyester
powder coat finish. Gloss: 85%;
Reflectance: 93%; Hardness: 2H;
Salt Spray: 500 Hours.
D ... Lamps
(By Others)
E ... Lens Retention
Unique, Particulock(TM) lens
retention system utilizes
continuous, 18 ga. media
clampdowns to sandwich
gasketing and integrate lens and
door frame for even environmental
seal.
F ... Hinge
Two braided, stainless steel cables
on one side of door provide
hinging.
G ... Door
(To be specified.) One-piece, 18
ga., fully gasketed, outside door
Door Cont.
with die-formed and beveled edges
eliminates seams which could
entrap microscopic contaminants.
H ... Ballast
Standard Class P, CBM/ETL ballast.
I ... Gasket
White, closed cell, Flexiseal(TM)
triple gasketing system surrounds
perimeter of lens to seal lens to
door frame and around perimeter
of door to seal door to housing.
Sealing from fixture to ceiling by
others.
J ... Access
A gasketed access plate on top of
the housing with two flattened,
7/8" diameter knockouts allows
connection of vapor tight conduit
fitting.
Labels
U.L. listed, C.S.A. certified,
standard wet label.
CFS
34W - 160W
Fluorescent
2' X 2'
2' X 4'
FLUORESCENT SURFACE
One-Piece Door
C
B
DH J
A
F
I
G
E
23 11/16"
[602mm]
4 5/16"
[110mm]
E N E R G Y DATA
Input Watts:
STD Ballasts & STD Lamps
(2) 20W T12 Fluorescents: 53W
(3) 20W T12 Fluorescents: 85W
(4) 20W T12 Fluorescents: 106W
(2) 40W Biaxial Fluorescents: 82W
(3) 40W Biaxial Fluorescents: 127W
ES Ballasts & STD Lamps
(2) 17W T8 Fluorescents: 45W
(3) 17W T8 Fluorescents: 68W
(4) 17W T8 Fluorescents: 90W
(2) 32W T8 Fluorescents: 71W
(3) 32W T8 Fluorescents: 108W
(4) 32W T8 Fluorescents: 142W
(2) 40W T12 Fluorescents: 86W
(3) 40W T12 Fluorescents: 136W
(4) 40W T12 Fluorescents: 172W
(2) 40W U-Lamps: 86W
ES Ballasts & ES Lamps
(2) 40W T12 Fluorescents: 76W
(3) 40W T12 Fluorescents: 120W
(4) 40W T12 Fluorescents: 152W
(2) 40W U-Lamps: 76W
Electronic Ballast Data
Consult Factory
9 1/2"
[241mm]
5"
[127mm]
5"
[127mm]
5"
[127mm]
9 1/2"
[241mm]
7 1/2"
[190mm]
7 1/2"
[190mm] 6"
[152mm]
3"
[76mm]
6"
[152mm]
4 3/4"
[121mm]
4 3/4"
[121mm]
Surface Type-One-piece Door
1 1/2"
[38mm]
10 3/16"
[259mm]
12"
[305mm]
23 11/16"
[602mm]
(2) 7/8" [22mm] KO
Gasketed Access Plate
(4) 3/8" [10mm] Dia.
Mounting Hole
36"
[914mm]
48"
[1219mm]
1 3/4"
[44mm]
1 1/2"
[38mm]
10 3/16"
[259mm]
12"
[305mm]
23 11/16"
[602mm]
(2) 7/8" [22mm] KO
Gasketed Access Plate
(4) 3/8" [10mm] Dia.
Mounting Hole
12"
[305mm]
24"
[610mm]
FAIL-SAFE®

Fail-Safe • Customer First Center • 1121 Highway 74 South • Peachtree City, GA 30269 • TEL [phone] • FAX [phone]/2007 2:09:42 PM
Specifications and Dimensions subject to change without notice.
ADC041650
PHOTOMETRICS
ORDERING INFORMATION
CFS
500
1000
1500
2000
2500
Candlepower Distribution Zonal Lumen Summary
Zone Lumens %Lamp %Luminaire
0-30 2728 21.7 32.0
0-40 4499 35.7 52.8
0-60 7316 58.1 85.8
0-90 8526 67.7 100.0
90-180 0 0.0 0.0
0-180 8526 67.7 100.0
80% 70% 50% 30% 10% 0%
70 50 30 10 50 30 10 50 10 50 10 50 10 0
81 81 81 81 79 79 79 75 75 72 72 69 69 68
75 72 69 67 70 68 66 67 64 65 62 62 60 59
69 64 60 57 63 59 56 61 55 58 54 56 52 51
64 58 53 49 57 52 48 55 48 53 47 51 46 45
59 52 46 42 51 46 42 49 42 48 41 46 40 39
54 46 41 37 46 40 36 44 36 43 36 42 35 34
50 42 36 32 41 36 32 40 32 39 31 38 31 30
46 38 32 28 37 32 28 36 28 35 28 34 28 26
43 34 28 25 33 28 24 33 24 32 24 31 24 23
39 30 25 21 30 25 21 29 21 29 21 28 21 20
37 28 22 19 27 22 19 27 19 26 19 25 19 17
rc=Ceiling reflectance, rw=Wall reflectance, RCR=Room cavity ratio
CU Data Based on 20% Effective Floor Cavity Reflectance.
Test No. ITL36036
CFS-24-440-IK12
Lamp=(4) 40WT12
Lumens=8526
Spacing Criteria
=1.4 =1.2
Efficiency=67.7%
rc
rw
RCR
0
1
2
3
4
5
6
7
8
9
10
Coefficient of Utilization
Av e r a g e
Luminance
Deg.
45 1595 1323
55 1154 980
65 822 779
75 871 857
85 1018 933
