Cooper Lighting Metalux HBOT T8 SERIES User manual

Catalog #
Project
Comments
Prepared by
Type
Date
SPECIFICATION FEATURES
07/01/2008 11:14:52 AM
Consult your representative for additional options and finishes.
Specifications and Dimensions subject to change without notice.
ADF060954
LAMP CONFIGURATIONS
DIMENSION TOP VIEW
DESCRIPTION
The HBOT series is an outstanding solution for high mounting height
industrial or retail applications. The HBOT optic has been optimized to
provide maximum performance. Optional uplight component is provided to
enable excellent ceiling uniformity. HBOT's high lumen package allows the
benefits of fluorescent to be applied at high mounting heights that were
traditionally exclusive to H.I.D. The primary benefits include exceptional
color rendering, high system efficacy, 95% lumen maintenance, long lamp
life, instant on/instant re-strike, economical dimming, and uniform
brightness control. Primary applications include retail, shopping malls, light
industrial, and recreational environments.
A ... Construction
Specification grade open body
housing, end plates and socket
tracks are die formed 20-gauge
cold rolled steel. The HBOT
channel provides strength and
numerous KOs for easy
installation. Top Ballast Access
Plate. Allows for removal or
service of ballast from above
without removal of lamps. Die
formed external reflectors are
available in both high reflectance
specular material or in painted-
after-fabrication white enamel.
B ... Electrical
Class "P" ballasts are positively
secured by mounting bolts.
Roto-lock lampholders. Optional
modular power receptacle and
cord sets meets UL2459 and NEC
410.73 and are UL/cUL rated for
make and break under load from
outside the luminaire. UL/CUL
listed. Suitable for damp locations.
Thermally optimized for environ-
ments up to 122°F (50°C) when
used with high temperature
ballasts.
C ... Finish
Electrostatically applied baked
white enamel finish is preceded by
a multistage cleaning cycle, iron
phosphate coating with rust
inhibitor.
D ... Downlight/Uplight Optics
Die formed reflectors are faceted
for 8 lamp configurations with two
optical distributions - medium and
wide. Medium beam optical
modules utilize 95% specular
aluminum while the wide distri-
bution utilizes a high performance
95% reflective polyester powder
coated finish. Uplight option
provided to enable ceiling
uniformity.
Mounting
The HBOT series is suited for
surface or suspension mounting
with wire hook and chain set, stem
or cable mounting. Optional top
connector box mounting is
available.
F-BAY
HBOT T8 SERIES
Nominal 3' x 4' High-Bay
(8) T8 Lamps
HIGH-BAY INDUSTRIAL
OPEN TOP LUMINAIRE
E N E R G Y D ATA
Input Watts:
EB Ballast
832 = 218
EB/Plus Ballast
832 = 294
ER Ballast
832 = 224
ER/Plus Ballast
832 = 288
Luminaire Efficacy Rating
LER = 77 (White)
LER = 84 (Specular)
Catalog Number: 3HBOT-832-UPL
Yearly Cost of 1000 Lumens,
3000 hrs. at .08 KWH = $2.84
* Reference the lamp/ballast data in the
Tecnical Section for specific lamp/ballast
requirements
** Consult Pre Sales Technical Support.
LAMPS CONTAIN MERCURY. DISPOSE ACCORDING
TO LOCAL, STATE OR FEDERAL LAWS
Safe and convenient means of
disconnecting power
5-3/16"
[131mm]
32-11/16" [830mm]
ABC D
32-11/16" [830mm]
XXXXXXX
5-3/16" [131mm]
X=4"
[102mm]
8-Lamp
48-1/16" [1221mm]
11/16" X 1"
KO (2)
7/8" KO (4)
Ceiling Standoff
Embossment
Top Connector
Emboss
33" [838mm]
41-1/2" [1054mm]
32-11/16"
[830mm]
8-Lamp
COOPER LIGHTING - METALUX®

Metalux • Customer First Center • 1121 Highway 74 South • Peachtree City, GA 30269 • TEL [phone] • FAX [phone]/2008 11:14:52 AM
Specifications and Dimensions subject to change without notice.
ADF060954
PHOTOMETRICS
SHIPPING INFORMATION
ORDERING INFORMATION
HBOT
Coefficients of Utilization
Effective floor cavity reflectance 20%
rc 80% 70% 50% 30% 10% 0%
rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0
RCR
0
1
2
3
4
5
6
7
8
9
10
Zonal Lumen Summary
Zone Lumens %Lamp %Fixture
0-30
0-40
0-60
0-90
0-180
Candela
Angle Along II 45° Across
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
3HBOT-832-UPL
(2) Electronic Ballasts
(8) 32W T8 lamps
3000 lumens
Spacing criterion:
(II) 1.3 x mounting
height, ( ) 1.3 x
mounting height
Efficiency 89.8%
Test Report: 18445
LER =84
Yearly Cost of 1000
lumens, 3000 hrs
at .08 KWH = $2.84
9244 9244 9244
9215 9146 9136
9092 8966 8971
8882 8776 8995
8595 8674 8786
8228 8404 8223
7779 7876 7417
7261 7129 6852
6670 6294 5874
6025 5639 4647
5311 4603 3196
4574 3427 1921
3783 2141 954
3000 1061 309
2204 378 30
1442 46 13
765 18 1
250 30 21
13 1 1
106 106 106 106 103 103 103 103 98 98 98 93 93 93 88 88 88 86
99 95 92 89 96 93 90 87 88 86 84 84 83 81 81 79 78 76
91 85 80 75 88 83 78 74 79 75 72 76 73 70 73 70 68 66
84 76 69 64 81 74 68 63 71 66 62 68 64 60 65 62 59 57
77 68 61 56 75 66 60 55 64 58 54 61 57 53 59 55 52 50
72 61 54 49 70 60 53 48 58 52 47 56 51 46 54 49 46 44
66 55 48 43 64 54 48 43 52 46 42 51 45 41 49 44 41 39
62 50 43 38 60 50 43 38 48 42 37 46 41 37 45 40 36 35
58 46 39 34 56 45 39 34 44 38 34 43 37 33 41 37 33 31
54 43 36 31 52 42 35 31 41 35 30 39 34 30 38 33 30 28
50 39 33 28 49 39 32 28 38 32 28 37 31 27 36 31 27 26
7164 29.8 33.2
11585 48.3 53.8
18756 78.2 87.0
20692 86.2 96.0
21549 89.8 100.0
Luminance Data
Average Average Average
Angle 0-Deg 45-Deg 90-Deg
in Deg cd/sm cd/sm cd/sm
45 8579 8030 6617
55 8029 6016 3372
65 7148 2527 735
75 5611 178 49
85 2887 344 237
Cooper Lighting’s F-Bay Modular Power Supply option allows external
fixture access for safe and easy servicing. There is no need to
remove lamps or reflectors to disconnect fixture power with F-Bay
Modular Power Supply. Access to the individual fixtures power supply
allows servicing without turning off all the fixtures disrupting
occupants. F-Bay Modular Power Supply is a time saver in installation
– simply plug & power.
1 2
Modular F-Bay Power Supply
1. Modular Power Supply Receptacle supplied
mounted into fixture Access Plate.
2. Modular Power Cord & Plugs in 120, 277, 347,
& 480V configurations for easy plug & power
into existing supply.
No internal fixture
access required for
installation or
disconnecting power.
Code Compliance
• UL/cUL Certified for Make/Break
under load (UL2549)
• Meets NEC requirements for
ballast disconnect (NEC 410.73G)
• Allows for addition of Occupancy
Sensor without hard connections
• Receptacles complete with
insulating dustcap
Modular Motion Sensor Option
supplied with Mounting Box and
Modular Power Supply Receptacle.
3HBOT-832-G-120V-UPL 27 lbs.
.tW.oNgolataC
S A M P L E N U M B E R : 3 H B O T- 8 3 2 - U N V- E B 8 2 / P L U S - U P L- U
No. of Lamps
8=8 Lamps
Lamp Type
32=32WT8 (4') Lamp
Series
HBOT=High Bay Open
Top Version
Width
3=32" wide
Voltage(2)
UNV=Universal
120/277 Voltage
UNC=Universal
347/480 Voltage
(T5 linear only)(6)
120V=120 Volt
277V=277 Volt
347V=347 Volt
480V=480 Volt
Distribution
Blank=Medium (Specular Aluminum)
G=Wide (White Painted)
Options
UPL=Uplight Apertures
MWS=Modular Wiring System
MS=Aisle Coverage Motion
Sensor(4)
MSO=360° Coverage Motion
Sensor(4)
MP=Modular Power Receptacle(1) (2)
PC3-=3' Power Cord & Plug (Specify Voltage)(2)
PC6-=6' Power Cord & Plug (Specify Voltage)(2)
TCBP=Top Connector Box Plate(5)
Packaging
U=Unit Pack
PAL=Palletized
Out of Carton
PALC=Palletized
In Carton
Options
Lamps Installed
L8830=T8 Lamp, 85CRI 3000K
L8835=T8 Lamp, 85CRI 3500K
L8841=T8 Lamp, 85CRI 4100K
L8850=T8 Lamp, 85CRI 5000K
GL=Single Element Fuse
GM=Double Element Fuse
EL=Emergency Installed(2)
BallastType
T8 Systems
EB8 =T8 Electronic Instant Start.(7)
Total Harmonic Distortion < 10%
EB8 /PLUS=T8 Electronic Instant Start.(7)
High Ballast Factor >1.15.
Total Harmonic Distortion < 10%
ER8 =T8 Electronic Program Rapid Start.(7)
Total Harmonic Distortion < 10%
ER8 /PLUS=T8 Electronic Program Start.(7)
High Ballast Factor >1.15.
Total Harmonic Distortion < 10%
No. of Ballast
2 or 3
No. of
Ballast
2 or 3
No. of Ballast
2 or 3
NOTES: (1)Requires use of MC or MPC cord accessories, specify voltage for plugs. (2)Voltage must be specified when ordered with plugs, motion or emergency
ballasts. (4)Specify voltage on ballast. (5)For use withTop Connector Box options. See accessories. (6)2 lamp ballast configurations only in EHT-UNC versions.
(7)ER8 and EB8 ballast systems suitable for operation in ambient environments up to 122°F (50°C) in open uplight configuration.
Accessories (order separately)
AYC-CHAIN/SET/U=(2) Hooks, 36" Chain
Sets w/S-Hooks
TCB=Top Connector Box
RH-1=Retrofit Hanger
FH-1=Fixture Hook
FL-1=Fixture Loop
MPC6=6' Modular Power Cord & Plug
(Specify Voltage)
MC6=6' Modular Power Cord
MMS-CPD1200H=Aisle Motion Sensor,
Box, Modular Power Receptacle (120/277V)
MMS-CPD500H=360° Motion Sensor, Box,
Modular Power Receptacle (120/277V)
No. of
Ballast
2 or 3
