Cooper Lighting PM615cb User manual

®
RSA Lighting 9660-9700 Topanga Canyon Blvd. Chatsworth, CA 91311
Toll Free: 800-356-3030 • 818-349-3030 • Fax: [phone]
©2004 RSA Lighting • All Rights Reserved • Specifications are subject to change without notice www.cooperlighting.comwww.rsalighting.com
PM56
C
L
C
L
BUSWAY SURFACE
370º Locking
Adjustability 270º Locking
Adjustability
6.07”
7.76”
5.07”
5.59”
8.46”
5.93”
PM615cb
60 Amp Busway Adapter
Catalog #
Type
Project
A machined aluminum track fixture for low voltage
PAR36 lamps for 35 or 50 watts. For use with RSA
Profile Series 60 Amp Busway.
Front loading lamp with bayonet action lens /
accessory bezel. Optical accessories are captured
in the bezel with a threaded retainer ring preventing
accessory spill-out during relamping. Can accom-
modate up to three optical accessories.
Auto extending / retracting lamp holder. Lamps
extend for easy access and automatically retract
to optimum position. This is extremely helpful when
dealing with varying accessory combinations or dif-
fering manufacturer lamp dimensions.
Optical accessories include color filters, UV fil-
ters, screens, spread lenses, louvers, hex louvers,
snoots. Consult RSA for details.
Locking on both the horizontal and vertical
planes. 370º vertical rotation possible due to over-
center locking mechanism (60 amp busway only).
270º horizontal locking adjustment.
UL and CUL listed
Available in White, Black, Natural Aluminum or
custom finishes.
PAR36 12V
Closed Back Machined Fixture
PM615cb
Ordering Example: PM615cb-50-AL
Open Back Machined Fixture Lamp Wattage Finish
❑ PM615ob - PAR36 for 60 Amp Busway ❑ 35 35 Watt 12V PAR36 ❑ WH White
❑ 50 50 Watt 12V PAR36 ❑ BK Black
❑ AL Natural Aluminum
❑ PT Custom Finish

PM57
®
0° Aiming Angle 30° Aiming Angle 30° Aiming Angle 45° Aiming Angle
Horizontal Footcandles Horizontal Footcandles Vertical Footcandles Vertical Footcandles
D FC L W D FC L W CB D FC L W CB D FC L W CB
FC FC
FC
CB
CB
L L
L
30° 30°
D
W
D
W
W
Lamp Performance Data
D = Distance to the horizontal or vertical surface.
FC = Initial footcandles at the center of the beam.
L = Length of the beam where candlepower is reduced to 50%
of center beam candlepower.
W = Width of the beam where candlepower is reduced to 50%
of center beam candlepower.
CB = Distance to the center of the beam.
Lamp data given is typical and is based on bare lamp performance.
Contact lamp manufacturers for availability and specific performance.
Distance, length and width given in decimal feet.
PAR36 12V Halogen Screw Terminal
35 PAR36 /H /SP5 GEL 10 250 1.0 1.0 8 254 0.9 0.9 4.6 3 347 1.0 0.5 5.2 6 246 1.0 0.7 6.0
Beam Spread = 5° x 5° 14 128 1.4 1.4 10 162 1.1 1.1 5.8 5 125 1.7 0.8 8.7 8 138 1.3 0.9 8.0
CBCP = 25,000 18 77 1.9 1.9 12 113 1.4 1.3 6.9 7 64 2.4 1.1 12.1 10 88 1.6 1.0 10.0
Rated Life = 4,000 Hrs. 22 52 2.3 2.3 14 83 1.6 1.5 8.1 9 39 3.0 1.5 15.6 12 61 1.9 1.4 12.0
35 PAR36 /H /SP8 GEL 8 312 0.8 0.8 7 265 0.8 0.7 4.0 3 278 0.9 0.5 5.2 5 283 0.7 0.6 5.
Beam Spread = 8° x 8° 12 139 1.2 1.2 10 130 1.1 1.0 5.8 4 156 1.2 0.7 6.9 7 144 1.0 0.7 7.0
CBCP = 20,000 16 78 1.6 1.6 13 77 1.4 1.4 7.5 5 100 1.5 0.8 8.7 9 87 1.3 0.9 9.0
Rated Life = 4,000 Hrs. 20 50 2.0 2.0 16 51 1.7 1.7 9.2 6 69 1.8 1.0 10.4 11 58 1.5 1.1 11.0
35 PAR36 /H /FL30 GEL 2 225 0.9 1.3 2 165 1.1 1.4 1.2 1.0 204 0.8 1.0 1.7 1.5 190 1.0 1.2 1.5
Beam Spread = 30° x 30° 3 100 1.4 2.0 3 73 1.7 2.2 1.7 1.5 91 1.3 1.5 2.6 2.0 107 1.4 1.7 2.0
CBCP = 900 4 56 1.9 2.6 4 41 2.3 2.9 2.3 2.0 51 1.7 2.0 3.5 2.5 68 1.7 2.1 2.5
Rated Life = 4,000 Hrs. 5 36 2.3 3.3 5 26 2.8 3.6 2.9 2.5 33 2.1 2.5 4.3 3.0 48 2.1 2.5 3.0
50 PAR36 /H /SP5 GEL 10 350 1.0 1.0 9 281 0.9 1.0 5.2 4 273 1.1 0.7 6.9 7 253 0.9 0.9 7.0
Beam Spread =5° x 5° 15 156 1.5 1.5 13 135 1.4 1.4 7.5 6 122 1.6 1.1 10.4 9 153 1.2 1.1 9.0
CBCP = 35,000 20 87 2.0 2.0 17 79.0 1.8 1.8 9.8 8 68 2.2 1.5 13.9 11 102 1.4 1.4 11.0
Rated Life = 4,000 Hrs. 25 56 2.6 2.6 21 52.0 2.2 2.3 12.1 10 44 2.7 1.9 17.3 13 73 1.7 1.6 13.0
50 PAR36 /H /SP8 GEL 10 300 1.0 1.1 8 304 0.9 0.9 4.6 4 234 1.4 0.8 6.9 6 295 1.0 0.8 6.0
Beam Spread = 8° x 8° 15 133 1.6 1.6 12 135 1.4 1.4 6.9 5 150 1.7 1.1 8.7 8 166 1.3 1.1 8.0
CBCP = 30,000 20 75 2.1 2.1 16 76 1.8 1.8 9.2 6 104 2.1 1.3 10.4 10 106 1.6 1.3 10.0
Rated Life = 4,000 Hrs. 25 48 2.6 2.7 20 49 2.3 2.3 11.5 7 77 2.4 1.5 12.1 12 74 2.0 1.6 12.0
50 PAR36 /H /FL30 GEL 2 325 0.9 1.3 2.0 224 1.2 1.4 1.2 1.0 262 1.0 1.0 1.7 1.5 248 1.1 1.2 1.5
Beam Spread = 30° x 30° 3 144 1.4 1.9 3.0 99 1.8 2.1 1.7 1.5 117 1.5 1.5 2.6 2.0 140 1.5 1.6 2.0
CBCP = 1,300 4 81 1.9 2.5 4.0 56 2.3 2.8 2.3 2.0 66 2.0 2.0 3.5 2.5 89 1.9 2.0 2.5
Rated Life = 4,000 Hrs. 5 52 2.3 3.2 5.0 36 2.9 3.6 2.9 2.5 42 2.6 2.5 4.3 3.0 62 2.2 2.4 3.0
PAR36 12V Incandescent Screw Terminal
50 PAR36 VNSP GEL 8 297 1.3 1.3 8 223 1.5 1.4 4.6 4 297 2.1 1.3 6.9 6 264 1.7 1.3 6.0
Beam Spread = 5° x 5° 12 132 1.7 1.7 11 118 1.9 1.7 6.4 6 132 2.8 1.7 10.4 9 117 2.3 1.7 9.0
CBCP = 19,000 16 74 2.1 2.1 14 73 2.3 2.1 8.1 8 74 3.6 2.1 13.9 12 66 2.8 2.2 12.0
Rated Life = 2,000 Hrs. 20 48 2.4 2.4 17 49 2.7 2.4 9.8 10 48 4.4 2.4 17.3 15 42 3.4 2.6 15.0
50 PAR36 /NSP GEL 6 306 0.7 0.8 6 198 0.9 0.9 3.5 2 344 0.9 0.6 3.5 4 243 0.9 0.8 4.0
Beam Spread = 8° x 8° 8 172 1.0 1.1 8 112 1.2 1.3 4.6 3 153 1.3 0.9 5.2 5 156 1.1 1.0 5.
CBCP = 11,000 10 110 1.2 1.2 10 71 1.5 1.6 5.8 4 86 1.7 1.1. 6.9 6 108 1.3 1.2 6.0
Rated Life = 2,000 Hrs. 12 76 1.4 1.4 12 50 1.8 1.9 6.9 5 55 2.2 1.4 8.7 7 79 1.6 1.4 7.0
Optivex UV
Filter
Red Color
Filter
Blue Color
Filter
Amber Color
Filter
Cosmetic Peach
2800K Filter
Milk White
Lens
Diffusion Spread
Lens
Linear Spread
Lens
LN85 LN86 LN87 LN89 CP111 LN84 LN81 LN83
Prismatic Spread
Lens
20% Reduction
Screen
30% Reduction
Screen
40% Reduction
Screen
Hex Cell
Louver
Cross
Baffle
Snoot
LN82 RS2036 RS3036 RS4036 LN80 CB111 SN36
