1250 SERIES
High Performance
Pendant Luminaire
Indirect/Direct
Luminous Shallow Bowl
With Four Trim Options
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
shaperlighting.com
The 1250 Direct/Indirect High Performance Luminous Pendant is
available in three diameters with multiple mounting options.
SPECIFICATION FEATURES
Material/Mounting
Painted and plated cold rolled
steel or natural aluminum with a
matte white acrylic bowl.
Single Stem (Standard): 5/8"
stem with a standard hang
height of 28" (OA) for the 26"
dia., 32" (OA) for the 36" dia. and
42" ( OA) for the 44" dia.
Minimum overall hang height is
18" (OA). Maximum overall hang
height for one piece stem
assembly is 8'(OA). 9' to 30' (OA)
stems are supplied in multiple
sections and require field
assembly. Supplied with a swivel
canopy which will accommodate
up to 45° adjustment.
Finish
Standard: Matte White (MW).
Premium: Natural Aluminum
(NA) [Sustainable Design], Satin
Chrome (SC), Polished Chrome
(PC), Satin Brass (SB), Polished
Brass - only (PB), Oxidized Brass
(OBRS), Lacquered Satin
Aluminum (SAL), Satin Copper
(SCP), Polished Copper - only
(PCP), Satin Nickel (SN), Polished
Nickel (PN), Oxidized Copper
(OCP), Gun Metal (GNM),
Lacquered Satin Chrome (SCL),
Lacquered Satin Nickel (SNL) or
Custom Color (CC).
Custom Decorative Metals:
(Specify a Color and Pattern)
Colors - Clear (CLR), Cabernet
(CBT), Sapphire (SPE), Sage
(SGE), Brass (BRS), Copper
(CPR), Black Pearl (BPL), Slate
Green (SGN), Champagne (CMP),
Chocolate (CLE), Indigo (IDO),
Royal Blue (RBE), or Pewter
(PWR). Patterns - Coral (COL),
Seashell (SHL) or Smooth (SMT).
Note: Select a standard or
premium finish for the stem(s),
canopy and solid or floating rod
trims. Example: CLR (Clear color)
- COL (Coral pattern) - SC (Satin
chrome) stems, canopy and trim.
Minimum quantity is 5 for one
color/pattern. Contact the factory
for lead-time.
Optics
Dedicated CFL lamp optics with a
"kick reflector" formed out of
94% reflective specular anodized
aluminum.Three or four
individualT6 metal halide or
halogen dedicated optic systems.
The main reflector is formed with
94% reflective specular anodized
aluminum and the upper
reflector is formed out of 94%
reflective semi-specular anodized
aluminum. Refer to
www.shaperlighting.com for
complete photometrics.
Ballast
Integral CFL electronic HPF,
multi-volt 120/277V (347V
Canada), thermally protected
with end-of-life circuitry to
accommodate the specified lamp
wattage. Metal Halide ballast is
electronic HPF, multi-volt
(120V/277V) for the specified
lamp wattage. 347V MH ballast -
contact factory.
Lamp/Socket
26" -Three (3) or six (6) 27W
(2G11) high lumen CFL lamps,
three (3) 32W (GX24q-3) or 42W
(GX24q-4) 4-pin triple CFL lamps,
or three (3) 39W or 70WT6 CDM
metal halide lamps, or three (3)
T4 (DC Bay) clear linear halogen
lamps.
One (1) 22W (2GX13)T5 circular
lamp (bowl illumination).
Downlight: (Optional) One (1)
20W MHMR-16 (Twist lock, GX10)
metal halide, 39W MHMR-16
(Twist lock, GX10) metal halide
(Contact factory for availability)
or 50W HMR-16 (BI-PIN, GX5.3)
halogen lamp (Contact factory
for other halogen MR-16 base
options).
36" -Three (3) or six (6) 27W,
39W, 40W, 50W or 55W (2G11)
high lumen CFL lamps, three (3)
32W (GX24q-3), 42W (GX24q-4)
4-pin triple CFL lamps, 57W
(GX24q-5) or 70W (GX24q-6) 4-
pin triple HO CFL lamps, three (3)
39W, 70W or 150WT6 CDM metal
halide lamps, or three (3) 150W
T4 (DC Bay) clear linear halogen
lamps.
One (1) 40W (2GX13)T5 circular
lamp (bowl lumination).
Downlight: (Optional) One (1)
20W MHMR-16 (Twist lock, GX10)
metal halide, 39W MHMR-16
(Twist lock, GX10) metal halide
(Contact factory for availability)
or 50W HMR-16 (BI-PIN, GX5.3)
halogen lamp. (Contact factory
for other halogen MR-16 base
options).
44" - Four (4) or eight (8) 27W,
39W, 40W, 50W or 55W (2G11)
high lumen CFL lamps, four
(4)57W (GX24q-5) or 70W
(GX24q-6) 4-pin triple HO CFL
lamps, four (4) 70W or 150WT6
CDM metal halide lamps or four
(4) 150WT4 (DC Bay) clear linear
halogen lamps.
One (1) 40W (2GX13)T5 circular
lamp (bowl illumination).
Downlight: (Optional) One (1)
20W MHPAR-20 (MED BAS)
metal halide or 39W MHPAR-20
(MED BAS) metal halide. CFL
sockets injection molded plastic.
Metal halide socket ceramic
pulse-rated, 4KV. Lamps
furnished by others.
Installation
Installation requires 1/4-20 UNC-
2A AllThread rod. AllThread
(supplied by others) through a
standard J-box to an integral
support canopy support system.
The 1/4-20 UNC-2A AllThread
rod must be attached to the
building structure to support the
fixture's weight.
Options
Dimming Ballast - Except 27W
and DM bowl illumination as a
MOD withT5 55W only, contact
factory for ballast options (DM),
Sloped Ceiling Adaptor - Specify
up to 45° (SCA),Triple Stem (3S),
Single Stem with Aircraft Cable
(1SAC), Aircraft Cable with White
SJ Cord (SJWAC), Aircraft Cable
with Clear SJ Cord (SJCAC),
DESCRIPTION
Catalog # Type
Date
Project
Comments
Prepared by
ADS051195
2008-09-11 08:53:43
New Custom
Decorative Metals Finish
SUSTAINABLE
DESIGN
Shaper has a long-standing history
of offering environmentally-friendly
fixtures. The copper and bronze alloys
used in our exterior luminaires feature
up to 98% recycled content, contribute
less undesirable air emissions compared
to painted aluminum and are easy to
recycle.
Shaper offers a line of products that
offer optically-engineered, high
performance optics for compact
fluorescent, metal halide and halogen
sources.
HIGH PERFORMANCE
OPTICS
Refer to the Icon Legend
Link on shaperlighting.com.

Specifications and dimensions subject to change without notice.
Shaper Lighting •1141 Marina Way South •Richmond, CA 94804 •ph 510.234.2370 •fax [phone]
Sample Number: 1250-26-CFL/3/27 + T5/1/22-120V-SC-FF-28
Options
1SAC Single Stem
Aircraft Cable
=
3S Three Stem=
QP Quad-Pod=
SJCAC Aircraft Cable w/
Clear SJ Cord
=
SJWAC Aircraft Cable w/
White SJ Cord
=
TP Tri-Pod=
GTR Glass Trim Rings=
DL Damp Location=
DM CFL Dimming Ballast 3
=
FF Factory Fuse=
REM Remote Emergency
Battery
=
SCA Sloped Ceiling Adapter=
SSW Separate Switching=
FB Hand Painted Faux
Alabaster Bowl
=
Finish
Standard
MW Matte White=
Premium
CC Custom Color=
NA Natural Aluminum=
OBRS Oxidized Brass=
PB Polished Brass 1
=
PC Polished Chrome 1
=
PCP Polished Copper 1
=
PN Polished Nickel 1
=
SAL Lacquered Satin
Aluminum
=
SB Satin Brass=
SC Satin Chrome=
SCL Lacquered
Satin Chrome
=
SCP Satin Copper=
SN Satin Nickel=
SNL Lacquered Satin
Nickel
=
Custom Decorative Metals
CLR Clear=
CBT Cabernet
=
SPE Sapphire=
SGE Sage=
BRS Brass=
CPR Copper=
BPL Black Pearl=
SGN Slate Green=
CMP Champagne=
CLE Chocolate=
IDO Indigo=
RBE Royal Blue=
PWR Pewter=
Pattern 2
COL Coral=
SHL Seashell=
SMT Smooth=
Lamp (Bowl)
T5/1/22
T5/1/40
Series
1250
1250-ATR
1250-STR
1250-3R
Lamp
Size
26"
36"
44"
Voltage
120V
277V
347V
Stem and Canopy Finish 6
Standard
MW Matte White=
Premium
CC Custom Color=
NA Natural Aluminum=
OBRS Oxidized Brass=
PB Polished Brass=
PC Polished Chrome=
PCP Polished Copper=
PN Polished Nickel=
SAL Lacquered Satin=
SB Satin Brass=
SC Satin Chrome=
SCP Satin Copper=
SN Satin Nickel=Suspension Height
28'' (OA) - 26'' dia.
32'' (OA) - 36'' dia.
42'' (OA) - 44'' dia.
or Specify
1
Notes:
2
3
4
Available in 26" Only.
5
Available with Custom Decorative Metal Finish only.
6
Not available in 27W.
OCP Oxidized Copper=
GNM Gun Metal=
7
T5 22 & 40W - dimming ballast are not available. If bowl illumination
requires dimming, contact the factory for aT5-55W MOD.
LNB=Hand Painted Faux
Linen Bowl
7
26"
CFL/3/27
Aluminum
(Optional)
26”
MR16MH/1/20
MR16MH/1/39
MR16H/1/50
36”
MR16MH/1/20
MR16MH/1/39
MR16H/1/50
44”
PAR20MH/1/20
PAR20MH/1/39
Supplied by others.
Select a standard or premium finish for the stem(s) and canopy.
Example: SGE (Sage color) - SMT (Smooth pattern) for the double
trim rings - SC (Satin Chrome) for the stem(s) and canopy. Minimum
quantity is 5 for one color/pattern. Contact the factory for lead-time.
Interior applications only.
CFL/3/39
CFL/3/40
CFL/3/50
CFL/3/55
CFL/6/27
CFL/6/39
CFL/6/40
CFL/6/50
CFL/6/55
CFL/3/42
CFL/3/57
CFL/3/70
MH/3/39
MH/3/70
MH/3/150
HAL/3/150
CFL/3/32
CFL/3/32
CFL/6/27
CFL/3/42
MH/3/39
MH/3/70
HAL/3/150
36"
CFL/3/27 44"
CFL/4/27
CFL/4/39
CFL/4/40
CFL/4/50
CFL/4/55
CFL/8/27
CFL/8/39
CFL/8/40
CFL/8/50
CFL/8/55
CFL/4/57
CFL/4/70
MH/4/70
MH/4/150
HAL/4/150
5
Color
1
OCP = Oxidized Copper
GNM = Gun Metal
ORDERING INFORMATION
Quad Pod - 44" only (QP),Tri-Pod - 26" and
36" only (TP), Hand Painted Faux Alabaster
Bowl (FB), Hand Painted Faux Linen Bowl
(LNB), Remote Emergency Battery (REM) -
contact factory. Separate Switching (SSW),
Factory Fuse (FF), Damp Location (DL): All
Painted Finishes, Lacquered Satin Chrome
(SCL) and Lacquered Satin Nickel (SNL)
finishes only. Contact factory for Multi-bowl
and alternative mounting options.
Labels
U.L. and C.U.L approved for indoor and
damp location. See Options for damp
location finishing requirements.
Modifications
Shaper's skilled craftspeople with their depth
of experience offer the designer the flexibility
to modify standard high performance
pendant luminaires for project specific
solutions. Contact the factory.
ADS051195
2008-09-11 08:53:43
28"
5-3/4"
32"
6-3/4"
42"
8-3/4"
1250 - 26" STANDARD 1250 - 36" STANDARD 1250 - 44" STANDARD
DIMENSIONS
1250 SERIES HP PENDANT LUMINAIRE

Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
1250 SERIES HP PENDANT LUMINAIRE
28"
5-3/4"
28"
5-3/4"
28"
5-3/4"
28"
5-3/4"
42"
8-3/4"
1250 - SINGLE STEM
AIRCRAFT CABLE (1SAC)
1250 -TRIPLE STEM (3S)
1250 - AIRCRAFT CABLE
WITH SJ CORD (SJWAC)
1250 - QUAD-POD HANGER - 44" (QP)
1250 -TRI-POD - 26" & 36" (TP)
1250 - SUSPENSION OPTIONS STANDARD
SUSPENSION OPTIONS
Triple Stem (3S): 5" cast canopy with a 1 1/2" swivel ball. One 5/8" stem with a standard hang height of 24" (OA), minimum
Single Stem Aircraft Cable (1SAC): Three or four 3/8" stems with a standard hang height of 24" (OA), minimum 18" (OA).
Aircraft Cable with a White SJ Cord (SJWAC): One 5/8" stem and 3/32" cables with a standard hang height of 24" (OA), minimum
Tri-Pod (TP): 3/32" cables with a standard hang height of 24" (OA), minimum 18" (OA). Maximum overall hang height is 25' (OA).
Quad-Pod (QP): 3/32" cables with a standard hang height of 24" (OA), minimum 18" (OA). Maximum overall hang height is 25' (OA).
INSTALLATION
Contractor to provide appropriate structural support for fixture weight. Refer to the installation drawings for details.
Integral safety cable provided.
18" (OA). Maximum overall hang height for one piece stem assembly is 5' (OA). Lengths from 5' to 25' a collector body (CB)
will be provided. Specify SCA for sloped ceilings up to 45°.
Maximum overall hang height is 8' (OA). Contact factory for lengths above 8'. Specify SCA for sloped ceilings up to 45°.
18" (OA). Optional clear SJ cord (SJCAC).
Contact factory for lengths above 25'. Specify SCA for sloped ceilings up to 45°. 26" & 36” dia. only.
Contact factory for lengths above 25'. Specify SCA for sloped ceilings up to 45°. 44"dia. only.
1250 - SUSPENSION OPTIONS STANDARD
ADS051195
2008-09-11 08:53:43

Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
605658692 699
COMPANION PRODUCTS
ADS051195
2008-09-11 08:53:43
1250 SERIES HP PENDANT LUMINAIRE
HIGH LUMEN CF TRIPLE/HEX HO CF T6 MH/HAL
44"
36"
26"
44"
36"
26"
44"
36"
26"
1250 - OPTIC DRAWINGS STANDARD
1250-3R
1250 - PLAN VIEW STANDARD
1250-STR
1250-ATR
1250-3R
1250-3R
1250-STR
1250-ATR
1250 - TRIM DETAIL STANDARD
